GASTROBACK®
Operating Instructions
DESIGN KETTLE ADVANCED
Art.-No. 42413
13
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 13

The Design Kettle Advanced is designed for boiling drinking quality water. Powerful 2200VA
heating elements are integrated in the bottom of the stainless steal kettle and therefore protec-
ted against damage, making cleaning and decalcifying quite easy. An illuminated water gauge
will help you to measure off the required amount of water.
For household use only.
Features of Your Design Kettle
2,200 VA concealed
heating element
Power base with
cord storage
Illuminated water gauge
with LED control lamp
Power switch;
green – ON;
red – OFF
Removable scale filter
1.7 litre stainless steal
water container
Self-opening lid with
viewing window,
just press the
opening button
Opening button
14
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 14

Important Safeguards
Carefully read all instructions before operating this appliance and save for
further reference. Do not attempt to use this appliance for any other than the intended use,
described in these instructions. Any other use, especially misuse, can cause severe injuries or
damage by electric shock, heat or fire.
Any operation, repair and technical maintenance of the appliance or any part of it other than
described in these instructions may only be performed at an authorised service centre. Please
contact your vendor.
• Do not attempt to operate the appliance if the appliance or any parts are likely to be dama-
ged or subject to inadmissible strain (i.e. mechanical or electric shock, overheating). Before
operating, always ensure that there are no objects in the water container, and check the appli-
ance and each part of it on impeccable operation or any damage or leakage. The pins of the
power plug must be tidy, smooth and clean.
Do not attempt to operate the appliance and immediately switch off and
unplug the appliance if water leaks out of the kettle.
• Any use of accessories, attachments or spare parts not recommended by the manufacturer
may result in fire, electric shock and injuries to persons. If the appliance or any part of it is like-
ly to be defective or not operating in the intended way or water leaks out of the kettle, imme-
diately unplug from the power supply and return the entire appliance to an authorised service
centre for examination and repair.
Any maintenance, repair and operation other than described in these instructions must be per-
formed at an authorised service centre to avoid risk of electric shock, fire or injuries to persons.
• Close supervision is necessary when the appliance is used near young children. Do not let
young children play with any parts of the appliance. The appliance is not intended for use by
children or infirm persons without supervision. For storage always keep the entire appliance
dry and clean and where young children cannot reach it. Do not place any hard and/or heavy
objects on the appliance or any part of it.
• Always place the appliance on a stable, level, dry, heat-resistant and easy accessible surfa-
ce. Do not place the appliance near the edge of the table or counter or on an inclined surfa-
ce. Ensure, that the power base will not tilt or wobble before placing the kettle on it. Do not
place any cloth or tissue beneath or on the appliance to avoid any risk of fire, electric shock
and overheating. Always keep the table or counter clean and dry and immediately wipe off
spilled liquids.
• During operation keep the appliance in an appropriate distance of at least 20 cm on each
side to furniture, walls, boards, curtains and other objects. Keep at least 1 m of free space
above the appliance. Do not operate the appliance near any heat-sensitive or moisture-sensi-
tive materials or under boards to avoid damage caused by steam and condensate.
• The kettle is heated electrically. Do not place the appliance and any part of it on or near hot
surfaces, (i.e. burner, heater or oven). The appliance and any part of it may never touch hot
surfaces.
• Do not leave the power base unattended, when connected to the power
supply. Always unplug when the appliance is not in use and before cleaning or moving the
15
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 15

