Garwoods EC-2220 Manual

0
Intelligent Two-zone Infrared Cooker
智能雙頭電陶爐
Model/型號：EC-2220/EC-2228
Installation & Operating Instructions
產品使用說明書

1
1、 Product Introduction-------------------------------------------------- 2
1.1 .Introduction of Product
1.2 .Function & Characteristics
2、 Installation Guideline-------------------------------------------------- 3-5
3、 Control Panel Instructions-------------------------------------------- 6-7
4、 peration Method----------------------------------------------------- 8-9
4.1 . peration Instructions
4.2 .Usable and Non-usable Cookware
4.3. Heating Power Distribution
5、 Safety Precautions----------------------------------------------------- 10
5.1 . Safety Notes
5.2 . Warning
6、 Daily Maintenance----------------------------------------------------- 11
7、 Product Specification-------------------------------------------------- 11
8、 Trouble-Shooting Guideline------------------------------------------ 12
8.1 . Code f Breakdown
8.2 . Trouble Shooting
CONTENTS

2
1、Product Introduction
1.1、Introduction Of Product：
Thank you for choosing Garwoods EC Infrared Cooker. This product utilizes German EG
radiant heating element. The thermal efficiency is extremely high and reach 500-600

c in
just a few seconds. It is controlled by the micro-computer touching sensor control system.
Please read this operation manual carefully before installing or using this product.
1.2 、Function & Characteristics：
 Energ -efficient

The cooker utilizes radiant heating element for a brand-new
calefaction principle. The thermal efficiency is extremely high. There is a high
temperature remains on the surface for short-time cooking without power after cooking.
It is energy-saving.
 Multi-function

The cooker utilizes newest micro-computer chip program control. It
offers multiple scales for heating power level regulation. Also, it offers timer; overheat
protection; auto-temperature adjustment; high temperature indicator etc.
 Safet & Environmental Friendl

Safety & Environmental Friendly of the product is on
our top priority. The cooker contains a serious of safety system such as safety lock;
high temperature indicator; automatic shut-off when 2 hours not in use; and
auto-temperature adjustment.
 Eas -to-clean Surface

Ceramic glass top panel is easy to clean. When the high
temperature indicator is off and the surface is cool down after cooking, wipe it with a
damp cloth.

Notice :The surface is under a ver high temperature condition after cooking,
please do not place an combustible materials on the surface and touch the surface to
avoid an risk of fire and getting burnt

 Touch Buttons Operation

Touch button design is easy for use.
 Intellectual Power

The cooker adopts intellectual power distribution technology and
the specified power can be distributed to each cooker zone by the micro-computer
system.

3
2、Installation Guideline
★ Installation should be followed below requirements：

The walls on top of the working face and next to the installation of infrared cooker must
be heat-proof.

The laminated boards and adhesive used for installation must be heat-resistant.

For any installation method, the air under the cooker and behind the cooking range
should have enough space for cooling in order to ensure the safety of operating the
infrared cooker.

Based on the prescribed dimensions, a square hole is opened on the work table. Ensure
the distance between any side of the work table and the walls is

100mm.

Protect the opening: If in contact with damp, the laminated boards used in marking the
work table will easily expand more. It is required to stick varnish or special adhesive onto
the edge of the opening in order to prevent any steam from condensation under the
work table.

For any condition of installation, the infrared cooker should have a good ventilation
condition with air inlet and air outlet not blocked.

Don’t place other equipments on the working face of the double cooking zones of the
infrared cooker and within the range of 30cm around the working face.

If choosing a table-top installation, ventilation hole shall be at least 100mm from wall
surface.

The infrared cooker must be complied with a 13A power outlet.
★ Steps on Installation：
~ pen an installation hole on the worktop of cabinet as per

illustration 1

.
(Note : The height shall be more than 100mm)
Cut out dimensions(unit/mm)

(W) 670 x (D) 350 x (H) 100

illustration 1


4
~ In front of the cabinet, open an air inlet with more than 100cm2 under the location of
infrared cooker as per

illustration II

. If the cabinet is not sealed, the air inlet may not be
opened so as to ensure heat elimination.

illustration II

~ Before put the infrared cooker into the hole, an water-proof type is properly applied on the
bottom of front panel of the infrared cooker as per

illustration III

. If the old size of the
hole is large than the current size of cutting hole, a double side type can be used to fix the
movement between infrared cooker and worktop.

illustration III


5
~ Put infrared cooker into hole. Insert plug of power line into corresponding socket. The
infrared cooker can be used after power connection as per

illustration IV

.

