PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021 Page i
Table of Contents
Table of Contents
1 – Introduction 1-1
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
How to Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Parts Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Remanufactured Board Express . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Abbreviations and Acronyms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
2 – Commercial Parts 2-1
Base and Motor Shaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Pump Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Reset/Register Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Pulser Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Meter Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
9823 Totalizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
9123K and 9823K Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Remote Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Remote Register Chassis Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Index Index-1

Page ii PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021
Table of Contents
This page is intentionally left blank.

PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021 Page 1-1
Purpose Introduction
1 – Introduction
Purpose
This manual provides information to help stock spare parts. Review this information, and
stock the recommended parts and quantities for the corresponding Gasboy® Atlas® equipment
in your service area.
How to Use This Manual
This manual provides spare parts information in a tabular form. The tables have parts that are
recommended for Authorized Service Contractors (ASCs) and distributors.
Parts Tables
The tables in this manual are set up as follows:
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Assembly, Meter Check Valve N23619-G4 All Medium 1 2 5
Definitions for each column are provided below:
Part Description
The part description column provides a detailed name for each recommended part. Other
information such as colors, dimensions, or other details are also provided, wherever
applicable.
Part Number
The part number column indicates the current Gasboy part number for each item.
Where Used
The where used column helps to identify specific units or areas where a part is used and avoid
ordering of parts already in stock.
The where used key at the bottom of the table provides definitions for the where used column.

Remanufactured Board Express Introduction
Page 1-2 PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021
Critical
The critical column indicates how important a part is to the operation of a unit. Definitions are
as follows:
Importance Description
High Loss of this part will shut down a system.
Medium Loss of this part will cause the loss of console, and some pump or dispenser control or service.
Low Routine service part significantly affecting the usage of the unit.
ASC and Distributor
The ASC and Distributor columns indicate how many units of each part must be stocked for
both ASCs and distributors. The 100 and 500 columns indicate recommended quantities for
ASCs and distributors with either 100 or 500 of a particular unit in their service area.
Quantities shown in this manual are for reference only. The actual quantities that must be
stocked by an ASC or distributor are dictated by the business conditions for the area (such as
the age of equipment, number of technicians, and distance between the ASCs and distributor).
Remanufactured Board Express
We encourage you to use genuine Gasboy boards repaired through Gasboy’s remanufactured
board express service for replacements during warranty. This is approved within Gasboy’s
warranty policy.
Abbreviations and Acronyms
Term Description
ASC Authorized Service Contractors
IC Integrated Circuit
I/F Interface
LCD Liquid Crystal Display
OIML International Organization of Legal
Metrology
PCA Printed Circuit Assembly
PCB Printed Circuit Board
TB Terminal Block
Warranty
For information on warranty, refer to MDE-4255 Gasboy Warranty Policy Statement. If you
have any warranty-related questions, contact Gasboy’s Warranty Department at its Greensboro
location.

PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021 Page 2-1
Base and Motor Shaft Commercial Parts
2 – Commercial Parts
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Motor 3/4HP 220/380V (3 Phase, 50/60
Hz) 220V Relay
M01068B303 All High 1 3 5
Belt Adjustable (45” Length) M07022B003 All High 1 3 5
Electric Motor (1 Phase, 50 Hz) R14213-33 All 50 Hz Applications High 1 3 5
Electric Motor (1 Phase, 60 Hz) M13377B102 All 60 Hz Applications High 1 3 5
Base and Motor Shaft
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
O-ring 2.237 X 0.103 Q10067-31 All Medium 5 5 10
Bypass Valve M04920K100 All High 5 5 10
Strainer M04920K101 All Low 10 10 20
Master Seal M04920K102 All Medium 3 3 6
Blades M04920K116 All Low 10 10 20
Control Valve M04920K104 All High 5 5 10
Shaft Seal M04920K105 All Medium 5 5 10
Pumping Element Field Rebuild M04920K117 All High 2 5 10
Sump Float - International
Organization of Legal Metrology
(OIML) (B005)
M04920K107 All Medium 3 3 6
Pumping Element Shop Rebuild M04920K118 All Medium 3 3 6
Inlet Check Valve M04920K109 All Medium 2510
Overflow Check Valve M04920K110 All High 2 5 10
Sump Float - Non-OIML (B001) M04920K107 All Medium 2 4 8
Pump Assembly

Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Drive Register Assembly 9120 Gallon G022834 Mechanical Medium 125
Drive Register Assembly 9120 Liter G022835 Mechanical Medium 125
9120K Reset Assembly Elec Unli 115/60 Hz M09919A101 Mechanical High 125
9120K Reset Assembly Elec Unli 230/50 Hz M09919A201 Mechanical High 125
9120K Reset Assembly Elec Unli 230/60 Hz M09919A203 Mechanical High 125
Reset/Register Module Commercial Parts
Page 2-2 PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021
Reset/Register Module
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Contactor 10 to 1 G021788 Mechanical Medium 1 3 6
Pulse Transmitter
(100:1)
G047648 Mechanical Medium 1 3 6
Pulser Module
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
Note: This part is sold in bags of 50. No longer sold as individual pieces.
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Assembly, CFT and VFT Meters T20150-G9 (Gal.)
T20150-G10 (liters)
All High 2 3 5
2-stage Sol Valve and Filter Manifold M04607B002 (220V)
M04607B001 (115V)
All High 1 3 5
Strainer Insert High Capacity (see note) R19457 All Low 3 5 10
Assembly, Meter Check Valve M13257A001 All Medium 1 2 5
Assembly, Drive Gear US Gallon, Brass M07296A001 All High 2 5 10
Meter Assembly

Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Kit-Totalizer 9820 Liter Factory G025936 9823K Liter Low 2 4 6
Kit-Totalizer 9820 Gallon Factory G025934 9823K Gallon Low 2 4 6
PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021 Page 2-3
9823 Totalizer Commercial Parts
9823 Totalizer
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Window, Bezel 9120Q G028811 Mechanical Low 1 3 5
Window, Totalizer 9-digit (with Vapor) G069076 Mechanical Low 1 3 5
9123K and 9823K Windows
Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Panel, Top Cover, 9820 Register G040996 Electronic Low 0 1 2
Standoff, 5/16-18 M/F 7/8 LG HEX C09585 Electronic Low 1 3 5
Sleeve, Handle Stop C09584 Electronic Low 0 1 2
Lever, Control, 9820 Machining G003771 Electronic Medium 1 3 5
Panel Weld Assembly, Sides/Back 9820 G040999 Electronic Low 0 1 2
Hood G029416 Electronic Low 1 2 3
Hood, Support Assembly G063507 Electronic Low 1 2 3
Bearing Plate Assembly G045988 Electronic Medium 1 2 3
Bracket Nozzle MNTG Cover-9820 G015760 Electronic Low 1 2 3
Bracket Hook Support-9820 G015694 Electronic Medium 1 2 3
Roll Pin, 1/8 X 1-3/8 G042657 Electronic Medium 1 2 3
Remote Register

Where Used key:
All = all unit models
Mechanical = all models with a mechanical computer or non-computer
Electronic = all units with an electronic readout
I/F Option Only = optional Pulser Interface Board
Pumps = all units with pumping units
Notes:

1. Units made before April 2011.
2. Units made after April 2011.
ASC Distributor
Part Description Part Number Where Used Critical 100 100 500
Weld Assembly, Chassis C35584 Electronic Low 0 1 2
Cable Assembly, DC Power C06679 Electronic Medium 1 3 5
Printed Circuit Board
(PCB) Assembly, Power Supply without Battery, 115 V
M15579K001 Electronic High 1 3 5
Bracket Assembly, RH Hinge C35538 Electronic Medium 0 1 2
Relay Assembly C06681 Electronic High 1 3 5
Cable Assembly, 5-positions Terminal Block (TB) C06674 Electronic Low 0 1 2
Cable Assembly, 10-positions TB C06675 Electronic Low 0 1 2
Fuse Holder, Quick Connection C09546 Electronic Low 1 3 5
PCB Assembly, CPU M06333K9800AQ Electronic High 2 3 5
Reflector, Liquid Crystal Display (LCD) Backlight C35399 Electronic Low 1 3 5
Assembly, Main Display M12158A004 Electronic Medium 1 3 5
Bracket Assembly Display Door C35543 Electronic Low 1 3 5
Cable Assembly Totalizer with Bracket C06673 Electronic Low 1 3 5
Actuator, Totalizer Q12514-02 Electronic Low 1 3 5
Integrated Circuit (IC) RAM 2K X 8 C01383 Electronic High 2 3 5
PCB Assembly, Sale Backlight, Green (old, see note 1) C06372 Electronic Medium 1 3 5
Cable Assembly Backlight Power C06668 Electronic Medium 1 3 5
Cable Assembly, Ground Strap C06454 Electronic Medium 1 3 5
Bracket Assembly, LH Hinge C35539 Electronic Medium 1 3 5
RS-485 Interface (I/F) Board M06725A001 I/F Option Only High 2 5 7
Pump I/F Pulse Out Board M06587A001 I/F Option Only High 2 5 7
Printed Circuit Assembly (PCA), Display Backlight,
White (new, see note 2)
M12019A001 Electronic Medium 23 5
Remote Register Chassis Assembly Commercial Parts
Page 2-4 PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021
Remote Register Chassis Assembly

Index
PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021 Index-1
Numerics
9123K 2-3
9123K and 9823K Windows 2-3
9823 Totalizer 2-3
B
Base and Motor Shaft 2-1
C
C01383 2-4
C06372 2-4
C06454 2-4
C06668 2-4
C06673 2-4
C06674 2-4
C06675 2-4
C06679 2-4
C06681 2-4
C09546 2-4
C09584 2-3
C09585 2-3
C35399 2-4
C35538 2-4
C35539 2-4
C35543 2-4
C35584 2-4
G
G003771 2-3
G015694 2-3
G015760 2-3
G021788 2-2
G022834 2-2
G022835 2-2
G025934 2-3
G025936 2-3
G028811 2-3
G029416 2-3
G040996 2-3
G040999 2-3
G042657 2-3
G045988 2-3
G063507 2-3
G069076 2-3
M
M01068B303 2-1
M04607B001 2-2
M04607B002 2-2
M04920K100 2-1
M04920K101 2-1
M04920K102 2-1
M04920K104 2-1
M04920K105 2-1
M04920K107 2-1
M04920K109 2-1
M04920K110 2-1
M04920K116 2-1
M04920K117 2-1
M04920K118 2-1
M06333K9800AQ 2-4
M06587A001 2-4
M06725A001 2-4
M07022B003 2-1
M07296A001 2-2
M09919A101 2-2
M09919A201 2-2
M09919A203 2-2
M12019A001 2-4
M12158A004 2-4
M13257A001 2-2
M13377B102 2-1
M15579K001 2-4
Meter Assembly 2-2
P
Pulser Module 2-2
Pump Assembly 2-1
Q
Q10067-31 2-1
Q12514-02 2-4
R
R14213-33 2-1
R19457 2-2
Remote Register 2-3
Remote Register Chassis Assembly 2-4
Reset/Register Module 2-2
T
T20150-G10 2-2
T20150-G9 2-2
Index

© 2021 GASBOY
7300 West Friendly Avenue · Post Office Box 22087
Greensboro, North Carolina 27420
Phone [phone] · http://www.gasboy.com · Printed in the U.S.A.
PT-1959B Atlas®9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021