power base. Always switch OFF the kettle and allow to cool down before cleaning or filling.
Before use, always make sure that the lid is closed properly and a sufficient amount of water
is filled in (between water level mark 500 and 1700/MAX). Do not operate the applian-
ce with the water level below the water level mark 500. Do not overfill the water container
above the maximum water level mark 1700/MAX.
• Do not use this appliance to boil any other liquids or foodstuffs others than pure drinking
water without any additional ingredients.
• Never use abrasive cleaners, cleaning pads or any hard and sharp objects (i.e. metal scou-
ring pads) for cleaning. Clean the kettle and power base with a damped sponge or tissue and
carefully dry the power base and exterior of the kettle after cleaning. Do not handle the appli-
ance or any part of it with violence. The lid is easily opened by pressing the opening button.
Do not lift or carry the kettle by the lid. Always use the handle for moving the kettle.
• Do not immerse the kettle base, switch area, power base or power cord in water, or allow
moisture to come in contact with these parts. Never place the appliance or any part
of it in an automatic dishwasher.
• This appliance is for household use only and NOT intended for use in moving vehicles or out-
doors. Do not operate or store the appliance in humid or wet areas.
During operation a little amount of moisture could condensate on the power base. This is no
indication for any failure.
Important Safeguards for Electrical Appliances
Care must be taken when using any electrical appliance. Please adhere to the following pre-
cautions.
• Ensure that the voltage rating of your mains power supply corresponds to the voltage requi-
rements of the appliance (220/240 V, 50 Hz, AC, rated for 16 A). Always connect the appli-
ance directly to a separately protected mains power supply wall socket with protective con-
ductor (earth/ground) connected properly. Do not use any extension cord or multi socket out-
let. The installation of a residual current safety switch with a maximum rated residual operating
current of 30 mA in the supplying electrical circuit is recommended. If in doubt, contact your
electrician for further information.
• Always handle the power cord with care. The power cord may never be knotted, twisted or
squeezed. Do not pull or strain the power cord. Do not let the plug or power cord hang over
the edge of the table or counter. Take care that no one will pull the appliance by the power
cord, especially when young children are near. Always grasp the plug to disconnect the power
cord from the power outlet. Do not touch the plug or power base with wet hands, when the
plug is connected to the power supply.
• Before operation completely unwind the power cord, insert the power cord in the gap on the
bottom of the power base, and ensure that the power base will not tilt or wobble during ope-
ration. Do not place the kettle or power base on the power cord.
• Always switch off the kettle and unplug the power base from the power
outlet when not in use and before moving or cleaning the power base. Do
not leave the power base unattended while connected to the power supply.
16
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 16

• When the power cord warms up during operation or is likely to be damaged, it must be
replaced by an authorised Service Centre. Do not attempt to repair the power cord!
• Do not immerse the kettle, power base or power cord in water or any other liquid. Do not
spill or drip any liquids on the power base, power cord or switch area of the kettle to avoid
risk of fire and electric shock. When liquids are spilled on the exterior of the appliance or con-
densate has built up on the power base, immediately switch OFF the kettle, unplug the power
base and dry the appliance.
Hot Surfaces – Risk of Burns
The exterior of the Design Kettle will get very hot during operation. In addition, beware of steam
and hot condensate during operation and even some minutes after switching off the applian-
ce, especially when opening the lid or pouring out water.
• The kettle is still hot, even some minutes after switching off. Do not touch hot surfaces (exte-
rior of the water container and lid) while the appliance is in use. Always use the soft grip hand-
le for moving the kettle. Always use the opening button for opening the lid.
Do not place the kettle on any heat-sensitive objects, while it is hot. Never place any heat-sen-
sitive objects in or on the kettle.
• Close supervision is important, when moving the kettle immediately after switching off. Take
care to hold the kettle level, especially when filled to the maximum level.
• For operation place the appliance on a dry, stable, heat-resistant and water-resistant, level
surface (i.e. glass, ceramics, stone). Never place any clothes or other objects on or under the
appliance during operation to avoid overheating. Always let the kettle cool down to room tem-
perature before cleaning.
• Always keep your hands, face and arm as well as any clothing and other objects away from
the lid and spout during operation to avoid scalds and damage. Beware of steam and hot con-
densate, when opening the lid. Always keep the lid closed, when operating the kettle.
Otherwise power consumption increases significantly and, additionally, the automatic swit-
ching off of the heating elements will not work out. Ensure all persons stay in sufficient distan-
ce to the appliance during operation.
First use
Unpack the appliance carefully and remove any promotional material attached to the kettle,
but do not remove the warning or model labels on the appliance. Before first use, fill the kettle
to its maximum level (1700/MAX), boil and discard the water.
CAUTION: The lid opens automatically just by pressing the opening button. Ensure that there
are no objects in the interior of the kettle.
Do not immerse the kettle base, switch area, power base or power cord in
water, or allow moisture to come in contact with these parts.
1. To fill the kettle, remove it from the power base and open the lid by pressing the opening
button.
17
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 17

