Gasmate OBSIDIAN GM142-160 User manual

1
Modern, warming focal point for your outdoor area
Powerful 52.8MJ/h stainless steel gas burner lit by
electronic ignition
Adjustable heat output
Heat resistant glass surround for wind protection and
safety
Composite MGO construction
Glass beads provide ambient heat and a stunning
flame effect
9kg LPG cylinder storage under unit
Operates for approximately 8.5 hours on a properly
filled 9kg LPG cylinder
Complete with hose and regulator
Assembled Dimensions (mm): 1060 W x 510 D x 590 H
2 year warranty
Approved to NZ Standards
Important: Retain these instructions for future use.
5128-06/19
Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living - Hamilton, N.Z. www.gasmate.co.nz
OBSIDIAN
GAS FIRE TABLE
Model No. GM142-160
DANGER
If you smell gas:
1. Shut off the gas to the
appliance.
2. Extinguish any open
flame.
3. If odour continues,
keep away from
the appliance and
immediately call your
gas supplier or fire
department.
WARNING:
Do not store or use gasoline, or other
flammable vapors and liquids, in the vicinity
of this or any other appliance.
An LPG Cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
Improper installation, adjustment, alteration,
service or maintenance can cause injury
or property damage. Read the installation,
operating, and maintenance instructions
thoroughly before installing or servicing this
equipment.
CARBON MONOXIDE HAZARD
This appliance can
produce carbon monoxide
which has no odor.
Using it in an enclosed
space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or home.
WARNING:
For Outdoor Use Only
CARBON MONOXIDE HAZARD
This appliance can
produce carbon
monoxide which has
no odour.
Using it in an enclosed
space, eg. boat,
caravan, tent, car,
campervan or house,
may cause death.
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has
no odour.
Using it in an enclosed
space, eg. boat, caravan,
tent, car, campervan or
house, may cause death.
CARBON MONOXIDE HAZARD
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odour.
Using it in an enclosed space, eg. boat, caravan,
tent, car, campervan or house, may cause death.
This appliance can produce carbon
monoxide which has no odour.
Using it in an enclosed space, eg. boat,
caravan, tent, car, campervan or
house, may cause death.

