G.A.S FlavourSpec Instruction manual

Quickstart Manual
FlavourSpec® with PAL RSI
G.A.S. Gesellschaft für
analytische Sensorsysteme mbH

FlavourSpec®–Quickstart Manual
2/66
Version 1.00, October 2020
Valid from FlavourSpec® Firmware Version 4.00 in combination with
Autosampler PAL3-RSI Series II
All data, texts, designs, images and other elements used in this user manual are
protected by copyright law. Any infringement may be subject to legal action.
Passing it on to third parties and producing copies of any kind or form –on the whole
or in parts - is not permitted without written agreement of G.A.S. Any infringement
may be subject to legal action.
G.A.S. reserves the right to realize technical changes to the product without explicitly
mentioning them.
CE-Marking according to:
International Standard EN ISO 17050-1:2004
Directive 2014/35/EU (Low voltage directive);
Directive 2014/30/EU (Electromagnetic compatibility);
Directive 2011/65/EU (RoHS);
Directive 2012/19/EU on waste disposal (Waste Electrical and Electronic
Equipment –WEEE)
© Copyright 2020
G.A.S. Gesellschaft für analytische Sensorsysteme mbH
44227 Dortmund - Germany
All Rights Reserved.
G.A.S. Gesellschaft für analytische Sensorsysteme mbH
Otto-Hahn-Str. 15
D-44227 Dortmund
Germany
Phone: [phone]
Fax.: [phone]
E-Mail: [email protected]
Internet: www.gas-dortmund.de

FlavourSpec®–Quickstart Manual
3/66
Table of Content
1General Information ............................................................................................. 5
1.1 Information about the Manual........................................................................ 5
1.2Explanation of Symbols................................................................................. 5
1.3 Notation for dialogs, elements and references .............................................. 6
1.4 Scope of Supply ............................................................................................ 7
1.5 Liability and Guarantee................................................................................ 13
1.6 Copyright..................................................................................................... 13
1.7 Return and Disposal.................................................................................... 14
1.8 Software Updates........................................................................................ 14
1.9 Customer Service........................................................................................ 14
2Safety................................................................................................................. 15
2.1 Intended Use Only....................................................................................... 15
2.2 Responsibility of Operator........................................................................... 15
2.3 Requirements of Personnel......................................................................... 16
2.4 Dangers....................................................................................................... 16
3Transport, Packing and Storage ........................................................................ 18
3.1 Inspection after Transport............................................................................ 18
3.2 Packing........................................................................................................ 18
3.3 Storage and Transport................................................................................. 18
4Cleaning and Maintenance ................................................................................ 19
4.1 Cleaning...................................................................................................... 19
4.2 Maintenance................................................................................................ 19
5Installation FlavourSpec Device......................................................................... 20
5.1 Installation Requirements............................................................................ 20
5.2 Unpack the device....................................................................................... 22
5.3 Unpack the accessories .............................................................................. 25
5.4 Mount the Safety guard............................................................................... 27
5.5 Connect the PAL RSI Terminal ................................................................... 28
5.6 Check the Preinstalled Connecting Cable................................................... 29
5.7 Connect the Gas Supply.............................................................................. 30
5.8 Connect the Power Supply.......................................................................... 35
5.9 Remove the Transport Lock........................................................................ 37

FlavourSpec®–Quickstart Manual
4/66
5.10 Complete the Device................................................................................... 38
5.11 Switch on the Device................................................................................... 38
5.12 Check essential device postion ................................................................... 39
5.13 Prepare the device for operation ................................................................. 40
6System Operation .............................................................................................. 44
6.1 Measurement Requirements ....................................................................... 44
6.2 Workflow: Check Injector Position............................................................... 45
6.3 Workflow: Check Agitator Position............................................................... 48
6.4 Workflow: Check Tray Reference Position.................................................. 52
6.5 Workflow: Run a measurement with autosampler ....................................... 57
6.6 Workflow: Run a measurement with manual injection................................. 61
7Appendix............................................................................................................ 64
7.1.1 IMS-Spectrum Examples ...................................................................... 64
7.2 Corresponding G.A.S. Documents and Tutorials......................................... 66

