GAYLORD ClearAir RSPC-TPF-PCV Series Installation and operating instructions

Revision 3
TECHNICAL MANUA L
FOR I N ST A LL A TIO N ,
OPERATION AND
MA
I N TE NANC E
OF
THE GAYLORD "ClearAir™ "
MODEL "RSPC-TPF-PCV" S ER IES
DUCT MOUNTED
POLLUTION
CONTROL UN ITS
W ARN I N G
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
Only trained and qualified service personnel should install or
service this equipment.
10900 S.W. AVERY STREET • TUALATIN, OR 97062 USA
PHONE: [phone] • TOLL FREE: 800-547-9696 • FAX: [phone]
email: [e-mail] • www.gaylordventilation.com

GAYLORD I ND U S T R I E S
World Headquarters: 10900 S.W. Avery Street • Tualatin, Oregon 97062 U.S.A.
To Our Customers. . .
Congratulations on your recent purchase of a Gaylord
ClearAirTM Pollution Control Unit. We are proud to be able
to provide you with a quality product that exemplifies our
long-standing dedication to quality engineering.
Your unit is assembled from some of the very finest
components available and is designed for years of
efficient, effective, and trouble-free operation. In addition,
this unit has undergone rigorous quality control
inspections and was fully operationally tested prior to
shipment.
If you have further questions, please contact us toll free at
1-800-547-9696, or [e-mail]. We
are more than happy to help.
Sincerely,
Gaylord Industries
STREET ADDRESS: 10900 S.W.Avery Street, Tualatin, Oregon 97062-8549 U.S.A.
PHONE: [phone] • 800-547-9696 • FAX:[phone] • email: [e-mail] • www.gaylordventilation.com
COMMERCIAL KITCHEN EXHAUST SYSTEMS • FIRE PROTECTION • UTILITY DISTRIBUTION •POLLUTION CONTROL
1|PAGE

TECHNICAL MANUA L
FOR I N ST A LL A TIO N ,
OPERATION AND
MA
I N TE NANC E
OF
THE GAYLORD “ClearAir™”
MODEL “RSPC-TPF PCV”
SE R IES POLLUTION
CONTROL UN IT
Published by: GAYL O RD I NDU ST R IES
Tualatin, Oregon 97062
U .S.A.
First Printing: Feb 2018
© Copyright 2020, Gaylord Indu str i es
ALL RIGHTS RESERVED. NO PART OF THIS BOOK MAY BE REPRO-
DUCED, STORED IN A RETRIEVAL SYSTEM, OR TRANSMITTED IN ANY
FORM BY AN ELECTRONIC, MECHANICAL, PHOTOCOPYING, RECORD-
ING MEANS OR OTHERWISE WITHOUT THE WRITTEN PERMISSION
OF GAYLORD INDUSTRIES. ©2020.
The manufacturer reserves the right to modify the materials and specifications resulting from a continuing
program of product improvement or the availability of new materials.
Additional Copies $25
. 00
GAYLORD I
NDU ST R IES
10900 S.W. Avery Street, Tualatin, Oregon 97062
2|PAGE

TABLE OF CONTENTS
RECEIVING & INSTALLATION ............................................................................ 5
HORIZONTAL INSTALLATION GUIDELINES ....................................................... 6
VERTICAL INSTALLATION GUIDELINES ............................................................. 7
SERVICE AND MAINTENANCE......................................................................8
REPLACING FILTERS AND MEDIA PANELS.................................................9
WARRANTY………………………………………………………Inside Back Cover
3|PAGE

