GE GE MONOGRAMTM ZET837DBSB User instructions

Monogram.
™
Specification Created 8/99
R
Listed by
Underwriters
Laboratories
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
ZET837DBSB - GE Monogram™30" Single Convection Wall Oven
Dimensions and Specifications (in inches)
Cutout Dimensions:
Height 23" max.
Width 28" min.
28-3/8" max.
Depth 23-1/2" min.
Cabinet depth required from front frame to inside rear
cabinet wall.
Monogram Built-In Convection Single Ovens require a
separate, properly grounded 3-wire 208/120 or
240/120 volt, 60Hz power supply, protected by a time
delay fuse or circuit breaker. Ovens are supplied with
a flexible power cable.
Convection single ovens are rated at 3.3 KW at 240
volts and 2.8 KW at 208 volts.
Installation Information:
Before installing, consult installation instructions,
packed with the product, for current dimensional data
and for alternate installation options.
23-1/2"
21-1/4"
23-1/4"
29-1/4"
22"
30"
23"
28" min.
28-3/8" max.
Locate junction box
above or below
cutout or through
cabinet sides.
34"
24"
25"
30"
2"x 4" or
Equivalent Runners
Must Support 200 lbs.

Monogram.
™
Specification Created 8/99
ZET837DBSB - GE Monogram™30" Single Convection Wall Oven
Features and Benefits
•Convection Self-Cleaning Oven
•Electronic Clock and Kitchen Timer
•Convection Bake and Convection Roast
•Convection Broil
•Bread Proofing Mode
•Timed Cooking
•Concealed Bake Element
•3,000-Watt Variable Broil with Twelve-Pass
Broil Element
•Porcelain-Enameled Broiler Pan with
Chrome-Plated Grid
•Self-Clean Delay Option with Automatic Door Lock
•3 Removable Racks and 4 Rack Positions
•Convection Roasting Rack and Convection
Floor Rack
•Preheat Light
•Frameless Glass Oven Door
•Tubular Stainless Steel Handle
•30" Oven Cabinet Width Required
•Model ZET837WBWW - White on white
•Model ZET837BBBB - Black on black
•Model ZET837SBSS - Stainless steel
•Model ZET837DBSB - Stainless steel on black
200
WARM
OFF CONV
BAKE
CONV
ROAST
CONV
BROIL
SELF
CLEAN
BROIL
BAKE
PROOF
CLEAN
BROIL
ON
250
300
350
400
450
500
Monogram
MANUAL
TIMED
SET
CLOCK
TIMER
COOK
TIME
START
TIME
