Ganz ZN?PTZW36VPIPE4100 User manual

IMPORTANT!
TheexplanationandspecificationatthismanualaremainlyonthebasisofZN‐PTZW36VP
whichusesSony36XOpticalZoommodule.


(ZN‐PTZxxVP‐XTisanOutdoorPTZCamera,AddinganOutdoorHousingtoIndoorPTZZN‐
PTZxxVP)




INFORMATIONTOUSER

CAUTION
RISKOFELECTRICSHOCK,
DONOTOPEN
!
CAUTION:TOREDUCETHERISKOFELECTRICSHOCK,
DONOTREMOVECOVER(ORBACK).
NOUSERSERVICEABLEPARTSINSIDE.
REFERSERVICINGTOQUALIFIEDSEERIVCEPERSONEL.



Thissymbolisintendedtoalerttheusertothepresenceofun‐insulated
“dangerousvoltage”withintheproduct’senclosurethatmaybeofsufficient
magnitudetoconstituteariskofelectricshocktopersons.
!
Thissymbolisintendedtoalerttheusertothepresenceofimportant
operatingandmaintenance(servicing)instructionsintheliterature
accompanyingtheappliance.



TableofContents
1.FEATURES ...............................................................................................................6
2.PACKAGECONTENTS .............................................................................................. 7
3.PARTNAMES ..........................................................................................................8
4.INSTALLATION ...................................................................................................... 11
4.1.SettingtheImageAttribute.............................................................................................. 12
4.2.OperatingtheOSDMenu.................................................................................................. 12
5.CONNECTIONS ...................................................................................................... 13
5.1.Connectors ........................................................................................................................ 13
6.CONFIGURATION .................................................................................................. 18
6.1.Setupnetworkenvironment ............................................................................................ 18
6.2.Viewvideoonwebpage ................................................................................................... 18
6.2.1.ViewvideousingIPAdminTool ................................................................................. 18
6.2.2.ViewvideousingIPaddress ...................................................................................... 20
6.3.Reset................................................................................................................................. 20
6.4.FactoryDefault................................................................................................................. 20
APPENDIX(A):SPECIFICATIONS ................................................................................ 21
Summary ................................................................................................................................. 21
ElectricalCharacteristics ......................................................................................................... 23
EnvironmentCondition ........................................................................................................... 23
APPENDIX(B):DIMENSIONS..................................................................................... 24
Dome ....................................................................................................................................... 24
OutdoorHousing..................................................................................................................... 25
APPENDIX(C):ACCESSORIES..................................................................................... 26
Outdoorpart ........................................................................................................................... 26
Assemblingoutdoorhousing .................................................................................................. 27
APPENDIX(D):HEXADECIMAL‐DECIMALCONVERSIONTABLE .................................. 29
REVISIONHISTORY ................................................................................................... 30


ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  6
1.FEATURES
Camera
Indoor/OutdoorPTZDomeIPCamera
IP66vandalproof(supportedonlywithOutdoorHousing)
Sony1/4”ExviewHADCCD
x36OpticalZoom,x12DigitalZoom
TrueDay&Night(IRCutFilter)+DSS
Streaming
Dualstreamingmode(suchasdifferentcodec/resolution/bitrateandsoon.)
De‐interlacingonDSP
Burnt‐intextsupported
Unicast/Multicastsupported
Video/Audio
Videocompression:H.264/MPEG/MJPEG,25/30FPS@D1(PAL/NTSC)
Audiocompression:G.711(µLaw,aLaw)/PCM
Analogvideooutforexternalmonitors
VideoMotionDetectionsupported
Two‐waymonoaudiosupported
Network
RTSP/HTTPprotocolsupported
10/100Base‐TEthernet
AdditionalFeatures
RS‐485supported
OSDsupported
SDK(SoftwareDevelopmentKit)provided
4chDI/2chDOsupported
VCA(VideoContentAnalysis)
Built‐inAuto‐Trackinglicense
VCAPresence(Includedasbasic)
VCASurveillance(Optional)



ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  7
2.PACKAGECONTENTS
Unpackcarefullyandhandletheequipmentwithcare.Thepackagingcontains:

CameraCeilingMountBracket

CeilingCover Screws

WrenchTerminalblock
(2Pin,3Pin,5Pin,6Pin)


SafetyWire CableTies

QuickInstallationGuide



Note
i

Theabovecontentsaresubjecttochangewithoutpriornotice.


ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  8
3.PARTNAMES

LockScrew
Bubble
LockHolder
DipSwitch
CameraLens
CeilingMountBracketforindoor

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  9

ALARM AUX
GND 1 2 12
D+
34GND
D- GND
AC24VRS 485
GND
ON VIDEO
OUT
LINE OUT
MIC/
100 BaseT LINE IN
①
②
③
④
⑤
⑥
⑧
⑨
⑦
*Modelshereinandtheirappearance
aresubjecttochangewithoutanyprior
notice.

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  10
①LANConnector(Ethernet)
ThisisaRJ45LANconnectorfor10/100Base‐TEthernet.

ThisLEDlightsupasorangeandturnsgreenwhentheencoderispoweredon.

LEDoperationsetting:
Forthefactorydefaultsetting,LED2blinksfortheheartbeatandLED1turnsonforvideosignal.To
changeitssetting,refertothesection4.5.11.LEDSettingoftheNVCWebPageUser’sManual.

②RS‐485
ThecamerasupportsRS‐485SerialCommunicationPort.

③3pinconnectorforpower
ThecameraneedsanAC24Vforpowersupply.Refertothesection“5.1.Connectors”formorespecific
information.

④Externalvideo
Itisananalogvideooutputport.

⑤5pinconnectorforD/O
Thecameraprovides2channelD/O.Refertothesection“5.1.Connectors”formorespecific
information.

⑥6pinconnectorforD/I
Thecameraprovides4channelD/I.Refertothesection“5.1.Connectors”formorespecificinformation.

⑦AudioOutput
Thecamerahasamonoaudiooutput.

⑧AudioInput
Thecamerahasamonoaudioinput.

⑨Reset
ResetswitchisusedforrestartingorresettingthecameraasFactoryDefault(FD).Refertothesection
“6.3.Reset”formorespecificinformation.

LED1LED2

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  11
4.INSTALLATION

Beforeyouinstallthecamera,youshouldset
theDIPswitchestoconfigurethecameraID,
communicationprotocol.Pleaserefertothe
page15.DIPSwitch

1.Findtheplaceswhicharestrongenoughto
supportthecamera,about2kg.

2.Makeahole,Ø147mm,ontheceiling.

3.Hookthesafetywiretosuspensionandthe
safetywireholdonthebracket.

4.Installtheceilingmountbracketbydriving4
screws,Ø4mmtappingscrews.

5.Youcanmakewiressimplebycableties.
SAFETY WIRE
CABLE TIE
LOCK HOLDER 2
MOUNT HOLDER
147.0 mm
COVER HOLE
LOCK HOLDER 1
SAFETY WIRE HOLE MOUNTING HOLE
CELING BRACKET
SCREW(Ø4.0)
AB
C

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  12

Caution
!

Thecameramayfallofftheceilingevenaftertheproperinstallationand
mounting.Topreventanyaccident,makesuretheceilingisfirmandstable
enoughtosupportthecamera.Ifanyreinforcementisneeded,consultwithyour
safetypersonnelandproceedwiththeinstallation.

4.1.SettingtheImageAttribute
Youcansettheimageattributeofcamerathroughthewebpage.
ThemenuofimageattributecanbeseenunderSetup>Video&Audio>Video‐in>AttributeSetting.
Brightness,contrast,hue,saturationandsharpnesscanbeadjusted.

4.2.OperatingtheOSDMenu
TooperatetheOSDofcamera;refertothe”OSDMenuControlManual”intheSDK.

COVER HOLE
COVER LOCK
LOCK HOLDER.2
10°
LOCK HOLDER.1
COVER 
SCREW
(M3.0)
DE
F

6.Makethewiresgothroughthesquarehole.

7.Insertmountholderandtwistthecamera
counterclockwise.

8.Fixthecamerabydrivingascrewonlock
holder1and2.

