Gaggenau VP 414 610 User manual

Gaggenau
Installation instructions..........................2
Instructions d’installation.....................12
Instrucciones de instalación................22
VP 414 610
Teppan Yaki
Teppan Yaki
Teppan Yaki

2
Table of Contents Installationinstructions
Safety Definitions
9WARNING
This indicates that death or serious injuries may
occur as a result of non-observance of this
warning.
9CAUTION
This indicates that minor or moderate injuries
may occur as a result of non-observance of this
warning.
NOTICE: This indicates that damage to the appliance
or property may occur as a result of non-compliance
with this advisory.
Note: This alerts you to important information and/or
tips.

3
9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
IMPORTANTSAFETYINSTRUCTION READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THESE INSTRUCTIONS WITH
THE APPLIANCE AFTER INSTALLATION IS
COMPLETE.
IMPORTANT: SAVE THESE INSTRUCTIONS FOR
THE LOCAL ELECTRICAL INSPECTOR'S USE.
WARNING
If the information in this manual is not followed
exactly, fire or shock may result causing property
damage or personal injury.
WARNING
Do not repair, replace or remove any part of the
appliance unless specifically recommended in the
manuals. Improper installation, service or
maintenance can cause injury or property damage.
Refer to this manual for guidance. All other servicing
should be done by a qualified technician.
Appliance Handling Safety
Hidden surfaces may have sharp edges. Use caution
when reaching behind or under appliance.
Safety Codes and Standards
This appliance complies with one or more of the
following Standards:
▯UL 858, The Standard for the Safety of Household
Electric Ranges
▯UL 923, The Standard for the Safety of Microwave
Cooking Appliances
▯UL 507, The Standard for the Safety of Electric
Fans
▯ANSI Z21.1, The American National Standard for
Household Cooking Gas Appliances
▯CAN/CSA-C22.2 No. 113-M1984 Fans and
Ventilators
▯CAN/CSA-C22.2 No. 61-M89 Household Cooking
Ranges
It is the responsibility of the owner and the installer to
determine if additional requirements and/or standards
apply to specific installations.
Electric Safety
WARNING
Before you plug in an electrical cord or turn on power
supply, make sure all controls are in the OFF position.
If required by the National Electrical Code (or
Canadian Electrical Code), this appliance must be
installed on a separate branch circuit.
WARNING
Risk of electrical shock or fire
Frame grounded to neutral through a ground strap.
Grounding through the neutral conductor is prohibited
for new branch-circuit installations (1996 NEC),
mobile homes, and recreational vehicles, or in an area
where local codes prohibit grounding through the
neutral conductor.
For installations where grounding through the neutral
conductor is prohibited,
a) disconnect the link from the neutral,
b) use grounding terminal or lead to ground unit,
c) connect neutral terminal to lead branch circuit
neutral in usual manner (when the appliance is to
be connected by means of a cord kit, use a
UL listed 4-conductor cord for this purpose).
Be sure your appliance is properly installed and
grounded by a qualified technician. Installation,
electrical connections and grounding must comply
with all applicable codes.
Before installing, turn power OFF at the service panel.
Lock service panel to prevent power from being
turned ON accidentally.
Installer – show the owner the location of the circuit
breaker or fuse. Mark it for easy reference.
Related Equipment Safety
The appliance is only guaranteed safe to use if
installed by a specialist in accordance with these
installation instructions. The installer is liable for any
damage resulting from incorrect installation.
Remove all tape and packaging before using the
appliance. Destroy the packaging after unpacking the
appliance. Never allow children to play with packaging
material.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
4
Never modify or alter the construction of the
appliance. For example, do not remove leveling legs,
panels, wire covers or anti-tip brackets/screws.
To eliminate the risk of burns or fire by reaching over
heated surface units, cabinet storage space located
above the surface units should be avoided. If cabinet
storage is to be provided, the risk can be reduced by
installing a hood that projects horizontally a minimum
of 5 inches (127 mm) beyond the bottom of the
cabinet.
Verify that cabinets above the cooktop are a maximum
of 13" (330 mm) deep.
When installing a cooktop over a single oven, be sure
to follow both the oven’s and cooktop’s installation
manuals.
State of California Proposition 65
Warnings
WARNING
This product contains chemicals known to the State of
California to cause cancer, birth defects or other
reproductive harm.

