Samoa DF30 User manual

1
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
DF50
DF30
DF100
DF30 DF50 DF100
Ratio 1:1 1:1 1:1
Maximum free flow 10 gal/min (38 l/min) 13.21 gal/min (50 l/min) 26.5 gal/min (100 l/min)
Delivery per stroke 2.37 oz (0,07 l) 3.38 oz (0,1 l) 32 oz (0,25 l)
Air pressure operating range 22 to 115 psi (1,5 to 8 bar) 22 to 115 psi (1,5 to 8 bar) 22 to 115 psi (1,5 to 8 bar)
Solid in suspension max size 0.12 in (3 mm) 0.12 in (3 mm) 0.16 in (4 mm)
Maximum suction head 13.2 ft (4 m) dry
26.25 ft (8 m) wet
19.69 ft (6 m) dry
26.25 ft (8 m) wet
14.76 ft (4,5 m) dry
22.97 ft (7 m) wet
Weight 4.19 lb (1,9 kg) 7.72 lb (3,5 kg) metallic series with aluminium body
4.85 lb (2,2 kg) non metallic series
15.87 lb (7,2 kg) metallic series with
Aluminium body
24.69 lb (11,2 kg) metallic series with
Stainless steel body
11.24 lb (5,1 kg) non metallic series
Fluid inlet (single inlet) 1/2" BSP - NPT (F) 1/2" NPSM (F) and flange with metallic body
(BSP- NPT (F) and flange with plastic body) 1" BSP/NPT (F) and flange
Fluid inlet (double inlet) 2 x 3/8" BSP - NPT (F) 2 x 3/8" NPSM (F) with metallic body
(BSP - NPT (F) with plastic body) _
Fluid outlet 1/2" BSP - NPT (F) 1/2" NPSM (F) and flange with metallic body
(BSP - NPT (F) plastic body) 1" BSP/NPT (F) and flange
Air inlet 3/8" NPSM (F) 3/8" NPSM (F) 3/8" NPSM (F)
Wetted part materials View model specifications See model specifications See model specifications
Noise level 80 db 80 dB 80 dB
Temperature range
(see material temperature range
on page 2).
32 - 158 ºF (0 - 70 ºC) 32 - 158 ºF (0 - 70 ºC) 32 - 158 ºF (0 - 70º C)
1/2" DOUBLE DIAPHRAGM PUMP DF30 (38 l/min)
1/2" DOUBLE DIAPHRAGM PUMP DF50 (50 l/min)
1" DOUBLE DIAPHRAGM PUMP DF100 (100 l/min)
Operation and maintenance manual Codes:
DF30_-XXX-XX-XX-XX-X / 5530XX
DF50_-XXX-XX-XX-XX-X / 5520XX
DF100_-XXX-XX-XX-XX-X / 5510XX
Technical data 1
Warnings and cautions 2
Description 2
Capacity curves 3
Dimensions 4
Installation 5
Operating instructions 6
Composite body parts 7
Nomenclature of the pump 14
Alphanumeric pumps
repair kit codes 15
Troubleshooting 17
Maintenance guide 19
Declaration of conformity 96
Technical data
* (oz, ft, gal/min) all in EEUU units

2855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Warnings and cautions
In this document you will find warnings and cautions for installation, use
and maintenance of the Direcflo pumps.
This symbol aware that there is a danger of serious bodily injury or death
if you ignore the warning described.
This symbol aware that there is a danger of personal injury or property
damage if you ignore the caution described.
• This equipment is for professional use only.
• Do not degrade the integrity of the equipment. Use only original
replacement components from Samoa Industrial, S.A.
• Fluids not suitable for the pump can cause damage to the pump unit
and involve risk of serious personal injury.
• Always consult Samoa Industrial, S.A. if you have any questions about
the compatibility within the fluids and the pump materials, including
elastomers.
• Install and use the pump according to all local and national regulations
and abide all health and safety laws or legislation.
• The pump can produce fluid pressures equal to the air supply pressure.
Do not exceed the maximum allowable pressure of 115 psi (8 bar) air
supply. The total hydraulic pressure (differential pressure + system)
should never exceed 115 psi (8 bar).
• Never use a pump that leaks, that is damaged, that is corroded or
otherwise it may lack the capacity to contain the fluid.
• Frequently check that the bolts on the diaphragm cover of the pump
are torqued correctly.
Warning Caution
• Do not use a model with aluminium wetted surfaces to pump fluids for
human consumption, there is a possibility of trace contamination of lead.
• Danger of explosion if used 1,1,1-trichloroethane, methylene chloride
or other halogenated hydrocarbon solvents with aluminium wetted
materials. It could cause serious injury and property damage.
• Inside the pump, diaphragms separate the fluid that is being pumped
from the air supply. If a diaphragm breaks, the fluid can leak out of the
air exhaust and contaminate the environment.
• When handling hazardous fluids, always route the air exhaust into a
suitable container and locate it in a safe place.
• When the fluid source level is situated higher than the pump, (flooded
suction), the outlet tank must be at a higher level than the product to
prevent spills.
• For pumps handling hazardous fluids that are a danger to humans or
to the environment, install a suitable container surrounding the pump
to prevent any leaks or spills.
• Ensure that the operators of this equipment are trained on the
operation and limitations. Use safety equipment as safety goggles or
other equipment required.
Carefully read the instructions and warnings before operating the equipment!
Warning
Here’s the meaning of symbols you may find in this document and
general warnings that you should keep in mind.
Description
Air operated double diaphragm pumps are air-powered, reciprocating
positive displacement pumps with two pumping chambers. Two
diaphragms, centrally located in the chambers, separate the compressed
air (dry side) from the fluid being pumped (wet side). A shaft transmits
the reciprocating motion of one diaphragm to the other. A directional
valve alternatively distributes the air from one chamber to the other; thus
a reciprocating movement of the diaphragms is created. With each
stroke, fluid is discharged by one of the diaphragms whilst the opposite
diaphragm sucks new fluid into the expanding chamber. Check valves,
two on the discharge side and two on the suction side, control and direct
the fluid flow.
Material Temperature range
PTFE 5 ºC - 105 ºC / 41 ºF - 221 ºF
NBR 10 ºC - 80 ºC / 50 ºF - 176 ºF
Acetal 10 ºC - 90 ºC / 50 ºF - 194 ºF
Hytrel®10 ºC - 90 ºC / 50 ºF - 194 ºF
Neopreno -18 ºC - 93 ºC / 0 ºF - 200 ºF
Santoprene®-29 ºC - 135 ºC / -20 ºF - 275 ºF
Viton®-10 ºC - 120 ºC / -4 ºF - 248 ºF
Polypropylene®10 ºC - 80 ºC / 50 ºF - 176 ºF

