Installation and Operating Instructions for
99025/99026/99036 Seat Swivel System
Form 12.345
Write for
a Complete
Catalog
Phone: [phone]
PO Box 8, 644 2nd Street E-mail: [email protected]
St. Paul Park, Minnesota 55071 On the Web: www.garelick.com
2/01
INSTALLATION
Read instructions completely before installing. Refer to Fig. 1.
1. Position Seat Swivel on seat bottom and align 4 mounting
holes.
2. Secure Seat Swivel with appropriate hardware.
NOTE: Fasteners are not provided due to the wide variety
of installations.
NOTE: All EEz-In seats use 1/4"-20 threaded T-nuts.
SPECIAL NOTE: for rotational molded EEz-In seats:
A. Install with reinforcement brackets between seat swivel
and seat bottom.
B. Make certain that the portion of the screw entering the
seat shell’s T-Nut does not exceed 3/8". Seat shell T-nuts
are 1/4"-20 thread, use only 1/4"-20 machine screws.
3. Remove black delrin cup from swivel casting. Align splines
in cup with splines on seat pedestal and tap on with a soft
hammer, if necessary.
4. Slip seat with swivel onto pedestal.
SMOOTH TUBE INSTALLATION
Read instructions completely before installing. Refer to Fig. 2.
1. Slide Delrin Cup (59.858) over stanchion tube. Align
one of three countersunk holes to front of the tube. This
will index casting so seat will lock in the forward facing
position. Push down until rim of cup contacts top of tube.
Center punch tube at locations of three countersunk
holes.
2. Drill three holes 13/64" diameter through tube. File or
scrape clean the burrs left from drilling.
3. Fasten cup in place using three flathead screws (03.547)
and locknuts (03.027).
(continued on back)
FIG. 1
FIG. 2

Installation and Operating Instructions –
99025/99026/99036 Seat Swivel System
Form 12.345
FIG. 3
(continued)
SMOOTH DELRIN CUP INSTALLATION FOR ADJUSTABLE
HEIGHT SEAT BASES MODELS 75436/75437
Refer to Fig. 3.
1. Align 2 of the 3 countersunk holes in the Delrin cup
(59.858) as shown in figure 3. This will allow clearance of
the screws and nuts with the ribs on the inside wall of the
stanchion. Mark the 2 locations and remove the cup.
2. Center punch the 2 marks. With a 13/64" bit, drill 2 holes
through.
3. Fasten cup in place using 2 flat head screws (03.547) and
2 locknuts (03.027).
NOTE: After assembly and installation of the seat is
complete, check to see if the seat will lock in the forward
facing position. If the seat locks slightly left or right of
perfectly forward, it may be necessary to rotate the base
slightly to achieve the ability to lock your seat straight
forward.
TO OPERATE
1. To rotate seat and adjust the drag control feature for
rotation, Pull Handle “B” up to the horizontal position and
release. The handle will maintain the horizontal position.
The seat is now free to rotate 360 degrees. To increase the
drag on rotation, turn Handle “C” clockwise to desired
resistance. To decrease drag, turn Handle “C” counter
clockwise.
2. To positive lock the rotational feature, Push Handle “B”
down and the Positive Quick Lock feature hunts for the next
available locking spline.
NOTE: Always use positive lock feature when boat is
underway.
MAINTENANCE
Keep a light film of grease on:
– Slide plate surface that the casting slides on
– The multiple cam surfaces that the casting locks into
– The Cam Surface on the Bottom of Handle “B” that is
exposed when in the horizontal position
– The Stainless Steel bolt that Handle “C” is threaded onto
Periodically check and tighten the mounting screws between the
seat swivel and the seat bottom.
