Garwoods Domino EC-7 Series Manual

0
Domino Electric Cooker
Domino電能煮食爐
Model/型號: EC-7… Series/系列
For domestic use only (只供家居使用)
Installation & Operating Instructions
產品使用說明書

1
1、 Function & Characteristics ------------------------------------------- 2
2、 Installation Guideline-------------------------------------------------- 3-5
3、 Control Panel Instructions-------------------------------------------- 6-9
4、 Operation ethod----------------------------------------------------- 10-14
4.1 .Operation Instructions
4.2 .Usable and Non-usable Cookware
4.3. Heating Power Level
5、 Safety Precautions----------------------------------------------------- 14-15
5.1 . Safety Notes
5.2 . Warning
6、 Daily aintenance----------------------------------------------------- 15
7、 Product Specification-------------------------------------------------- 16
8、 Trouble-Shooting Guideline------------------------------------------ 17-18
8.1 . Code Of Breakdown
8.2 . Trouble Shooting
CONTENTS

2
Thank you for choosing Garwoods EC-7… Domino Electric Cooker. Please read this
operation manual carefully before installing or using this product and keep the operation
manual for future use.
1、Function & Characteristics
 Ener y-efficient

The electric cooker utilizes the brand-new calefaction principle and the
thermal efficiency is extremely high.
Induction cooker or Induction cookin zone – it is time saving & energy efficient because
it directly heats up the bottom of the cookware and heat transfer efficiency up to 90% is
achieved.
Infrared cooker or infrared cookin zone – it utilizes radiant heating element and the
surface remains a residual heat for short-time cooking without power after cooking. It is
energy-saving.
 Multi-function

The electric cooker utilizes newest micro-computer chip program control.
It offers multiple scales for heating power level regulation.
 Safety & Environmental Friendly

Safety & Environmental Friendly of the product is on
our top priority. The electric cooker contains a series of safety system such as safety lock;
high temperature indicator (Infrared cooker or infrared cooking zone);
auto-temperature adjustment (Infrared cooker or infrared cooking zone); overheat
prevention (Induction cooker or induction cooking zone); cookware sensor (Induction
cooker or induction cooking zone) etc.
 Easy-to-clean Surface

Ceramic glass top panel is easy to clean. When the surface is cool
down after cooking, wipe it with a damp cloth.

Notice

: The surface on the infrared cooker or infrared cookin zone is under a
very hi h temperature condition after cookin , please do not place any
combustible materials on the surface and touch the surface to avoid
any risk of fire and ettin burnt
 Touch Buttons Operation

Touch button design is easy for use.
 Intellectual Power

The electric cooker adopts intellectual power distribution technology
and the specified power can be distributed to each cooking zone by the micro-computer
system.

3
2、Installation Guideline
★ Installation should be followed below requirements：
1. The walls on top of the working face and next to the installation of electric cooker must
be heat-proof.
2. The laminated boards and adhesive used for installation must be heat-resistant.
3. For any installation method, the air under the electric cooker and behind the cooking
range should have enough space for cooling in order to ensure the safety of operating the
electric cooker.
4. Based on the prescribed dimensions, a square hole is opened on the work table. Ensure
the distance between any side of the work table and the walls is

55mm.
5. Protect the opening: If in contact with damp, the laminated boards used in marking the
work table will easily expand more. It is required to stick varnish or special adhesive onto
the edge of the opening in order to prevent any steam from condensation under the work
table.
6. For any condition of installation, the electric cooker should have a good ventilation
condition with air inlet and air outlet not blocked.
7. Don’t place other equipments on the working face of the cooking zone of the electric
cooker and within the range of 30cm around the working face.
8. If choosing a table-top installation, ventilation hole shall be at least 55mm from wall
surface.
9. The electric cooker must be complied with a 13A power outlet.
★ Steps on Installation：
~ Open an installation hole on the worktop of cabinet as per

illustration 1

.
(Note : The height shall be more than 100mm)
Cut out dimensions(unit/mm)