3
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Capacity curves
DF30
DF50
DF100
(*) 2 bar test with a PTFE (Teon®) diaphragms pump.
Air consumption
Nl/min SCFM
200 7.06
250 8.83
300 10.59
150 5.30
100 3.53
50 1.77
0 0
l/min
0 2.64 5.28 7.93 10.57
0 10 20 30 40
US gal/min
Fluid pressure
bar psi
1 14.5
2 29
3 43.5
4 58
5 72.5
6 87
7
8
100
126
0 0
8 bar - 120 psi
6 bar - 90 psi
4 bar - 60 psi
6 bar - 90 psi
8 bar - 120 psi
4 bar - 60 psi
2 bar - 30 psi (*)
2 bar - 30 psi (*)
Air consumption
Nl/min SCFM
200
250
350
300
400
150
100
50
0
Fluid pressure
bar psi
114.5
2 29
3 43.5
4 58
5 72.5
6 87
7
8
100
126
0 0
0 2.64 5.28 7.93 10.57 13.21 15.85
0 10 20 30 40 50 60
US gal/min
l/min
7.06
12.36
8.83
14.12
5.30
10.59
3.53
1.77
0
8 bar - 120 psi
6 bar - 90 psi
4 bar - 60 psi
2 bar - 30 psi (*)
6 bar - 90 psi
8 bar - 120 psi
4 bar - 60 psi
2 bar - 30 psi (*)
0 6.60 13.21 19.81 26.41
0 25 50 75 100
US gal/min
l/min
Fluid pressure
bar psi
1
2
3
4
5
6
8
7
0
14.5
29
43.5
58
72.5
87
126
100
0
Air consumption
Nl/min SCFM
200
250
300
350
400
450
500
150
100
50
0
7.06
12.36
15.89
8.83
14.12
17.65
5.30
10.59
3.53
1.77
0
8 bar - 120 psi
6 bar - 90 psi
4 bar - 60 psi
2 bar - 30 psi (*)
2 bar - 30 psi (*)
6 bar - 90 psi
8 bar - 120 psi
4 bar - 60 psi
Outlet pressure
Air consumption

4855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Dimensions
Only DF30T
Only DF50T
DF30 / DF30T
A B C D E F G H I J K L M N P
5.12" 6.3" 6.38" 4.13" 4.8" 0.31" 5.51" 5.31" 2.76" 1/2"
BSP
NPT
5.71" 3/8"
BSP
NPT
0.94"
M6
1,61"
130 mm 160 mm 162 mm 105 mm 122 mm 8 mm 140 mm 135 mm 70 mm 145 mm 24 mm 41 mm
DF50 / DF50T
A B C D E F G H
6.14" 6.3" 6.57" 4.13" 4.8" 0.31" 5.75" 5.51"
156 mm 160 mm 167 mm 105 mm 122 mm 8 mm 146 mm 140 mm
H I J K L M N P
5.51" 2.76" 1/2" BPS NPT
NPSM
5.91" 3/8" NPSM 0.94" M6 1.61"
140 mm 70 mm 150 mm 24 mm 41 mm
DF100
A B C D E F G H I J K L
8.5" 7.44" 8.94" 6.89" 6.06" 0.35" 7.24" 8.27" 3.72" 1"BSP
NPT
8.27" 3/8" NPSM
216 mm 189 mm 227 mm 175 mm 154 mm 9 mm 184 mm 210 mm 94,51 mm 210 mm

