GE Profile PHP900DM Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
220580
†Note: Check local codes for required breaker size
Important:Requires a 12" free area between
the bottom of the cooktop to any combustible
material, i.e., shelving. Free area not required
when installing wall oven underneath cooktop.
Refer to installation instructions. Requires a
15" minimum from cooktop to adjacent
overhead cabinets. Units are furnished with
a 36" flexible armored cable.
Note: 36" Ribbon cooktops are approved for use over GE 30" Single Wall
Ovens and Warming Drawers only. Refer to cooktop and wall oven/
warming drawer installation instructions packed with product for current
dimensional data. If installed with a GE Profile™ Telescopic Downdraft System,
consult both the cooktop and downdraft installation instructions packed with
product before installing. Cooktop gas/electric supply may need to be
re-routed to install downdraft. The countertop must be at least 26" deep
with a flat surface area of 23-1/2" or more, front to back. In addition,
other clearances to the front edge of the countertop must be considered,
especially on raised bullnose countertops. Consult cabinet and countertop
manufacturer’s specs for flush mount installation prior to install.
Installation Information: Before installing, consult installation instructions
packed with product for current dimensional data.
KW Rating
240V 7.7
208V 5.8
Breaker Size
240V 40 Amps†
208V 40 Amps†
Listed by
Underwriters
Laboratories
3-1/4*
Cooktop
2-1/2**
Required
28-1/2
19-5/8
29-3/4 21-3/8
*Depth of unit at conduit connection location (rear) is
6-1/4" on models PP980/975/950/945 and 4-5/8"
on models PHP960/900, PP972/962/942/932/912
and JP6SS/356/346/340.
**Raised bull nose countertops may require up to
3/8" additional clearance to prevent interference
with curved front.
Electrical junction box 16" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure
at front
2
" MIN.
clearance to
side wall
from cut-out
2
" MIN.
clearance to
side wall
from cut-out
1-3/4
" to
rear wall
13" MAX.
depth
15" MIN.
to cabinet
PHP900DM
GE Profile™ 30" Electric Induction Cooktop
Dimensions and Installation Information (in inches)
Specification Revised 2/10
Above illustration intended for dimensional reference only.
Refer to photograph for actual product appearance.

Features and Benefits
• InductionElements-Powerfulyetpreciseinductionelements
generate heat directly to the cookware leaving the unused portion
of the element unheated and easier to clean
• 11"Element-Offersalarge11"surface,wideenoughtohandle
bigger pots and pans and accommodate family meals of any size
• 11"Element-Atit'shighestsetting,the11"elementhas3700watts
of power, providing an incredibly fast time to boil water
• ElectronicTouchControls-Offereasy,point-and-cookconvenience
• 19ControlSettings-Choosefrom19differentpowerlevelstoselect
the temperature that is perfect for your meal
• PanPresenceSensor-Detectswhenaburnerelementisleft"on"
and automatically shuts it off when not in use
• ControlLockCapability-Providestheabilitytolockthecooktop's
controls, helping protect from unintended activation
• SeamlessAppearance-Installsnearlyflushwithcountertopfora
seamless appearance
• ElectronicKitchenTimer-Providesconvenientnotificationtohelp
coordinate meal preparation and cooking times
• FramelessDesign-Asmoothandseamlesscooktopsurfacemakes
cleaning quick and easy
• HotSurfaceIndicatorLights-Illuminatewhenthecookingsurfaceis
active and hot, adding convenience and safe caution
• ModelPHP900DMBB-Blackonblack
PHP900DM
PHP900DM
GE Profile™ 30" Electric Induction Cooktop
220580
Specification Revised 2/10