(W) 275 x (D) 495 x (H) 100

illustration 1


4
~ In front of the cabinet, open an air inlet with more than 100cm2 under the location of
electric cooker as per

illustration II

. If the cabinet is not sealed, the air inlet may not be
opened so as to ensure heat elimination.

illustration II

~ Before put the electric cooker into the hole, an water-proof type is properly applied on the
bottom of front panel of the electric cooker as per

illustration III

.

illustration III


5
~ Put the electric cooker into hole. Insert plug of power line into corresponding socket. The
electric cooker can be used after power connection as per

illustration IV

.

illustration IV

~ If the electric cooker is installed above an oven, fix an insulation part at least 15cm under
the electric cooker as per

illustration V

. Also, open an air inlet with more than 100cm2
under the location of the electric cooker to ensure ventilation and operation in good
conditions
 


6
3、Control Panel Instruction
Model：EC-7122IR

Cooking Zone


Control Panel

12 11 10 9 8 7 6 5 4 3 2 1
1…On/Off 2…On/Off Indicator
3…Lock Key 4…Lock Indicator
5…Power Plus Key 6…Power inus Key
7…LED Digital Indicator (Power/High Temperature)
8…Timer Plus Key 9…Timer inus Key
10…LED Digital Indicator (Timer) 11…Timer Key
12…Timer Indicator

7
Model：EC-7128IC

Cooking Zone


Control Panel

13 12 11 10 9 8 7 6 5 4 3 2 1
1…On/Off 2…On/Off Indicator
3…Lock Key 4…Lock Indicator
5…Power Plus Key 6…Power inus Key
7…Booster Power Key 8…LED Digital Indicator (Power)
9…Timer Plus Key 10…Timer inus Key
11…LED Digital Indicator (Timer) 12…Timer Key
13…Timer Indicator

8
Model：EC-7238IC

Cooking Zone


Control Panel

17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
1…On/Off 2…On/Off Indicator
3…Lock Key 4…Lock Indicator
5…Power Plus Key (Front Zone) 6…Power inus Key (Front Zone)
7…Booster Power Key (Front Zone) 8…LED Digital Indicator (Power – Front Zone)
9…Timer Plus Key 10…LED Digital Indicator (Timer)
11…Timer inus Key 12…Timer Key
13…Timer Indicator (Rear Zone) 14…Timer Indicator (Front Zone)
15…Power Plus Key (Rear Zone) 16…Power inus Key (Rear Zone)
17…LED Digital Indicator (Power/High Temperature – Rear Zone)

9
Model：EC-7288RC

Cooking Zone


Control Panel

17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
1…On/Off 2…On/Off Indicator
3…Lock Key 4…Lock Indicator
5…Power Plus Key (Front Zone) 6…Power inus Key (Front Zone)
7…Booster Power Key (Front Zone) 8…LED Digital Indicator (Power – Front Zone)
9…Timer Plus Key 10…LED Digital Indicator (Timer)
11…Timer inus Key 12…Timer Key
13…Timer Indicator (Rear Zone) 14…Timer Indicator (Front Zone)
15…Power Plus Key (Rear Zone) 16…Power inus Key (Rear Zone)
17…LED Digital Indicator (Power – Rear Zone)

10
4、Operation Method
4.1、Operation Instructions：
 Power Connection

After power connection, buzzer will make a short sound and the LED
digit will show “

” . That means the electric cooker keeps at the stand-by mode. If no
working of the electric cooker after 15 sec., the electric cooker will automatically be
locked and entering sleeping mode.
 Sleepin Mode

If no working of the electric cooker after 15 sec. when power connection
or surface of the electric cooker has been thoroughly cool down after cooking, the electric
cooker will automatically enter sleeping mode for energy saving. If resume and re-start
the working of the electric cooker, just touch any keys on the control panel, then press
the “ON/OFF” key.
 Lock Function

When lock indicator is on , that means the lock function is active. At this
time, all keys will be locked except

ON/OFF

key and

Lock

key in order to avoid
mis-operation. If resume the lock function, by pressing

Lock

key, buzzer will make a
short sound and the lock indicator will be off. If start again the lock function, by
pressing the