5
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Installation
Installation recommendations
• Remove the pump from its package and install it on the chosen location.
• Try to minimize the suction head. Install the pump as close as possible
to the fluid being pumped.
• Remember to have enough space around the pump to perform
maintenance tasks.
• Keep in mind to connect the inlet and outlet of the pump correctly.
• In case of diaphragm pump failure, the air exhaust will expell the
product being pumped.
• When the pump is installed in a place where a spill of fluid can cause
an environmental impact, the exhaust should be directed to a place.
where this spill could be contained.
• When installing the pump in its place, use brackets to secure its base.
• Fasten all bolts with the torques contained in this manual.
DF pumps are very easily configured and easy to install.
Flooded:
The pumping system was designed with positive pressure at the inlet.
This is the best possible installation when you need to evacuate the liquid
from the drum or tank, or when working with viscous fluids.
Not recommended for hazardous fluids.
Self-priming:
Pump is designed to generate vacuum. It is possible to evacuate all the
air from a hose or pipe without damaging the pump. Maximum suction
height is 19.69 ft (6 m), with the suction hose empty and up to 26.25 ft
(8 m) with the hose primed. (See page 1 for corresponds suction lift).
Submerged:
All pumps can be immersed in fluids. It is important to verify that all
components that are in contact with the fluid are chemically compatible.
In this case, air exhaust and fluid must be carried by hoses (optional air
connection).
Recommended installation
The figure below shows the recommended
configuration for the installation of a
diaphragm pump.
Read the warnings and recommendations of
the previous page before starting.
NOTE: Use a pressure regulator with built-in
filter inlet.
NOTE: The compressed air supply must be
between 43.5 psi (3 bar) and 115 psi (8 bar).
Air exhaust disposal
• Optional kit is required for remote exhaust.
• Remove the muffler.
• Connect a hose to the exhaust port of the pump and install the muffler
at the end of the hose. Use a hose with the same diameter as the
exhaust port. (If the hose is more than 5 feet (1.5 m), consult your
dealer or Samoa Industrial, S.A.).
• Have a moat, a protective housing, etc. at the end of the hose.
The pump exhaust should be directed to a safe place, away from people,
animals and food.
Warning

6855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Operating instructions
This pump is self-priming.
To prime it the first time, you must connect the air pump supply to a low
pressure using the pressure regulators while keeping the outlet valve open.
When fluid begins to flow from the pump outlet, the pump is primed. For
Installation
Warning
Air connection
To ensure that the air supply is sufficient to meet the demand of the
pump, the diameter of the pipe must be equal to the diameter of the
supply port of the pump. Choose auxiliary air treatment equipment and
fittings with sufficient airflow to exceed the air consumption of the pump.
In addition, peripheral air treatment equipment must be installed as close
as possible to the pump unit.
The use of a coupler to connect the hoses aids future operation and
maintenance tasks.
regulation of fluid pressure, the unit must be supplied with an air
pressure between 43.5 and 115 psi (3 and 8 bar). Adjust the discharge
valve on the discharge side to control flow. For the performance
characteristics of the pump see the capacity curve shown on page 3.
Stopping the pump
• Close the inlet valve of the pump and stop the air supply.
• Make sure for your safety that the air valve is closed.
• Turn off the air compressor, or close the valve on the air supply side of
the auxiliary equipment.
• Close the discharge valve on the discharge side, then begin to slowly
open the drain valve and discharge pressure fluid.
• Open the air valve of the pump, turn on the pump and flush the
remaining fluid.
• After ensuring that the pump was turned off and the pressure was released,
fully open and close the regulator valve and drain valve of the pump.
Grounding the pump
• When installing the pump, be sure to perform grounding in the
specified location.
• Also connect ground wires for the auxiliary equipment and piping.
• Use a grounding cable of at least 12 gauge (2.0 mm2).
STICKER THAT SHOWS
THE POSITION OF THE
GROUND WIRE
• Connect grounding wires to the pump, piping and all other equipment too.
• When the pump operates ungrounded or with an incorrect connection,
friction between parts and abrasion caused by some fluids that flow
inside the pump, can generate static electricity. Moreover, according to
the type of fluid pump and the installation environment (such as gases
in the air or the type of the surrounding facilities) static electricity can
cause fire or electric shock.
Warning
• If the pump you have purchased is valid for Atex, a specific Atex
manual will accompany this one. Read this manual before operating
the pump.
• If the unit is marked with the symbol, it can be used in potentially
explosive atmospheres. Below this symbol, in the nameplate of the
pump, are indicated the areas for which the equipment is approved.
You will also find the maximum allowable surface temperature in the
same plate.

7
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Composite body pump parts
No. Code Description Qty. Notes
1 Table 1 Directional Valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings / Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensors - Not available in externally controlled models
7755117 /
855685
Diaphragm cover metallic pumps /
Non metallic pumps 2 (Not sold as a kit)
8 940380 /
940072
Diaphragm cover bolts metallic series /
Non metallic series 12 (Not sold as a kit)
9 Table 9 Pump shields 2 (Not sold as a kit)
11 855420 Diaphragm cover washers 4 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
15 855414 /
855687
Pump support /
Non metallic support 1 (Not sold as a kit)
16 940319 Support bolts 4 (Not sold as a kit)
17 855646 Cover 2 (Not sold as a kit)
Directional valve is sold as
kit. Assembled and verified
in Samoa facilities.
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.
DF30 AND DF30T

8855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Composite body pump parts
DF50 AND DF50T
COMPOSITE
No. Code Description Qty. Notes
1 Table 1 Directional valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings / Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensor - Not available with externally controlled models
7755106 /
894622
Diaphragm cover metallic enclosure pumps /
Non metallic pumps 2 (Not sold as a kit)
8 940380 /
940072+942156
Diaphragm cover bolts metallic series /
Non metallic series + washer 16 (Not sold as a kit)
9 Table 9 Pump shields 2 (Not sold as a kit)
11 855413 Diaphragm cover washers 4 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
15 855414 /
855687
Pump support /
Non metallic support 1 (Not sold as a kit)
16 940319 Support bolts 4 (Not sold as a kit)
17 855601 Cover 2 (Not sold as a kit)
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.
Directional valve is
sold as kit. Assembled
and verified in Samoa
facilities.