5
Before You Begin
Tools and Parts Needed
▯Screwdriver Torx T20
▯Pencil
▯Drill with ¼" (6 mm) bit
▯Jigsaw
▯Tape Measure
Note: Additional materials may be necessary for
installation in solid surface countertops. Contact the
countertop manufacturer.
Parts Included
Special accessories
You can order the following accessories from your
specialist dealer:
Use the accessories only as indicated. The
manufacturer assumes no liability for incorrect usage
of the accessories.
Cabinet Requirements
The distance from the top of the cooktop to the
bottom of cabinets above must be a minimun of A=30"
(762 mm).
Verify that the cabinets above the cooktop are a
maximum of B=13" (330 mm) deep.
Countertop Requirements
9WARNING
To reduce the risk of ignition of surrounding
combustible materials, install at least
2" (51 mm) from both sidewalls and the rear
wall.
The countertop must be level and horizontal. The
stability of the countertop must be maintained after
the cut-out has been made.
Solid surface countertops often require special
installations. For example, heat-reflective tape and
rounded corners may be necessary. Contact the
countertop manufacturer for instructions specific to
your countertop.
VA 440 010 Stainless steel appliance cover
VA 420 000 Connection strip for combination with
other Vario appliances in the 400 series
for flush installation
VA 420 001 Connection strip for combination with
other Vario appliances in the 400 series
for flush installation with appliance
cover/compensation strip
VA 420 010 Connection strip for combination with
other Vario appliances in the 400 series
for surface-mounted installation
VA 420 011 Connection strip for combination with
other Vario appliances in the 400 series
for surface-mounted installation with
appliance cover/compensation strip
VA 450 400 Appliance extension 15” (38 cm)
%
$

6
Prepare Installation Space
The kitchen unit must be heat-resistant to at least
200° F (90°C). The stability of the unit must be
maintained after producing the cut-out.
Produce the cut-out in the countertop for one or more
Vario appliances as shown in the installation sketch.
The angle between the cut surface and the countertop
must be 90°.
The cut edges at the sides must be flat to ensure a
good fit of the retaining springs on the appliance. In
laminated worktops, it may be necessary to fit strips at
the sides of the cut-out.
Remove shavings after cutting. Seal cut surfaces for
resistance to heat and so they are watertight.
Pay attention to a minimum gap of 3/8“ (10 mm) from
the underside of the appliance to kitchen units.
Use suitable base constructions to ensure load-
carrying capacity and stability, especially in the case
of thin countertops. Pay attention to the weight of the
appliance, including any payload. Reinforcement
material used must be resistant to heat and moisture.
Note: Wait until the appliance has been installed in
the installation opening before checking that it is
level.
Cutting out countertop
Flush mounting: Flush mounting into a countertop is
possible.
Flush installation: The appliance can be installed in
the following temperature- and water-resistant
countertops:
▯Stone countertops
▯Plastic countertops (such as Corian®)
▯Solid wood countertops: Only in consultation with
the manufacturer of the countertop (seal cut-out
edges)
▯Installation in other countertops only in
consultation with the manufacturer of the
countertop.
Installation in countertops made of particleboard is
not possible.
Note: Any cut-out work on the countertop must be
performed in a workshop according to the installation
diagram. The cut-out must be made cleanly and
precisely since the cut-out edge is visible on the
surface. Clean and degrease the cut-out edges with a
suitable cleaning agent (bear in mind silicone
manufacturer's processing instructions).






  

 PP
PLQ  

PLQ


PLQ
  
PLQ



PLQ
PLQ

  
U
  




 






   
 PP











7
Combining several Vario devices: The connecting strip
VA 420 000/001/010/011 is required for the
combination of several Vario appliances. This is
available separately as a special accessory. Consider
additional space requirement for the connecting strip
between the appliances when making the cut-out (see
installation instructions VA 420 000/001/010/011).
Appliances can also be installed in individual cut-outs,
bearing in mind a minimum distance between the
devices of 2" (51 mm).
When combining several appliances with or without
appliance cover, you can use the appliance extensions
VA 450 110/-400/-600/-800/-900 (depending on
appliance width) to balance out dimension
differences.
Combination with appliance cover: The appliance
cover VA 440 010 is available separately as a special
accessory. When creating the cut-out, bear in mind
the additional space required for the appliance cover.
Flush installation:
9$
9$
9$
PLQ
PLQ





