Garden Oasis SS-J-251-1NMT User manual

Date of Purchase:
Receipt of Purchase:
Attach Here
_____ /_____ /_____
OWNER'S MANUAL
Product Code: D71 M80193
See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com
UPC Code: 7-6945575806-4
Saratoga 5 Piece Bar Set
1
Vendor Item: SS-J-251-1NMT

C (2)
Left Mesh Shelf
PARTS
Read through all the instructions before beginning assembly. Unpack and identify all the parts.
Place them on a flat, non-abrasive surface. Assembly by two people is recommended.
A (1)
Left Tempered
Glass with Rim
B (1)
Right Tempered
Glass with Rim
ACCESSORIES
Ga (9 + 1 spare)
Short Bolt
Gc (7 + 1 spare)
Nut
D (2)
Right Mesh Shelf
E (1)
Left Side Apron Panel
F (1)
Right Side Apron Panel
Gd (17 + 1 spare)
Metal Washer
Ge (7 + 1 spare)
Lock Washer
Gf (1 spare)
Glass Bumper
Gg (2)
Allen Wrench
Gh (2)
Hex Wrench
Gi (1)
Touch-up Paint
Gj (1)
Assembly
Instructions Sheet
2
Gb (8 + 1 spare)
Long Bolt

ASSEMBLY INSTRUCTIONS
Stand the assembled panels (E& F) upright. Level
the unit by adjusting panel leg feet up and down as
desired. See Fig. 2.
Attach one left mesh shelf (C) to one right shelf (D)
by inserting a short bolt (Ga) through a metal
washer (Gd), through the mesh shelf holes (C&D),
through a lock washer (Ge) and a nut (Gc) for each
hole. Tighten all bolts and nuts. Repeat procedure
for the other pair of mesh shelves (C&D). See Fig. 3.
Place this assembled lower mesh shelf (C&D) into
place by fitting mesh shelf edges into all panel “L”
brackets. Push (do not force) mesh shelf into place.
Repeat procedure for upper mesh shelf (C&D).
See Fig. 4.
1
2
3
4
Place the left and right side apron panel (E&F)
on a flat surface. Assemble side apron panels (E& F)
by sliding the hinge pins together. Rotate the hinges
to ensure a secure fit. See Fig. 1.
Place the tabletop (A&B) upside on a flat surface.
Attach left tabletop glass (A) to right tabletop
glass (B) by using a short bolt (Ga) through a
metal washer (Gd), through the tabletop
holes (A&B), through a lock washer (Ge) and a
nut (Gc) for each hole. Tighten all bolts and nuts.
See Fig. 5.
5
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
3
E
F
F
E
A
B
Gd
Ge Gc
Ga
DC
Ge
Ga
Gd
Gc

CARE INSTRUCTIONS
Wash with a mild solution of soap and water; rinse thoroughly. Dry completely. Do not use bleach or solvents.
Cover furniture with outdoor furniture covers when not in use.
6Turn over the assembled tabletop (A& B) and place
it onto the assembled body. Insert a short bolt (Ga)
through a metal washer (Gd), through the tabletop (A)
and into the side panel (E) for each hole. See Fig. 6.
Do not tighten. Adjust the plastic receiver positions
on the rim by sliding back and forth when necessary.
Insert a long bolt (Gb) through a metal washer (Gd),
through the U shaped tabletop bracket, and into the
side panel (E) for each hole. See Fig. 7. Do not
tighten. Insert a long bolt (Gb) through a metal
washer (Gd), through the T shaped tabletop bracket
and into the side panel (E) for each hole. Do not
tighten. See Fig. 8. Repeat procedure for the right
panel (F) the right tabletop (B).
Tighten all bolts. You can readjust level by
twisting knobs on the bottoms of the legs as desired.
Your bar table is ready for use.
4
Fig. 7
Fig. 8
Fig. 6
Made in CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL 60179
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
For questions or comments about product:
Call toll-free:
800-457-4652
Please refer to part numbers when reordering
sears.com
7
E
B
F
Gb
Gd
Ga
Gd
Gb
Gd
A