Lock

key, buzzer will make a short sound and lock indicator will be on.
 On switchin

Place cookware on heating zone (Pls. refer to Usable and Non-usable
Cookware), by pressing the “ON/OFF” key, then by pressing “Power Plus” key, LED will
show the pre-set power level.
 Power Level Alteration

At the power function, by pressing “Power plus” Or “Power
minus” key to increase or decrease power level. LED digit shows the set power level. To
stop the power output, by pressing “Power minus” key to decrease the power level to
“

”

two-zone electric cooker should decrease the power level to “

” at the same time.
After 15 sec. , the electric cooker will be automatically locked and power off or by
pressing “ON/OFF” key to power off the cooker directly.
(Notice : The surface on the Infrared cooker or infrared cooking zone is under a very high
temperature condition after cooking, therefore, when you decrease the power level to
“

”, the LED digit will show “H” instead of “

”. That means that the cooker is under
cooling down (Pls. refer to below high temperature indicator).
Induction cooker or induction cooking zone with high power consumption offers a
booster function. By pressing “Booster Power” key, the cooking zone may be used to
shorten heating-up times and the LED digit will show “P”. The booster works for max 5
min and the cooking zone will return to previous power level when the work time of
booster power is reached.

11
 Hi h Temperature Indicator

When using infrared cooker or infrared cooking zone after
cooking, the LED digit will show “H” and flicker, that means the temperature on the
heating zone is over 70

c. At this time, the heating zone is under a very high
temperature condition, please do not attempt to place any combustible materials on the
heating zone and touch the heating zone to avoid any risk of fire and getting burnt until
the fan is stop operation and the “H” in the LED Digital Indicator is vanished.
 Selectin Timer

By pressing

Timer

key, the time indicator will be on. At the time, by
pressing

Timer plus

Or

Timer minus

key to set the required time. The operational
setting range is between 1 min. and 99 min. When set time is reached, buzzer will make a
long sound and the electric cooker stops heating. To cancel time setting, set the timing to
“ZERO”.
 Off Switchin

During heating, by pressing

ON/OFF

key to switch off.
4.2、Usable and Non-usable Cookware：
1. Please refer to below information to select a suitable cookware cater for all delicious
cuisine by the infrared cooker or infrared cookin zone.
 ost of materials for a flat bottom cookware are suitable for use of the infrared cooker
or infrared cooking zone, such as stainless steel pot, iron pot, aluminum pot, ceramic pot
and glass pot etc. The diameter of the flat bottom cookware is within 12-24 cm. For a
good effect, it is recommended for an around 22 cm in diameter and depends on the
thickness of the cookware at the flat bottom.
 It is normal that feeling hot from the heating zone if the flat bottom cookware does not
cover the circle on the heating zone because it will release far infrared rays when cooking.
2. Please refer to below information to select a suitable cookware cater for all delicious
cuisine by the induction cooker or induction cookin zone.
Usable Cookware Non-usable Cookware

Materials

Iron, cast iron, stainless steel
and enamel cookware.

Materials

Cookware made of pottery,
aluminum, glass, copper or bronze.

Shape and size

The diameter more than
120mm (4.5 inches) are recommended.

Shape and size

The bottom diameter of
the cookware is less than 120mm (4.5
inches). And, the cookware with curved
bottom, with concave bottom (the concave
depth
!
4mm) or with legs (the
height
!
4mm).

Sorts of suitable cookware

Stainless
steel kettle, iron tray, bottom pan, iron pot,
iron tray, enamel pot etc.

Sorts of un
-
suitable cookware

Copper,
bronze and aluminum pot, glass pot,
pottery pot, bronze pan etc.