2. Fill in pure tap water (drinking quality) up to the water level mark 1700/Max. Try to hold
the kettle as level as possible, while doing so.
Boil the water as described in the following section (Operating Your Design Kettle).
3. Discard the water.
NOTE: Your kettle will only operate when positioned on the power base with the power switch
in the ‘On’ position (red). The kettle will automatically switch OFF, once the water has boiled.
Too little water will result in the kettle switching OFF before the water has boiled.
Operating Your Design Kettle
CAUTION! Only fill with pure drinking water. Do not fill any other liquids or foodstuffs into
the water container and do not add any additional ingredients, such as spices or flavours. Do
not place any foreign objects in the water container. Do not drip or spill any liquids on the exte-
rior of the kettle or on the power base.
Ensure the kettle is filled with the appropriate amount of water (water level between 500 and
1700/MAX) before switching on the appliance.
WARNING! Do not use any extension cord or multi socket outlet to avoid
risk of fire and electric shock. Always connect the appliance directly to a separately pro-
tected mains power supply wall socket with protective conductor (earth/ground) connected pro-
perly (see Important Safeguards for Electrical Appliances). Always completely unwind the
power cord before connecting the plug to the power supply.
Do not use any mains adapter other than the supplied power base for the kettle.
Always place the appliance on a stable, level, dry and sufficiently large surface. Ensure, that
the power base will not tilt or wobble during operation. Do not operate the appliance on an
inclined surface, to avoid scalding and damage by boiling water overflowing the brim of the
kettle.
Beware of hot surfaces! The exterior of the kettle and lid will get very hot during operation.
Only use handles and knobs for handling the appliance. Beware of hot condensate and steam,
when opening the lid.
Immediately switch OFF and unplug the appliance, if water leaks out of the kettle.
1. Prepare the power base for use.
Completely unwind the power cord from the cord storage and insert it in the gab on the bot-
tom of the power base.
Place the power base on an appropriate surface (level, dry, water-resistant and heat-resistant).
During operation, always keep the appliance away from other objects: leave at least 20 cm of
free space on each side and 1 m of free space above the appliance. Ensure, that the power
base will not tilt or wobble.
2. Fill with pure drinking water.
Press the opening button to open the lid. Fill with the desired amount of water. Always fill the
kettle between the minimum (500) and maximum marks (1700/MAX) on the water gauge.
• Too little water will result in the kettle switching OFF before the water has boiled.
• Filling above the maximum mark on the water gauge of the kettle may result in boiling
water splashing from the kettle.
18
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 18

WARNING! Do not overfill the water container beyond the maximum water level mark
1700/MAX (1.7 litre). Otherwise boiling water could splash from the kettle during operation,
causing injuries to persons and damage. Only use clear water without any ingredients. Dry
spilled water immediately.
3. Ensure, that the lid is locked firmly into place and place the kettle onto the power base.
The electric contacts of the multi-directional power base will slide into a corresponding opening
in the bottom of the kettle. The power base will work out in any orientation.
NOTE: Always keep the lid closed during operation. Otherwise power consumption increases
significantly.
CAUTION! Only with the lid closed, the kettle automatically switches OFF, once the water has
boiled.
4. Plug the power cord into a 230/240V power outlet and switch ‘ON’ (‘green’ position). The
power ‘ON’ light and the water gauge will illuminate and the heating element starts heating.
WARNING! The exterior of the kettle will get very hot during operation and even some minu-
tes after switching ‘OFF’ the appliance. In addition, beware of steam venting from the lid and
spout and hot condensate, especially when opening the lid or pouring out water. Always keep
your hands, face and arm as well as any clothing and other objects away from the lid and
spout of the kettle. Always use the soft grip handle for moving the kettle and take care to keep
the kettle level to avoid boiling water pouring out unintentionally.
Note: The kettle will automatically switch ‘Off’ once the water has boiled and a bell rings, but
the automatic switching off only works out with the lid closed.
5. Lift the kettle by the handle from the power base and pour the water. When moving the kett-
le, ensure to hold the kettle level, especially when filled to the maximum level.
NOTE: Use caution when pouring boiling water from the kettle. Do not pour the water too
quickly, as boiling water could splash.
6. To reboil, it may be necessary to wait for about 1 or 2 minutes to allow the kettle to cool
down and the control to reset.
7. Switch OFF the kettle (power switch position ‘red’) and unplug the power connector. Pour
out any remaining water.
Do not leave remaining water cool down to room temperature in the kettle to avoid any exces-
sive accumulation of mineral deposits on the interior of the water container and water gauge.
The kettle may be stored on its power base, when not in use to protect the connector pins from
dust and splashes. The power switch must be switched ‘OFF’ and the appliance must be unplug-
ged from the power supply, when not in use.
WARNING: Always switch OFF the kettle and unplug from power supply,
when the kettle is not in use, to avoid risk of fire and electric shock. DO NOT
leave the power base unattended with the power plug connected to the
power supply.
19
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 19

