Oreck DualMax User manual

DualMax
Air Purier
™
Important!
Read this manual
carefully, and
keep for future
reference.
User’s
Guide

Congratulations on your purchase of the Oreck DualMax™ air
purier. Use this manual to learn the features, operation and
maintenance of the Oreck Air Purier.
Welcome to our Call. Click. Visit. customer service program.
To contact Oreck:
Enjoy
1
Click
Visit
Call
Other Oreck accessories available at:
Other Oreck accessories available at:
Other Oreck accessories available at:
USA: 1•800•989•3535
Canada: 1•888•676•7325
www.oreck.com
Visit one of our many Oreck store locations

Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General Warnings........................3
Placement Warnings ......................4
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Operation.................................7
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning Intervals . . . . . . . . . . . . . . . . . . . . . . . 8
Cleaning the Pre-Filter ....................9
Cleaning the Truman Cell®.................9
Drying the Truman Cell® ....................11
Dry Operation Mode........................11
Cleaning the Exhaust Grille ..................12
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Spanish ................................. 15
French .................................. 30
2

Safety
3
!
General Warnings
• Do not operate unit if cord or plug is damaged. Doing so can
result in electric shock. Discard the damaged unit or take it to
an authorized service facility for examination and/or repair.
USA: 1•800•989•3535 Canada: 1•888•676•7325
• Do not run cord under carpeting. Do not cover cord with throw
rugs, runners, or similar coverings. Do not route cord under
furniture or appliances. Arrange cord away from traffic area
and where it will not be tripped over.
• Only use the air purifier as described in this manual.
• Donothandletheunitwithwethands.Thoroughlydryyour
hands before handling any part of the air purifier.
• Hair,looseclothingandbodypartscangetcaughtinthe
machine resulting in injury. Keep hair, loose clothing and body
parts away from openings and moving parts.
• Donotunplugbypullingonthecord.Doingsomayresultin
electrical spark or fire. Unplug the unit by grasping, and pulling
the plug.
• Donotuseanextensioncord.
• Donotplacetheairpuriernearsourcesofheat,suchas:
stove tops, ovens, radiators or computers.
• Unplugtheappliancefromthepowersupplybeforecleaning.
• Thisequipmentshouldbeinspectedfrequentlyandthedirt
that has collected should be removed regularly to prevent
excessive accumulation that may result in flashover or fire.
•Caution:HighVoltage
•Donotdefeatinterlock.
• Donotusetheairpurieroutdoorsoronwetsurfaces.
!
WA R NI NG :Toreducetheriskofre,electricshockorinjury,
read and understand this user guide before operating this appliance.
Cleaning the unit while it is plugged in may
result in electric shock, electric spark and
serious injury. Unplug the unit before cleaning or
maintenance.
IMPORTANT SAFETY
INSTRUCTIONS

4
•Donotusetheairpurierinanenclosedspacewhereammable,
combustible or explosive gases are present.
•Donotuseinanareawheretoxicvapors,ammabledustor
oxygen tanks are present. Check the location and make sure
these elements are not present.
•Warning:ProductcontainschemicalsknowntotheStateof
California to cause cancer, birth defects, or other reproductive
harm.
• Do not place open flames, including candles, directly in front
of the air purifier.
• It is important to keep all objects away from the air intake
grille.
• Placetheairpurieronaat,solid,stablesurface.Neverplace
the unit on soft surfaces such as a bed or sofa.
• Positiontheairpuriersothatthedirtyairisnotdrawnacross
your head or body while sitting or sleeping.
• Placetheairpuriersotheplugonthepowercordeasily
reaches a standard electrical outlet for a polarized plug.
• Children should be supervised when product is in use. Do not
allow children to play on or near the air purifier. Keep children’s
hair, loose clothing, and body parts away from/out of the intake
grille, vents, holes, or openings.
• Thisproductissuitableforusewithsolid-statespeedcontrols.
READ AND SAVE THESE
INSTRUCTIONS
Note:Toreducetheriskofelectricshockthisproducthasa
polarizedplug(onebladewiderthantheother).Theplugwill
only fit in a polarized outlet only one way. If the plug does not
tproperly,reversetheplug.Ifitstilldoesnott,contactqualied
personnel to install the proper outlet. Do not alter the plug in any
way.