12
3. It is normal that sound

ze..ze..

from the cookware when heating.
4. The cookware is placed in the center of the circle at the heating zone.
4.3、Heatin Power Level：
 When two single zones are operating in the same time, the total power level is up to
2800W. However, the power of one single zone will reduce automatically when the
other zone is being cooking so as to maintain the total power level will not exceed
2800W.
 Induction cooker or induction cooking zone with high power consumption offers a
booster function. By pressing “Booster Power” key, the cooking zone may be used to
shorten heating-up times and the LED digit will show “P”. The booster works for max 5
min and the cooking zone will return to previous power level when the work time of
booster power is reached.
Model：EC-7122IR
Power Level Power (W)
7
2200
6
1800
5
(Pre-set level)
1400
4
1000
3
600
2
400
1
200
"
/H
Stop power output

13
Model：EC-7128IC
Power Level Power (W)
P
(Booster function)
2600
9
2400
8
2200
7
2000
6
(Pre-set level)
1800
5
1600
4
1000
3
800
2
600
1
200
"
Stop power output
Model：EC-7238IC
Front Zone
Rear
Zone
Level
Power
(
W
)
Level
Power
(
W
)
"
Stop power output
P
(Booster function)
2
8
00
1
200
9
2400
1
200
8
2200
2
600
7
2000
3
800
6
1800
4
1000
5
(Pre-set level)
1
6
00
5
(Pre-set level)
1
2
00
4
1000
3
800
2
600
1
200
"
Stop power output

14
Model：EC-7288RC
Front zone
/
Induction cookin zone
Rear
zone
/
Infrared cookin zone
Level
Power
(
W
)
Level
Power
(
W
)
"
/H
Stop power output
P
(Booster function)
2600
1
200
9
2400
1
200
8
2200
2
600
7
2000
3
800
6
1800
4
1000
5
(Pre-set level)
1600
5
(Pre-set level)
1200
4
1000
3
800
2
600
1
200
"
Stop power output
5、Safety Precautions
5.1 Safety Notes：
 No other objects then cookware to be placed on the calefaction area.
 Do not insert any objects like iron wire etc. into the vent in order to prevent any electric
shock.
 Do not put anything to block the air outlet
#
 Do not heat up unopened tins of food on the heating zone as pressure will build up in the
tin and it can explode, which in turn could result in injury and scalding or damage.
 Do not use the electric cooker in a high temperature environment. Keep it far away
from fire.
 Always keep children away from the electric cooker.
 Keep a distance between the water supply and the electric cooker, to prevent any electric
shock and interference or malfunction on function of the electric cooker.
 Water or liquid on the control panel will affect interference or malfunction on function of
the electric cooker.

15
5.2、Warnin ：
 The electric cooker must not be installed over any metal work top or electrical appliances
such as dishwasher, oven, and fridge etc.
 Do not place metallic objects such as knives, forks, scoops or spoons on the electric
cooker, calefaction area in order to prevent any danger caused by high temperature
 The surface is under a very high temperature condition after cooking, please do not place
any combustible materials on the surface and touch the surface to avoid any risk of fire
and getting burnt
 If power wire is broken, you must shut off the power supply immediately and contact our
After Sales Service professional to change the broken wire. User does not allow repairing
by yourself, otherwise the maintenance of the electric cooker will be invalid.
 Do not smash the glass surface, switch off the electric cooker when the glass surface is
cracked.
6、Daily Maintenance
 Clean the electric cooker only when it has cooled down and high temperature indicator
is off.
 Do not put any tinder of acid or alkaline materials near the electric cooker in order to
avoid the electric circuits inside the stove from the erosive damages of acidity and alkali
which can affect the life span of the electric cooker.
 Never use a steam cleaner or aggressive or abrasive detergent to clean the electric
cooker.
 Do not swash the electric cooker directly with water.
 When cleaning the ceramic surface, wipe all coarse soiling off using a damp soft cloth
and apply a few drops of proprietary-cleaning agent for ceramic surfaces.
 Do not let the bottom of the electric cooker rubs the glass surface of the working area
so as to prevent lacerating. (The laceration of the glass surface of the working area does
not affect the normal operation of the electric cooker).
 The air inlet should be cleaned regularly in order to have a good ventilation
condition.
 Be sure to remove stains from the bottom of cookware. Otherwise, the stains will be
scorched and stuck on the top plate.