9$
PLQ
PLQ






8
Hole for control knob
The built-in control console can be integrated into the
lower cabinet at drawer level. Panel thickness: 5/8" - 1"
(16 - 26 mm)
1If front panel thickness is greater than 1" (26 mm):
Mill out front panel on rear side to the dimensions
31/8" x 123/16" (80 x 310 mm) to the point that the
thickness doesn't exceed 1" (26 mm).
For flush mounting:
2According to the figure, create the drill hole Ø 1
3/8" (35 mm) for fixing in place the control knob in
the front side of the lower cabinet. A drilling
template is included for precise positioning of the
drill hole.
For flush mounting:
PLQ PLQ
  [  
[
PLQ PLQ
PLQ


PLQ


  [  
[




PLQ 
PD[ 
 
 



 PP




 PP
PLQ
 
PD[  


 

 








9
Installation Procedure
Installation of control console
Note: Only install the appliance in conjunction with
the corresponding control console.
1Remove the packaging of the control knobs and
the protective film from the light rings.
2Open the cover of the terminal box on the control
console. Secure the mains connecting lead as
shown in the terminal diagram and secure it with
pull relief. Close the terminal box cover.
3Hold the retaining plate against the front panel
from behind. Stick the control knobs into the
holes from the front and screw it tight from
behind with the nuts. Make sure that the control
knobs are correctly arranged.
4Screw the control console tight to the retaining
plate using the nuts included.
Install Appliance
9WARNING
Before you plug in an electrical cord or turn on
power supply, make sure all controls are in the
OFF position.
1Firmly plug together the connecting lead from the
appliance and the control console. The plugs
must engage. Insert the control cable in the
socket on the appliance. The plug must engage.
2Evenly insert the unit in the cut-out. Press the unit
firmly into the cut-out from above.
Note: The unit must sit firmly in the cut-out and
must not move (e.g. during cleaning). If
necessary, secure strips at the sides in the cut-
out if the cut-out width is at the top tolerance
limit.



















&/,&.

10
3Connect the appliance to the mains and check
that it is working. If both illuminated rings behind
the control knobs flash alternately, the connecting
cable between the control console and the
appliance is not plugged in. Check that the
connecting cable is fitted correctly.
4Flush installation only: it is imperative to test
functioning before jointing! Joint the surrounding
gap with a suitable, temperature-resistant silicone
adhesive (such as OTTOSEAL®S 70). Smoothen
the seal joint with smoothing agent recommended
by the manufacturer. Observe the notes on
processing the silicone adhesive. Do not operate
the appliance until the silicone adhesive has dried
completely (at least 24 hours, depending on room
temperature).
NOTICE: Unsuitable silicone adhesive used on
natural stone worktops will cause permanent
discoloration.
Connect Electrical Supply
Refer to data plate for more information. See "Service"
for data plate location.
The branch-circuit breakers ampacity, the wire sizes
and the connections must be conform to the
requirements of the National Electrical Code or
Canadian Electrical Code and all local codes and
ordinances.
Attach flexible conduit to the junction box. Connect
the lead wires to the junction box supply wires in
proper phase:
▯black (L1) to black
▯red (L2) to red
▯green to ground
The mains connecting cable must at least correspond
to the type SJTO 3x16 AWG 105°C. The mains
connecting cable must only be purchased through and
connected by an authorised specialist.
Connection with a plug
▯Plug has to be conform with NEMA
CONFIGURATIONS FOR PLUGS AND
RECEPTACLES.
▯The appliance must be properly grounded.
▯Plug must be rated not less than type 6-20 P (2-
pole 3-wire grounding).
▯Only a qualified electrician should connect the
plug.
▯Install a socket outlet earthed in accordance with
regulations approx. 27" (700 mm) above the floor
behind the appliance. The socket outlet must still
be accessible after installation.
Check the Installation
9WARNING
Before you plug in an electrical cord or turn on
power supply, make sure all controls are in the
OFF position.
Remove everything from the cooktop surface.
Switch on the circuit breaker.
Verify that elements function properly.
Removing appliance
Disconnect the appliance from the power supply. For
flush-mounted appliances, remove the silicone joint.
Push out the appliance from below.
9CAUTION
Damage to appliance! Don't lever device out
from above at the frame.
