GE DNCD450GGWC Manual

Dimensions and Installation Information (in inches)
DNCD450EG/GG
GE®Super 7.0 Cu. Ft. Capacity Commercial Dryer
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
370408
Specification Revised 5/09
Exhaust Options:
Electric: 4-way via rear, right, left and bottom. Maximum recom-
mended exhaust duct length is 45 feet of 4" rigid ducting with two
90° elbows and a 4" dampered wall cap.
Gas: When viewed from the front of the unit, exhaust 3-way via rear,
left and bottom. Maximum recommended exhaust duct length is 15
feet of 4" rigid
ducting with two 90° elbows and a 4" dampered wall cap.
Circuit Requirements:
An individual, properly-grounded branch circuit, protected by a 30-
amp circuit breaker or a time-delay fuse, is required.
Electric Dryer Rating:
208/240V, 5600W, 24A, 60Hz
208V, 4400W, 22A, 60Hz
Note: Dryer wall outlet must be located within 36" of service cord
entry and accessible when dryer is mounted in position.
Installation Information: For complete information, see installation
instructions packed with your dryer.
36
25-1/2
42
51
Side View
27
Rear View
36 42
27
23-1/2
2-1/2
25-1/2*
Side View Rear View
8-1/2
28-1/4
23-1/2
11-1/2
*24-1/2" from the edge of the side panel to the front.
25-1/2" from front to edge of endcaps.
Washer/Dryers SC QSart

Dimensions and Installation Information (in inches)
DNCD450EG/GG
GE®Super 7.0 Cu. Ft. Capacity Commercial Dryer
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
370408
Specification Revised 5/09
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust duct.
If rigid metal duct cannot be used, then UL-listed flexible metal (semi-rigid) ducting can be used
(Kit WX08X10077). In special installations, it may be necessary to connect the dryer to the house
vent using a flexible metal (foil-type) duct. A UL-listed flexible metal (foil-type) duct may be used
ONLY in installations where rigid metal or flexible metal (semi-rigid) ducting cannot be used AND
where a 4” diameter can be maintained throughout the entire length of the transition duct.
Please see installation instruction packed with your dryer for complete instructions when using
flexible metal (foil type) ducting.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or
bottom of dryer, add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is shown
in the table. A turn of 45° or less may be ignored. Two 45° turns within the duct length should
be treated as a 90° elbow. A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution:
For personal safety do not terminate exhaust into a chimney, under any enclosed house floor
(crawl space), or into an attic, since the accumulated lint could create a fire hazard or moisture
could cause damage. Never terminate the exhaust into a common duct or plenum with a
kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting,
etc. The wall cap must also be located at least 12" above the ground or any other obstruction
with the opening pointed down.
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the
dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side; 3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq.
in. of open area equally distributed. If this closet contains both a washer and a dryer, doors
must contain a minimum of 120 sq. in. of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the
National Electric Code and National Fuel Gas Code, ANSI Z223 for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides; 3" rear
Dryer Exhausting Information – Use Metal Duct Only - Vertical and Horizontal Ducting
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
7.0, 6.0 and 5.8 cu. ft.
capacity models
all electric dryers
0
1
2
3
4
90 ft.
60 ft.
45 ft.
35 ft.
25 ft.
60 ft.
45 ft.
35 ft.
25 ft.
15 ft.
A
4
B
2-1/2
A

DNCD450EG/GG
GE®Super 7.0 Cu. Ft. Capacity Commercial Dryer
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
370408
Specification Revised 5/09
DNCD450EA/GA.EPS
02-09-2001
Commercial
Dryer
HIGH
MED
LOW
EXTRA
LOW
ET
R
HEAT
SETTINGS
AUTOMATICSETTINGS
CLOTHES CARE SELECTION
DOOR OPEN DRYING COOLDOWN
STATUS
CLEAN LINT FILTER
COTTONS: HIGHHEAT
MIXEDLOADS: HIGHHEAT
PERMPRESS: MED HEAT
KNITS: LOWHEAT
DELICATES: EXTRALOW HEAT
AIRDRY: NOHEAT
KNITS
COTTONS
DELICATES
MIXED
LOADS
AIR DRY
PERM
PRESS
START
PAUSE
STOP
CANCEL
Features and Benefits
• Super 7.0 Cu. Ft. Capacity
• 5 Dry Cycles: Cottons (High Heat); Mixed Loads (High Heat); Permanent Press
(Medium Heat); Knits (Low Heat); Delicates (Extra Low Heat)
• 4 Temperatures
• Air Dry
• Digital Cycle Countdown
• Hush Quiet Package
• Lockable Lint Filter
• Reversible Door Swing
• DuraDrum™Interior
• Model DNCD450EGWC – White
• Model DNCD450GGWC – White