32
2. Adequate clearance around air openings into the
combustion chamber, clearances from combustible
materials, provisions for accessibility and for
combustion and ventilating air supply must be
maintained at all times when the appliance is
operating.
3. Proper clearance from combustible materials must
be maintained at all times. The minimum clearances
are as follows::
Minimum Clearance from Combustibles
Side 1220mm Rear 1220mm
DO NOT locate this appliance under any overhead
enclosure. Avoid using near or under overhanging trees
and shrubs. Combustible materials should never be
within 3m of the top of the appliance.
Combustible materials are considered to be wood,
compressed paper, plant fibres, plastic, plexiglas or
other materials capable of being ignited and burned.
Such materials shall be considered combustible even
though flame proofed, fire-retardant treated or plastered.
Additional clearance may be required for glass, painted
surfaces and other materials which may be damaged by
radiant or convection heat.
4. The appliance must be placed on a non-combustible
level and adequate footing and be readily accessible.
5. The gas manifold supply pressure must be regulated
at 2.75 kPa utilising an approved regulator (supplied
with appliance).
6. The appliance must be inspected before each use,
and at least annually by a qualified service person.
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
IMPORTANT SAFETY RULES
This appliance must only be used in a well ventilated
area.
1. This appliance shall not be installed or used
indoors, in buildings, garages or any other
enclosed area.
2. ALWAYS place the appliance on a firm and level
surface.
3. DO NOT place articles on or against this
appliance.
4. DO NOT use or store flammable materials near
this appliance.
5. DO NOT use in windy conditions.
6. DO NOT burn solid fuels in the appliance. 7. This
is a decorative appliance only and any kind of
cooking is strictly forbidden.
8. Children and adults should be alerted to the
hazards of high surface temperatures, burns and
clothing ignition.
9. Children should be carefully supervised when they
are in the area of the appliance.
10.NEVER hang anything including clothes or other
flammable items on the appliance.
11.DO NOT use this appliance if any part has been
under water. Immediately call a qualified service
technician to inspect the appliance and to replace
any part of the control system and any gas
control that has been under water.
12.DO NOT operate this appliance unless it is fully
assembled.
13.DO NOT SPRAY AEROSOLS IN THE VICINITY
OF THIS APPLIANCE WHILE IT IS IN
OPERATION.
14.Before use: Remove any debris from within the
grate area.
15.Installation and repair should be done by a
qualified service person. The appliance must be
inspected before use and at least annually by a
qualified service person. More frequent cleaning
may be required as necessary. It is imperative
that control compartment, burners and circulating
air passages of the appliance and light be kept
clean.
Prior to assembling your appliance, the following must be
reviewed. Compliance with the following should result in
satisfactory appliance operation. This instruction manual
should be retained for future reference. The installation
must conform with local codes or authority having
jurisdiction.
1. The appliance is intended for residential and
nonresidential outdoor spaces. The installation must
conform with New Zealand Standard 5601 “Gas
Installations”.
a. The appliance area must be kept clear and free
of combustible materials, gasoline and other
flammable vapours and liquids.
b. Gas orifices and burner must be kept clear of
dirt and cobwebs. Flow of combustion and
ventilation air through the perforated portions of
the appliance must not be obstructed. Cleaning
with a soft brush before use and at least every six
months is recommended.
c. All gas connections should be checked for leaks
utilising a soap solution. Never use a flame for this
purpose.
d. The flame pattern at the emitter grid should
be visually checked whenever the appliance is
operated. If black soot is accumulating on the
glass beads, the appliance should be turned off
immediately. The appliance should not be operated
again until the unit is serviced and or repaired.
e. Any cleaning agent used on the appliance should
be of a non-combustible and non-corrosive nature.
Warm soapy water is ideal. While washing the
appliance, be sure to keep the area around the
burner and pilot assembly dry at all times. If the gas
control is exposed to water in any way, do NOT try
to use it. The appliance should be regularly cleaned
and protected to reduce oxidation, ideally a cover
should be used when not in use.