illustration IV

~ If the infrared cooker is installed above an oven, fix an insulation part at least 15cm under
the infrared cooker as per

illustration V

. Also, open an air inlet with more than 100cm2
under the location of the infrared cooker to ensure ventilation and operation in good
conditions
 
 !"#$

6
3、Control Panel Instruction
Model: EC-2220

Cooking Zone


Control Panel

9 8 7 6 5 4 3 2 1
1… n/ ff Switch 2…Plus Key
3…LED Digital Indicator (Heating & Timer) 4…Minus Key
5…Timer Key 6…Timer Indicator
7…Lock Key 8…Lock Indicator
9…High Temperature Indicator

7
Model : EC-2228

Cooking Zone


Control Panel

9 8 7 6 5 4 3 2 1
1… n/ ff Switch 2…Plus Key
3…LED Digital Indicator (Heating & Timer) 4…Minus Key
5…Timer Key 6…Timer Indicator
7…Lock Key 8…Lock Indicator
9…High Temperature Indicator

8
4、Operation Method
4.1、Operation Instructions：
 Power Connection

After power connection, buzzer will make a short sound. LED Digital
Indicator will show
%
----
&
and the induction cooker keeps at the stand-by mode.
 On switching

Place cookware on heating zone (Pls. refer to Usable and Non-usable
Cookware), by pressing the “ N/ FF” key, LED will show the pre-set power 1400W.
 Power Level Alteration

At the power function, by pressing “
'
” r “
(
” key to increase
or decrease power level. LED digit shows set power level.
(Note : This infrared cooker adopts intellectual power distribution technology. When the
power level of a cooker zone is increased and total power level exceeds specified value, the
micro-computer system will automatically decrease power level of another cooker zone so
as to assure total power is under specified value.)
 Selecting Timer

By pressing
)
Timer
*
key, the time indicator will be on. At the time, by
pressing
)'*
r
)(*
key to set the required time. The operational setting range is
between 1 min. and 3 hrs 59 min. (Display form in
+
hrs : mins
,
). After setting, the LED
will change to power level. When set time is reached, buzzer will make a long sound and
the induction cooker stops heating, the time indicator will be off and LED shows “END”.
During time setting, by pressing
)
Timer
*
key again to check the residual time. To cancel
time setting, set the timing to “ZER ”.
 Lock Function

By pressing the
)
Lock
*
key, buzzer will make a short sound and a red dot
will be on. At this time, all keys will be locked in order to avoid mis-operation. By
pressing
)
Lock
*
key again, buzzer will make a short sound and a red dot will be off.
The infrared cooker will be locked automatically after 15 seconds when switching off.
For restarting the infrared cooker, by pressing the
)
Lock
*
key again, buzzer will make
a short sound and the red dot will be off, then by pressing the
)
N/ FF
*
key to enter
the normal cooking mode by other function keys.
 High Temperature Indicator

After cooking, the
)
High temperature indicator
*
will be
on, that means the temperature on the heating zone is over 60

c. At this time, the
heating zone is under a very high temperature condition, please do not attempt to
place any combustible materials on the heating zone and touch the heating zone to
avoid any risk of fire and getting burnt.
-
 Off Switching

During heating, by pressing
)
N/ FF
*
key to switch off.

9
4.2、Usable and Non-usable Cookware：
1. Most of materials for a flat bottom cookware are suitable for use of the infrared cooker,
such as stainless steel pot, iron pot, aluminum pot, ceramic pot and glass pot etc. The
diameter of the flat bottom cookware is within 12-24 cm. For a good effect, it is
recommended for a around 22 cm in diameter and depends on the thickness of the
cookware at the flat bottom.
2. It is normal that feeling hot from the heating zone if the flat bottom cookware does not
cover the circle on the heating zone because it will release far infrared rays when
cooking.
3. The cookware is placed in the center of the circle at the heating zone.
4.3、Heating Power Distribution：
When two single zones are operating in the same time, the total power is up to 2800W.
However, the power of one single zone will reduce automatically when the other zone is
being cooking so as to maintain the total power level will not exceed 2800W.
Heating Power (W)
Left zone Right Zone
2200 600
1800 1000
1600 1200
1400 1400
1200 1600
1000 1800
600 2200
300 300

