Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
JP655TM/BM
GE®36" Built-In CleanDesign Electric Cooktop
†Note: Check local codes for required breaker size
Important: Requires a 5" free area between
the bottom of the cooktop to any combustible
material, i.e., shelving. Free area not required
when installing wall oven underneath cooktop.
Refer to installation instructions. Requires a
15" minimum from cooktop to adjacent
overhead cabinets. Units are furnished with
a 48" flexible armored cable.
Note: 36" Ribbon cooktops are approved for use over GE 30" Single Wall
Ovens and Warming Drawers only. Refer to cooktop and wall oven/
warming drawer installation instructions packed with product for current
dimensional data. If installed with a GE Profile™ Telescopic Downdraft System,
consult both the cooktop and downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply may need to be
re-routed to install downdraft. The countertop must be at least 26" deep
with a flat surface area of 23-1/2" or more, front to back. In addition,
other clearances to the front edge of the countertop must be considered,
especially on raised bullnose countertops. Consult cabinet and countertop
manufacturer’s specs for flush mount installation prior to install.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
KW Rating
240V 8.4
208V 6.3
Breaker Size
240V 40 Amps†
208V 40 Amps†
3-1/4*
Cooktop
2-1/2**
Required
33-7/8
19-1/8
36
36_color_cktp_install.eps
20-7/8
Electrical junction box 16" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure
at front
2 " MIN.
clearance to
side wall
from cut-out
2 " MIN.
clearance to
side wall
from cut-out
1-3/4
"
to
rear wall
13" MAX.
depth
*Depth of unit at conduit connection location (rear) is
6-1/2" on models PP980/950 and 4-5/8" on models
PP975/972/962/945/942/932/912, JP655/356/346.
**Raised bull nose countertops may require up to
3/8" additional clearance to prevent interference
with curved front.
15" MIN.
to cabinet
Specification Created 10/06 321366

JP655TM/BM
GE®36" Built-In CleanDesign Electric Cooktop
Features and Benefits
• Ceramic Glass Cooktop - A smooth cooktop surface makes cleaning
quick and easy
• Ribbon Heating Elements - Provide powerful heat beneath a smooth
glass surface to ensure even heat and fast warm-up times
• Dual Size Ribbon Element - Offers a convenient choice of using a 6" or
9" heating element, depending on the size of the pan
• Frameless Design - A smooth and seamless cooktop surface makes
cleaning quick and easy
• Hot Surface Indicator Lights - Illuminate when the cooking surface
is active and hot, adding convenience and safe caution
• Heating Element "On" Light - Illuminates when the cooking surface
is activated
• Dishwasher-Safe Knobs - Feature a robust construction for safe and
easy cleaning
• Melt Setting - Optimized for melting chocolate, this setting delivers
the low gentle heat needed
• Simmer Setting - Ideal for making delicate sauces or melting butter,
and ensures a food-safe temperature of at least 140°F
• Model JP655TMWW - True white
• Model JP655BMBB - Black on black
JP655TM