9
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Composite body pump parts
No. Code Description Qty. Notes
1 Table 1 Directional valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings / Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensor - Not available with externally controlled models
7755106 Diaphragm cover 2 (Not sold as a kit)
8 940380 Diaphragm cover bolts 16 (Not sold as a kit)
9 Table 9 Pump shields 2 (Not sold as a kit)
10 940506 Pump shield bolts 8 (Not sold as a kit)
12 940319 Valves cap bolts 8 (Not sold as a kit)
13 Table 13 Balls caps 2 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
17 855601 Side cover 2 (Not sold as a kit)
Directional valve is
sold as kit. Assembled
and verified in Samoa
facilities.
DF50 AND DF50T
METALLIC
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.

10 855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Composite body pump parts
DF50 STAINLESS
No. Code Description Qty. Notes
1 Table 1 Directional valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings / Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensor - Not available with externally controlled models
7755106 Diaphragm cover metallic enclosure pumps 2 (Not sold as a kit)
8 940380 Diaphragm cover bolts metallic series 16 (Not sold as a kit)
9 Table 9 Pump shields 2 (Not sold as a kit)
13 Table 13 Balls caps 2 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
15 855414 Pump support 1 (Not sold as a kit)
16 940319 Support bolts 4 (Not sold as a kit)
17 855601 Cover 2 (Not sold as a kit)
Directional valve is
sold as kit. Assembled
and verified in Samoa
facilities.
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.

11
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Composite body pump parts
DF100 COMPOSITE
No. Code Description Qty. Notes
1 Table 1 Directional valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings /
Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensor - Not available with externally controlled models
7755111 /
894621
Diaphragm cover metallic enclosure pumps /
Non metallic pumps 2 (Not sold as a kit)
8 940334 /
940086+942158
Diaphragm cover bolts metallic series /
Non metallic series + washer 20 (Not sold as a kit)
10 940914 Upper and lower shield bolts 7 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
17 855604 Cover 2 (Not sold as a kit)
21 Table 9 Upper shield 1 (Not sold as a kit)
22 Table 9 Lower shield 1 (Not sold as a kit)
23 855416 Diaphragm cover washers 4 *Only for composite
Directional valve is
sold as kit. Assembled
and verified in Samoa
facilities.
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.

12 855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
No. Code Description Qty. Notes
1 Table 1 Directional valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings / Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensor - Not available with externally controlled models
7755111 Diaphragm cover enclosure 2 (Not sold as a kit)
8 940334 Diaphragm cover bolts 20 (Not sold as a kit)
10 940914 Upper and lower shield bolts 7 (Not sold as a kit)
12 940319 Valves cap bolts 8 (Not sold as a kit)
13 Table 13 Balls caps 2 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
17 855604 Cover 2 (Not sold as a kit)
21 Table 9 Upper shield 1 (Not sold as a kit)
22 Table 9 Lower shield 1 (Not sold as a kit)
Composite body pump parts
DF100 METALLIC
Directional valve is sold as
kit. Assembled and verified
in Samoa facilities.
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.

13
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Composite body pump parts
DF100 STAINLESS
Directional valve is sold as
kit. Assembled and verified
in Samoa facilities.
No. Code Description Qty. Notes
1 Table 1 Directional valve 1 Options:
Normal exhaust
Driven exhaust
Externally controlled
2 Table 2 Balls -
3 Table 3 Ball check seats / O-rings / Ball guides -
4Table 4 Bushing / Seal / Push rod -
5Table 5 Diaphragms -
6Table 6 Air sensor - Not available with externally controlled models
7755111 Diaphragm cover enclosure 2 (Not sold as a kit)
8 940334 Diaphragm cover bolts 20 (Not sold as a kit)
10 940914 Upper and lower shield bolts 7 (Not sold as a kit)
13 Table 13 Balls caps 2 (Not sold as a kit)
14 Table 14 Body 1 (Not sold as a kit)
17 855604 Cover 2 (Not sold as a kit)
21 Table 9 Upper shield 1 (Not sold as a kit)
22 Table 9 Lower shield 1 (Not sold as a kit)
NOTE: To identify proper repair kit for your pump, search for piece pump code in the nameplate of the pump. If that code corresponds to 55xxxx go to
page 14, if that code corresponds to DFXXXXXXXXX go to page 16.

