GE JGP628BEKBB Manual

Dimensions and Installation Information
For answers to your Monogram,® GE Profile™ or
GE® appliance questions, visit our website at
ge.com or call GE Answer Center® service,
800.626.2000. Dimension and installation information are shown in inches.
JGP628WEK/CEK/BEK
GE® 36" Built-In Gas Cooktop
Specification Created 11/04
330341
Gas Connection
Cooktop
2-1/2
(Min.)
33-7/8
19-1/8
3-3/16
36 21
Electrical junction
box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at
front
3-3/4" MIN.
clearance to
side wall
from cut-out
6" MIN.
clearance to
side wall
from cut-out
18" MIN.
to cabinet
2-1/4" to
rear wall
13" MAX.
depth
Electrical
cord
Electrical
outlet
Shut-off
valve
Pressure
regulator
1/2" pipe
Coupling
AGA Requirement: All gas cooktop models require
7/16" free area below cooktop height to combustible
material. Requires 18" minimum from countertop to
adjacent overhead cabinets.
Note: If installing with a GE ProfileTM Telescopic
Downdraft System, consult both cooktop and
downdraft installation instructions packed with
product before installing. Cooktop gas/electric
supply may need to be re-routed to install
downdraft.
Electrical Rating: 120V, 60Hz, 5A
Installation With Single Wall Oven Information:
30" Gas Cooktops are approved for use over select
GE 27" and 30" Wall Ovens and Warming Drawers.
30" and 36" Gas cooktops are approved for use
over 30" Wall Ovens and Warming Drawers.
Refer to cooktop and wall oven/warming drawer
installation instructions packed with product for
current dimensional data.
Installation Information: Before installing, consult
installation instructions, packed with product, for
current dimensional data.

JGP628WEK/CEK/BEK
GE® 36" Built-In Gas Cooktop
Features and Benefits
• Deep Recessed Cooktop - Designed with a recessed surface to help
contain spills and make cleaning easy
• Sealed Cooktop Burners - Eliminates the space between the burners
and the cooktop to help contain spills and boil over liquids, ensuring
easy cleanup
• High Output Burner - Provides a powerful burner output for efficient
heat-up and boiling
• Precise Simmer Burner - Delivers a low settng of 140 degrees, ideal
for delicate foods and sauces
• Continuous Grates - Provide a flat, sturdy surface allowing easy
movement of pans between burners
• Dishwasher-Safe Grates and Knobs - Feature durable construction
for worry-free, effortless cleaning and maintenance
• Upfront Controls - Controls are placed within easy reach at the front
center of the cooktop
• Electronic Pilotless Ignition - Provides reliable burner ignition operation,
eliminating the need for a standing pilot
• Model JGP628WEKWW - White on white
• Model JGP628CEKCC - Bisque on bisque
• Model JGP628BEKBB - Black on black
Specification Created 11/04
330341
