CONEXIONADO DEL EQUIPO
INSTALLATION DIAGRAM
INDEP. 1INDEP. 2
T-810T-810
TF-103
CV
230 Vca
SEC
PRI
INDEP. 1
INDEP. 2
Ind 10 5
2.50mm²
1.00mm²
0.50mm²
100m
1 3 4
El esquema muestra la conexión de un segundo teléfono independiente
(sólo placa PE-295/2). En caso de teléfonos en paralelo, unir
los hilos de llamada y doblar su sección.
The installation diagram shows the connection of an independent second
telephone (only PE-295/2 door panel). In case of telephones in
parallel, link the call wires and double its section.
3
PE-295
21 34510 CP L1 L2
70 3 10 5
70 3 10 5P1P1
~ ~
~ ~
~ ~
Portero Electrónico
Antivandálico
para chalet
Vandalproof audio door
entry system
for chalet
manual de instalación
instructions manual
T201
rev.0201
2
lose the door
Cpanel.
ijar la placa.
F
5
n caso de ser necesario, ajustar
Emediante un destornillador el
volumen de audio.
f necessary, adjust the audio
Ilevel by using a screw driver.
teléfono
telephone
placa
door panel
4
INSTALACIÓN DEL EQUIPO
SYSTEM INSTALLATION
NORMAS DE INSTALACIÓN
INSTALLATION RULES
1
3
1. No apretar excesivamente los tornillos de la regleta del alimentador.
2. Conectar siempre el alimentador a través de un magnetotérmico o de un enchufe macho.
3. Cuando se instale el equipo, hacerlo sin alimentación. Desconectar la alimentación para cualquier
modificación en la instalación.
4. Antes de conectar el equipo, verificar el conexionado entre placa y teléfonos, y el conexionado del
alimentador. Siga en todo momento las instrucciones de la información que se suministra.
1. Do not use excessive force when tightening the connector screws on the transformer.
2. Always connect the transformers using a magnetothermic or a male plug.
3. Install the equipment without the power connected. Disconnect from power for any
modification to the system.
4. Before to connect the system, check the connections between the door panel, the telephones
and the transformer, by following the supplied instructions.
SYSTEM INSTALLATION
INSTALACIÓN DEL EQUIPO
lush the embedding box and
Fconnect the installation wires .
Place the indentifying label of the
push button.
mpotrar la caja y conectar la
Einstalación a la regleta de conexión.
Colocar la etiqueta identificativa del
pulsador.
Dimensiones caja emp.
An Al P
Embedding box dim.
WHD
132 45
132
2
1
etalle de la instalación
Ddel alimentador y el
abrepuertas.
ransformer and door
Trelease installation.
etalle de la
Dinstalación de los
teléfonos T-810.
-810 telephone
Tinstallation.
DIN 46277DIN 46277
3
3,5
M 4 x 8
3,5 x 25
3,5 x 25
DIN-7971
3,5 x 25
DIN-7971
6
3,5 x 25
6
DIN-7972
DIN-963