14 855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Table 1 Table 2 Table 3
Pump size Lube code Directional valve Kit code Balls Kit code Ball valves seats / Seals / Cages Kit code
DF30
553010 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
553020 Standard 558300 ACETAL 558321 Stainless steel / Viton / Polypropylene 558316.001
553124 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
553160 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
553161 Standard 558300 PTFE 558319 Stainless steel / EPDM / Polypropylene 558316.001
553164 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
DF50
552010 Standard 558300 ACETAL 558321 Stainless steel / Viton / Acetal 558315
552011 Standard 558300 ACETAL 558321 Stainless steel / Viton / Acetal 558315
552012 Standard 558300 PTFE 558319 Stainless steel / Viton / Acetal 558315
552013 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552014 Standard 558300 PTFE 558319 Stainless steel / Viton / Acetal 558315.001
552015 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552016 Standard 558300 ACETAL 558321 Stainless steel / Viton / Acetal 558315.001
552017 Standard 558300 PTFE 558319 Stainless steel / Viton / Acetal 558315.001
552018 Standard 558300 ACETAL 558321 Stainless steel / Viton / Acetal 558315.001
552021 Standard 558300 ACETAL 558321 Stainless steel / Viton / Acetal 558315
552022 Standard 558300 PTFE 558319 Stainless steel / Viton / Acetal 558315
552023 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552024 Standard 558300 PTFE 558319 Stainless steel / Viton / Acetal 558315.001
552025 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552026 Standard 558300 ACETAL 558321 Stainless steel / Viton / Acetal 558315.001
552050 Standard 558300 PTFE 558319 Stainless steel / PTFE / Stainless steel 558341.001
552124 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552160 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552161 Standard 558300 PTFE 558319 Stainless steel / EPDM / Polypropylene 558336.001
552162 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
552164 Standard 558300 PTFE 558319 Stainless steel / Viton / Polypropylene 558316.001
DF100
551010 Standard 558350 ACETAL 558365 Stainless steel / NBR / Acetal 558357
551015 Standard 558350 PTFE 558363 Stainless steel / Viton / Polypropylene 558360.001
551017 Standard 558350 PTFE 558363 Stainless steel / Viton / Acetal 558359.001
551030 Standard 558350 NBR 558364 Stainless steel / NBR / Acetal 558357
551050 Standard 558350 PTFE 558363 Stainless steel / PTFE / Stainless steel 558378.001
551160 Standard 558350 PTFE 558363 Stainless steel / Viton / Polypropylene 558360.001
551162 Standard 558350 PTFE 558363 Stainless steel / Viton / Polypropylene 558360.001
551164 Standard 558350 PTFE 558363 Stainless steel / Viton / Polypropylene 558360.001
55XXXX Pumps repair kit codes (tables 1 to 5)
DF 55x xxx
*For Serial numbers prior to 329041/250 the replacement kit has to be ordered without .001 suffix.
x1
x4

15
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Table 4 (See note at the bottom of the page) Table 5 (See note at the bottom of the page) Table 6
Pump size Lube code Bushing / Seals / Shaft Kit code Diaphragms Kit code Air sensor Kit code
DF30
553010 PTFE / Viton / Stainless steel 558326.001 HYTREL 558337.001 Standard 558301
553020 PTFE / Viton / Stainless steel 558326.001 HYTREL 558337.001 Standard 558301
553124 PTFE / Viton / Stainless steel 558326.001 HYTREL 558337.001 Standard 558301
553160 PTFE / Viton / Stainless steel 558326.001 PTFE 558344.001 Standard 558301
553161 PTFE / EDPM / Stainless steel 558328.001 PTFE 558344.001 Standard 558301
553164 PTFE / Viton / Stainless steel 558326.001 HYTREL 558337.001 Standard 558301
DF50
552010 PTFE / NBR / Stainless steel 558304.001 HYTREL 558303.001 Standard 558301
552011 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552012 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552013 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552014 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552015 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552016 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552017 Conductive PTFE / Viton / Stainless steel 558307.001 PTFE 558309.001 Standard 558301
552018 Conductive PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552021 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552022 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552023 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552024 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552025 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552026 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552050 PTFE / PTFE-Stainless steel / Stainless steel 558310.001 PTFE 558309.001 Standard 558301
552124 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
552160 PTFE / Viton / Stainless steel 558307.001 PTFE 558309.001 Standard 558301
552161 PTFE / EPDM / Stainless steel 558333.001 PTFE 558309.001 Standard 558301
552162 Conductive PTFE / Viton / Stainless steel 558307.001 PTFE 558309.001 Standard 558301
552164 PTFE / Viton / Stainless steel 558307.001 HYTREL 558303.001 Standard 558301
DF100
551010 PTFE / NBR / Stainless steel 558352.001 HYTREL 558368.001 Standard 558301
551015 PTFE / Viton / Stainless steel 558353.001 HYTREL 558368.001 Standard 558301
551017 Conductive PTFE / Viton / Stainless steel 558399.001 PTFE 558371.001 Standard 558301
551030 PTFE / NBR / Stainless steel 558398.001 NBR 558457.001 Standard 558301
551050 PTFE / PTFE-Stainless steel / Stainless steel 558358.001 PTFE 558371.001 Standard 558301
551160 PTFE / Viton / Stainless steel 558399.001 PTFE 558371.001 Standard 558301
551162 Conductive PTFE / Viton / Stainless steel 558399.001 PTFE 558371.001 Standard 558301
551164 PTFE / Viton / Stainless steel 558353.001 HYTREL 558368.001 Standard 558301
Alphanumeric pumps repair kit codes
DF 55x xxx
*For Serial numbers prior to 329041/250 the replacement kit has to be ordered without .001 suffix.

