Operating Instructions
FOR INDOOR USE ONLY
1.Turn the unit upside down and find the slot labeled HOUSE CODE.
2. Set the HOUSE CODE to any one of the following settings:
NOTE: Make sure ALL your GE Smart Remote Plus devices have the same HOUSE CODE setting. The
transmitters WILL NOT control the receivers if they have different HOUSE CODE settings.
IMPORTANT! HOUSE CODES help eliminate interference (devices randomly turn on / off).
If you experience interference, change the HOUSE CODE on all your GE Smart Remote Plus
transmitters and receivers to a different setting.
3. Keeping the unit upside down, set the CHANNEL by using the knob as shown.
NOTE: If you set your Socket Adapter to CHANNEL 1, the unit can be controlled
using any transmitter set to CHANNEL 1. If you set your Socket Adapter to
CHANNEL 2, the unit can be controlled using any transmitter set to CHANNEL 2 … and so on.
IMPORTANT! A transmitter will control a receiver ONLY if they have the same
HOUSE CODE and CHANNEL settings.
4. Screw the Socket Adapter into a powered 125VAC socket.
5. Screw the light bulb you wish to control into the Socket Adapter as shown.
The following are examples of devices you can control with your Socket Adapter:
6. Using any of the transmitters set to the same CHANNEL and HOUSE CODE, test the installation
by using the ON and OFF buttons. An indicator light on the Socket Adapter lights RED when it
receives an ON signal.
CAUTION: WHEN THE INDICATOR LIGHT IS ON, THE OUTPUT SOCKET IS POWERED.
DO NOT SCREW / UNSCREW BULBS INTO / FROM THE SOCKET ONCE IT IS POWERED.
If your unit does not work properly or if you want additional assistance, please call 1-800-443-4924.
We would be happy to answer ALL of your questions. Visit us on the web at www.GESmartHome.com
to download application notes, manuals and to find out more about the GE SmartHome™product line!
Specifications
FOR INDOOR USE ONLY
DO NOT EXCEED ELECTRICAL RATINGS
Electrical Rating .................................................................................................................................. 120 V, 60Hz
Maximum Tungsten Load .............................................................................................................................. 200W
Maximum Motor Load .................................................................................................................................... 1/ 3 HP
* Functional range may be adversely affected by one or more of the following factors: weather, radio
frequency interference, low transmitter battery and obstructions between the transmitter and receiver.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and;
2. This device must accept any interference received, including interference that may cause
undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Made in China for GE Home Electric Products, Inc.
Nela Park, Cleveland, OH 44112
Desc.: RF104RXPS
Indoor Outlet
RF100RXPS
Outdoor Outlet
RF106RXPS
Socket Adapter
RF104RXPS
Dimmer Switch
COMING SOON!
Garage Adapter
COMING SOON!
Wall Switch
RF102RXPS
Enclosed you will find
(1) Socket Adapter
The GE SmartRemote
Plus™ advantage
Any transmitter in the GE Smart Remote Plus
product line is capable of controlling every
receiver—the ultimate in home convenience.
Control any number of light fixtures or
appliances from up to 150ft
* away by
choosing the transmitter and receiver
combination that best suits your needs.
The following GE Smart Remote Plus transmitters (sold separately) can control THIS receiver:
The transmitters above can also control the following GE Smart Remote Plus receivers (sold separately):
IMPORTANT! These devices are NOT compatible with devices from other systems.
You must purchase Smart Remote Plus transmitters and receivers to ensure compatibility.
Socket Adapter
Smart Remote Plus Receiver
LISTED
CUS
WARNING
Risk of electric shock
• Turn power off before inspection,
installation or removal
• Keep children away
• Use indoors only
• Do not use in wet locations
• Screw in securely
Risk of fire
• Do not exceed electrical ratings
12
ON
8
7
6
5
4
3
2
1
8
7
6
5
4
3
2
1
ENERGY-SAVING BULB CEILING LIGHTLAMP
INCLUDED!
To extend the range of the
transmitters and receivers
in your system, use the
GE Smart Remote Plus
Range Extender
(sold separately).
User’s Manual
Range Extender
RF100RXTX
Key Chain Remote
RF100TXPS
Whole-Home Control
RF2000KINPS
Wall Mount Control
RF102TXPS
Garage Control
COMING SOON!
Motion-Sensing Control
RF613TX
Expanding your system
The GE Smart Remote Plus devices operate on any of 8 user-settable channels. The channels are
easy to set / adjust – with the simple turn of a knob. Set up your GE SmartHome™by purchasing as
many transmitters and receivers as you need. The following table is just one example of how you
can configure your Smart Remote Plus system:
Area CH Transmitters Receivers
Bedroom 1 Bedside - Wall Mount Control (2) Bedside Lamps - (2) Socket Adapters
Entrance - Wall Mount Control Corner Torchiere - Indoor Outlet Adapter
Overhead Light Fixture - Wall Switch
Entertainment System - Indoor Outlet Adapter
Living Room 2 Coffee Table - Timer/Controller (2) End Table Lamps - (2) Socket Adapters
Entrance - Wall Mount Control Overhead Light Fixture - Wall Switch
Entertainment System - Indoor Outlet Adapter
Christmas Tree - Indoor Outlet Adapter
3 Window Santa - Indoor Outlet Adapter
Lighted Poinsettia - Indoor Outlet Adapter
Basement 4 Entrance - Wall Mount Control (4) Overhead Can Fixtures - (4) Socket Adapters
(2) Fluorescent Fixtures - (2) Indoor Outlet Adapters
Garage 5 Entrance - Wall Mount Control (2) Fluorescent Fixtures - (2) Outdoor Outlet Adapters
Overhead Light Fixture - Wall Switch
Outdoor 6 Foyer- Wall Mount Control Entry Light - Wall Switch
Car Keys - Key Chain Remote Coach Lantern - Wall Switch
7 Christmas Lights - Outdoor Outlet Adapter
Yard Santa - Outdoor Outlet Adapter
Kitchen 8 Entrance - Wall Mount Control Coffee Maker - Indoor Outlet Adapter