32
7. The hose assembly should be properly located out
of pathways where people may trip over it. The hose
must be protected from contact with hot or sharp
surfaces both during use and while in storage. The
hose assembly should be visually inspected prior
to each use of the appliance. If excessive abrasion
or wear is evident, or the hose is cut, it must be
replaced prior to operating the appliance. The
replacement hose assembly may be obtained from
the distributor.
8. DO NOT use any pressure regulator or hose
assembly other than those supplied with the
appliance. Replacement pressure regulator and hose
assembly must be those specified. Replacement
parts may be obtained from the distributor.
9. Installation and use of this appliance must conform
with New Zealand Standard 5601 “Gas Installations”.
10. This appliance is designed to operate with a standard
9Kg LPG cylinder to DOT 4BA-240 with Approved
Cylinder Connection.
11. The valve outlet must be maintained in good
condition. When the cylinder is not in use, be sure
to cover it with a dust cap. A leak test should be
performed with soapy water whenever connecting a
new cylinder. NEVER use a flame to test for leaks.
12. The LPG cylinder must be turned off whenever the
appliance is not in use. When the appliance is to be
stored indoors, the LPG cylinder and the appliance
must be disconnected and the cylinder stored in
accordance with LPG Dangerous Goods Regulations.
13. Store the appliance upright in an area sheltered
away from weather conditions. The use of a cover is
recommended.
14. The appliance has been designed with several safety
features which include a tip over switch and a flame
safeguard system which means if the pilot goes out
the unit will automatically turn off.
REGULATOR SAFETY FEATURE
All QCC regulators (the part that attaches to the gas
cylinder to regulate the flow of gas) have a safety feature
included that restricts gas flow in the event of a gas leak.
You can inadvertently activate this safety feature without
having a gas leak. This typically occurs when you turn
on the gas using the appliance control knob before you
turn on the gas cylinder valve. If the gas regulator safety
feature activates, the appliance will operate with reduced
output as gas flow is restricted.
These steps should be taken first to reset the gas
regulator safety device:
1. Turn gas cylinder valve off.
2. Turn appliance off.
3. Disconnect the regulator from the gas cylinder.
4. Wait 30 seconds.
5. Reconnect the regulator to the gas cylinder.
6. Leak test the connection using a soapy water
solution. Ensure no bubbles appear before
proceeding.
7. Slowly open the gas cylinder valve all the way. Do
not put excessive force on the valve at the full open
position, to avoid damaging the valve.
8. Light the appliance as per the instructions provided.
Any modification to the appliance not described in the
installation instructions may compromise the safety of
this appliance. Special concern is as follows:
(1) DO NOT bypass thermocouple safety burner;
(2) DO NOT operate appliance without the grate in
place;
Clothing or other flammable materials should not be hung
from the appliance, or placed on or near the appliance.
The area above the burner may be extremely hot. Direct
contact with these metal surfaces should be avoided in
order to prevent burns or clothing ignition.
QCC CYLINDER CONNECTION DEVICE
Screw the coupling nut of regulator into the cylinder valve
outlet.
Type of Gas I3/P28-30/ULPG
Consumption 52.8MJ/h
Operating Pressure 2.75kPa
Injector Size 1.95 mm
Heater specifications can be found on the data label.

54
GENERAL ASSEMBLY
Connecting & Disconnecting to Gas Source
Familiarise yourself with the general information and
safety guidelines located at the front of this manual.
Check:
1. The cylinder is filled. A sloshing sound will be heard
when shaken.
2. The control knob is in the ‘OFF’ position.
Connecting
1. Ensure cylinder valve is in its full off position.
2. Check for any damage to either the cylinder
connection or the hose. NEVER attempt to use
damaged equipment.
IMPORTANT: Before connecting and
disconnecting appliance to gas source,
make sure control knob is in ‘OFF’ position.
CAUTION: When the appliance is not in use,
the gas must be turned off at the cylinder.
PARTS LIST
3. When connecting the hose to the cylinder tighten the
nut to a positive stop by hand.
4. Open cylinder valve fully. If a leak can be heard at
either end of the hose, turn cylinder off and tighten
joint. Wait 5 minutes before re-testing and use a
soapy water solution to check the joint. If bubbles
appear the connection will need to be re-tightened.
Refer to page 6 for more detailed instructions on
connecting the appliance to the cylinder.
Disconnecting
1. Ensure the burner control is in the ‘OFF’ position.
2. Ensure cylinder valve is in the full off position.
For storage and cylinder exchange, disconnect hose
at the cylinder only, DO NOT disconnect hose from
appliance.
ABC D E
Glass Beads Body
1PC
Door
1PC
Cover
1PC
Battery (AAA)
1PC
E
A
C
B
D

54
GENERAL ASSEMBLY
GLASS SURROUND PARTS LIST
No. Part Name Qty
1 Screen 1
2 Thermocouple 1
3 Fire pan 1
4Grounding wire 1
5 Ignition Pin/wire 1
6 Fire Table 1
7 Control knob 1
8 Igniter 1
9 Wing screw 1
10 Control panel 1
11 Battery 1
12 Door 1
13 Hose and regulator 1
14 Nozzle 1
15 Burner 1
A. Glass Panel
4PCS
B. Bracket
4PCS
C. Screw
8PCS
D. L shaped silicon
pad 65 x 65mm
4PCS
E. Square silicon pad
20 x 20mm
8PCS
1
2
3
4
5
6
7
8
9
10
11
12
14
15
13