16 855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Alphanumeric pumps repair kit codes
Table 3 BALL CHECK SEATS / O-RINGS / BALL GUIDES ASSEMBLY - (Repair kit)
DF30 DF50 DF100
METALLIC COMPOSITE METALLIC COMPOSITE
1= SS / NBR / Acetal 558314.001 558314 558314.001 558357 558357.001
2= SS / FKM / Acetal 558315.001 558315 558315.001 558359 558359.001
3= SS / FKM / PP 558316.001 558316 558316.001 558360 558360.001
4= SS/ FKM / PTFE 558317.001 558317 558317.001 558361 558361.001
5= PVDF / FKM / PP 558318.001 558318 558318.001 558362 558362.001
6= SS / EPDM / Acetal 558334.001 558334 558334.001 558391 558391.001
7= SS / EPDM / PTFE 558335.001 558335 558335.001 558392 558392.001
8= SS / EPDM / PP 558336.001 558336 558336.001 558393 558393.001
9= SS / PTFE / No guide - 558341*ask samoa with yout S.
Number 558341.001* 558378* 558378.001*
F= PVDF / FFKM + FEP / PVDF 558346.001 558346 558346.001 558452 558452.001
G= PVDF / FFKM/ + FEP / Polypropylene 558407.001 558407 558407.001 558454 558454.001
H= SS / FFKM + FEP / Acetal 558403.001 558403 558403.001 558453 558453.001
L= SS / FFKM + FEP / PP 558349.001 558349 558349.001 558450 558450.001
Table 4 BUSHING / SEAL / PUSH ROD ASSEMBLY - (Repair kit)
DF30 DF50 DF100 with Hytrel or
Santoprene diaphragms DF100 with PTFE diaphragms / NBR
1= PTFE / NBR / SS 558325.001 558304.001 558352.001 558398.001
2= PTFE / FKM / SS 558326.001 558307.001 558353.001 558399.001
3= PTFE / PTFE / SS 558327.001 558310.001 558354.001 558358.001
4= PTFE / FKM / HASTELLOY 558346.001 558312.001 - 558355.001
5= Conductive PTFE/ PTFE / SS 558327.001 558310.001 558354.001 558358.001
6= Conductive PTFE / FKM / SS 558326.001 558307.001 558353.001 558399.001
7= Conductive PTFE / EPDM / SS 558328.001 558333.001 558382.001 558379.001
8= PTFE / EPDM / SS 558328.001 558333.001 558382.001 558379.001
9= Conductive PTFE / PTFE / SS 558327.001 558310.001 558354.001 558358.001
A= Conductive PTFE / FKM / SS 558326.001 558307.001 558353.001 558399.001
B= Conductive PTFE / EPDM / SS 558328.001 558333.001 558382.001 558379.001
U= UV special bushing / PTFE / SS 558348.001 558348.001 558396.001 558452.001
K= Conductive PTFE / no seals /HASTELLOY 558402.001 558401.001 - 558451.001
Table 5 DIAPHRAGMS - (Repair kit)
DF30 DF50 DF100
H= Hytrel®558337.001 558303.001 558368.001
T= PTFE 558344.001 558309.001 558371.001
S= Santoprene®558343.001 558306.001 558369.001
W= PTFE / PVDF 558345.001 558347.001 558395.001
N = NBR - - 558457.001
All body codes are threaded in BSP.
To order a NPT threaded body request some body with .300 sulfix example:
DF100 Aluminium BSP body: 755110
DF100 Aluminium NPT body: 755110.300
SS = Stainless Steel, PP = Polypropylene
PTFE = Teflon®, FKM = Viton®, EPDM = Sinthetic rubber
PVDF = Polyvinyl fluoride.
Table 1 AIR VALVE MODULE - (Repair kit)
DF30 DF50 DF100
A= Aluminum 558300 558300 558350
P= PP 558343 558343 558395
B= PP conductivo 558343 558343 558395
Table 2 BALL CHECK VALVES - (Repair kit)
DF30 DF50 DF100
C= Acetal 558321 558321 558365
T= PTFE 558319 558319 558363
S= SS 558342 558342 558367
N = NBR - - 558364
MODEL EXAMPLE
ADF50 A A 2 3 T H
PUMP SIZE
AIR VALVE MODULE
WETTED PUMP BODY
PUMP SHIELD
BUSHING / SEAL /
PUSH ROD ASSEMBLY
CONNECTIONS
BALL CHECK SEATS / O-RINGS /
BALL GUIDES ASSEMBLY
BALL CHECK VALVES
DIAPHRAGMS
BAS
Table 1
Table 14
Table 9
Table 4
Table 3
Table 2
Table 5
Table 1
Table 14 Table 9
Table 4
Table 3
Table 2
Table 5
DF 55x xxx

