Pack contents/ partsDOUBLE 52&.(5
USA
Pack contents/ parts
1877 579 1550
AFTER SALES SUPPORT 5
[email protected]
MODEL: 2416  04/
USA
NO. Picture Description Qty
Right Arm
Left Arm
Chair Seat/Back
Large Washer
Screw(M6*12)
Srew(M6*40)
Washer
Screw Cap
Allen Key
Rocker

SafetyDOUBLE 52&.(5
USA
Warning
1. Do not crawl or stand on the chair seat.
2. This chair holds a maxmum weight of 200lbs.(91kgs) on each seat. DO NOT
EXCEED
3. Use the chair only on level ground.
6
1877 579 1550
AFTER SALES SUPPORT
[email protected]
MODEL: 2416 04/
USA

Set-upDOUBLE 52&.(5
USA
Set-up
Identify all the parts packaged in the carton against the parts list. Remove all
protective materials and place parts on a nonabrasive surface to avoid scratching.
If any parts are missing or damaged, DO NOT attempt to assemble. Please
contact our customer service center (Mondy-Friday 9:00 am - 4:00 pm Est.) at
1-877-579-1550.
Caution
7ZR SHRSOH UHFRPPHQGHG IRU DVVHPEO\Read all the instructions before
assembly. Failure to do so may result in faulty assembly and potential injury!
Assemble product on a soft, non-abrasive surface such as a carpet or
cardboard to avoid damaging the item. Seek assistance to assemble bulky or
heavy items. After final alignments, make sure all bolts and nuts are securely
tightened with screw covers pressed in place.
1877 579 1550
AFTER SALES SUPPORT 7
[email protected]
MODEL: 2416  04/
USA
FIG.1
A
B
CC
F
H
I
washers (H). Cover all hardware with screw caps (I). Repeat this step to
attach the right arm (A). See Fig.1
1..Attach the left arm (B) to the leg (C) using four M6*12 Screws (F), and foWT

Set-upDOUBLE 52&.(5
USA
8
1877 579 1550
AFTER SALES SUPPORT
[email protected]
MODEL: 2416 04/
USA
FIG.2
2. Open the chair seat/back (D). See Fig.2
FIG.3
3.1. Attach the chair seat (D) to the arm rear side using one M6*12 screws (F), one
D
D
Fig.1
D
B
F
H
I
F
H
I
G
H
I
E
washers (H) and one large washer (S). Cover all hardware with screw caps (I).
3.2. Attach the chair seat (D) to the arm front side using one M6*12 screws (F), one
washers (H) and one large washer (S). Cover all hardware with screw caps (I).
3.3. Attach the chair back (D) to the arm rear side using one M6*12 screws (G), one
washers (H). Cover all hardware with screw caps (I). See Fig.3

Set-upDOUBLE 52&.(5
USA
1877 579 1550
AFTER SALES SUPPORT 9
[email protected]
MODEL: 2416  04/
USA
washers (H) and one large washer (S). Cover all hardware with screw caps (I).
4.2. Attach the chair seat (D) to the arm front side using one M6*12 screws (F), one
FIG.4
washers (H). Cover all hardware with screw caps (I). See Fig.4
FIG.5
A
F
H
I
G
H
I
Fig.1 F
H
I
E
4.1. Attach the chair seat (D) to the arm rear side using one M6*12 screws (F), one
washers (H) and one large washer (S). Cover all hardware with screw caps (I).
4.3. Attach the chair back (D) to the arm rear side using one M6*12 screws (G), one
5.5.Fully tighten all screws using Allen Key (J). Cover all hardwares wi
screw caps (I). See Fig.5

1
1877 579 1550
AFTER SALES SUPPORT
[email protected]
MODEL: 2416 04/
USA
MaintenaceDOUBLE 52&.(5
USA
Care & Maintenace
Be careful to never allow water build up in frames as this will cause corrosion and
freeze damage in cold climates. Wash all frames with a solution of mild soap and
water. Rinse with clean water and dry with a soft absorbent cloth towel. Frames
can be treated with a liquid wax for maximum protection against UV rays and/or
salty damp air. If your set includes cushions, slings and/or an umbrella, they may
be cleaned by hand with a solution of soap and water with a clean water rinse.
