Change a Menu item 4:1
!
1. Press and hold the “PROGRAM” key (5 sec) or
until the software version is displayed.
!
GC450 V.06.31
!
!
!
!
!
!
!
!
2. Press the “PROGRAM” key Twice until
“SYSTEM SETUP” appears.
!
SYSTEM SETUP
!
!
!
!
!
!
!
!
3. Press and hold the “UP ARROW” key
(approximately 8 sec) until Gap Calibration
appears.
!
GAP CALIBRATION 0000
!
!
!
!
!
!
!
!
4. Press the “PROGRAM” key twice
for “MENU ITEMS”.
!
MENU ITEMS
!
!
!
!
!
!
!
!
5. Press the “MENU SELECT” key twice for
“4:1 Clam Yes”.
!
4:1 CLAM YES
!
!
!
!
6. Press the “Temp” key: Remove In: 120 sec
REMOVE IN 120
!
!
!
!
!
!
!
!
7. Press the “TEMP” key:
Alarm: select the “Auto” key to toggle between
Auto or Manual - select : ”AUTO”
!
ALARM: AUTO
!
!
!
!
!
!
!
!
8. Press the “TEMP” key: Gap Settings: .500
!
GAP SETTING .500
!
!
!
!
!
!
!
!
9. Press the “TEMP” key: Stage 1 Time: 10 sec.
!
STAGE #1 TIME 010
!
!
!
!
!
!
!
!
10. Press the “TEMP” key: Stage 1 Gap: .425
!
STAGE #1 GAP .425
!
NEW 4:1 MULTI-STAGE COOKING ON IRON
PROGRAMMING INSTRUCTIONS
NOTE: Press the “TEMP” key for each level.
Press the “UP ARROW” key to change the
flashing number and press the
“RIGHT ARROW” key to move to the next digit.
050716!
MODEL 9501
INFINITE GAP GRILL

Page 2of 2
!
!
!
11. Press the “TEMP” key: Stage 2 Time: 17 sec.
!
STAGE #2 TIME 017
!
!
!
!
!
!
!
!
12. Press the “TEMP” key: Stage 2 Gap: .490
!
STAGE #2 GAP .490
!
!
!
!
!
!
!
!
13. Press the “TEMP” key: Stage 3 Time: 057 sec.
!
STAGE #3 TIME 057
!
!
!
!
!
!
!
!
14. Press the “TEMP” key: Stage 3 Gap: .450
!
STAGE #3 GAP .450
!
!
!
!
!
!
!
!
15. Press the “TEMP” key: Must Remove in: 00
!
MUST REMOVE IN 00
!
!
16. Press the “TEMP” key: Toast Buns 000
!
TOAST BUNS 000
!
!
!
!
!
!
!
!
17. Press the “TEMP” key:
Alarm: select the “Auto” key to toggle between
Auto or Manual - select : ”AUTO”
!
ALARM: AUTO
!
!
!
!
!
!
!
!
18. Press the “TEMP” key: TOP TEMP: 425 F
!
TOP TEMP 425F
!
!
!
!
!
!
!
!
19. Press the “TEMP” key: BOTTOM TEMP:
(365 F not shown)
!
BOTTOM TEMP 365F
!
!
!
!
!
!
!
!
20. Press the “TEMP” key multiple times to scroll
though the menu to verify the changes you
made are correct.
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Return To Main Menu!
1. Press the “PROGRAM” key once
2. Press the “RIGHT ARROW” key once
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!
!
!
!
050716JED
10:1 CLAM YES
ALARM AUTO
THE COOK TIME IS A “START POINT” FOR COOKING.
AFTER THE PROGRAMMING CHANGES ARE MADE,
COMPLETE A “BEEF INTEGRITY” CHECK TO SET THE
CORRECT COOK TIME FOR THE 4:1 PRODUCT.