RECEIVING & INSTALLATION
RECEIVING
Most ClearAir™units are shipped in one piece. However, some
units, because of size or special jobsite conditions, may be
shipped in multiple sections. Follow the instructions that are
provided with the unit to join sections back together. If the unit
includes media bed odor control, the KOR48/carbon odor
control media is packaged separately. Verify against the
shipping documents that you have received all items and note
any shipping damage, obvious or hidden, to your carrier and
on your Bill of Lading. If damage is found, immediately file a
claim with the transport company. All units are thoroughly
inspected and fully operation tested at the factory prior to
shipment.
Verify that the electrical and air flow ratings on the unit name
plate agrees with jobsite requirements. If a contradiction arises
notify the factory prior to proceeding with installation.
SAFETY CONSIDERATIONS
Installing and servicing the ClearAir™ unit can be hazardous
due to the presence of electrical components. Only trained
and qualified service personnel should install or service this
equipment.
Untrained personnel can perform basic maintenance, such
as cleaning and replacing filters. All other operations should
be performed by trained service personnel. When installing or
servicing, observe precautions in literature and on tags and
labels attached to unit.
Follow all safety codes. Wear safety glasses and work gloves.
Use quenching cloth for brazing operations. Have fire
extinguisher available. Read these instructions thoroughly.
WARNING
Before installing or servicing system, always turn off main
power, exhaust and supply fans to system. There may be
more than one disconnect switch. Electrical shock can cause
personal injury or death.
RIGGING
All units are provided with a minimum of four (4) lifting points,
or (2) continuous mounting flanges for rigging attachment.
WARNING: Use all lifting points provided (Refer to Page 10).
Spreader bars are mandatory to prevent contact and damage
to the unit by lifting hooks, straps, cables, or chains. Consult the
mechanical or structural engineer before moving the unit
across the roof deck. Hanging weight is 375 lbs. for the 1x1
and 540 lbs. for the 2x1.
INSTALLATION CODES
This unit requires external plumbing and electrical connections
to be made in the field. It is recommended that the Authority
Having Jurisdiction (AHJ) be consulted regarding local codes
and installation procedures. Gaylord Industries is not
responsible for obtaining necessary approvals and permits
which may be required for installation, nor is it responsible for
verifying that the unit has been installed in accordance with
national, state, and local codes. In the absence of locally
adopted codes use the latest editions of the national electrical
code and the uniform/International mechanical code.
Connections of the exhaust duct to the inlet and outlet of the
ClearAir™ unit must be fully welded to comply with NFPA-96.
INSTALLATION PRECAUTIONS
1. The services of qualified contractors are essential for safe
and proper installation of this equipment.
2. The air volumes and external static pressures that are
listed on the unit are for the middle of the operating range of
the filters. The initial air volume should be at least 10% higher
than the listed CFM. As the filters load up the air volume will
drop. This is inherent to this type of unit. If the unit is set up
at or below the design CFM, as the filters load up, the kitchen
hood may experience smoke loss problems. Please consult
the factory if you have questions.
3. The unit is designed for installation on a level surface.
4. When installed in an enclosed space a fire-rated
enclosure may be required for the unit and associated duct
work. Consult the Authority Having Jurisdiction.
5. Consult the Authority Having Jurisdiction (AHJ) regarding
requirements covering the point of termination of the exhaust
outlet of this unit. Minimum distances must usually be
maintained between the exhaust outlet and any outside air
intakes and/or adjacent structures or property lines.
6. Do not apply power to the unit until all electrical
connections have been made and a pre-start-up
preliminary inspection has been completed.
7. Allow a minimum of 36 inches clearance in front of the
filter access door and electrical compartment door for ser-
vice and routine maintenance.
SHORT TERM STORAGE
Units that include media bed odor control are provided with
KOR48/carbon media which is shipped separate from the
unit. KOR48/carbon media must be stored in a dry place with
less than 95% relative humidity.
LONG TERM STORAGE (OVER ONE MONTH)
Units must be covered and stored in a warm dry location to
prevent excess moisture from accumulating in the odor media
and final filters.
4|PAGE

EQUIPMENT INSTALLATION – HORIZONTAL MOUNTING
5|PAGE

THIS PAGE INTENTIONALLY LEFT BLANK
6|PAGE

ODOR CONTROL SECTION – MEDIA BED TYPE
General Description
ClearAir™ units are comprised of a UL 900, MERV 16 final
filter and a Potassium Permanganate/activated carbon
blended module.
Service and Maintenance
The Potassium Permanganate / carbon media is deep purple
in color when new, turning to a dark brown during use and
light tan when expended. To verify the life of the media,
inspect the panels at scheduled service intervals consistent
with the final filter change outs. For additional information
contact Green Ladder at 630-457-1872.
Ordering New Media Panels:
Green Ladder Technologies, LLC
1502 Louis Bork Drive
Batavia, IL 60510
Email: [e-mail]
Phone: [phone]
Gaylord Odor Control System Components
Filters
Smoke control filters in the odor control section of the system
require replacement prior to them becoming loaded. It is
recommended that the filters be inspected in accordance
with the “Odor Control Media Inspection Frequency Chart”
on this page, and replaced when necessary. Note that failure
to maintain the final filter will accelerate the degradation of
the odor media, thus a regular schedule of change outs
needs to be established.
Replacement filters can be purchased through Gaylord
Industries’ partners Parts Town or Heritage Parts.
Filter replacement part number:
Airguard MPN VPL-0495-DOP. Filter replacements are
dimensionally 24x24x12. See ref 1.
Applications servicing solid fuel cooking equipment require
MICRO GUARD 95 MH-2958971/M2323B33-0EA750300
replacement filters. See ref 2.
Symptoms of excessive filter loading will be evident from a
lack of capture performance experienced at the kitchen
hood(s). Systems equipped with the Gaylord AirVantage will
compensate for filter loading and issue a YELLOW service
alert at the AirVantage command center when the filters are
ready to be replaced.
7|PAGE