17
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Troubleshooting
The pump does not work
Cause Recommended measure
The discharge valve on the discharge side is not open. Open the discharge valve on the discharge side.
No air supply. Turn on the compressor and open the air valve and air regulator.
The air supply pressure is low. Check the compressor and the configuration of the air line.
Air leaks in connecting elements. Check the connection elements and the tightening of the screws.
The air pipes or ancillary equipment is clogged with mud. Check and clean the air line.
The exhaust port (muffler) of the pump is clogged with mud. Check and clean the exhaust port and muffler.
The fluid pipe is clogged with mud. Check and clean the fluid line.
Pump is clogged with mud. Remove, inspect and clean the pump body.
The pump runs but no fluid comes out
Cause Recommended measure
The valve on the suction side is not open. Open the valve on the suction side.
Too much suction or discharge height. Confirm the configuration of the pipe and reduce the height of the same.
Fluid pipe discharge side (including the filter) is clogged with mud. Check and clean the fluid line.
Pump is clogged with mud. Dismantle the pump, check and clean.
The ball and ball seat is worn or damaged. Inspect and replace parts.
The flow is decreasing
Cause Recommended measure
The air supply pressure is low. Check the compressor and the configuration of the air line.
The air line or peripheral equipment clogged with mud. Check and clean the air line.
Valve discharge side drive will not open normally. Adjust the discharge valve discharge side.
The air mixes with the fluid. Replenish fluid and check the configuration of the pipe on the suction side.
Cavitation occurs. Adjust air supply pressure and discharge pressure and reduce the suction.
Vibrations. Adjust air supply pressure and discharge pressure. Reduce the flow of the inlet valve to adjust pressure and volume of fluid.
Ice formation in the air exhaust. Remove ice from the air bypass valve and check and clean the air filter. Use a pipe in the exhaust air that the ice does
not form in the muffler.
The fluid line (including the filter) plugged with mud. Check and clean the fluid pipe and strainer.
The exhaust port (muffler) of the pump is clogged with mud. Check and clean the exhaust port and muffler.
Pump is clogged with mud. Remove, inspect and clean the pump body.
Leakage of fluid through the hollow exhaust (silencer)
Cause Recommended measure
The diaphragm is damaged. Remove and inspect the pump and replace the diaphragm.
Irregular noise
Cause Recommended measure
The air supply pressure is too high. Adjust air supply pressure.
The pump is clogged with sludge particles
larger than the diameter allowed.
Remove, check and clean the pump body.
Irregular vibration
Cause Recommended measure
The elements of connection and the
support of the pump are loose.
Review each element of connection and tighten
the screws.
The air supply pressure is too high. Adjust air supply pressure.
The range and ball valve vibrates. Adjust air supply pressure and exhaust pressure.
Powered air leak pressure of 3 to 8 bar
Cause Recommended measure
Wear directional valve. Replace directional valve components.
No start-up and is leaking air without cycles
Cause Recommended measure
Stiff air sensors. Change air sensor.
Wear directional valve. Replace.
In fluid with air bubbles
Cause Recommended measure
Diaphragm damaged. Replace diaphragm.
Suction hose loose or broken. Tighten or replace.
Alphanumeric pumps repair kit codes
Table 14 WETTED PUMP BODY (Not sold a kit one piece per code)
DF30 DF30T DF50 DF50T DF100
A= Aluminum - - 755104 755105 755110
B= Conductive PP 855661 - 855649 - 855651
C= Acetal - - 855618 855619 -
D= Conductive Acetal 855660 - 855628 - 855632
N= Electroless Nickel Plated Aluminum - - ASK SAMOA - ASK SAMOA
P= PP 755400 - 855607 855608 855630
S= SS - - 755050 - 755051
W = PVDF 855676 - 855692 - 894623
K = Conductive PVDF 855677 - 855697 - 855698
Table 9 PUMP SHIELD - (Not sold as kit one piece per code)
DF30 DF30T DF50 DF50T DF100
A= Aluminum - 755108 IN: 755109 UPPER: 755113
OUT: 755108 LOWER: 755114
P= PP 855645 IN: ASK SAMOA 855625 IN: 855626 UPPER: 855637
OUT: 855625 OUT: 855625 LOWER: 855636
B= Conductive
PP
UPPER: 855624
LOWER: 855625
Table 13 VALVE CAPS (Not sold a kit one piece per code)
DF30 DF50 DF100
A= Aluminum - 855107 855112
S= SS - ASK SAMOA ASK SAMOA

18 855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
Repair and maintenance procedures
Torques necessary for the proper functioning of the pump
For proper operation of the pump and to prevent accidents which may damage equipment and in the worst case, people, you must periodically review
the torques of the diaphragms covers and the DIRECTIONAL VALVE. In the next table are shown the appropriate torques for this purpose:
Torques DF50
Diaphragm cover 48.67 - 53.1 lbf·in (5,5 - 6 N·m)
Directional valve 44.25 lbf·in (5N·m)
Valve cap 35.4 lbf·in (4 N·m) Aluminium - 30.9 lbf·in (2 N·m) composite
Diaphragm replacement
Torques DF30
Diaphragm cover 70.81 lbf·in (8 N·m)
Directional valve 44.25 lbf·in (5 N·m)
Valve cap 30.9 lbf·in (2 N·m) composite
Torques DF100
Diaphragm cover 137.7 lbf·in (15 N·m)
Directional valve 44.25 lbf·in (5 N·m)
Valve cap 35.4 lbf·in (4 N·m) Aluminium - 30.9 lbf·in (2 N·m) composite
Before any intervention: DISCONNECT AIR SUPPLY OF THE PUMP.
IT IS NOT NECESSARY TO REMOVE THE PUMP FROM THE FLUID LINE.
1. Close fluid valves.
2. Drain the fluid inside the pump. Anticipate a drainage of fluid from inside
the pump.
3. Remove the directional valve while being careful not to damage the
seals shown in the figure.
4. Remove the diaphragm cap.
NOTE: To tighten these screws you must use a torque wrench
calibrated to (see torque table in this page).
5. Remove the cover by gently pulling back.
6. Remove the used diaphragm and place the new one in the proper
position.
Assemble components.
4
A
6
5
3
Pushing rod
Remove the side cover on the right of the fluid inlet as shown in the
figure, following the procedure to “Replace diaphragms".
Once the shaft is visible, use the following procedures:
1. Remove the shaft from its housing by pulling it from one end.
The Teflon®sleeve is threaded into the body. To remove use snap ring
pliers in the two holes indicated in the figure.
2. Once the cap has been removed, remove the quad ring inside the
pump body.
3. Replace the kit following the correct order shown in the assembly
drawing.
Reassemble the pump in reverse order.
2
1
3