Features
1. Pre-Filter: Filter large particles such as dust, hair and lint.
2. Cleaning Brush: Use to clean the front and back grilles.
Stores snuggly in the compartment under the cover.
3. Odor Absorber System: This component combines advanced
catalytic technologies to reduce odors and chemical fumes
from glues, solvents, and synthetic materials when air passes
through the lter and is activated by the DualMax™ internal
lights. (The Odor Absorber System cannot be removed.)
4. Truman Cell®: Electrostatically charges and collects small
particles such as dust, smoke, pollen, mold, and fungi from
the air that passes through the lter.
5. Exhaust Grille: Directs the ow of air as it exits the unit.
6. Power Cord: Plug into the outlet to begin use.
7. Night Light: The Oreck logo on the front panel & the
indicators on the control panel will illuminate when the night
light is activated.
8. Collector Cell Light: A solid amber light is included as a
handy reminder to clean the Truman Cell after 30 days.
A blinking light indicates a malfunction that has caused
the Truman Cell® to shut down and requires attention.
9. Speed Indicator Light: The speeds will be cumulatively
indicated: 1=silent; 1+2=medium; 1+2+3=high.
10. Odor Absorber Button: This button turns the internal lights
on or off as desired. If turned off, the unit will continue to
lter particles from the air that passes through the lter but
its odor and VOC capability will be greatly reduced.
11. Motor Speed/Power Button: Press the power buttons
repeatedly for the desired speed.
• Low for Silence Technology®
• Medium for normal use
• High for maximum cleaning
12. Night Light Button: Repeatedly press this button to change
the lighting scheme to best suit your preference.
13. Front Grille: Air enters here for the rst stage of cleaning.
5

6
TRUMAN CELL
4
7
13 5
3
8
11
9
10 12
6
1
2

1
2
TRUMAN CELL
3
Operation
1. Place. Locate the air purier on a solid surface. Be sure the
grille is not blocked by other objects and there are no candles
or ames near the unit.
2. Plug In. Plug into nearest standard electrical outlet that
accepts a polarized plug.
3. Select the air cleaning speed. Press the motor speed/power
button until you reach the desired speed.
7

WARNING!
!
Cleaning
Cleaning the unit while it is plugged in may result
in electric shock, electric spark and serious injury.
Unplug the unit before cleaning or maintenance.
Cleaning Intervals
Proper care and cleaning of the air purier is critical to performance.
The following chart shows the cleaning intervals and method.
Part Cleaning
Time
Method
Cabinet As needed Wipe with damp cloth first.
If required, follow with mild,
non-abrasive cleaner.
Truman Cell®2 to 4
weeks
Spray Oreck Assail-a-Cell®
cleaner or soak in warm water or
warm water with mild liquid
detergent. Rinse and dry.
Pre-Filter 2 to 4
weeks
Rinse thoroughly in warm water
or as needed.
Air Direction
Grille
As needed Use the brush provided with the
air purier to brush away debris
in between the slots.
8

1
2
3
3
1
Cleaning the Truman Cell®
Note: The Truman Cell® may require more frequent cleaning if
“arcing” occurs. Arcing is a sharp snapping sound that occurs
when large particles are collected in the Truman Cell®. If
prolonged or continuous arcing occurs, the Truman Cell
®
should
be cleaned.
1. Unplug the air purier.
2. Open the Cover by
gently pulling from
the top corners.
3. Remove the Truman
Cell
®
by unlocking top
and bottom knobs and
pulling straight out.
4. Separate the Truman
Cell® from the Wire
Assembly for easier
access to each during
cleaning.
Cleaning the Pre-Filter
1. Unplug the air purier.
2. Open the Cover by gently pulling from the top corners.
3. Pull the Pre-Filter straight out of the Cabinet.
4. Thoroughly rinse the Pre-Filter and let it air dry before
placing it back in the Cabinet. Do not use heated or
compressed air as part of the drying process.
5. Slide the Pre-Filter back into the unit.
6. Close the Cover securely.
9