Ref. 1 – Air Guard Vari-Plus filter. To be
used on all applications except solid fuel.
Ref. 2 – MICRO GUARD 95 MH Filter used for
systems serving solid fuel.
ODOR CONTROL SECTION – MEDIA BED TYPE
8|PAGE

ODOR CONTROL SECTION – MEDIA BED TYP
Replacing the Media and Filters
CAUTION - each odor module weighs approximately 28
lbs. and may be awkward to handle particularly when
accessing the unit from overhead. It is highly
recommended that a heavy-duty steel wheeled ladder be
used when removing modules when located overhead.
Utilize (2) technicians where possible to safely remove and
shuttle modules to an area where service can be
performed.
CAUTION - Exhaust fan must be off before opening the
odor control media access door.
Replacing the media is a relatively simple task not requiring
any special tools. Follow steps 1-11:
Step 1. Deactivate the exhaust fan utilizing the C-7000
Command center, AirVantage, or wall fan
switch. Locate and turn the exhaust fan
disconnect to prevent the fan from turning on
during service.
Step 2. Provide safe sturdy access to the odor control
module.
Step 3. Pull tee-handles on each side of the access
cover. Remove access cover and securely set
aside. Inspect access panel gaskets and
replace as necessary. CAUTION: Store access
cover in a location where it will not be
susceptible to damage or falling onto staff or
other equipment.
Step 4. Remove and Inspect final filter.Note filter(s)
slide in and out of the unit through a rack.
Replace as necessary. Replacement is
required when: 1) Back side of filter is
contaminated 2) AirVantage Yellow Alert is
present at the Command Center 3) hood(s)
starts to perform poorly (Smoke Loss).
Step 5. Odor Media Panels: Carefully slide the panels
out of the unit.
Step 6. Lift the locking clip as shown below.
Step 7. Lift out both Media Panels as shown below.
Step 8. Slide in the new Medial Panels making sure the
label stating “Inlet Side” is facing out. The two
stiffening rods on the back of the panel should
be facing the inside of the “V”. Note the foam
seal will be on the top side of the V.
Step 9. Place the Media Panels back in the unit with
the sharp end of the “V” as shown below.
Step 10. Confirm all filters and media panels are in
place. Replace odor media access panel.
Secure in place with the tee-handles. Confirm
a good seal has been established.
Step 11. Dispose of the used Media Panels.
ODOR CONTROL SECTION – MEDIA BED TYPE
9|PAGE

LIMITED WARRANTY
THE GAYLORD ClearAir™ POLLUTION CONTROL UNIT
LIMITED WARRANTY
The Gaylord ClearAirTM
Pollution Control Unit is warranted by GAYLORD INDUSTRIES to be free from
defects of material and workmanship under normal use when installed, operated and serviced in
accordance with factory recommendations.
GAYLORD INDUSTRIES’ obligation under this warranty shall be limited to repairing or replacing at its
option any part of said equipment which GAYLORD INDUSTRIES examination shall disclose to its
satisfaction to be thus defective, for a period of one (1) year from the date of installation provided proper
and acceptable evidence of such installation is recorded at the factory, or 18 months from date of
shipment which - ever occurs first.
GAYLORD INDUSTRIES SHALL NOT BE RESPONSIBLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM A BREACH OF THIS WARRANTY.
All replacement parts furnished under this warranty shall be .F.O.B. Gaylord Industries of Tualatin,
Oregon. The owner shall pay the necessary freight delivery charges, and necessary labor for
removal and installation of parts, and any federal, state or local taxes.
SPECIFIC ITEMS NOT COVERED BY THIS WARRANTY:
1. Fan belts if equipped with an exhaust fan.
2. Pre-filters, bag filters, final filters, after filters, and KOR48/carbon media if equipped with odor
control.
3. Routine maintenance and cleaning as spelled out in The Gaylord ClearAir™ Model OCU-FF Series
Unit Technical Manual.
4. Malfunction or improper operation caused by fluctuating electrical or power surges or improper
installation.
This is the sole warranty with respect to the aforesaid items. NEITHER GAYLORD INDUSTRIES
OR ANY OTHER PARTY MAKES ANY OTHER WARRANTY OF ANY KIND WHATSOEVER,
EXPRESSED OR IMPLIED, AND ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE WHICH EXCEED THE AFORESAID
OBLIGATIONS ARE HEREBY DISCLAIMED AND EXCLUDED FROM THIS AGREEMENT.
10|PAGE

FORM NO.TM RSPC-TPF-PCV 23188 032020 ©2020 GAYLORD INDUSTRIES LITHO USA