FlavourSpec®–Quickstart Manual
5/66
1 General Information
1.1 Information about the Manual
INFORMATION!
This Quickstart User Manual is an excerpt of the most important
information for installation and initial setup from the User Manual. It
is an addition to the User Manual and does not replace the User
Manual.
This manual describes a safe and adequate handling of the device. Following the
instructions of the indicated safety aspects and instructions as well as the national
and/or local rules and general safety regulations concerning the prevention of
accidents are absolutely imperative.
Before starting the work with the device read the manual completely and thoroughly
particularly the chapter security and respective safety references. Assure that you/the
operator comprehend the terms described.
The manual is part of the device. It must be stored together with and next to the
device at any time.
INFORMATION!
The graphics in this user manual are schematic and may differ from
the actual conditions. The firmware and PC software screenshots in
this user manual may differ from the actual conditions.
1.2 Explanation of Symbols
Important and safety-relevant references in this manual are characterized by
symbols. These indications which are in-line with industrial safety must be respected
and followed at any time.
INFORMATION
This symbol calls information, which are to be considered for
efficient and perfect handling of the equipment.
WARNING
This symbol indicates references, which can lead to damages,
malfunctioning and/or loss of the device.

FlavourSpec®–Quickstart Manual
6/66
DANGER
This symbol marks references, which can lead to health
impairments, injuries, lasting body damages or to death due to
electric current.
DANGER
This Symbol marks paragraphs, which describe potential dangers and
damage due to exposure to radioactive radiation.
1.3 Notation for dialogs, elements and references
Example Dialog:
System ›Connections ›LAN File Transfer ›Settings… ›Test Connection
Example Elements:
Gas Out, Sample gas in
Example: References
Advanced User Manual, Chapter 5.1 Installation Reguirements
Example: Information
keep the transport box

FlavourSpec®–Quickstart Manual
7/66
1.4 Scope of Supply
Assure that you have received the full scope of supply. If there is any part missing,
please contact the GAS-hotline immediately.
FlavourSpec Scope of Supply
FlavourSpec Device coupled Autosampler
PAL3 Series II
FlavourSpec Power supply with cable (1
piece)
FlavourSpec Gas tube Kit
•Driftgas/Carriergas (1 piece)
•2 m 3mm PFA Tubes with 3 mm
Swagelok-Connector (2 Pieces)
•0,65 m 3mm PFA Tubes with 3 mm
Swagelok-Connector (1 Pieces)

FlavourSpec®–Quickstart Manual
8/66
Molecular sieve 200 ml with 1/8” connections
(1 piece)
LAN Cable (1 piece)
FlavourSpec-PAL3 Connection Cable
FlavourSpec Blind plug Set (4 pieces)
(Swagelok 3mm Blind plug with red cap
installed on device connectors)

FlavourSpec®–Quickstart Manual
9/66
FlavourSpec Torx Tool Kit
•Torx Srewdriver 8 mm (1 piece)
•Torx Srewdriver 10 mm (1 piece)
Document Map with Documents and Device
User Manuals
USB-Stick Box with Software und Documents
(1 piece)
Autosampler PAL3 Series II Scope of Supply
Autosampler Power supply with cable (1
piece)

FlavourSpec®–Quickstart Manual
10/66
Terminal with Connection Cable (1 piece)
Agitator Connection Cable (installed)
(1piece)
PAL3 Torx Tool Kit
•Torx Screwdriver 8 mm (1 piece)
•Torx Screwdriver 10 mm (1 piece)
•Torx Screwdriver 20 mm (1 piece)
•Torx Screwdriver 25 mm (1 piece)
Safety Guard including screws (1 piece)

FlavourSpec®–Quickstart Manual
11/66
Syringe Kit (2 pieces)
PAL3 Teaching Tool
Starter Kit
(100 x 20 ml Headspace Vials, 100 magnetic
caps, 3 Septa for Injector
Transport box (1 piece)

FlavourSpec®–Quickstart Manual
12/66
FlavourSpec Transport palett (120 x 80 cm)
Optional Scope of Supply (only available if ordered)
Nitrogen Generator with accessories
(example picture)
Laptop Computer (different design) including
software for control and evaluation
PAL ITEX-Kit