19
R. 02/17 855 821
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
ENGLISHESPAÑOL
FRANÇAIS
DEUTSCH
РУССКИЙ
2017_02_01-13:00
Repair and maintenance procedures
Ball valves replacement
1. Close fluid valves.
2. Drain the fluid from inside the pump.
Anticipate a drainage of fluid from inside
the pump.
3. Loosen the screws to remove the directional
valve. Take special care with the seals.
4. Remove the valve cover by loosening the
screws with an Allen wrench. Take note of
the orientation of the cap, as it is critical to
replace it correctly during reassembly.
5. Install a new set of valves according to
these assembly drawings. Ensure that the
ball guides are assembled as shown in the
figure on the left, and tighten the screws
with a maximum torque (see torque table
page 18).
6. Assemble the directional valve with
being careful not to damage the O-rings
and tighten the screws with a maximum
torque of 44.25 lbf·in (5 N·m).
To avoid fluid restriction and leakages, follow
the position of the ball checks guides in the
figure above. the valves cups must be placed
with the area indicated in the figure below
facing the body.
Attention
Air sensor (only for models with directional valve)
The air sensors are on the inside part of the diaphragm covers. To access
them, follow the procedure for “Replacing diaphragms".
Once removed the covers following procedure:
1. Remove the two screws that secure the air sensor to the top.
2. Remove all components of the sensor. Clean the area.
3. Introduce new components in the order shown.
4. Fit the cover on the pump and tighten the screws to the body of the
pump. Maximum tightening torque (see torque table page 18).
Fit the remaining components in reverse order.
21
3
4
METALLIC COMPOSITE

20 855 821 R. 02/17
SAMOA Industrial, S.A. · Pol. Ind. Porceyo, I-14 · Camino del Fontán, 831 · 33392 - Gijón - Spain · Tel.: [phone] · www.samoaindustrial.com
2017_02_01-13:00
DF30 DF50 DF100
Ratio 1:1 1:1 1:1
Máximo caudal salida libre 38 l/min (10 gal/min) 50 l/min (13.21 gal/min) 100 l/min (26.5 gal/min)
Desplazamiento por embolada 0,07 l (2.37 oz) 0,1 l (3.38 oz) 0,25 l (8.45 oz)
Rango de presión 1,5 a 8 bar (22 a 115 psi) 1,5 a 8 bar (22 a 115 psi) 1,5 a 8 bar (22 a 115 psi)
Max. tamaño de partículas en
suspensión 3 mm (0.12 in) 3 mm (0.12 in) 4 mm (0.16 in)
Altura máxima de succión 4 m (13.2 ft) seco
8 m (26.25 ft) húmedo
6 m (19.69 ft) seco
8 m (26.25 ft) húmedo
4,5 m (14.76 ft) seco
7 m (22.97 ft) húmedo
Peso 1,9 kg (4,19 lb)
3,5 kg (7.72 lb) Serie metálica con cuerpo
de Aluminio
2,2 kg (4.85 lb) Serie plástica
7,2 kg (15.87 lb) Serie metálica
cuerpo de Aluminio
11,2 kg (24.69 lb) Serie metálica
cuerpo de Acero inoxidable
5,1 kg (11.24 lb) Serie no metálica
Entrada de fluido (cuerpo con
entrada simple) 1/2" BSP - NPT (H) 1/2" NPSM (H) y bridas cuerpo metálico
(BSP- NPT (H) para cuerpo plástico) 1" BSP - NPT (H) y brida
Entrada de fluido (cuerpo con
entrada doble) 2 x 3/8" BSP - NPT (H) 2 x 3/8" NPSM (H) y bridas cuerpo metálico
(BSP - NPT (H) para cuerpo plástico) _
Salida de fluido 1/2" BSP - NPT (H) 1/2" NPSM (H) (BSP - NPT (H) para cuerpo
plástico) 1" BSP/NPT (H) y brida
Entrada de aire 3/8" NPSM (H) 3/8" NPSM (H) 3/8" NPSM (H)
Partes húmedas Ver especificaciones de los modelos Ver especificaciones de los modelos Ver especificaciones de los modelos
Nivel de fluido 80 db 80 dB 80 dB
Rango de temperaturas de trabajo
(consultar característica de los
materiales en página 21).
0 - 70 ºC (32 - 158 ºF) 0 - 70 ºC (32 - 158 ºF) 0 - 70 ºC (32 - 158 ºF)
1/2" BOMBA DE MEMBRANA SERIES DF30 (38 l/min)
1/2" BOMBA DE MEMBRANA SERIES DF50 (50 l/min)
1" BOMBA DE MEMBRANA SERIES DF100 (100 l/min)
Guía de servicio técnico y mantenimiento Código:
DF30_-XXX-XX-XX-XX-X / 5530XX
DF50_-XXX-XX-XX-XX-X / 5520XX
DF100_-XXX-XX-XX-XX-X / 5510XX
Datos técnicos 20
Advertencias y preacuciones 21
Descripción 21
Curvas de capacidad 22
Dimensiones 23
Instalación 24
Modos de operación 25
Partes de la bomba 27
Códigos alfanuméricos
kit bombas 34
Anomalías y soluciones 36
Reparación y mantenimiento 37
Declaración de conformidad 96
Datos técnicos
DF50
DF30 DF100
* (oz, ft, gal/min) todo en unidades americanas