5. Place each in sink, bathtub or other location where cleaner
can cover every surface.
6. Spray Oreck Assail-a-Cell® cleaner between each Cell Plate
and cover each surface. Allow the cleaner to soak for a few
minutes but do not let it dry. Thoroughly rinse the Truman
Cell® with clean water.
An alternative method to clean the Truman Cell® is to rinse
or soak it in warm water for loose debris. Mild liquid dish
detergent in water may also be used to help break down
tough dirt and residue. Thoroughly rinse the Truman Cell®
with clean water.
Note: To prevent damage to the components of the Truman
Cell®, do not put in dishwasher or use a cotton swab.
Tough residue such as tar from tobacco smoke may need
additional cleaning or longer soaking.
7. Shake excess water from the Truman Cell® to speed up
drying time. Do not use heated or compressed air to dry.
8. Reassemble the Wire Assembly and Truman Cell® by
inserting the (4) post located on the outside edges of the
Wire Assembly into the recessed channels of the Truman
Cell®. After guiding the post into the recessed channels,
slide the Wire Assembly until it locks into place.
9. Place the Truman Cell
®
back into the unit by sliding it straight
in and turning each knob to its locking position. The Truman
Cell® is specially designed so that it can only be inserted in
one direction.
10. Close the Cover securely.
TrumanCell
10
WireAssembly
Recessed
channel
Post

Drying the Truman Cell®
Note: The Truman Cell® must be completely dry after cleaning
in order to operate properly. A drying mode is available to help
remove any residual moisture. While in this mode, the fan will
be running on Medium speed, and no power will be supplied to
the Truman Cell. Once the unit detects that the Truman Cell® is
completely dry, it will return to its original operating settings and
function as normal.
“Dry Mode” Operation
If the power supply detects that the Truman Cell® is wet, it shuts
down power to the cell and causes the Collector Cell light to blink
rapidly.
1. While the Collector Cell light is blinking, press and hold the
power button to initiate “Dry Mode”.
2. Next, the following will all happen simultaneously:
• The lights directly above and below the power button will
ash 3 times.
• The unit will switch to medium speed.
• The Collector Cell light will start to blink in a slow pattern.
3. Once in “Dry Mode”
• The unit will run for 60 minutes and then attempt to reset
the power supply to the Truman Cell®.
• If the power supply successfully restarts, the unit will
return to its original speed and run as normal.
• If not successful, it will go through the same process up
to two more times.
• If still not successful after the third try, the cell is likely
damaged or is shorting out due to the presence of a foreign
object; it will return to the original speed and the Collector
Cell light will blink with a rapid blink pattern indenitely
until the unit is reset.
11
Once in “Dry Mode”

1
2
Cleaning the Exhaust Grille
1. Remove the Cleaning Brush from the storage slot located
under the Cover.
2. Brush away debris that has collected between the Grille
Slots.
3. Return the Cleaning Brush to the storage slot.
12

Problem Check Solution
Unit does not
turn ON
• Power Cord
• Selector Switch
• Cover
• Plug in Power Cord
• Set Selector Switch for desired fan speed.
• Make sure the cover is securely closed
Truman Cell®
light has turned
solid amber.
Truman Cell®• A solid amber light is a 30 day cleaning
reminder. Wash Collector Cell. Make sure
it is thoroughly clean before reinstalling.
Truman Cell®
light is blinking
amber.
Truman Cell®• A fast blinking light indicates the power
supply has shut down due to arcing or
short circuit. The cell should be inspected
and cleaned, repaired, or replaced.
• A slow blinking light indicates the unit is
in Dry Mode.
Unit does not
remove particles.
Truman Cell®• Clean the Truman Cell®.
• Truman Cell
® may be damaged. Contact
Oreck for service.
Unit sparks,
crcrackles and
pops.
Truman Cell® • Sparking or popping noise (arcing) can occur
when a large particle is captured in the
Truman Cell®. If the unit is arcing excessively,
the cell may be dirty. Try cleaning the
Truman Cell®.
• If excessive arcing continues after proper
cleaning, the Truman Cell
®
may be damaged.
If damaged, contact Oreck for service.
Unit still does
not operate
properly.
Review all the
above.
Contact Oreck for service.
Trouble-
shooting
Service problems that appear to be major can often be solved easily.
You can be your own troubleshooter by reviewing this guide.
All other servicing should be done by an Oreck authorized
service center.
13

