GE AGW18 Operating instructions

ge.com
©
©
Safety Instructions ........ 2, 3
Operating Instructions ..... 4, 5
Care and Cleaning
Air Fiher . ................. 6
Grille and Case ............. 6
Outdoor (;oils .............. 6
Installation Instructions
Preparing to Install the
Air Conditioner . ............ 7
Window Installauon ....... 8-19
Troubleshooting Tips ... 13, 14
Normal ()perating Sounds . . .14
Consumer Support
Consumer Support ......... 18
Product Registration ..... 15, 16
_A'arranty ................. 17
A GHI 8
AGWI8
©
Write the model and serial numbers here:
Model #
Serial #
Find these numbers on a label on the
side of the air conditionex:
3828A21031G 49-7526 11-05JR

iMPORTANTSAFETYiNFORMATiON.
READALLiNSTRUCtiONSBEFOREUSING.
m
For your safety the information in Nis manual must be followed to minimize the risk of fire, electric shock
or personal injury.
SAFETYPRECAUTIONS
Use this appliance only %r its intended
.,. (
pm])ose as descnbed m tins )wne_ s Manual.
This air conditioner must be properly
installed in accordance with the Installation
Instructions betbre it is used.
Never unplug your air conditioner by
pulling on the power cord. Ahvws grip
ping firmly and pull straight out flom
rite receptacle.
Replace immediamly all elecuic setMce
cords that haw become flayed or oflterwise
damaged. A damaged power supply cord
must be replaced with a new power supply
cord obtained flom the manufiacutrer and
not repaired. Do not use a cord that shows
cracks or abrasion damag_ along its length
or at eiflter rite plug or connector end.
_]_::Turn the unit OfFand unplug your air
conditioner before making any repairs
or cleaning.
NOTE.'_Aestrongly recommend that any
servicing be perforated by a qualified
individual.
E:,:For your safety'...do not store or use
combustible mamrials, gasoline or oflter
flammable vapors or liquids in the vicinity
of this or any other appliance.
E:,:All air conditioners contain refrigerants,
which under federal law must be remoxed
plior to product disposal. If you are getting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
HOWTOCONNECTELECTRICITY
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord. For
personal safe_ this appliance must be properly
grounded.
The power cord of fl_is appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-piong (grounding) wall
outlet m minimize the possibility of electric
shock hazard from this appliance.
Power cord includes a cnnent intemtpter
device. A rest and reset button is provided
on the plug case. The device should be rested
on a periodic basis by first pressing the rEsr
button and then the RESETbutton. If the rest
button does not trip or if rite RESt'button
will not stay eng'aged, discontinue use of rite
air conditioner and contact a qualified
service mchnician.
Haxe the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
Where a 2-prong wall outlet is encounmred
it is your personal responsibility and obligauon
to haxe it tel)laced with a properly grounded
3-piong wall outlet.
The air conditioner should always be
plug\g_d into its own indMdual electrical
outlet which has a xoltag_ rating fltat matches
the rating plato.
This provides the best perfommnce and also
prments oxerloading house wiring circuits
which could cause a fire hazard flom
oxeflleated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical
connection requirements.
2

ge.com
WARNING!!
USEOFEXTENSIONCORDS--115-Voltmode&only
Becauseofpotentialsafetyhazardsundercertain...^CAUTION:
conditions, we strongly recommend against the
use of an extension cord.
Howex_, if you must use all extension cord,
it is absolutely necessat T that it be a UiAismd,
14 gauge, 3-wire grounding type appliance
extension cord having a grounding type plug
and outlet and that the elecuJcal rating of the
cord be 15 amperes (minimum) and 195 volts.
DO NOT use an extension cord with any ofthe
230/208volt models.
USEOFADAPTERPLUGS--115-Voltmode&only
Because of potential safety hazards under certain
conditions, we strongly recommend against the
use of an adapter plug.
Howex>[; if you must rise all adaptei; where
local codes i)emfit, a temporaryconnection may
be made to a properly grounded 2-prong wall
outlet by use of a UiTlisted adapter available
at most local hardware stores.
Tile larger slot ill tile adaptor must be aligned
with tile larger slot ill the wall outlet to I)rovide
proper polarity in the connection of the
power cord.
'iA]mn disconnecting dm power cord tom tile
adaptel, alwws hold tile adaptor ill place with
one hand while pulling tile I)ower cord I)lug
with tile other hand. If this is not done, the
adaptor ground terminal is veUlikely' to bleak
with repeamd use.
If the adapter ground terminal breaks, DO NOT
USEthe air conditioner until a proper ground
has been established.
Attachingthe adaptergreundterminalto a waftoutlet
coverscrewdoesnot groundtheapplianceunlessthe
coverscrewis metal,andnot insulated,andthe waft
outlet isgroundedthreughthe housewiring. Youshould
havethecircuitcheckedby a qualifiedelectricianto
makesuretheoutlet is properlygrounded.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAgETHESEINSTRUCTIONS

Aboutthecontrolson theairconditioner.
Features and appearance may vary.
Fanon
(;eelon
COOL
FAN
Timeron
TEMPERATURE
Air ConditionerControls
-0 0-
RemoteControl
Controls
OON/OFFPad
TtlFns air conditioner on and off.
Increase •/Decrease • Pads
Use to set telnperature when in COOL nlode,
OMODE
Use to set the air conditioner to COOLor
FANinode,
FAN Pad
Useto set the tim speed to LOW(F1),
MED(F2)or HIGH(F3).
0
0
TIMER Pad
ON_\,Vhen the air conditioner is off,
it can be set to automatically COlile on in
1 to 12 hom_ at its previous setting. Each
touch will set the timer in hom_.
OFf--_4]_en the air conditioner is on,
it can be set to automatically tm'n off in
1 to ] 2 hems, Each touch will set the timer
in hems.
To cancel the timer, press the T/MER pad
tmtil the display time disappears.
Remote ControlSignal Receiver
Display
Shows the set temperature or time remaining
on [iII/eI;
Power Outage Recovery Feature
In the case el a power outage or interruption, the
trait will automatically re-start in the settings last
used after the power is restored, If the TIMER
teatm'e was set, it will resmne its cotmtdown,
Y_)u ma_ need to set a new time if desired,
Remote Control
::Ji::To ensm'e proper operation, aim the remote
control at the signal receiver on the air
conditione_;
iJi::The remote control signal has a range
of up to 21 teet.
::Ji::Make sure nothing is between the air conditioner
and the remote control that could block the
signal,
::Ji::Make stlre batteries are fl'esh and installed
correctly as indicated on the remote control,
4

ge.com
Lights next to the touch pads on the air conditioner
control panel indicate the selected settings.
COOLMode
Use the COOL mode with HIGH (F3), MED (F2) or
LOW(FI) tim fin" cooling. Use the INCREASEA /
DECREASEV pads to set the desired temperature
between 60°F and 86°F in l °F increments.
An electronic them/ostat is used to maintain the
room temperatm'e. The compressor will cyde on and
off to kee I) the room at the set level ot comtort. Set
the them/ostat at a lower nmnber and the indoor air
will become coole_: Set the them_ostat at a higher
number and the indoor air will become wam/e_:
NOTE:ff theair conditioneris off and isthenturnedon
whileset toa COOLsettingor if turnedfromafansetting
to a COOLsetting,it willtake approximately3minutes
for the compressorto startand coolingtobegin.
CoolingDescriptions
For Normal Coolin#---Sele('t the COOL mode and
HIGH (F3) or MED (F2)tim with a middle set
temperature.
ForMaximumCooliug--Select the COOLmode
and HIGH(F3)tim with a lower set temperatm'e.
For Quieter & Nighttime Cooling---Select the
COOL mode and LOW (F1)tim with a middle set
temperatm'e.
NOTE:If youswitch from a COOLsettingto OFForto
a fan setting,wait at least3 minutesbeforeswitching
back to a COOLsetting.
FAN Mode
Use tile FANat HIGH(F3),MED (F2)or LOW(FI)to
provide air circulation and filtering without cooling.
Since tim only settings do not provide cooling,
a temperature setting will not be displayed.
Vent Control
The vent control is located above the control
panels.
When set at CLOSE, only the air inside the room
will be circulated and conditioned. When set at
OPEN,some inside air is exhausted outside.
Toopenthe vent,pull the lever toward you.
Toclose it, push it in.
Air Direction--Side-to-Side
The side-to-side air direction is a(!i usted by moving
the lever to the left or right.
Air Direction--Up and Down
Fingertip pressm'e on the horizontal lou\'e_
ac!iusts the air direction up or down.

Careand cleaningoftheair conditioner.
Grille and Case
Turn the ......air conditioner off and remo',e the I_lug, To dean, use water and a mild detergent. Do not
from the wall outlet heft)re cleaning, use bleach or abrasixes.
Outdoor Coils
The coils on the outdoor side oI the air conditioner
should be checked regularly, If they are clogged
with dirt or soot, fl_e)' may be protessionally deaned.
Air Filter
The air filter behind the front grille should be
checked and cleaned at least exe_ 30 days or
IllOI'e olten i[ necess_H'v,
Toremove:
oo/ff
[_] Open the inlet gl'ille dowmvard b) )ullin,,
the top corne_ ot the inlet grille.
] Pull up slightly on the filter to release it and
pull it out.
Clean the filter with wamL soapy water; Rinse and
let the filter dry befiwe replacing it.
ACAUTION:DONOroperate_bea,_
conditionerwithouta filterbecausedirtandlintwillclogit
and reduce performance.