9.Installthecoverbyinsertingcoverlockand
twistingclockwise.

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  13
5.CONNECTIONS
5.1.Connectors


PowerConnection
Please,checkthevoltageandcurrentcapacityofratedpowercarefully.Ratedpowerisindicatedinthe
backofmainunit.

TypeRatedPowerInputVoltageRangeCurrentConsumption
IndoorAC24V18~32VAC850mA
OutdoorAC24V18~32VAC1.5A

RS‐485Communication
ForPTZcontrol,connectthislinetokeyboardandDVR.Tocontrolmultiplecamerasatthesametime,
RS‐485communicationlinesofthemisconnectedinparallel.

AnalogVideoConnection
ConnectwithBNCcoaxialcable.

AudioInput/OutputConnection
ConnecttotheaudioinputdevicesuchasaMicandtheaudiooutputdevicesuchastheamplifier
speaker.


Caution
!

Donotconnectthespeakerwithoutamplifier.

AC220/110V
AC24V
ADAPTOR
SIGNAL
IR SENSOR or DOOR SENSOR
GND
AUX 2
AUX 1
MONITOR
TERMINAL BLOCK
(FEMALE)
D
D
RS 485
ON
LINE OUT
MIC/ LINE IN
100 BaseT
LINE OUT
MIC IN
RS-485 Serial Device
LAN CABLE

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  14
Sensor(DI)connection
Thecameraprovides4channelD/I.Itcanbeconnectedtoarelaytypesensorasthefollowingfigures.

RelayRating:Max24VAC500mAor12VDC1A

Caution
!

Donotexceedthemaximumrelayrateing.



Alarm(DO)connection
Thecameraprovides2channelD/O.
RelayRating:Max24VAC500mAor12VDC1A

Caution
!

Donotexceedthemaximumrelayrating.

DO
COM
RelayType
Device
Internal
+5V
DI
COM
RelayType
Outputof
Sensor
Internal
+‐

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  15
DIPSwitch
Beforeyouinstallthecamera,youshouldsettheDIPswitchestoconfigurethecameraID,
communicationprotocol.


71 2 3 4 5 6
ON
8
71 2 3 4 5 6
ON
8
UNLOCK
2 mm
54 7
8654 7
ON
21
ON
21
3
3
DIP1 ‐CameraID
DIP2‐ RS485, PTZprotocol,Baudrate
6 8
Placingdomecover
Openingdomecover
Placedomecoverandrotatetotighten
UnlockthescrewRotatethecovertoremove
Lockthescrew

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  16
CameraIDSetup

123456
ON
ON
78


IDnumberofcameraissetusingbinarynumber.Theexampleisshownbellow.
DIP1
Pin12345678
IDValue1248163264128
Defaultonoffoffoffoffoffoffoff
ex)ID=10offonoffonoffoffoffoff

TherangeofIDis1~255.Donotuse0ascameraID.FactorydefaultofCameraIDis1.
Ifyouwanttocontrolacertaincamera,youmustmatchthecameraIDwithCamIDsettingofDVRor
Controller.

CommunicationProtocolSetup

SelecttheappropriateProtocolwithDIPswitchcombination.
DIP2
Pin12345678
IDValueRS485
Termination
Not
used
Protocol1Protocol2Not
used
Not
used
BaudRate1BaudRate2
DefaultOffOffOffOffOffOffOffOn

Pin1isusedforRS485,100Wtermination.SetONDIP2‐1stofonlythelastloopedcamerafromthe
controller.Evenincaseofonlyonecamera,setONDIP2‐1stofthecamera.










Pin3Pin4Protocol
OFFOFFPelco‐DorPelco‐P
ONONNotused
ONOFFMaxpro

Pin7Pin8BAUDRATE
OFFOFFNotUsed
OFFON2400bps(Pelco‐D)
ONOFF4800bps(Pelco‐P)
ONON9600bps(Maxpro)
TERMINATION
CAM 1 CAM 2 CAM n-1 CAM n

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  17

‐ IfyouwanttocontrolusingDVRorP/Tcontroller,theirprotocolmustbeidenticaltocamera.
Otherwise,youcannotcontrolthecamera.
‐IfyouchangedcameraprotocolbychangingDIPS/W,thechangewillbeeffectiveafteryoureboot
thecamera.
‐Factorydefaultofprotocolis“Pelco‐D,2400bps,8bit,1stopbit,noparity.”


ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  18
6.CONFIGURATION
6.1.Setupnetworkenvironment
ThedefaultIPaddressofyourIPdeviceis192.168.XXX.XXX.YoucanfindtheavailableIPaddressfrom
theMACaddressofyourdevice.PleasemakesurethedeviceandyourPCareonthesamenetwork
segmentbeforerunningtheinstallation.IfthenetworksegmentbetweenyourPCandthedeviceis
different,changeyourPC’ssettingsasbelow.

IPaddress:192.168.xxx.xxx
Subnetmask:255.255.0.0


6.2.Viewvideoonwebpage
ViewthelivevideoonawebpageusingyourIPdeviceanditsIPaddress.YoucanusetheIPAdminTool
orentertheIPaddressonthewebpage.
6.2.1.ViewvideousingIPAdminTool
IPAdminToolautomaticallysearchesallactivatednetworkencodersandIPcamerasandshowsthe
productname,IPaddress,MACaddressandetc.IPAdminToolisprovidedwithSDKatthefollowingSDK
path.

{SDKroot}\BIN\TOOLS\AdminTool\

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  19
TousetheIPAdminToolandviewthelivevideoonawebpage:

1. StartIPAdminTool.NamesandinfoofcurrentlyactivatedIPdevicesappearasalist.
2. Right‐clickonthedesireddeviceandselectWebview.
3. Clickpop‐upblockedandinstalltheActiveXsetup.exebyclickingtheRunorSavebutton.You
needtoinstalltheActiveXfordisplayingtheimages.



4. Followtheinstructionsofthedialogboxesandcompletetheinstallation.Thenthelivevideois
displayedonthemainpageofthewebbrowser.

5. Ifthelivevideoisnotdisplayedwiththemessagesaid,“ThissoftwarerequirestheMicrosoftXML
ParserV6orhigher.PleasedownloadMSXML6fromtheMicrosoftwebsitetocontinue.Error
code:CannotcreateXMLDOMDocument.”,pleasedownloadandinstalltherelevantMSXML.

Note
i

IftheActiveXsetup.exefilefailstobeinstalledsuccessfully,closealloftheInternet
ExplorerwindowsandgotoProgramFiles>AxInstallfolderonyourcomputer.Then,
runUninstall.exeandtrytoperformthesteps1to4aboveagain.

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  20
6.2.2.ViewvideousingIPaddress
ViewthelivevideoonawebpageusingyourIPdeviceanditsIPaddress.TohavethecorrectIP
addressreadyanduseitonawebpage:
1. ConvertaMACaddresstoanIPaddressorchecktheIPaddressontheIPAdminTool.Referto
Appendix(D):Hexadecimal‐DecimalConversionTable.
(TheMACaddressisattachedonthesideorbottomofthedevice.)



2. OpenawebbrowserandentertheIPaddressofthedevice.
3. Clickpop‐upblockedandinstalltheActiveXsetup.exebyclickingtheRunorSavebutton.Youneedto
installtheActiveXfordisplayingtheimages.
4. Followtheinstructionsofthedialogboxesandcompletetheinstallation.Thenthelivevideois
displayedonthemainpageofthewebbrowser.
6.3.Reset
1. Whilethedeviceisinuse,pressandholdtheResetbutton.
2. ReleasetheResetbuttonafter3seconds.
3. Waitforthesystemtoreboot.
6.4.FactoryDefault
1. Disconnectthepowersupplyfromthedevice.
2. ConnectthepowertothedevicewiththeResetbuttonpressedandheld.
3. ReleasetheResetbuttonafter5seconds.
4. Waitforthesystemtoreboot.

Thefactorydefaultsettingscanbeinferredasfollows:


IPaddress: 192.168.xx.yy
Networkmask: 255.255.0.0
Gateway: 192.168.0.1
UserID:  root
Password: pass
MACaddress=00‐13‐23‐01‐14‐B1 →IPaddress=192.168.20.177
t
theHexadecimalnumbertoDecimalnumber.

