SAFETY PRECAUTIONS
Use this unit only in the manner intended
by the manufacturer If you have questions, contact
the manufacturer
Before servicing or cleaning unit, switch power off
at service panel and lock the service disconnecting
means to prevent power from being switched
on accidentally When the service disconnecting
means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the
service panel
Do not use this unit with any solid-state speed
control device
This unit must be grounded
For general ventilating use
only. Do not use to exhaust hazardous or explosive
materials and vapors.
SMOTHER FLAMES with a close-fitting lid, cookie
sheet or metal tray, then turn off the burner
BE CAREFUL TO PREVENT BURNS If the flames do
not go out immediately, EVACUATE AND CALL THE
FIRE DEPARTMENT
NEVER PICK UP A FLAMING PAN—
You may be burned
DO NOT USE WATER, including wet
dishcloths or towels—a violent steam
explosion will result
Use an extinguisher ONLY if:
You know you have a Class ABC
extinguisher, and you already know
how to operate it
The fire is small and contained in the
area where it started
The fire department is being called
You can fight the fire with your back
to an exit
* Based on “Kitchen Firesafety Tips” published
by NFPA
Never leave surface units unattended at high
settings Boilovers cause smoking and greasy
spillovers that may ignite Heat oils slowly on low or
medium settings
Always turn hood ON when cooking on high
heat or when flambeing food (ie Crepes Suzette,
Cherries Jubilee, Peppercorn Beef Flambé)
Clean ventilating fans frequently Grease should not
be allowed to accumulate on fan or filter
Use proper pan size Always use cookware
appropriate for the size of the surface element
Installation work and electrical wiring must
be done by qualified person(s) in accordance with
all applicable codes and standards, including
fire-rated construction
Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of
fuel burning equipment to prevent back drafting
Follow the heating equipment manufacturer’s
guideline and safety standards such as those
published by the National Fire Protection Association
(NFPA), and the American Society for Heating,
Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities
When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities
Ducted fans must always be vented to the
outdoors
■ Do not attempt to repair or replace any
part of your downdraft cooktop unless it is
specifically recommended in this manual
All other servicing should be referred to a qualified
technician
2
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion,
electric shock, or to prevent property damage, personal injury, or loss of life.
When using electrical appliances, basic safety precautions should be followed, including
the following:
■
Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with local codes and the provided
installation instructions
■
Have the installer show you the location of
the circuit breaker or fuse Mark it for easy
reference
■
Do not leave children alone—children should
not be left alone or unattended in an area
where an appliance is in use They should never
be allowed to sit or stand on any part of the
appliance
■
Teach children not to play with the controls or
any other part of the cooktop
■
Do not allow anyone to climb, stand or hang on
the cooktop
■
Items of interest to
children should not be stored in cabinets above
a cooktop—children climbing on the cooktop to
reach items could be seriously injured
■
Always keep combustible wall coverings,
curtains or drapes a safe distance from your
cooktop
■
Always keep dish towels, dishcloths, pot holders
and other linens a safe distance away from your
cooktop
■
Always keep wooden and plastic utensils and
canned food a safe distance away from your
cooktop
■
Never wear loose-fitting or hanging garments
while using the appliance Flammable material
could be ignited if brought in contact with hot
surface units and may cause severe burns
■
Use only dry pot holders—moist or damp pot
holders on hot surfaces may result in burns
from steam Do not let pot holders touch hot
surface units Do not use a towel or other
bulky cloth Such cloths can catch fire on a hot
surface unit
■
For your safety, never use your appliance for
warming or heating the room
■
Do not use water on grease fires Never pick up
a flaming pan Turn the controls off Smother a
flaming pan on a surface unit by covering the
pan completely with well-fitting lid, cookie sheet
or flat tray Use a multi-purpose dry chemical or
foam-type extinguisher
■
Flaming grease outside a pan can be put out
by covering with baking soda or, if available,
by using a multi-purpose dry chemical or
foam-type fire extinguisher
SAFETY PRECAUTIONS
COOK MEAT AND POULTRY THOROUGHLY…
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry
to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against
foodborne illness.
