Gateway WGR-250 User manual

User Guide
Gateway Wireless-G Access Point/Router

i
www.gateway.com
Contents
1 The Gateway Wireless-G Access Point/Router . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 Setup for Typical Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the setup wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Where to go from here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Initial Setup for Advanced Users. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Contacting and configuring the access point/router . . . . . . . . . . . . . . . . . . . . . . . . 13
Contacting the access point/router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Configuring the access point/router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Where to go from here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4 Setting Up Windows Ethernet Networking . . . . . . . . . . . . . . . . . . . . . . 25
Naming the computers and the workgroup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Naming the computers and the workgroup in Windows XP . . . . . . . . . . . . . . . 26
Naming the computers and the workgroup in Windows 2000 . . . . . . . . . . . . . 32
Naming the computers and the workgroup in Windows Me or Windows 98SE 33
Configuring the TCP/IP protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Configuring your computer for DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Wireless operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Setting up a network (WEP) key in Windows XP . . . . . . . . . . . . . . . . . . . . . . . 40
Setting up a network (WEP) key in Windows 98SE, Windows 2000, or Windows Me 41
Where to go from here . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5 Using Your Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Sharing an Internet connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting up Internet Explorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Accessing the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Sharing drives and printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Turning on file and printer sharing in Windows XP or Windows 2000 . . . . . . . 50

ii www.gateway.com
Turning on file and printer sharing in Windows Me or Windows 98SE . . . . . .51
Sharing drives or folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Un-sharing drives, folders, and files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Sharing printers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Using the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Viewing shared drives and folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Mapping a Network Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Opening files across the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Copying files across the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Printing files across the network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
6 Routine Access Point/Router Settings and Status. . . . . . . . . . . . . . .59
Using access point/router settings and features . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Restoring the access point/router’s default settings . . . . . . . . . . . . . . . . . . . . .60
Upgrading the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Changing default access point/router settings . . . . . . . . . . . . . . . . . . . . . . . . .63
Access point/router status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
7 Advanced Configuration and Settings. . . . . . . . . . . . . . . . . . . . . . . . . . .67
Setting up security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Establishing an access point/router security scheme . . . . . . . . . . . . . . . . . . . .68
Advanced settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Changing data transmission settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Setting up filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Setting up port forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Setting up the routing mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Setting up static routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
8 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Determining network connections and IP addresses . . . . . . . . . . . . . . . . . . . . . . .86
Setting a static IP address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Problem resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Automated troubleshooting system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Telephone numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
A Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Terms you should know . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
B Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104

iii
www.gateway.com
C Safety, Regulatory, and Legal Information . . . . . . . . . . . . . . . . . . . . . 105
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

iv www.gateway.com

Chapter 1
1
TheGatewayWireless-G
AccessPoint/Router
■Product features
■Safety
■Package contents
■Connectors and LEDs

2
Chapter 1: The Gateway Wireless-G Access Point/Router
www.gateway.com
Features
Your Gateway wireless access point/router features:
■Compact, modern design
■High speed (55 Mbps in the 2.4 GHz band - 802.11g)
■Downward compatibility to the 802.11b wireless LAN standard (11 Mbps data rate)
■Remote administration and firmware upgrades through the Internet
■DHCP service to your network
■Sophisticated security features, including 128-Bit network (WEP) encryption, Web and
port filtering, WAN request blocking, and DMZ hosting
■Virtual Private Networking (VPN) over the Internet (with IPSec, L2TP, and PPTP
pass-through)
Importantsafeguards
Precautions
■Do not place your wireless access point/router in direct sunlight or near a heat source,
as this may damage the housing or electronic components of the device.
■Do not open or try to repair the device yourself.
■Do not place your wireless access point/router in a damp or excessively humid location,
such as a bathroom.
■To avoid possible electrical damage due to lightning or power surges, use a shielded,
surge protector.
■To avoid possible damage due to lightning, turn off and unplug the access point/router
during electrical storms.
Caution Do not attempt to remove the cover. There are no
user-serviceable parts inside. Removing the cover voids
the warranty.
Have your wireless access point/router repaired by
qualified service personnel only.

