GE DMCD330GHWC Manual

370407
DMCD330GH
GE®7.0 Cu. Ft. Capacity Coin-Operated Gas Dryer
Specification Revised 5/09
DCD330EB
6/10/03
36
27
25-1/2
42
Exhaust Option:
Shipped with exhaust to the rear.
When viewed from the front of the unit,
exhaust 3-way via left, bottom and rear.
Maximum recommended exhaust duct
length is 15 feet of 4"rigid ducting with two
90˚elbows and dampered wall cap.
(See Installation Instructions)
Gas: An individual branch circuit fused to
15- or 20-amp is required for each dryer.
Gas Dryer Rating: 120V, 60Hz
Gas (BTU/HR):
20,000. Factory equipped for natural gas.
Tested for LP gas. A conversion kit is required
for LP gas. Check installation instructions
for correct kit number. Have a qualified
technician install a conversion kit. Equipped
with energy saving Glo-Bar ignition.
Dryer Note: Dryer wall outlet must be
located within 36" of service cord entry and
accessible when dryer is mounted in position.
Installation Information: For complete
information see installation instructions
packed with product.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.

370407
DMCD330GH
GE®7.0 Cu. Ft. Capacity Coin-Operated Gas Dryer
Specification Revised 5/09
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal
exhaust duct. If rigid metal duct cannot be used, then UL-listed flexible metal (semi-
rigid) ducting can be used (Kit WX08X10077). In special installations, it may be
necessary to connect the dryer to the house vent using a flexible metal (foil-type) duct.
A UL-listed flexible metal (foil-type) duct may be used ONLY in installations where rigid
metal or flexible metal (semi-rigid) ducting cannot be used AND where a 4” diameter
can be maintained throughout the entire length of the transition duct. Please see
installation instruction packed with your dryer for complete instructions when using
flexible metal (foil type) ducting.
Exhaust Length Calculation:
1.Determine the number of 90° turns needed for your installation. If you exhaust to the
side or bottom of dryer, add one turn.
2.The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated
is shown in the table. A turn of 45° or less may be ignored. Two 45° turns within the
duct length should be treated as a 90° elbow. A turn over 45° should be treated as a
90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any
enclosed house floor (crawl space), or into an attic, since the accumulated lint could
create a fire hazard or moisture could cause damage. Never terminate the exhaust
into a common duct or plenum with a kitchen exhaust, since the combination of lint
and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts,
bird nesting, etc. The wall cap must also be located at least 12" above the ground or
any other obstruction with the opening pointed down.
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label
on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side; 3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a minimum
of 60 sq. in. of open area equally distributed. If this closet contains both a washer and
a dryer, doors must contain a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes,
with the National Electric Code and National Fuel Gas Code, ANSI Z223 for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces are: 0" both sides; 3" rear
Dryer Exhausting Information: Use metal duct only, vertical and horizontal ducting.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
7.0, 6.0 and 5.8 cu. ft.
capacity models
all electric dryers
0
1
2
3
4
90 ft.
60 ft.
45 ft.
35 ft.
25 ft.
60 ft.
45 ft.
35 ft.
25 ft.
15 ft.
A
4
B
2-1/2
A

370407
Specification Revised 5/09
Features and Benefits
• Greenwald Coin System - Includes coin box, key, coin slide and
related parts
• Auto Dry - Uses thermostats to monitor air temperature and reduce
fabric wear
• Pushbutton Controls - Simplifies cycle selection
• LED Readout - Provides accurate wash times, from fill to finish
• Painted Drum - Painted drum coated with a rustproof finish to stand up
to heavy use
• Three Heat Selections - Offer a choice of drying temperatures for better
fabric care
• Three Dry Cycles - Simple options for reliable drying performance
• Reverse-A-Door - Offers added installation flexibility
• Model DMCD330GHWC –White on white
DMCD330GH
GE®7.0 Cu. Ft. Capacity Coin-Operated Gas Dryer