3
4
■
Do not let cooking grease or other flammable
materials accumulate on the cooktop
■
Do not touch surface units These surfaces may
be hot enough to burn even though they are
dark in color During and after use, do not touch,
or let clothing or other flammable materials
contact the surface units or areas nearby the
surface units; allow sufficient time for cooling
first
■
Potentially hot surfaces include the cooktop and
areas facing the cooktop
■
To minimize the possibility of burns, ignition of
flammable materials and spillage, the handle of
a container should be turned toward the center
of the cooktop without extending over any
nearby surface units
■
Always turn the surface unit control to off before
removing the cookware
■
Use proper pan size—Select cookware having
flat bottoms large enough to cover the surface
unit heating element The use of undersized
cookware will expose a portion of the surface
unit to direct contact and may result in ignition
of clothing Proper relationship of cookware to
burner will also improve efficiency
■
Never leave surface units unattended at high
heat settings Boilovers cause smoking and
greasy spillovers that may catch on fire
■
Only certain types of glass, glass/ceramic,
earthenware or other glazed containers are
suitable for cooktop cooking; others may break
because of the sudden change in temperature
■
Keep an eye on foods being fried at high or
medium high heat settings
■
Foods for frying should be as dry as possible
Frost on frozen foods or moisture on fresh foods
can cause hot fat to bubble up and over the
sides of the pan
■
Use little fat for effective shallow or deep-fat
frying Filling the pan too full of fat can cause
spillovers when food is added
■
If a combination of oils or fats will be used in
frying, stir together before heating, or as fats
melt slowly
■
Always heat fat slowly and watch as it heats
■
Use a deep fat thermometer whenever possible
to prevent overheating fat beyond the smoking
point
■
Never try to move a pan of hot fat, especially a
deep fat fryer Wait until the fat is cool
■
Do not store flammable materials near the
cooktop
■
Keep the vent grille and grease filters clean to
maintain good venting and to avoid grease fires
■
Do not store or use combustible materials,
gasoline or other flammable vapors and liquids
in the vicinity of this or any appliance
■
Clean only parts listed in this Owner’s Manual
■
Do not leave paper products, cooking utensils or
food on the cooktop when not in use
■
Keep cooktop clean and free of accumulation of
grease or spillovers which may ignite
■
Never heat unopened food containers Pressure
buildup may make container burst and cause
injury
■
Never leave jars or cans of fat drippings on or
near your cooktop
SAFETY PRECAUTIONS
5
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY
Use care when touching the cooktop. The glass surface of the cooktop will retain heat after the controls
have been turned off.
RADIANT SURFACE UNITS
■
Avoid scratching the glass cooktop The cooktop
can be scratched with items such as sharp
instruments, rings or other jewelry and rivets on
clothing
■ Large scratches or impacts to glass cooktops
can lead to broken or shattered glass
■
Never use the glass cooktop surface as a cutting
board
■
Do not place or store items on top of the glass
cooktop surface when it is not in use
■
Be careful when placing spoons or other stirring
utensils on glass cooktop surface when it is in
use They may become hot and could cause
burns
■
Avoid heating an empty pan Doing so may
damage the cooktop and the pan
■
Do not allow water, other liquids or grease to
remain on the cooktop
■
To minimize the possibility of burns, always be
certain that the controls for all surface units are
at the off position and the entire glass surface is
cool before attempting to clean the cooktop
■
Do not operate the glass surface units if the
glass is broken Spillovers or cleaning solution
may penetrate a broken cooktop and create
a risk of electrical shock Contact a qualified
technician immediately should your glass
cooktop become broken
■
Clean the cooktop with caution If a wet sponge
or cloth is used to wipe spills on a hot surface
unit, be careful to avoid steam burns Some
cleansers can produce noxious fumes if applied
to a hot surface
■
We recommend that you avoid wiping
any surface unit areas until they have cooled
and the indicator light has gone off
Please see Cleaning
the Glass Cooktop in the Care and Cleaning
section
■
When the cooktop is cool, use only CERAMA
BRYTE® Ceramic Cooktop Cleaner and the
CERAMA BRYTE® Cleaning Pad to clean the
cooktop
■
To avoid possible damage to the cooking
surface, do not apply the cleaning cream to the
glass surface when it is hot
■
After cleaning, use a dry cloth or paper towel to
remove all the cleaning cream residue
■
Read and follow all instructions and warnings on
the cleaning cream labels
■
Use care when touching the cooktop The glass
surface of the cooktop will retain heat after the
controls have been turned OFF
■
Do not stand on the glass cooktop
6
Throughout this manual, features and appearance may vary from your model.
