Garden Oasis SS-J-251-1NB/4 User manual

Date of Purchase:
Receipt of Purchase:
Attach Here
_____ /_____ /_____
OWNER'S MANUAL
Product Code: D71 M80193
See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com
UPC Code: 7-6945575806-4
Saratoga 5 Piece Bar Set
Vendor Item: SS-J-251-1NB/4
1

PARTS
Read through all the instructions before beginning assembly. Unpack and identify all the parts.
Place them on a flat, non-abrasive surface. Assembly by two people is recommended.
ACCESSORIES
2
A (4)
Chair Frame
B (4)
Sling Seat and Back
Ca (8 + 1 spare)
Short Bolt
Cb (8 + 1 spare)
Long Bolt
Cc (16 + 1 spare)
Metal Washer
Cd (1)
Allen Wrench
Ce (1)
Assembly Instructions
Sheet

ASSEMBLY INSTRUCTIONS
1
3
CARE INSTRUCTIONS
Wash with a mild solution of soap and water; rinse thoroughly. Dry completely. Do not use bleach or solvents.
Cover furniture with outdoor furniture covers when not in use.
Made in CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL 60179
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
For questions or comments about product:
Call toll-free:
800-457-4652
Please refer to part numbers when reordering
sears.com
Place the sling seat and back (B) on the chair
frame (A) and align the holes in the seat with
the holes in the frame. Insert a short bolt (Ca)
through a metal washer (Cc), through the front
crossbar under the sling seat and secure into
the leg. See Fig. 1. Don’t tighten completely.
Repeat procedure for the other side.
Fig. 1
Fig. 2
Align the holes in the sling back with the holes
in the frame. Insert a long bolt (Cb) through a
metal washer (Cc), through the side rail of sling
back and secure into the rear leg. See Fig. 2.
Don’t tighten completely. Repeat procedure for
the other side.
2
Now go back and securely tighten all bolts
by using Allen Wrench (Cd) provided.
Repeat procedure for the remaining 3 chairs.
Your bar chairs are now ready to use.
3
Cc Ca
Cc Cb
B
A