Warranty
ORECK MANUFACTURING COMPANY: (Oreck
Manufacturing Company gives you the following limited warranty
for this product only if it was originally purchased for residential
use, not for resale, from Oreck or an Oreck Authorized Retail
Dealer.)
Oreck will repair or replace, free of charge, to the original
purchaser, any part that is found to be defective in material or
workmanship within ve (5) years following the date of purchase
for all residential models. NOTE: If the unit is used commercially,
a one (1) year overall warranty applies.
This limited warranty does not cover the replacement of
expendable or consumable parts such as lters, cartridges, and
other parts subject to normal wear unless they are defective in
material or workmanship.
This limited warranty does not apply to any part subjected to
accident, abuse, commercial use, alteration, misuse, damage
caused by act of God, the use of voltages other than on the data
plate of this product or service of this product by other than Oreck
or a participating Factory Authorized Service Center.
Oreck does not authorize any person or representative to assume
or grant any other warranty obligation with the sale of this product.
Oreck’s limited warranty is valid only if you retain proof of
purchase from Oreck or an Oreck Authorized Retail Dealer for
this product. If you purchase this product from any other source,
your purchase is “AS IS,” which means Oreck grants you no
warranty, and that you, not Oreck, assume the entire risk of the
quality and performance of this product, including the entire cost
of any necessary servicing or repairs of any defects.
Oreck’s liability for damages to you for any costs whatsoever
arising out of this statement of limited warranty shall be limited
to the amount paid for this product at the time of original purchase,
and Oreck shall not be liable for any direct, indirect, consequential
or incidental damages arising out of the use or inability to use
this product. Some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation
or exclusion may not apply to you.
ALL EXPRESS AND IMPLIED WARRANTIES OTHER
THAN THE LIMITED WARRANTY SET FORTH ABOVE,
FOR THIS PRODUCT, INCLUDING IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE EXPRESSLY DENIED.
This warranty gives you specic legal rights, and you may also
have other rights which vary from state to state.
14

Puricador de aire
DualMax
¡Importante!
Lea cuidadosamente
este manual, y guarde
para futura consulta.
Guía del
usuario
TM

Other Oreck accessories available at:
Other Oreck accessories available at:
Felicitaciones por su compra del puricador de aire DualMax™
de Oreck. Utilice este manual para conocer las características,
manejo y mantenimiento del Puricador de Aire Oreck.
Bienvenidos a nuestro programa de servicio al cliente
“Llame. Haga clic. Visite” (Call. Click. Visit.). Para
comunicarse con Oreck:
Disfrute
Haga clic
Llame
EE.UU.: 1•800•989•3535
Canadá: 1•888•676•7325
16
www.oreck.com
Visite
Other Oreck accessories available at:
Visite una de nuestras muchas tiendas Oreck

Contenido
Seguridad ............................... 18
Advertencias generales ................... 18
Advertencias acerca de la ubicación ...........19
Características............................ 20
Manejo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Limpieza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Limpieza del Pre-Filtro ................... 24
Limpieza de la celda Truman Cell®.......... 24
Secado de la celda Truman Cell® . . . . . . . . . . . . . 26
Funcionamiento en “Modo de secado” . . . . . . . . . 26
Limpieza de la rejilla de salida ................27
Solución de problemas...................... 28
Garantía................................. 29
Francés ................................. 30
17