(Features and appearance may vary)
Left Rear Surface Unit
Bridge Surface Unit
Left Front Surface Unit
Vent Grille
Vent Filter (below the vent grille)
Right Rear Surface Unit
Dual Surface Unit
Model and Serial Number Label (under the cooktop,
on the right side of the vent chamber)
Left Rear Surface Unit Control
Left Front Surface Unit Control
Left Side Hot Surface Indicator Lights (one for each surface unit)
Vent Fan Speed Control
Control Lock Knob
Right Side Hot Surface Indicator Lights (one for each surface unit)
Dual Surface Unit Control
Right Rear Surface Unit Control
Surface Unit On Indicator Light
7
Never cook directly on the glass
Always use cookware
The radiant cooktop features heating units
beneath a smooth glass surface
A slight odor is normal when a new
cooktop is used for the first time. It is caused
by the heating of new parts and insulating
materials and will disappear in a short time.
On models with light colored glass
cooktops, it is normal for the cooking zones to
change color when hot or cooling down. This is
temporary and will disappear as the glass cools
to room temperature.
The surface unit will cycle on and off to
maintain your selected control setting
It is safe to place hot cookware from the oven
or surface on the glass surface when the
surface is cool
Even after the surface units are turned off, the
glass cooktop retains enough heat to continue
cooking To avoid over-cooking, remove pans
from the surface units when the food is cooked
Avoid placing anything on the surface unit until
it has cooled completely
■ Water stains (mineral deposits) are removable
using the cleaning cream or full strength
white vinegar.
■ Use of window cleaner may leave an
iridescent film on the cooktop. The cleaning
cream will remove this discoloration.
■ Don’t store heavy items above the cooktop. If
they drop onto the cooktop, they can cause
damage.
■ Do not use the surface as a cutting board.
SURFACE
COOKING
OFF CENTER
Always place the pan in the center
of the surface unit you are cooking on
DRAGGING
Do not slide cookware across the
cooktop because it can scratch the
glass The glass is scratch-resistant,
not scratchproof
The control for the radiant surface unit can
be set anywhere between and for an
unlimited number of heat settings With the
infinite switch the coil cycles on and off to
maintain your selected control setting
To bring liquids to a boil faster, use a lid to
cover the pan
The control knob must be pushed down and
turned from the position When the
control knobs are in any position other than off,
they may be turned without pushing down
Be sure you turn the control knob off when you
finish cooking You will feel a click at the
position
The surface unit indicator light will glow
when any surface unit is on
The surface unit ON indicator light may
glow between the surface control settings of LO
and OFF, but there is no power to the surface
units.
Cooktop temperatures increase with the
number of surface units that are on With 3 or 4
units turned on, surface temperatures are high
so be careful when touching the cooktop
The indicator lights will glow
when any radiant element is turned on, and
will remain on until the surface is cooled to
approximately 150°F.
■ Hot Surface Indicator Lights come on instantly
and stay on even after the surface unit is
turned off.
■ They glow brightly until the unit is cooled to
approximately 150°F.
■ Be sure to turn the control knob off when you
finish cooking.
Be sure you turn the control knob
to OFF when you finish cooking.
8
Make sure the pan rests flat on the glass
cooktop and it is not resting on the trim If you
notice poor cooking performance, move the
pan to make sure it is flat on the cooktop
To use the bridge burner, turn the burner knob
to and select the desired setting The unit will
heat the front surface burner and the bridge
Choose pans that match the circle/bridge area
as closely as possible
To use only the front surface unit, turn the
burner knob to and select the desired
setting The unit will only heat the front surface
burner
You can create an oblong heated area by using
the left rear unit in addition to the front unit
bridge combination.
