Garrison 043-6080-0 User manual

PLUG-IN CONVECTION HEATER
WITH THERMOSTAT
Instruction Manual
model no. 043-6080-0
IMPORTANT: Please read this manual carefully
before running this heater and save it for reference
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 1043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 1 5/16/2013 6:31:20 PM5/16/2013 6:31:20 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

2
model no. 043-6080-0
Table of ContentsFeatures
1. Adjustable Thermostat
2. Two Settings:
High 1500 W (5120 BTUs)
Low 750 W
3. Top Mounted Control Panel
4. Power Indicator Light
5. Safety Overheat Protection
6. Safety Tip-Over Protection
7. Silent Operation
8. Efficient Convection Heating
Features 2
Specifications 3
Know Your Heater 3
Operation 4–5
Cleaning and Maintenance 6
Safety Features 6
Important Safeguards 7-8
Warranty 9
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 2043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 2 5/16/2013 6:31:24 PM5/16/2013 6:31:24 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

3
Model 043-6080-0
Voltage/Amps 120 V AC / 12.5 A
Frequency 60 Hz
Watt High: 1500 W (5120 BTUs); Low: 750 W
SpecificationsKnow Your Heater
KNOW YOUR PLUG-IN CONVECTION HEATER WITH THERMOSTAT
Before use of this product, familiarize yourself with all operating features
and safety rules.
This product is intended for indoor residential, office and personal shop use only, not
for industrial or other commercial applications. Use only with electrical wiring that is in
good working order and that meets applicable codes and ordinances. If you have any
questions about whether your wiring is adequate, consult a qualified electrician.
Use your heater only with a working smoke detector located in the vicinity of the heater.
While using your heater, you should follow the IMPORTANT INSTRUCTIONS listed
below. As part of those instructions, we have used the word “WARNING” to indicate the
level of hazard: WARNING indicates a hazard which, if not avoided, could result in injury
or death.
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 3043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 3 5/16/2013 6:31:24 PM5/16/2013 6:31:24 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

4
model no. 043-6080-0
Operation
HEATER OPERATION
Always operate the heater in the upright position following all instructions and
recommendations listed in this manual. HEATER LOCATION: Place the heater in the area of
the room that is coldest. HEATER CONNECTION: Plug heater directly into 120 V AC,
60 Hz wall outlet. Be sure plug fits tightly in outlet. A loose connection may cause
overheating and damage to the plug or heater. NOTE: To prevent overloading a circuit, do not
plug the heater into a circuit that is servicing other electrical needs.
!WARNING: FIRE HAZARD Do not use near combustible materials or
flammable gases or sources of heat. Do not place the heater near a bed
because objects such as pillows or blankets can fall off the bed and be ignited
by the heater.
!WARNING: SHOCK HAZARD Use your heater only in dry environments. This
heater is not intended for use near sinks, washing machines, swimming pools
or other sources of water. Do not use in damp environments such as flooded
basements.
To start the heater, turn the Power Control dial from the OFF position to the LOW or
HIGH setting. Then rotate the Thermostat Control clockwise to the HIGH THERMOSTAT
position as described below. (During the heater’s initial use, you may experience a slight
odour or smoking. This is the result of the heating element lubrication “burning off”. This
is normal and will go away after a few minutes of use.)
TURNING HEATER ON
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 4043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 4 5/16/2013 6:31:24 PM5/16/2013 6:31:24 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

5
Operation
POWER INDICATOR LIGHT
This heater is equipped with a Power Indicator Light.
The light will illuminate when the unit is plugged in.
This heater has two heat settings: High and Low. Use the
higher setting (1500 W) to raise the room temperature
quickly. When the desired temperature is reached use
the Low setting. It is usually sufficient to maintain a
comfortable temperature.
POWER CONTROL DIAL
!WARNING: HOT SURFACES Do not touch body of heater when in use.
1
1
23
1. Power Control Dial
2. Thermostat Control
3. Power Indicator
Light
After heater has been turned on and the room has
reached the desired temperature, slowly rotate the
thermostat knob counter-clockwise until the heater
shuts off (you should hear a faint “click”). By leaving the
thermostat at this setting it will automatically maintain
this temperature. To lower temperature, rotate the knob
further counter-clockwise (towards the LOW position).
To raise the temperature, rotate the thermostat knob
clockwise (towards the HIGH position).
SETTING THERMOSTAT
Turn the Power Control Dial to the OFF position before
unplugging or plugging in the heater. Heater should be
unplugged when not in use.
TURNING OFF
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 5043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 5 5/16/2013 6:31:25 PM5/16/2013 6:31:25 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