Installation
Instructions Air Conditioner
I_-_ Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: ge,com
BEFORE YOU BEGIN
Read these instructions completely
and carefully.
• IMPORTANT - Savethese
instructions for local inspector's use.
• IMPORTANT - Observeall
governing codes and ordinances.
•Note to Installer - Be sure to leave these
instructions with the Consumer.
•Note to Consumer - Keep these
instructions for future reference.
• Skill level - Installation of this appliance
requires basic mechanical skills,
•Completion time - Approximately 1 hour
• We recommend that two people install
this product.
•Proper installation is the responsibility
of the installer.
• Product failure due to improper installation
is not covered under the Warranty.
(_ ELECTRICAL REQUIREMENTS
Some models require a 115/120-volt a.c.,
60 Hz grounded outlet protected with a
15-amp time delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall
outlet you plan to use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
©Some models require 230/208-volt a.c.,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for
best performance and to prevent
overloading house or apartment wiring
circuits, which could cause a possible
fire hazard from overheating wires.
I
CAUTION:
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems--consult a qualified electrician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Flat-blade screwdriver
Pencil Ruler or tape measure
Level Scissors or knife
Power cord includes a current interrupter
device. A test and reset button is provided on
the plug case. The device should be tested on a
periodic basis by first pressing the TEST button
and then the RESET button, If the TEST button
does not trip or if the RESET button will not stay
engaged, discontinue use of the air conditioner
and contact a qualified service technician.

Installation instructions
PARTS INCLUDED
(Appearance may vary)
Window
;ash seal
Left Top. ___
accordion mount,ng Foam top /__ _'"_
rail
panel \ w indowgasket ___
To0_ount,n0\ _ __"
--1 _seal st ri_.__ _
i:
i, 1
Frame guide (2) _ _-.,_,_-.._ " ./_/ Right
_ _ _._'_ • /J/ / accordion
"__ __ panel
_ Sill;acket (2) k= JIIIIIII
Window locking upport rac et ( )
bracket [Jr,_
Type A (14) Type B (7) Type C (5) Type D (2) Carriage Bolt (2) Lock Nut (4)
@
8

Installation instructions
[] WINDOW REQUIREMENTS
• These instructions are for a standard
double-hung window. You will need to
modify them for other types of windows.
• The air conditioner can be installed
without the accordion panels if needed
to fit in a narrow window. See the
window opening dimensions.
• All supporting parts must be secured
to firm wood, masonry or metal.
• The electrical outlet must be within
reach of the power cord.
18" min.
29" to 41"
(With accordion panels)
27" min.
(Without accordion panels)
ir
[] STORM WINDOW REQUIREMENTS
A storm window frame will not allow the
air conditioner to tilt toward the outside,
and will keep it from draining properly.
To adjust for this, attach a piece of wood
to the stool.
WOOD PIECES-
WIDTH: 2"
LENGTH: Long enough to fit inside the
window frame.
THICKNESS: To determine the thickness,
place a piece of wood on the stool to
make it 1/2" higher than the top of the
storm window frame.
Attach securely with nails or screws
provided by the installer.
+
1/2" hi
than frame Stool
Storm
window
fra me

Installation instructions
[] REMOVE THE AIR CONDITIONER
FROM THE CASE
IAq Remove the 2 shipping screws from the
Inl back of the case.
[] Remove the 2 screws on each side of the
case. Keep these for later use.
[] Slide the air conditioner from the case by
gripping the base pan handle and pulling
forward while bracing the case.
[] PREPARE THE WINDOW AND
THE CASE
[] Cut the window sash seal to the proper
length. Peel off the backing and attach the
seal to the underside of the window sash.
[] PREPARE THE WINDOW AND
THE CASE (CONT.)
[] Carefully insert the plastic frame guides
into the bottom of the case on each side.
Bottom
of case
_ Frame guide
[] Remove the backing from the top mounting
rail seal strip and attach it to the bottom of
the top mounting rail.
[] Install the top mounting rail with 3 type A
screws on the inside of the case. Insert the
frames for the accordion panels into the top
mounting rail and the frame guides. Attach
the accordion panels to the side of the case
using 5 type A screws on each side.
Top mounting rail
\ Frame guides
10