The right front surface unit has 2 cooking sizes
to select from so you can match the size of the
unit to the size of the cookware you are using
To use the large (9-inch) surface unit, turn the
knob clockwise to and select the desired
setting The unit will heat the entire area
contained by the larger circle
To use the small (6-inch) surface unit, turn the
knob counterclockwise to and select the
desired setting The unit will only heat the area
inside the smaller circle
Small 6"
surface unit
setting
Large 9"
surface unit setting
Every radiant surface unit has a temperature
limiter
The temperature limiter protects the glass
cooktop from getting too hot
The temperature limiter may cycle the units off
for a time if:
■ The cooktop is on while cooking.
■ The pan boils dry.
■ The pan bottom is not flat.
■ The pan is off-center.
■ There is no pan on the unit.
The built-in vent system helps remove cooking
vapors, odors and smoke from foods prepared
on the cooktop
To operate the downdraft vent system, turn
the vent fan speed control knob to
or , as needed
Continuous use of the vent system while
cooking helps keep the kitchen comfortable
and less humid, reducing cooking odors
and soiling moisture that normally creates a
frequent need for cleaning
Front
Burner and
Bridge
Front
Burner
only
Surface elements will cycle on and off to
maintain the temperature you have selected
All radiant surface elements have a
temperature limiter that protects the glass
cooktop from getting too hot
The temperature limiter may cycle the
elements off while cooking if:
■ The pan boils dry
■ The pan bottom is not flat.
■ The pan is off-center.
■ There is no pan on the element.
To activate control lock-out, turn the Control
Lock knob to LOCK This will prevent surface
units from heating An indicator light will glow
to show that they are locked The downdraft
fan will remain operable with control lockout
engaged
In the locked position, the cooktop will produce
an audible sound if any surface unit control
knob is engaged or moved to a position other
than OFF
9
The following information will help you choose cookware which will give good performance on glass cooktops. Use a pan
that matches the diameter of the surface element you are using. Cooking performance will not be as good if the cookware
itself is smaller or larger than the surface unit.
recommended
heavy weight recommended
Good conductivity Aluminum residues
sometimes appear as scratches on the
cooktop, but can be removed if cleaned
immediately Because of its low melting point,
thin weight aluminum should not
be used
recommended
Copper may leave residues which can
appear as scratches The residues can be
removed, as long as the cooktop is cleaned
immediately However, do not let these pots
boil dry Overheated metal can bond to glass
cooktops An overheated copper bottom pot
will leave a residue that will permanently stain
the cooktop if not removed immediately
recommended
As long as the cookware is covered
completely with porcelain enamel, this
cookware is recommended Caution is
recommended for cast iron cookware that
is not completely covered with smooth
porcelain enamel, since it may scratch the
glass-ceramic cooktop
usable, but not recommended
Poor performance May scratch the surface
usable, but not recommended
Poor performance May scratch the surface
Check pans for flat bottoms by
using a straight edge
Pans with rounded, curved,
ridged or warped bottoms are not
recommended
■ Place only dry pans on the surface elements
Do not place lids on the surface elements,
particularly wet lids
Do not place wet pans
on the glass cooktop
Be sure electrical power is off and all surfaces are cool before cleaning any part of the cooktop.
The control knobs may be removed for easier
cleaning
Make sure the knobs are in the positions
and pull them straight off the stems for
cleaning
place them in a
dishwasher or wash with soap and water Rinse
with clean water Make sure the insides of knobs
are dry before replacing
Replace the knobs in the position to
ensure proper placement
10
remove it from the
cooktop by lifting it up and off Wipe with a
damp cloth If necessary, the vent grille can be
washed in the sink
Use dishwashing liquid for cleaning
Do not use abrasive cleaners They will damage
the vent grille’s finish
Do not clean the vent grille in the dishwasher
Shaped area
Remove and replace the filter diagonally through the
vent opening
To order filters please call our toll-free number:
The filter is held in place at an angle with a
hold bump Lift the filter up and out of the
vent opening diagonally
swish it in hot, soapy water
Rinse well and dry thoroughly
When replacing the filter, make sure it rests, at an
angle, on the supports in the vent opening
use hot, soapy
water Rinse with clean water and dry
thoroughly Do not use abrasive cleaners; they
will damage the finish Replace the filter after it
is cleaned and dry
(on some models)
use warm
sudsy water or a stainless steel cleaner or
polish Always wipe the surface in the direction
of the grain Follow the cleaner instructions for
cleaning the stainless steel surface
To inquire about purchasing stainless steel
appliance cleaner or polish, or to find the
location of a dealer nearest you, please call our
toll-free number:
Vent
Chamber
Vent Filter
Carefully grasp a corner of the protective
shipping film with your fingers and slowly peel
it from the appliance surface Do not use any
sharp items to remove the film Remove all of
the film before using the appliance for the first
time
To assure no damage is done to the finish
of the product, the safest way to remove
the adhesive from packaging tape on new
appliances is an application of a household
liquid dishwashing detergent Apply with a soft
cloth and allow to soak
The adhesive must be removed from all
parts. It cannot be removed if it is baked on.
