Gardco Quadracycle User manual

PAUL N GARDNER COMPANY
9104 GUILFORD ROAD, SUITE H EMAIL [e-mail]
COLUMBIA, MD 21046 USA PHONE [phone]

Drying Time Recorder Measures and Records Drying
Times of all types of Coatings, Adhesives and More
Meets ASTM D5895
The Drying Time recorder consists of a stepper motor mounted on
a rubber tipped tripod. The arm and ball assembly has a counter-poised vertical stylus consisting of a
Teflon 3/8-inch (10 mm) ball stylus and a counterweight to adjust to zero. The Teflon®stylus typically
under a 12g load (weight supplied) is moved in a 360-degree arc at a pre-selected fixed speed. A shaft
arm with the Teflon ball scriber produces a 2” diameter circular path. Drying time is observed and
recorded as the ball penetrates the film and produces a circular groove over a period of time.
After drying is completed a clear plastic time template is placed over
the area so that the drying time record can be converted into minutes
or hours.
The new design display is now even easier to read and positioned on
an angle to make for easy viewing.
Operating Controls
On/Off Button
Press to turn the Quadracycle On or Off. When the On/Off button is pressed and the Green LED is
illuminated to note the instrument is ready for testing. If the On/Off button is held down for two
seconds while the instrument is testing the current test will be terminated and the Red LED will
illuminate.
1 Hour, 6 Hour, 12 Hour and 24 Hour Buttons
When the Green LED is energized the Quadracycle is ready for testing.
Select the desired test time by depressing one of the four time cycles.
Testing will start immediately after depressing the selected cycle. The
time selected and “Testing” will be displayed on the LCD. The
Quadracycle will stop upon completion of the selected time cycle
and display “Test Complete” on the LCD. If there is a power
interruption the Red LED will energize and the LCD will display
“Test Interrupted”. To reset depress the On/Off Button.
Gardco Quadracycle DTR Instruction
BYK-Gardner USA
9104 Guilford Road
Columbia, MD 21046
USA
Phone [phone]
[phone]
Fax [phone]
[phone]
www.byk-instruments.com

Instructions for Use
1. Attach the arm and ball assembly to the motor shaft by way of the hex screw. Once tightened to
the desired position do not forcefully move the arm and ball position without loosening as this can
cause damage to the gearbox assembly.
2. Balane the arm by adjusting the rear counterweight before placing the 12 gram weight on the ball
shaft.
3. Apply the coating to your test panel using a Gardco Microm Film Applicator or other wet film
applicator.
4. Immediately place the Drying Time Recorder on your test panel and lower the clean 3/8 in.
weighted Teflon stylus gently into position.
5. Select the desired drying time and the stylus will then begin to be drawn along the test panel.
6. After the selected time cycle is complete the Drying time recorder will automatically stop. Evaluate
the test panel using the supplied Time Template to determine the stages of drying time.
7. Place the clear Time Template over the circular area scribed by stylus
and note appropriate scale number of minutes or hours required for
the film to cure, the character of the track by the 3/8 inch Teflon ball
stylus relate
to the drying of the film (Reference ASTM D5895).
8. Record the results and if desired, record the temperature,
humidity and the wet film thickness as these factors are
important in considering the drying time of films.