Dry-out Protection
If there is not enough water in the kettle during operation, the boil dry cut-out switches off the
heating element automatically. To reset the appliance:
1. Switch OFF the kettle and wait some minutes for the heating elements to cool down. Then
press the opening button to open the lid and slowly fill with water. Always keep the water level
between the minimum and maximum water level mark (500 to 1700/MAX) during operation.
2. Close the lid, replace the kettle on the power base and switch on the kettle.
For additional safety your kettle is fitted with an additional thermal cut out. In the event of over-
heating, the kettle will automatically shutdown to prevent further damage. In this case, take your
kettle to an authorised service centre for inspection and repair.
WARNING: Do not attempt to operate the appliance after shutdown by the thermal cut out.
Any maintenance, repair and operation other than described in these instructions must be per-
formed at an authorised service centre to avoid risk of electric shock, fire or injuries to persons.
Care and Cleaning
WARNING! Always switch OFF (‘green’ position), unplug and let the appliance cool down
before removing the mesh filter, moving the power base or cleaning the appliance.
CAUTION! To avoid damage, do not use any chemicals, disinfectants, steel wool, abrasive
cleaners or hard or sharp utensils to clean the appliance. Handle with care. Do not place or
immerse the kettle base, power base or power cord in any liquids. Do not spill any liquids
on the kettle base, switch area, power base or power cord.
Do not place the kettle or power base in an automatic dishwasher.
Removable Stainless Steal Filter Mesh
The Design Kettle features a removable mesh filter to filter out scale deposits for clearer water.
Additionally the filter will prevent boiling water from splashing, when you pour the water. Clean
the filter regularly to avoid blockage of the mesh.
CAUTION: Handle the stainless steal filter mesh with care. Do not scratch, scrub or scrape on
the filter mesh with hard or sharp utensils to avoid damage.
1. Switch off and unplug the appliance and allow to cool down. Press the opening button to
open the lid. Grasp the grey bar of the mesh filter and lift it up and out of the kettle.
2. Clean the mesh filter.
Rinse the filter under running water. Possibly use a plastic cleaning brush or sponge. If the mesh
is blocked with lime: leave the filter overnight in warm vinegar. Carefully rinse with clear tap
water.
3. To replace the filter, simply slide the filter in the correct orientation down into the slots behind
the spout of the kettle (see Features of Your Design Kettle).
Push the filter down, until the grey bar is in line with the brim of the kettle and the lid of the kett-
le can be shut tightly.
20
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 20

Cleaning the kettle
In normal case there is no need to clean the interior of the kettle. Before first use or after a lon-
ger period of storage rinse the interior of the kettle with clear drinking water. However, depen-
ding on the water hardness in your residential area you should decalcify the water container
regularly to avoid any loss of performance and excessive power consumption. See Decalcifying
the Water Container.
WARNING: Immediately wipe off condensate or spilled water. Do not spill any liquids on the
appliance. Do not immerse the kettle base, switch area, power base or power cord in water to
avoid risk of electric shock. Always keep the table or counter clean and dry and immediately
wipe off spilled liquids or condensate.
Do not place the appliance or any part of it in an automatic dishwasher.
1. Wipe the outside of the kettle with a damp cloth. In the same way, the power base may be
cleaned. Make sure not to spill or drip any liquids on the power base.
2. Dry with a soft dry cloth. Polish the stainless steel parts with a soft cloth, when required.
Decalcifying the Water Container
CAUTION: Never use abrasive cleaners, any chemicals, disinfectants, cleaning pads or any
sharp utensils (i.e. metal scouring pads) for cleaning. Handle the kettle and power base without
violation. Never place the appliance or any part of it in an automatic dishwasher.
Depending on the water hardness in your residential area, mineral deposits build up in the
water container, causing decolouration and increasing energy loss. Therefore we recommend
to decalcify the water container regularly.
1. Combine ca. 400 to 500 ml vinegar and 800 to 1000 ml water, fill this solution in the kett-
le and boil. Make sure, the room is well ventilated.
2. Switch OFF and unplug. Allow to stand overnight.
3. Empty the solution from the kettle. Fill the kettle with clean water to water level mark
1700/MAX, bring to boil and discard the water.
4. Thoroughly rinse the interior of the water container with clear water. After that the kettle will
be ready for use.
21
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 21

Storage
Store the entire appliance (including the power base and operating instructions) on a clean and
dry surface, where it may not tilt or fall and no other objects could fall on it and where it is safe
from frost and inadmissible strain (mechanical or electric shock, heat) and where it is out of
reach of young children. Do not place any hard or heavy objects on the appliance or any parts
of it.
Always switch OFF the kettle and unplug the power base, when the appli-
ance is not in use.
Empty remaining water and place the kettle on the power base to protect the connector pins in
the power base from dust.
When the appliance is not in use for a long period of time, decalcify the interior of the water
container (see Decalcifying the Water Container). When required, wind the power cord round
the cord storage in the bottom of the power base.
Notes for disposal
Dispose of the appliance must be effected in accordance with the corresponding local regula-
tions and requirements for electrical appliances. Please contact your local disposal company.
22
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 22

GASTROBACK GmbH
Gewerbestraße 29
D-21279 Hollenstedt/Germany
http://www.gastroback.de
E-Mail: [email protected]
42413_Manuel.qxd 31.01.2005 17:24 Uhr Seite 24