11
The CERAMA BRYTE® Ceramic
Cooktop Scraper and all
recommended supplies are
available through our Parts
Center See instructions under “To
Order Parts” section on next page
Do not use a dull or nicked
blade
Allow the cooktop to cool
Use a single-edge razor blade scraper
at approximately a 45° angle against
the glass surface and scrape the soil It
will be necessary to apply pressure to
the razor scraper in order to remove
the residue
After scraping with the razor
scraper, spread a few drops of
CERAMA BRYTE® Ceramic Cooktop Cleaner
to the entire burned residue area Use the
CERAMA BRYTE® Cleaning Pad to
remove any remaining residue
For additional protection, after all
residue has been removed, polish the
entire surface with CERAMA BRYTE®
Ceramic Cooktop Cleaner and a paper
towel
use CERAMA BRYTE® Ceramic Cooktop
Cleaner on the glass cooktop Other creams
may not be as effective
To maintain and protect the surface of your
glass cooktop, follow these steps:
Before using the cooktop for the
first time, clean it with CERAMA BRYTE®
Ceramic Cooktop Cleaner This helps
protect the top and makes clean-up
easier
Daily use of CERAMA BRYTE® Ceramic
Cooktop Cleaner will help keep the
cooktop looking new
Shake the cleaning cream well
Apply a few drops of CERAMA
BRYTE® Ceramic Cooktop Cleaner directly
to the cooktop
Use a paper towel or CERAMA
BRYTE® Cleaning Pad for Ceramic
Cooktops to clean the entire cooktop
surface
Use a dry cloth or paper towel
to remove all cleaning residue
No need to rinse
It is very important that you DO NOT
heat the cooktop until it has been cleaned
thoroughly.
DAMAGE to your
glass surface may occur if you use scrub
pads other than the pad included
with your cooktop.
Allow the cooktop to cool
Spread a few drops of CERAMA BRYTE®
Ceramic Cooktop Cleaner to the entire
burned residue area
Using the included CERAMA BRYTE®
Cleaning Pad for Ceramic Cooktops, rub
the residue area, applying pressure as
needed
If any residue remains, repeat the steps
listed above as needed
For additional protection, after all
residue has been removed, polish the
entire surface with CERAMA BRYTE®
Ceramic Cooktop Cleaner and a paper
towel
Use a CERAMA BRYTE® Cleaning
Pad for Ceramic Cooktops or a
Scotch-Brite® Multi-Purpose No
Scratch blue scrub pad
12
Turn off all surface units Remove hot
pans
Wearing an oven mitt:
Use a single-edge razor blade
scraper (CERAMA BRYTE® Ceramic
Cooktop Scraper) to move the spill to
a cool area on the cooktop
Remove the spill with paper towels
Any remaining spillover should be left
until the surface of the cooktop has
cooled
Don’t use the surface units again until
all of the residue has been completely
removed
If pitting or indentation in the glass
surface has already occurred, the cooktop
glass will have to be replaced. In this case,
service will be necessary.
Be careful not to slide pots and pans
across your cooktop It will leave metal
markings on the cooktop surface
These marks are removable using
the CERAMA BRYTE® Ceramic Cooktop
Cleaner with the
CERAMA BRYTE® Cleaning Pad
for Ceramic Cooktops
If pots with a thin overlay of aluminum
or copper are allowed
to boil dry, the overlay may leave black
discoloration on the cooktop
This should be removed immediately
before heating again or the
discoloration may be permanent
Carefully check
the bottom of pans for roughness that would
scratch the cooktop.