3
Package contents
www.gateway.com
Packagecontents
Along with your wireless access point/router, the package also containsthe following items:
■Power supply
■Ethernet cable
■CD containing Gateway Wireless-G Access Point/Router Setup Wizard and Gateway
Wireless-G Access Point/Router user guide
■Gateway Wireless-G Access Point/Router setup poster
Partsandaccessories
The following additional parts and accessories may be helpful in setting up your wireless
network:
■Wireless network controller cards (for desktop computers or notebooks)
■RJ-45 (Cat-5) network cables (various lengths)
Contact Gateway for information on ordering these and other accessories.

4
Chapter 1: The Gateway Wireless-G Access Point/Router
www.gateway.com
Front
LED Description
Power Off - The access point/router is turned off.
On (red) - The access point/router is turned on.
Blink (red) - After a firmware upgrade this LED will blink for the first minute.
Wireless Flashing (orange) - The wireless connection is operating.
WAN Flashing (orange) - Indicates activity on the Internet link.
LAN 4-1 Off - The connection does not have an Ethernet link.
On (green) - An Ethernet link has been detected on the indicated connection.
Flashing (green) - Data traffic is occurring on the indicated connection.

5
Back
www.gateway.com
Back
Connector/component Description
Antenna Sends and receives signals from wireless Ethernet computers and
devices.
Reset switch Press and hold the reset switch for 10 seconds to return all
configuration settings to the default.
LAN ports Connect a computer, hub, or switch to these RJ-45 Ethernet ports.
WAN port Connect the DSL or cable modem to this RJ-45 Ethernet port.
-OR-
If you are adding this access point/router to an existing network that
has a router, connect the LAN port from the existing router to this
RJ-45 Ethernet port.
Power connection Plug the AC adapter into this connection. Use only the AC adapter
that came with the wireless access point/router. Use of any other
AC adapter may damage your access point/router and void the
warranty.
Antenna Antenna
Reset switch
WAN Port Power connectionLAN Ports

6
Chapter 1: The Gateway Wireless-G Access Point/Router
www.gateway.com
Gettingstarted
If you are a typical user that wants to set up and use the wireless access point/router and
adjust the basic security settings, go to “Setup for Typical Users” on page 7.
If you are an advanced user that wants to set up and use the wireless access point/router
and adjust the advanced security settings or use advanced features such as router security
schemes, access authentication, and port forwarding, go to “Initial Setup for Advanced
Users” on page 11.

Chapter 2
7
SetupforTypicalUsers
■Preparation
■Using the wizard

8
Chapter 2: Setup for Typical Users
www.gateway.com
Preparation
If you intend to use the access point/router to connect your network to the Internet, you
need a broadband Internet connection (DSL or cable). You also need the following
information and equipment:
■A host computer (initially connected to the broadband modem or to a pre-existing
router) that has a network interface card
■An RJ-45 Ethernet cable (Cat-5 or better)
■A DSL or cable modem (purchased or provided by your ISP)
■Host computer’s IP address (assigned by your ISP, if a static IP address is required)
■Subnet mask (assigned by your ISP, if a static IP address is required)
■Default gateway (assigned by your ISP, if a static IP address is required)
■Primary DNS IP address (assigned by your ISP, if a static address is used)
■Host computer’s name and workgroup (available through the Windows Control Panel
under System information)

9
Using the setup wizard
www.gateway.com
Usingthesetupwizard
To set up the access point/router using the wizard:
1Insert the CD into the disc drive on the computer attached toyour broadband modem.
If the The Gateway Wireless-G Access Point/Router Setup Wizard opens, go to Step 5.
- OR -
If the wizard does not start automatically, go to Step 2.
2Click Start, then click Run. The Run dialog box opens.
3In the Open text box, type d:\WGR250.exe (where dis the drive letter of your disc
drive).
4Click OK. The Gateway Wireless-G Access Point/Router Setup Wizard opens.
5Click Setup. Read and follow the instructions on each wizard screen. When you have
completed using the wizard, you are ready to use your network.
Important For more information about using the Gateway Wireless-G
Access Point/Router Setup Wizard, see the Gateway
Wireless Access Point/Router setup poster.