16
7、Product Specification
Description Single Zone Infrared Cooker
Model EC-7122IR
Power Supply AC220V/50Hz
Total Rated Power 2200W
Overall Dimension(W x D x H) 288x 510x 50mm
Net Wei ht 6 kgs
Description Single Zone Induction Cooker
Model EC-7128IC
Power Supply AC220V/50Hz
Total Rated Power 2600W
Overall Dimension(W x D x H) 288x 510x 55mm
Net Wei ht 6 kgs
Description 2-Zone Induction Cooker
Model EC-7238IC
Power Supply AC220V/50Hz
Total Rated Power 2800W
Overall Dimension(W x D x H) 288x 510x 55mm
Net Wei ht 7 kgs
Description 2 IN 1 Electric Cooker
Model EC-7288RC
Power Supply AC220V/50Hz
Total Rated Power 2800W
Overall Dimension(W x D x H) 288x 510x 50mm
Net Wei ht 7 kgs

17
8、Trouble-shootin Guideline
8.1、Code Of Breakdown：
In case of improper installation or use, abnormal power supply or breakdown of the electric
cooker, the LED digit on front panel will display code of breakdown, first display shows “E”,
then numeral and flicker.
In rared cooker or in rared cooking zone:-
Code of breakdown Root cause of breakdown
E5 High power voltage
E6 Low Power voltage
Induction cooker or induction cooking zone:-
Code of breakdown Root cause of breakdown
E0 Failure of Circuit
E1 Cookware not be sensed on the cooking zone
E2 High temperature inside induction heater
E3 Failure of heater temperature sensor
E4 Failure of IGBT temperature sensor
E5 High power voltage
E6 Low Power voltage

18
8.2、Trouble Shootin ：
Garwoods’s electric cooker has adopted the most advanced micro-computer inspection and
control technology. Some phenomena appeared in the course of working may not indicate
problems to occur.
Please check the electric cooker according to the follow specifications

Situation Reason Solution
Infrared cooker or infrared cookin zone:-
No power for the light
indicators
The power cord may not be
properly connected to power
outlet
Check the power cord if it has
been connected or not
Auto-power off during
working of product
1. The inlet of fan is off.
2. The fan stops working.
3. The surrounding
temperature is too high.
Pls. check if there is some
heating device nearby.
4. The temperature of the
stuff being heated rises
too high.
5. Errors of timer setting
1. Clean and remove the stuff
in the inlet of fan.
2. Ask help from a
professional service
technician.
3. Improve the ventilation.
4. Improve the ventilation.
5. Power off and re-start the
product
Induction cooker or induction cookin zone:-
The heater works for a while
and stop, indicating
$
E1
%
1. No cook ware put on the
cooking zone
2. Non-usable cookware is
used
1. Put the cookware on the
cooking zone
2. Refer to
$
Usable and
Non-usable cookware
%
in
the operation manual
The heater works for a while
and stops, indicating
$
E2
%
.
1.
The inlet of fan is off.
2.
The fan stops working.
3.
The surrounding
temperature is too high.
Pls. check if there is some
heating device nearby.
4.
The temperature of the
stuff being heated rises
too high.
5.
The outlet ventilation is
off.
1. Clean and remove the
stuff in the inlet.
2. Ask help from a
professional service
technician.
3. Improve the ventilation.
4. Remove the cause for
fry heating and continue
to use the electric
cooker after the
calefaction area is
cooling down.
5. Inspect the outlet
ventilation condition.
The heater works for a while
and stop, indicating
$
E3
%
or
$
E4
%
.
The temperature sensor
breakdown.
Ask help from a professional
service technician.

19
一、 產品性能特點----------------------------------------------------------- 20
二、 產品安裝說明--------------------------------------------------------- 21-23
三、 控制面板說明----------------------------------------------------------- 24-27
四、 產品操作說明----------------------------------------------------------- 28-32
I . 操作說明
II . 鍋具的選擇與使用
III. 火力段數及功率說明
五、使用注意事項--------------------------------------------------------- 33
I . 安全注意事
II . 警告
六、日常 養注意事項--------------------------------------------------- 34
七、產品規格--------------------------------------------------------------- 35
八、維修指南--------------------------------------------------------------- 36-37
I . 錯誤代碼
II . 簡易故障的判別和排除
目錄