FlavourSpec®–Quickstart Manual
13/66
Crimper for H 20 ml Headspace Vials
1.5 Liability and Guarantee
This user manual describes the safe and proper handling of the device.
All data and reference within this manual are compiled under the valid regulations,
the state-of-the-art as well as G.A.S. experiences of several years.
This user manual must be stored together with and close to the device at any time
and accessible to all persons, who operate or handle the device at any time.
This user manual must be read carefully before starting to work with the device.
G.A.S. does not assume any liability for damage and disturbances, resulting from
disregard of the instructions contained in this user manual. All claims of any kind
related to damage from a not intended use of the device will be rejected.
G.A.S. reserves the right to realize technical changes of the product due to
improvements without explicitly mentioning them.
1.6 Copyright
The manual is confidential. It is beyond doubt exclusively made and also meant for
the personnel directly dealing with the equipment. All data, texts, designs, pictures
and other representations within this manual are protected in the sense of the
copyright law and are subject to further commercial patent rights. Each abusive is
punishable by law.
Passing it on to third persons as well as duplications in any kind and form - also in
part - as well as the use and/or report of contents are not permitted without written
agreement of the manufacturer. Offences lead to payment of damages. We reserve
ourselves all rights of the practice of commercial patent rights.

FlavourSpec®–Quickstart Manual
14/66
1.7 Return and Disposal
For an adequate disposal, the device or/and its equipment must be returned to the
G.A.S. or to a third party authorized by the G.A.S.! For questions please contact
G.A.S.
1.8 Software Updates
If there are any software updates customers will be contacted by G.A.S. Gesellschaft
für analytische Sensorsysteme mbH as soon as the updates are available. The
updates are free of charge within the first 12 month after delivery. Users will be
provided with information about the changes and instructions for executing the
updates.
1.9 Customer Service
For questions concerning G.A.S. products a customer service is available:
G.A.S. Gesellschaft für analytische Sensorsysteme mbH
Otto-Hahn-Straße 15
44227 Dortmund
Germany
Phone: +49 (0) 231 / 97 42 - 65 50
Fax: +49 (0) 231 / 97 42 - 65 55
[email protected]
The telephone hotline is available from monday to friday from 9:00 to 16:00 hours. In
urgent cases or if you use fax or email please provide a telephone number for
callbacks.

FlavourSpec®–Quickstart Manual
15/66
2 Safety
2.1 Intended Use Only
WARNING!
Usage other than described in this manual may damage the device
and/or harm persons involved.
Do not use the device for other purposes. Damages due to misuse
are not covered by the guarantee. Such damage claims will be
rejected.
The device and its equipment are not certified for the employment in
areas with explosive gas air mixtures.
All claims or requirements of any kind against the manufacturer and/or its authorized
persons that arise due to damages from a not intended use of the device will be
rejected. All damages that arise from a not intended use are of the operator’s
responsibility.
The intended use of the equipment and its correct handling according are described
in the operating instructions of this manual. Other parts than the parts belonging to
the scope of supply, may only be used after G.A.S. approval.
2.2 Responsibility of Operator
The device may only be operated in a perfect technical condition. Before putting the
device into operation the condition of the device and its equipment must be checked.
The information and instructions provided in this manual have to be followed at any
time.
Besides the instructions provided in this manual the local rules for the prevention of
accidents, general safety regulations - valid for the area of application of the device -
as well as the valid environmental-protection regulations must be considered and
respected.
The responsible technicians and operators have to make sure a failure-free use of
the device. Responsibilities among the involved persons regarding installation,
operation, maintenance and cleaning must be made clear.

FlavourSpec®–Quickstart Manual
16/66
2.3 Requirements of Personnel
Only authorized and trained technical personnel may work with the instruments. The
operator must have received an instruction over existing and all possible dangers
and should be regularly instructed in safety procedures and environmental protection
and that the personnel is fully aware of the complete operating instructions and
particularly the safety notes. Personnel that might be under the influence of drugs or
alcohol are to be kept off the device at any time.
Technical personnel in this context are defined as skilled employees who are
knowledgeable due to their educational background. In case the foreseen personnel
do not have the necessary qualifications to operate the instrument, it must be trained.
Further to that non-authorized personnel should not operate the device.
The competencies for the work on and with the device must be specified and kept
undoubtedly at any time so that with respect to security issues no unclear situation
might come up.
Any changes of the equipment, which impair security of the personnel, must
immediately be reported to the operator and every person dealing with it.
2.4 Dangers
The device and its equipment is subject to an endangerment analysis. The
construction and execution of the device corresponds to the today's state-of-the-art.
The device is reliable in service when operated according to its intended use.
INFORMATION!
If the housing of the device is damaged, the device must not be used
anymore and must be returned to the G.A.S. by using the original
transportation case.
DANGER
The FlavourSpec® device contains a radioactive radiation Tritium
source of 75 MBq which in all EURATOM countries is below the
exemption limit. However, do not open the device! Do not try to
recover malfunctions of the device! Malfunction recovery, repairs and
any maintenance work may only be performed by G.A.S. or by
qualified personnel authorized by G.A.S.