Seguridad
18
Advertencias generales
• Nopongaenfuncionamientolaunidadsielcableoenchufeestá
dañado.Hacerloasípodríaresultarendescargaeléctrica.Deseche
launidaddañadaollévelaaunestablecimientodeservicioautorizado
para inspección y/o reparación.
EE.UU.: 1•800•989•3535 Canadá:1•888•676•7325
• Notiendaelcabledeenergíadebajodealfombras.Nocubraelcable
deenergíaconalfombrasgrandes,tapetesnicubiertassimilares.No
coloqueelcabledesuministrodeenergíadebajodemuebleso
aparatos.Coloqueelcablealejadodelasáreasdetránsitoyenun
lugardondeéstenocausetropezones.
• Sóloutiliceelpuricadordeairesegúnsedescribeenestemanual.
• Nomanipulelaunidadconlasmanoshúmedas.Sequecompletamente
susmanosantesdemanipularcualquierpartedelpuricadordeaire.
• Elpelo,laropaholgadaycualquierpartedelcuerpopuedenser
atrapadosporlamáquinayproducirlesiones.Mantengaelpelo,la
ropa holgada y las partes del cuerpo alejados de las aberturas y piezas
móviles.
• Nohaleelcableparadesenchufarlaunidad.Hacerloasípodría
producirchispaeléctricaoincendio.Desenchufelaunidadagarrando
y halando el enchufe.
• Noutilicecabledeextensión.
• Nocoloqueelpuricadordeairecercadefuentesdecalor,tales
como: estufas, hornos, radiadores o computadoras.
• Desconecteelaparatodelafuentedealimentaciónantesdelimpiarlo.
• Esteequipodebeinspeccionarsefrecuentementeylasuciedadque
se haya acumulado debe eliminarse periódicamente para e v i t a r
acumulaciónexcesivaquepudieraresultarencombustiónsúbitao
incendio.
•Atención:AltaTensión
•Noanuleelenclavamiento
• Noutilice el puricador de aire en exteriores ni sobre supercies
mojadas.
!
ADVERTENCIA:Parareducirelriesgodeincendio,descargaeléctrica
olesiones,leayentiendaestaguíadelusuarioantesde poneren
funcionamiento este aparato.
Limpiar la unidad mientras está enchufada podría
resultar en descarga eléctrica, chispa eléctrica y lesiones
graves. Desenchufe la unidad antes de limpiar o realizar
servicio de mantenimiento.
INSTRUCCIONES DE
SEGURIDAD IMPORTANTES

19
• Noutiliceelpuricadordeaireenunespaciocerradodondeexistan
gases inflamables, combustibles o explosivos.
• Noloutiliceenunáreadondeexistanvaporestóxicos,polvoinam-
ableotanquesdeoxígeno.Reviselaubicaciónyveriquequeestos
elementosnoestánpresentes.
• Advertencia:Elproductocontienesustanciasquímicasconocidaspor
elestadodeCaliforniacomocausantesdecáncer,defectosdenacimien-
to, u otros daños en el sistema reproductivo.
• Nocoloquellamasexpuestas,incluyendovelas,directamentealfrente
del purificador de aire.
• Es importante mantener todos los objetos alejados de la rejilla de
entrada de aire.
• Coloqueelpuricadordeairesobreunasupercieplana,sóliday
estable.Nuncacoloquelaunidadsobresuperciesblandastalescomo
unacamaosofá.
• Coloqueelpuricadordeairedemodoqueelairecontaminadono
seaarrastradoalrededordesucabezaocuerpomientrasustedestá
sentado o durmiendo.
• Coloqueelpuricadordeairedemodoqueelenchufedelcablede
energíalleguefácilmenteauntomacorrienteeléctricoestándarpara
enchufe polarizado.
• Losniñosdebensupervisarsecuandoelproductoestáenuso.No
permitaquelosniñosjueguenenocercadelpuricadordeaire.
Mantengaelcabello,laropaholgadaylaspartesdelcuerpodelos
niños alejadas de/fuera de la rejilla de entrada de aire, los respiraderos,
los orificios o las aberturas.
• Este producto es apropiado para uso con controles de velocidad de
estado sólido.
LEA Y CONSERVE ESTAS
INSTRUCCIONES
Nota:Parareducirelriesgodedescargaeléctrica,esteproductotiene
unenchufepolarizado(unapataesmásanchaquelaotra).Elenchufe
sóloenchufarádeunamaneraenuntomacorrientepolarizado.Siel
enchufe no encaja apropiadamente, invierta el enchufe. Si el enchufe
siguesinenchufar,comuníqueseconunelectricistacalicadoparaque
instaleeltomacorrienteapropiado.Noaltereelenchufedeninguna
manera.