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  21
APPENDIX(A):SPECIFICATIONS
Summary
Theexplanationandspecificationatthismanualaremainlyonthebasisofthespecificcameramodel,
whichusesSony36XOpticalZoommodule.

CameraModule
ImageSensorSony1/4”ExviewHADCCD Samsung1/4"InterlineTransferCCD
EffectivePixelsNTSC768(H)*494(V)380K/PAL752(H)*582(V)440K
TVSystemNTSC/PAL
Horizontal
Resolution550TVLines550TVLines
WhiteBalanceAuto/Manual(Red,Blue
GainAdjustable)
ATW/AWC/OUTDOOR/MANUAL(1700°K~
11,000°K)
ScanningSystem2:1Interlace
SyncSystemInternal(12VDC)
Min.Illumination1.4Lux(50IRE),
0.01Lux(ICROn)
0.2Lux(50IRE),
0.02Lux(ICROn)
Lens(Optical)36xOpticalZoom(F=1.6~
4.5,f=3.4to122.4mm)
27xOpticalZoom(F=1.6~
2.8,f=3.5to95mm)
37xOpticalZoom
(F=1.6~F3.9,f=3.5~129.5
mm)
Lens(Digital)12x(432xwithoptical)16x(432xwithoptical)16x(592xwithoptical)
FocusAuto/Manual/SemiAutoAuto/Manual/Onepush
IrisAuto/ManualOn/Off
Day&NightAuto/Day/Night(ICR)
DigitalSlowShutterOn/Off
LuminanceS/N
RatioMorethan50dB(AGCoff)
AGCNormal/High/OffLow/Medium/High/Off
BLCOn/Off
HCLNoOn/Off
FlickerlessOn/Off
SSNRLow/Middle/High/Off
PAN/TILT
PanRotationAngle360°QuickEndlessRotation
Manual0.5°~100or200°/sec(64step)
Pan
SpeedPresetMax300°/sec,Min10°/sec
TiltRotationAngle ‐2°~90°
Manual0.5°~45°/sec(64step)
TiltSpeedPresetMax250°/sec,Min200°/sec

ZN‐PTZ(W)xxVPIPE4100/IPE4500InstallationGuide
06A.02  22
SystemAccuracy0.024°
Dome
HorizontalAngleof
View(Approx.)57.8°(Wideend)to1.7°(Teleend)
Preset165positionswith16characterlabels/
Independentpresetcharacteristicsetup
AutoScanProgrammableAutoScan
GroupTourMax.8Programmablegrouptours
(eachoneconsistingofupto60presetstepswithdifferentsteps)
Pattern8ProgrammablePatterns(total480seconds)
Sector8SelectableSectorswith16characters
PrivacyZone248
AutoFlipOn/OFF
OnScreen
Display(analog)CameraID,Pan/Tiltangle,Flip,Zoom,etc
Video
CompressionH.264,MPEG‐4,MJPEGSelectableperStream
NumberofStreamsDualstream,Configurable
ResolutionD1,4CIF,2CIF,VGA,CIF,QVGA,QCIF
CompressionFPS25/30fps@D1(PAL/NTSC)
De‐interlacingSupported(DSP)
MotionDetectionSupported
Burnt‐in
Text(digital)Supported(DSP)
AnalogVideo
Output1LoopOut(BNCConnector)
Audio
Input/Output1/1ch
CompressionPCM,G.711
Function
Network10/100Base‐T
DI/DO4/2CH
RS‐485Supported
SDMemoryCard
SlotSupported(microSDtype)
Protocol
TCP/IP,UDP/IP,HTTP,RTSP,RTCP,RTP/UDP,RTP/TCP,
SNTP,mDNS,UPnP,SMTP,SOCK,IGMP,DHCP,
FTP,DDNS,SSLv2/v3,IEEE802.1X,SSH,SNMPv2/v3
Mechanical
MotorTypeSteppingmotor
MicroSteps 1/8MicroStep