6
model no. 043-6080-0
Cleaning and Maintenance
CLEANING
CAUTION - Before cleaning the heater be sure to disconnect power cord and allow the heater
to cool completely. Clean the outside surface with a clean damp cloth. Do not use harsh
chemical or abrasive cleaners. DO NOT IMMERSE THE HEATER IN WATER. Allow heater to
dry completely before use.
REPAIR
DO NOT OPERATE THE HEATER WITHOUT THE GRILL IN PLACE. DO NOT USE THE
HEATER IF IT HAS MALFUNCTIONED OR BECOME DAMAGED IN ANY WAY.
STORAGE
Keep original carton for storage of the heater. Coil and tie the power cord to avoid damage
during storage.
Safety Features
The power indicator light, located near the control panel, lights whenever the heater is
plugged in. The heater is equipped with an automatic overheat protection device located
inside the body of the heater. If the heater grill is obstructed, or if the heater gets too hot for
any reason, the automatic overheat protection device will turn the heater off. To reset the
heater, simply turn power off and unplug the heater for 10 minutes until it cools down, then
plug in and restart the heater. Be sure that the heater is on a smooth level surface with no
obstructions. The heater is also equipped with a safety tip-over switch. This switch will shut
the heater off if the heater is tipped over. It will reset when the heater is placed upright.
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 6043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 6 5/16/2013 6:31:25 PM5/16/2013 6:31:25 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

7
Important Safeguards
When using electrical appliances, basic precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
If provided, use handles when moving this heater. Keep combustible material, such as
furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the
front of the heater and keep them away from the sides and rear.
3. Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not operate any heater with a damaged cord or plug or after the heater malfunctions.
has been dropped or damaged in any manner. Discard heater, or return to authorized
service facility for examination and/or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never locate heater where it may fall into a bathtub or other water container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from
traffic area and where it will not be tripped over.
9. To disconnect heater, turn controls to off, then remove plug from outlet.
10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
11. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use
on soft surfaces, like a bed, where openings may become blocked.
12. A heater has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or flammable liquids are used or stored.
13. Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons.
14. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension
cord or relocatable power tap (outlet/power strip).
15. SAVE THESE INSTRUCTIONS.
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 7043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 7 5/16/2013 6:31:25 PM5/16/2013 6:31:25 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

8
model no. 043-6080-0
Important Safeguards
Important Safeguards
!WARNING: ELECTRICAL SHOCK HAZARD Do not use with damaged cord
or plug. Use with adequate electrical system that is up to code.
The supply cord has a polarized plug. As a safety feature this plug will fit
in a polarized outlet only one way. To prevent electric shock, match wide
blade of plug to wide slot, fully insert plug. If the plug does not fit contact
a qualified electrician. Never use an extension cord. DO NOT attempt to
defeat this safety feature.
Do not operate heater with a broken heating element or ceramic cone or
any visual imperfections. For repairs covered under warranty, see warranty
statement. For all other repairs contact Garrison’s Customer Service by
telephone or mail for information and assistance.
Do not use an extension cord because the extension cord may overheat and
cause a risk of fire.
Do not operate heater with its ventilation obstructed.
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 8043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 8 5/16/2013 6:31:25 PM5/16/2013 6:31:25 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

9
Warranty
This Garrison®product carries a one (1) year warranty against defects in workmanship
and materials. Trileaf Distribution agrees to replace a defective product within the stated
warranty period, when returned to the place of purchase with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 9043-6080-0 Garrison_Elec Basebrd Htr_EN_5.15.2013.indd 9 5/16/2013 6:31:26 PM5/16/2013 6:31:26 PM
Process CyanProcess CyanProcess MagentaProcess MagentaProcess YellowProcess YellowProcess BlackProcess BlackPANTONE 287 CPANTONE 287 C

Made in China
Imported by Trileaf Distribution Trifeuil
Toronto, Canada M4S 288