Metal Marks and Scratches
To order CERAMA BRYTE® Ceramic Cooktop
Cleaner and the cooktop scraper, please call
our toll-free number:
8006262002
# WX10X300
# WX10X0302
# WB64X5027
(Kit includes cream and razor scraper)
#WX10X350
• Save these instructions
for local inspector’s use
• Observe all governing
codes and ordinances
• Be sure to leave these
instructions with the Consumer
• Keep these instructions for
future reference
• Unless very knowledgeable in the installation of
this product, engage a professional installer
• Proper installation is the responsibility of the
installer
• Product failure due to improper installation is not
covered under the Warranty
Radiant
Downdraft Cooktop
13
Before beginning the
installation, switch power off at the service
panel and lock the service disconnecting means
to prevent power from being switched on
accidentally When the service disconnecting
means cannot be locked, securely fasten a
prominent warning device, such as a tag, to
the service panel
A Installation work and electrical wiring must be
done by qualified person(s) in accordance with
all applicable codes and standards, including
fire-rated construction
B
Sufficient air is needed for proper combustion
and exhausting of gases through the flue
(chimney) of fuel burning equipment to
prevent back drafting Follow the heating
equipment manufacturer’s guidelines and
safety standards such as those published by
the National Fire Protection Association (NFPA),
and the American Society for Heating,
Refrigeration and Air Conditioning Engineers
(ASHRAE), and the local code authorities
C
When cutting or drilling into wall or ceiling, do
not damage electrical wiring and other hidden
utilities
D
Ducted fans must always be vented to the
outdoors
• This unit must be properly grounded
• Blower assembly
• Blower plenum
• (4) Nuts (10-32 keps – nuts with
lock washers attached)
• (9) Sheet metal screws
(8-18 x 3/8")
• Foam gasket tape (9 ft roll)
• Vent grille
• Vent filter
• Cleaning cream
• Scrub sponge or scraper
(on some models)
Vent Grille
Cleaning Cream Scrub Sponge
Sheet Metal
Screws (9) (8-18 x
3/8≤)Foam Gasket Tape
Blower Assembly and (4) Mounting
Nuts (10-32 keps – nuts with lock
washers attached)
Blower
Plenum
14
Vent
Filter
Check to be sure that all packing materials
and tape have been removed This will include
tape on control knobs (if applicable), adhesive
tape, wire ties, cardboard and protective
plastic Failure to remove these materials could
result in damage to the appliance once the
appliance has been turned on and surfaces
have heated
• Saw
• Flat-blade screwdriver
• Electrician’s pliers
• Duct tape
• Measuring tape or scale
• Carpenter’s square
• 7/16≤ wrench or socket set
• Drill and drill bit
• Sheet metal screws
• Junction box*
• 3/4≤ flexible conduit*
• Electrical wire per local code*
• Wire nuts*
• Ductwork
Electrical installation kit JXCK89 may be
ordered separately and includes all the parts
necessary to connect the cooktop to typical
rough-in wiring
201⁄2”
22”
283⁄4”
This appliance must be supplied with the proper voltage
and frequency, as listed in these Installation Instructions,
and connected to an individual, properly grounded branch
circuit, protected by a 40-amp circuit breaker or time delay
fuses
All wire connections must be made in accordance with
local codes and properly insulated Check with your local
utility for governing electrical codes and ordinances In the
absence of local electrical codes, the National Electrical
Code, ANSI/NFPA No 70 – Latest Edition, governing electric
range installations, must be followed
A copy of the National Electrical Code can be obtained by
writing to:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02260
Effective January 1, 1996, the National Electrical Code
requires that new, but not existing, construction utilize a
four-conductor connection to an electric range When
installing an electric range in new construction, follow
the instructions in NEW CONSTRUCTION AND FOUR-
CONDUCTOR BRANCH CIRCUIT CONNECTION
You must use a three-wire, single-phase AC 208Y/120 Volt
or 240/120 Volt, 60 Hertz electrical system with separate
ground If you connect to aluminum wiring, properly