10
Chapter 2: Setup for Typical Users
www.gateway.com
Wheretogofromhere
Now that you have your access point/router configured, it is time to configure your
computers to use it. Go to “Setting Up Windows Ethernet Networking” on page 25.

Chapter 3
11
InitialSetupforAdvanced
Users
■Preparation
■Contacting and configuring the access
point/router

12
Chapter 3: Initial Setup for Advanced Users
www.gateway.com
Preparation
If you intend to use the access point/router to connect your network to the Internet, you
need a broadband Internet connection (DSL or cable). You also need the following
information and equipment:
■A host computer (initially connected to the access point/router) that has a network
interface card
■An RJ-45 Ethernet cable (Cat-5 or better)
■A DSL or cable modem (purchased or provided by your ISP)
■Host computer’s IP address (assigned by your ISP, if a static IP address is required)
■Subnet mask (assigned by your ISP, if a static IP address is required)
■Default gateway (assigned by your ISP, if a static IP address is required)
■Primary DNS IP address (assigned by your ISP, if a static address is used)
■Host computer’s name and workgroup (available through the Windows Control Panel
under System information)
Connectingthehardware
To connect the hardware:
1Turn off and unplug the host computer, the DSL or cable modem, and the access
point/router.
2Using an RJ-45 Ethernet cable (Cat-5 or better), connect the Ethernet port of the host
computer to the LAN 1 connection on the back of the access point/router. You can
also connect as many as three additional computers to the access point/router if you
plan to use the access point/router in wired mode. To connect more than four
computers to your network in wired mode, connect them to a hub or switch, then
connect the hub or switch to one of the LAN ports on the access point/router. This
is not required in wireless mode.
3Using an RJ-45 Ethernet cable (Cat-5 or better), connect the Ethernet port of your
DSL or cable modem to the WAN connection on the back of access point/router.
4Plug the AC adapter into an electrical outlet. Connect the other end of the adapter
to the power connector on the back of the access point/router. For more information,
see the illustration on page 5.
■The red Power LED turns on
■The Wireless LED starts blinking

13
Contacting and configuring the access point/router
www.gateway.com
5Turn on the DSL or cable modem. Check the LEDs on the modem to make sure that
the modem is connected and operating normally. The WAN LED on the access
point/router lights when the modem is connected correctly to the access point/router.
6Turn on the host computer. The LAN LED corresponding to the RJ-45 jack used for
the LAN connection on the access point/router lights to when the computer is
connected correctly to the access point/router.
Contactingandconfiguringtheaccess
point/router
Now that all the hardware connections have been made, you must configure the access
point/router to operate on your network and to connect to the Internet through an ISP.
Initial configurations vary somewhat, depending on your ISP. Contact your ISP, before you
configure your access point/router, and determine the following:
■If your ISP assigns a static IP address or provides one automatically (DHCP) each time
you connect to the ISP
■For an automatic IP address, the Host Name (if required) and the Domain Name (if
required)
■For a static IP address, the IP address, subnet mask, default gateway, and DNS address
(at least one)
■If you are connected with a DSL modem using Point-to-Point Protocol over Ethernet
(PPPoE), or if your ISP requires a user name and password, the user name and password
you need to use
■If your ISP uses RAS (Singapore) or PPTP (Europe), instructions for setup
Caution Use only the AC adapterand power cord provided with the
access point/router. Use of any other adapter or power
cord may damage your access point/router and void your
warranty.
Important If you are not comfortable with the procedures covered in
this section, use the Gateway Wireless-G Access
Point/Router Setup Wizard. For more information, see
“Setup for Typical Users” on page 7.

14
Chapter 3: Initial Setup for Advanced Users
www.gateway.com
Contactingtheaccesspoint/router
To contact the access point/router:
1Open your Web browser on the host computer.
2In the address field, type 192.168.1.1, then press ENTER. The Connect to dialog box
opens.
3Type admin in the User name box.