10
5、Safet Precautions
5.1 Safet Notes：
 The infrared cooker should be immediately plugged out or switch of the socket should
be turned off as soon as cooking is finished.
 No other objects then cookware to be placed on the calefaction area.
 Do not insert any objects like iron wire etc. into the vent in order to prevent any electric
shock.
 Do not put anything to block the air outlet
.
 Do not heat up unopened tins of food on the heating zone as pressure will build up in
the tin and it can explode, which in turn could result in injury and scalding or damage.
 Do not use the infrared cooker in a high temperature environment. Keep it far away
from fire.
 Always keep children away from the infrared cooker.
5.2、Warning：
 The infrared cooker must not be installed over any metal work top or electrical
appliances such as dishwasher, oven, and fridge etc.
 Do not place metallic objects such as knives, forks, scoops or spoons on the infrared
cooker, calefaction area in order to prevent any danger caused by high temperature
 The plate of the infrared cooker is hot after cooking; do not touch the heating area by
hand until the high temperature indictor is off or the glass surface has cooled down.
 If power wire is broken, you must shut off the power supply immediately and contact
our After Sales Service professional to change the broken wire. User does not allow
repairing by yourself, otherwise the maintenance of the infrared cooker will be invalid.
 Do not smash the glass surface, switch off the infrared cooker when the glass surface is
cracked.

11
6、Dail Maintenance
 Clean the infrared cooker only when it has cooled down.
 Do not put any tinder of acid or alkaline materials near the infrared cooker in order to
avoid the electric circuits inside the stove from the erosive damages of acidity and
alkali which can affect the life span of the infrared cooker.
 Never use a steam cleaner or aggressive or abrasive detergent to clean the infrared
cooker.
 Do not swash the infrared cooker directly with water.
 When cleaning the ceramic surface, wipe all coarse soiling off using a damp soft cloth
and apply a few drops of proprietary-cleaning agent for ceramic surfaces.
 Do not let the bottom of the infrared cooker rubs the glass surface of the working area
so as to prevent lacerating. (The laceration of the glass surface of the working area
does not affect the normal operation of the infrared cooker).
 The air inlet should be cleaned regularly in order to have a good ventilation
condition.
7、Product Specification
Description Intelligent Two-zone Infrared cooker
Model EC-2220/EC-2228
Power Suppl AC220-240V/50Hz
Total Rated Power 2800W
Overall Dimension(W x D x H) 750 x 450 x 65 mm (EC-2220)
710 x 410 x 65 mm (EC-2228)
Net Weight 10 Kg

12
8、Trouble-shooting Guideline
8.1、Code Of Breakdown：
In case of improper installation or use, abnormal power supply or breakdown of the infrared
cooker, the LED digit on front panel will display code of breakdown.
Code of breakdown Root cause of breakdown
E5 High power voltage
E6 Low Power voltage
8.2、Trouble Shooting：
Garwoods’s infrared cooker has adopted the most advanced micro-computer inspection and
control technology. Some phenomena appeared in the course of working may not indicate
problems to occur.
Please check the infrared cooker according to the follow specifications

Situation Reason Solution
No power for the light
indicators
The power cord may not be
properly connected to power
outlet
Check the power cord if it has
been connected or not
Auto-power off during
working of product
1. The inlet of fan is off.
2. The fan stops working.
3. The surrounding
temperature is too high.
Pls. check if there is some
heating device nearby.
4. The temperature of the
stuff being heated rises
too high.
5. Errors of timer setting
1. Clean and remove the stuff
in the inlet of fan.
2. Ask help from a
professional service
technician.
3. Improve the ventilation.
4. Improve the ventilation.
5. Power off and re-start the
product

13
一、 產品簡介---------------------------------------------------------------- 14
I . 產品介紹
II . 性能特點
二、 產品安裝說明--------------------------------------------------------- 15-17
三、 控制面板說明----------------------------------------------------------- 18-19
四、 產品操作說明----------------------------------------------------------- 20-21
I . 操作說明
II . 鍋具的選擇與使用
III. 火力功率及功率 配說明
五、使用注意事項--------------------------------------------------------- 22
I . 安全注意事項
II . 警告
六、日常 養注意事項--------------------------------------------------- 23
七、產品規格--------------------------------------------------------------- 23
八、維修指南--------------------------------------------------------------- 24
I . 錯誤代碼
II . 簡易故障的判別和排除
目錄