installed connectors approved for use with aluminum
wiring must be used
15
227⁄16”
(229⁄16” SS) 297⁄8”
(30” SS) 23⁄16”
(21⁄4” SS)
16
The cooktop is designed to look best when centered in a
cabinet at least 30≤ wide
The exhaust vent beneath the cooktop must be located
between wall studs or floor joists so that the ductwork may
be installed properly
At least 6≤ must be allowed between side edges of the
cooktop and adjacent walls
Avoid placing cabinets above the cooktop unit, if possible,
in order to reduce the hazards caused by reaching over
heated surface units If cabinets are placed over the
cooktop, the risks can be reduced by installing a range
hood that projects horizontally a minimum of 5 inches
beyond the bottom of the cabinets
If cabinetry is used above the cooktop, allow a minimum
30" clearance between the cooking surface and the bottom
of any unprotected cabinet
If the clearance between the cooktop and the cabinetry is
less than 30", the cabinet bottom must be protected with
flame retardant millboard at least 1/4" thick, covered with
28 gauge sheet steel or 0020" thick copper Clearance
between the cooktop and the protected cabinetry
Installation of a listed microwave oven or
cooking appliance over the cooktop shall conform to the
installation instructions packed with that appliance
A 15" minimum must be kept from the side edge of the
cooktop to the bottom of any cabinet not directly above the
cooktop If the clearance is less than 15", adjacent cabinets
should be at least 6" from the side edge of the cooktop
1
This cooktop is designed to fit easily into a variety
of cabinets However, some cabinets may require
modifications
In some cabinets, the sides may need to be scooped or cut
down 53⁄4” as shown, and the corner braces removed in
order to accommodate the unit
In 75 cm and 90 cm frameless European cabinets,
the back panel may need to be cut down 53⁄4” to
accommodate the unit
In a peninsula or island-type cabinet, the sides may need to
be scooped or cut down, and the corner braces removed in
order to accommodate the unit
53⁄4
”
Approx
53⁄4
”
Approx
for European
cabinets
2
Install an approved junction box within shaded area
shown in diagram Junction box must be at least 101⁄2
”
below top of cabinet
Run conductors from residence wiring to junction box
according to local electrical codes
3
16"
9" 4"
20”
101⁄2”
C
L
13" max
depth of
unprotected
overhead
cabinets
6" min
clearance
from cutout
to side walls
30" min
clearance from
countertop
to unprotected
overhead surface
15" min height
from countertop
to nearest cabinet
on either side of
the unit
The countertop must have a deep flat surface
to accommodate the cooktop and the vent
Countertops with a rolled front edge and
backsplash may not provide the flat surface
area required
Clearance between inside front of cabinet and
rear of countertop cutout must be 205⁄8” in order to
accommodate cooktop depth
A 1/2" wide flat area is required around the edge
of opening for support of the unit The cooktop
unit must be level and sit squarely into countertop
opening
Carefully cut countertop opening according to the
dimensions shown in the illustration Be sure that
the opening is cut squarely, with sides parallel to
each other and the rear exactly perpendicular to
the sides
Cut hole in cabinet wall or floor as appropriate for your
installation Make sure exhaust duct is located between wall
studs or floor joists
17
205⁄8”
17⁄8” min
25" 287⁄8”
91⁄8≤
183⁄4”
101⁄8”
61⁄8”
Back Venting
(Requires 31⁄4” x 10")
Rear Wall Venting Downward Venting
4
In general, the use of flexible ducting is discouraged because
it can cause severely restricted airflow However, if the
blower outlet and the floor or wall duct location do NOT align
well, then flexible METAL ducting can be used to adapt to an
offset Good alignment without use of flexible ducting is best
• Do not exceed the maximum recommended offset of 6"
• Do not allow the flexible ducting to kink or collapse
• Do stretch the flexible ducting as much as possible to
eliminate as much of the corrugation as possible
5
6
205⁄8”17⁄8” min
23⁄8” min
A 31⁄4” x 10" rectangle to 6” round transition duct is available at
