GE Monogram ZHU30RSR User instructions

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
130257
Specification Revised 9/10
Listed by
Underwriters
Laboratories
ZHU30RSR
GE Monogram®30" Electric Induction Cooktop
Dimensions and Installation Information (in inches)
Cutout Dimensions:
30" Models A B C D
ZHU30RSR 29-3/4" 21-3/8" 28-1/2" 19-5/8"
269Dia1
A
C
2" Min.
to Side Walls
B
2-1/2"
Min.
to Front
Edge
1-3/4"
Min.
D
269Dia2
3-1/4" 6-1/4"
5-1/2"
557ZEU669
16" Min
Junction
Box
Combination installations
Consideration must be given to electrical supply locations
when the cooktop is installed with other products in the same
cabinet. Always refer to each product's installation instructions
for clearances and electrical requirements.
• Install these cooktops with any exhaust hood of the same
or treater width; 300 CFM or greater air flow rating is
recommended.
• Install the 36" cooktop with a 36" downdraft vent. See
downdraft vents for details.
• A Monogram single oven (except Trivection oven) may be
installed below these cooktops.
The serial plate is located on the bottom of the cooktops.
Electrical requirements
Product rating is 120/240V, 60Hz, 36" cooktops
to a 50-amp circuit; and 30" cooktops to a 40-
amp circuit. The cooktops must be connected
to a supply circuit of the proper voltage and
frequency and protected by a time-delay fuse or
circuit breaker.
All models require 12" minimum clearance below
the cooktop bottom to combustible materials.

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
130257
Specification Revised 9/10
Listed by
Underwriters
Laboratories
ZHU30RSR
GE Monogram®30" Electric Induction Cooktop
Features and Benefits
• Induction Technology - Induction elements use
electricity to produce a magnetic field that reacts
with the iron in metal cookware - including cast
iron and magnetic stainless steel pans - and
transfers the heat to the cookware
• Sophisticated Styling - Mirrored metallic models
have a reflective metallic finish that captures light
and colors inside the kitchen
• Digital Controls - Embedded in the cooktop offer
added style and convenience
• 3,700-Watt, 11" Element - The most powerful
induction element in the industry, it provides
instantaneous heat across 19 different
cooking settings
• Digital Pan-Sensing Technology - Detects the
presence of pans made of iron materials, a
requirement for induction cooking
• Pan Size Sensor - Automatically adjusts the heating
element to the size of the pan
• Warm Setting - provides just enough heat to
maintain an ideal serving temperature
• Timer, Control-Lock Capability and Hot-Surface
Indicator - provide an extra measure of
convenience and safety
• Flexible Installation - Above a Monogram single
wall oven (except Trivection oven) is made possible
by shallow-depth configuration with integrated
cooling system
• Model ZHU30RSRSS – Mirrored metallic