FlavourSpec®–Quickstart Manual
17/66
DANGER
The FlavourSpec® and its equipment is not certified for the
employment in areas with explosive gas air mixtures (Zone 0).
DANGER
Exercise great care in handling current-carrying parts like the power
supply cord. Do not get directly in touch with current-carrying parts.
Do not open the housing. Do not use damaged parts.
DANGER
When Nitrogen is used as drift gas and helium as carrier gas,
ignition of a helium plasma may occur due to the high voltage
present in conjunction with a radiation source. This can damage the
IMS.

FlavourSpec®–Quickstart Manual
18/66
3 Transport, Packing and Storage
3.1 Inspection after Transport
Check the supply immediately after delivery concerning its completeness and/or
transport damages. If you detect externally visible transport damage, do not receive
the supply, or only under reservation. State the extent of the damage on the provided
delivery note and/or the transportation documents of the feeder. Generate a
complaint. Lodge a complaint of covered defect immediately after recognizing, as
claims due to transport damages can only be made valid within the complaint periods
(usually 7 days).
3.2 Packing
If no return agreement regarding the packing was agreed upon dispose the
packaging material always in an environmentally friendly way and according to valid
local regulations. If additional information is required please ask a recycling
company.
INFORMATION!
It is recommended to keep the transport box for a safe return
transport.
3.3 Storage and Transport
Store the device only under the following conditions:
•When not in use store the equipment in the supplied casing
•Prevent unauthorized access
•Do not store outside
•Protect the equipment from moisture and dust
•Put protective caps on all gas sockets
•Avoid mechanical vibrations
•Do not expose the equipment to aggressive substances
•Protect the equipment from direct sun light

FlavourSpec®–Quickstart Manual
19/66
•Storage temperature: 5 to 40 °C
•Relative Air Humidity: 0- 90%Rh, prevent condensation
•Instrument’s position: Horizontal
The equipment should be moved only packaged into the provided transport case. By
these means, transport damages can be avoided. The above-mentioned values are
considered for an instrument transported in its original new packing.
WARNING!
Protective caps should be put on gas sockets in case the device is
stored or transported.
4 Cleaning and Maintenance
Natural aging and the wear of certain components of the equipment require a regular
cleaning and maintenance.
4.1 Cleaning
Clean the device only with a dry or easily damp cloth.
WARNING!
Do not use cleaning agents, which contain solvents, acids, or
bases.
4.2 Maintenance
INFORMATION!
Maintenance of the device should only be carried out at G.A.S. or
through specially trained and by G.A.S. authorized personnel.
The recommended maintenance interval is 24 months.

FlavourSpec®–Quickstart Manual
20/66
5 Installation FlavourSpec Device
5.1 Installation Requirements
The following requirements must be fulfilled by the customer:
Location of Installation
•Available space of 1000 x 900 x 800 mm (W x D x H)
•Ambient temperature of 5 –40 °C
•Humidity: 0-90 % RH, non-condensating
•Robust table with a minimum carrying capacity of >40kg
Electricity
•Electricity supply free of interferences
•Power Supply of 230 V ± 10%, 50- 60 Hz ± 1%
Gas supply
•Nitrogen (Quality 5.0 (99,999%) or Synthetic Air (Quality 5.0 (99,999%)
•Stainless steel pressure reducer with 3mm or 1/8“ Swagelok-Connector
adjustable pressure range of 3 –6 bar and 3 mm Swagelok connector
Safety
•Availability of exhaust system for device exhaust gas tubes (Gas out and
Sample Gas out)
Computer
•Computer with current Microsoft Windows operating system