your local building supply store
Bottom Venting
6” Max
Centerline
to Centerline
Offset
25” min flat surface area required
Equivalent Number Equivalent
Duct Pieces Length* x Used = Length
5" round
straight 27 ft x ( ft)† = ft
6” round
straight 1 ft x ( ft)† = ft
31⁄4” x 10”
straight 1 ft x ( ft)† = ft
5”, 90°
elbow 37 ft x ( ) = ft
6”, 90°
elbow 12 ft x ( ) = ft
5”, 45°
elbow 18 ft x ( ) = ft
6”, 45°
elbow 7 ft x ( ) = ft
Flexible
metal offset
adapter 34 ft x ( ) = ft
31⁄4” x 10”
90° elbow 14 ft x ( ) = ft
31⁄4” x 10”
45° elbow 8 ft x ( ) = ft
31⁄4” x 10”
90° flat elbow
33 ft x ( ) = ft
5” round
to 31⁄4” x 10”
transition 3 ft x ( ) = ft
6” round
to 31⁄4” x 10”
transition 2 ft x ( ) = ft
Subtotal Column 1 = ft
* Equivalent lengths of duct pieces are based on actual
tests and reflect requirements for good venting
performance with any downdraft cooktop
† Measure and list feet of straight duct used Count and
list the quantity of all other duct pieces for the “Number
Used” of each type
For maximum efficiency, use the shortest and straightest
duct run possible, with as few fittings as possible
Venting performance is improved by using larger
diameter duct
Equivalent Number Equivalent
Duct Pieces Length* x Used = Length
5” round
to 31⁄4” x 10”
transition
90° elbow 37 ft x ( ) = ft
6” round
to 31⁄4” x 10”
transition
90° elbow 4 ft x ( ) = ft
31⁄4” x 10”
to 6” round
transition 2 ft x ( ) = ft
31⁄4” x 10”
to 6≤ round
transition
90° elbow 4 ft x ( ) = ft
Tapered 5”
round to
6” round
transition 6 ft x ( ) = ft
5” round collar
to 6” round
transition 13 ft x ( ) = ft
5” round
wall cap
with damper 84 ft x ( ) = ft
6” round
wall cap
with damper 24 ft x ( ) = ft
31⁄4” x 10”
wall cap
with damper 24 ft x ( ) = ft
6" round
roof cap 33 ft x ( ) = ft
Subtotal Column 2 = ft
Subtotal Column 1 = ft
ft
If flexible metal ducting is used, all the equivalent
feet values in the table should be doubled The
flexible metal duct should be straight and smooth
and extended as much as possible
Vent installation should not exceed 100 feet
equivalent length
18
19
Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of
other fuel burning equipment to prevent back drafting Follow the heating equipment manufacturer’s
guidelines and safety standards such as those published by the National Fire Protection Association
(NFPA), the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE) and
local code authorities
5” round duct may be used on SHORT DUCT runs,
but best results will be obtained using 31⁄4” x 10”
or 6” round ducting
To convert blower exhaust direction, remove four
nuts behind the filter which hold blower and wire
finger guard
Rotate blower and reinstall to vent chamber, as
shown above Retighten nuts, but do not overtighten
Use galvanized or aluminum duct in 6≤ round or
31⁄4” x 10" size, or a combination of both
PVC duct should be used if installing under a poured
concrete slab
Local building code must be followed in
specifying approved type and schedule of ALL
duct used
Always use an appropriate roof or wall cap with
damper Laundry-type wall caps should NEVER
be used
Install ductwork, making male-female connections
in the direction of airflow as shown Secure all joints
with sheet metal screws and duct tape to assure an
airtight seal
Use the shortest and straightest duct run possible
For satisfactory performance, the duct run should
not exceed 100 feet equivalent length Refer to the
“DUCTWORK CALCULATIONS” chart for equivalent
lengths Use this chart to calculate the total
equivalent length of the ductwork
20
Through Cabinet Toe Space Between Floor Joist
Downward Venting
Inside Wall to Roof Direct to Outside
Rear Wall Venting
Duct Tape Over Seam
and Screw
Air Flow
Screw
7
Other manuals for Profile PP989DNBB
1
This manual suits for next models
3
Table of contents
Languages:
Other GE Cooktop manuals
GE
GE Profile PP945BM User manual
GE
GE JGP963CEKCC - Profile: 36'' Sealed Burner Gas... Manual
GE
GE JP989 Series Original instructions
GE
GE JGP626AEV1AA User manual
GE
GE Profile PVP6004 User manual
GE
GE JGP337SEJSS Operating instructions
GE
GE 164D2966P161-1 User manual
GE
GE JP3030D User manual
GE
GE Profile JP340 User manual
GE
GE JGP328 User manual