14
一、產品簡介
I、產品介紹
多謝選購Garwoods EC智能雙頭電陶爐。本產品採用先進德國EGO核心發熱爐盤，
內置S型發熱絲而釋放紅外綫作加熱方式，數秒內可產生高温達500-600°C的熱量，
微電腦控制，輕觸式操作，安全耐用。適合各種不同的烹飪需求，是現代家庭廚
房的理想之選。請在安裝及使用本產品之前閱讀本說明書。
II、性能特點
/
 節能效益： 本產品採用全新紅外綫加熱原理，高熱效率，節能環保。在
使用烹調食物過程中，更可因應情况下截斷電源利用爐面產
生餘下的高温而作短暫烹煮，以達到節省燃料之效果
 齊全功能： 採用最新微電腦晶片程式操作，具有多段火力功率調節，定
時操控，自動調温，餘温警告指示燈等功能，方便實用。
 環保安全： 本產品在設計上充 考慮使用者的安全及環境保護。爐設有
安全功能，如安全鎖、餘温警告指示燈、2小時靜止操作及自
動調温功能等。
 容易清潔： 高級耐熱微晶玻璃面板、易潔耐用。烹調後，待餘温警告指
示燈熄滅及玻璃面板冷卻，才可進行清潔。
0123456789:;<=>?@ABCD;EFGHIJKLM
NOPQ<=;RSTUVWXYZ[\
 輕觸式操作： 輕觸式設計，只需要用手指輕輕觸摸玻璃控制面板上功能鍵
即可，簡便易用。
 智能功 ： 本產品採用智能功率 配技術。由微電腦根據用戶使用狀
况，將規定的總功率 配到每個爐頭。

15
二、產品安裝說明
★安裝須遵守以下說明要求：
1、 工作枱面及靠近電陶爐的牆壁必須是耐熱的。
2、 用於安裝電陶爐與廚櫃的層板和膠黏劑必須是耐熱的。
3、 在任何安裝方式中，應確保爐具底下及爐面後側能徹底散熱，以確保安
全。
4、 按規定尺寸在枱面上開一個安裝孔，同時確保任何一面距牆面距離至少
100mm。
5、 安裝孔防水保護：若與濕氣 觸，製作廚櫃所用的層板相對容易膨脹，在
開口邊緣塗上透明漆或專用膠黏劑，可防止水氣滲入造成篜氣在廚櫃枱面
下產生冷凝。
6、 在各種安裝條件下，電陶爐都需要良好的通風，要確保進氣口和出氣口不
會被堵塞。
7、 電陶爐爐面四周及爐面垂直上方30cm的範圍內不要設置其它設備。
8、 如選擇座檯式安裝時，亦須確保排風口距離牆壁至少100mm。
9、 使用此型號電陶爐時必須配備13安培獨立開關掣或固定線座。
★安裝步驟
1. 在需安裝電陶爐的廚櫃枱上按照【安裝圖 一】尺寸開一安裝孔
（注意：高度距離枱面需超過100mm）。
開孔尺吋(單位/mm)：(闊) 670 x (深) 350 x (高) 100
【安裝圖 一】

16
2. 在櫥櫃前側電陶爐放位置的下方開出一個大於100c㎡的進風口如【安裝圖
二】, 以確保電陶爐有足夠的散熱，如果櫥櫃不是密封式的，可以不開此口，
但電陶爐下方不可有任何雜物堵窒通風。
【安裝圖 二】
3. 安裝電陶爐在櫥櫃枱面前，必須將隨爐具所附的防水膠條如【安裝圖 三】，
貼在面板下方的四邊。如原枱面開孔大於本電陶爐開孔尺吋，應使用雙面貼
貼在底盤四邊，以固定爐具與枱面而避免產生移動。
【安裝圖 三】

17
4. 將貼好防水膠條的電陶爐放入枱面開孔中如【安裝圖 四】，然後將電源線
插頭插入對應的插座中，通電即可正常使用。
【安裝圖 四】
5. 如安裝電陶爐在烤箱上方時，櫥櫃內電陶爐與烤箱中必須加裝一個隔熱板如
【安裝圖 五】隔熱板與電陶爐底部至少有15cm的距離：電陶爐安裝位置的
前側必須開出一個大於100c㎡的進風口以確保電陶爐陶與烤箱能夠有足夠
的通風。
【安裝圖 五】
六、鍋具的選擇與使用

18
三、控制面板說明
型號: EC-2220

加熱區


功能鍵

9 8 7 6 5 4 3 2 1
]
開關鍵
]
調高鍵
]
LED數碼顯示區(火力功率及定時)
]
調低鍵
]
定時鍵
]
定時指示燈
]
安全鎖鍵
]
安全鎖指示燈
9
]
餘温警告指示燈

19
型號: EC-2228

加熱區


功能鍵

9 8 7 6 5 4 3 2 1
]
開關鍵
]
調高鍵
]
LED數碼顯示區(火力功率及定時)
]
調低鍵
]
定時鍵
]
定時指示燈
]
安全鎖鍵
]
安全鎖指示燈
9
]
餘温警告指示燈
