GE Profile DPGT650 Operating instructions

ge.com
SafetyInstructions .......... 2-s
Operoting Instructions
Controls .......................... 6-8
Cgcle Options ................... 9-10
Druer Features .................... !!
Loading and Using
the Druer ...................... 12, 13
/nsto#otion Instructions
Before You Begin ............... 14-16
Connecting a Gas Druer ........ 17-20
Connecting an
Electric Druer .................. 21-23
Exhausting the Druer .......... 24-28
Final Setup ..................... 29, 30
Reversing the Door Swing ...... 31, 32
Troubleshooting Tips .......... 33
Consumer Support
Consumer Support ................ 36
Warrantg (Canada)................ 35
Warrantg (U.S.).................... 34
DPGT650
UPGT650
Write the model ond seriol
numbers here:
Model #
Serial It
Theg are on the label on the front
of the drger behind the dooE
175D1807P603 49-90335 09-07JR

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, electric shock, or to prevent property damage, personal inJury, or
death.
•Do not store or use gasoline or other
flammable vapors and liquidsin the
vicinity of this or any other appliance.
• Installation end service must be
performed by e qualified installer,
service agency or the gas supplier.
WHAT TO DO IF VOU SMELL GAS:
[] Do not try to light amatch, or cigarette,
or turn on any gas or electrical
appliance.
F_ Do not touch any electrical switch;
do not use any phone in your building.
[] Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions carefully.
F_ lf gou cannot reach your gas supplier,
call the fire department.
F_ Clear the room, building or area of all
occupants.
California Safe Drinking Water and Toxic Enforcement Act
Thisact requiresthe governor of Californiato publisha listof substancesknown to the state to cause cancer,
birth defects or other reproductive harm and requiresbusinessesto warn customers of potential exposure to
such substances.
Gasappliances can cause minor exposureto four of these substances, namelu benzene,carbon monoxide,
formaldehude and soot, caused primarilu bu the incomplete combustion of natural gasor LPfuels.
Properlyadjusted druerswill minimizeincomplete combustion. Exposureto these substances can be minimized
further by properly venting the druer to the outdoors.

ge.com
PROPERINSTALLATION
This dryer must be properly installed and located in accordance with the Installation Instructions
before it is used. If you did not receive an Installation Instructions sheet, you con receive one by
visiting ge.com, or by calling 800.GE.CARE.S (800.432.2737).
[] Properlyground dryer to conform with all
governing codes and ordinances.Follow details
in Installation Instructions.
[] Installor store where itwill not be exposed to
temperatures belowfreezing or exposed to
the weather
[] Connectto a properly rated, protected and sized
power supply circuitto avoid electrical overload.
[] Removethe colored protective film from both the
control panel and the door
[] Removeall sharp packing items and disposeof all
shipping materials properly.
[] Do not remove the vent protector from the back of
the dryer (onsome models).
[] Pullthe protector out and down to its lowest
position and connect the exhaust duct to the dryer
Thelowered protector will prevent the duct from
getting crushed (onsome models).
Exhaust/Ducting:
E__]Dryers MUSTbe exhausted to the outside to
prevent large amounts of moistureand lint from
being blown into the room.
E_]Useonly rigid metal or flexible metal 4"
diameter ductwork insidethe dryer cabinet or for
exhausting to the outside.USEOFPLASTICOR
OTHERCOMBUSTIBLEDUCTWORKCANCAUSE
A FIRE.PUNCTUREDDUCTWORKCANCAUSEA
FIREIF ITCOLLAPSESORBECOMESOTHERWISE
RESTRICTEDIN USEORDURINGINSTALLATION.
Forcomplete details,follow the Installation
Instructions.

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
,&WARNING!
YOURLAUNDRYAREA
• Keepthe area underneath and around your
appliances free of combustible materials
(lint,paper,rags, etc.),gasoline, chemicals
and other flammable vapors and liquids.
• Keepthe floor around your appliances clean
and dry to reducethe possibility of slipping.
• Closesupervisionis necessary ifthis appliance
is usedby or near children. Do not allow childrento
play on,with or insidethis or any other appliance.
• Keep all laundry aids(suchas detergents, bleaches,
etc.)out ofthe reach of children, preferably in a
locked cabinet. Observeall warnings on container
labelsto avoidinjury.
• Never climb on or stand on the dryer top.
WHEN USING YOUR DRYER
• Neverreach into the dryer while the drum is
moving. Beforeloading, unloading or adding
clothes,wait until the drum has completely
stopped.
• Cleanthe lint filter before each load to prevent lint
accumulation insidethe dryer or in the room. DO
NOTOPERATETHEDRYERWITHOUTTHELINT
FILTERIN PLACE.
• Do not wash or dry articlesthat have been
cleaned in,washed in,soaked in or spotted with
combustible or explosivesubstances(suchas wax,
oil,paint, gasoline,degreasers,dry-cleaning
solvents,kerosene,etc.)which may ignite or
explode. Donot add these substances to the
wash water Donot useor placethese substances
around your washer or dryer during operation.
• Do not place items exposedto cooking oilsin your
dryer Items contaminated with cooking oilsmay
contribute to a chemical reaction that could cause
a clothesload to catch fire.
• Any article on which you have used a cleaning
solvent or that contains flammable materials (such
as cleaning cloths, mops,towels used in beauty
salons,restaurants or barber shops,etc.)must not
be placed in or near the dryer until solvents or
flammable materials have been removed.There
are many highly flammable items used in homes
such as acetone,denatured alcohol, gasoline,
kerosene,some household cleaners,some spot
removers,turpentines, waxes, wax removers and
products containing petroleum distillates.
• Thelaundry processcan reduce the flame
retardancy offabrics. Toavoid such a result,
carefully follow the garment manufacturer's
care instructions.
• Do not dry articles containing rubber,plastic,foam
or similar materials such as padded bras,tennis
shoes,galoshes,bath mats, rugs,bibs, baby pants,
plastic bags, pillows,etc.,that may melt or burn.
Somerubber materials, when heated, can under
certain circumstances producefire by spontaneous
combustion.
• Do not store plastic,paper or clothing that may
burn or melt ontop of the dryer during operation.
• Garments labeled Dry Away from Heat or DoNot
TumbleDry (suchas lifejackets containing kapok)
must not be put in your dryer
• Do not dry fiberglassarticles in your dryer
Skinirritation could result from the remaining
particles that may be picked up by clothing
during subsequent dryer uses.
• Tominimizethe possibility of electric shock, unplug
this appliance from the power supply or disconnect
the dryer at the building'sdistribution panel by
removing the fuse or switching off the circuit
breaker before attempting any maintenance or
cleaning (exceptthe removal and cleaning ofthe
lint filter).NOTE:PressingSTART,PAUSEor POWER
doesNOTdisconnect the appliance from the power
supply.
4

ge.com
WHEN USING YOUR DRYER(cont.)
• Never attempt to operate this appliance ifit is
damaged, malfunctioning, partially disassembled,
or hasmissing or brokenparts, including a
damaged cord or plug.
• The interior of the machine and the exhaust duct
connection insidethe dryer should be cleaned at
least once a gear bg a qualified technician. See
the Loading and Usingthe Dryer section.
• If yours is a gas dryer,it is equipped with an
automatic electric ignition and does not have
a pilot light. DO NOTATTEMPTTOLIGHTWITHA
MATCH.Burnsmay result from having your hand
in the vicinitg ofthe burner when the automatic
ignition turns on.
Youmag wish to soften gour laundered fabrics
or reducethe static electricitg in them bg using
a drger-applied fabric softener or an anti-static
conditioner We recommend you useeither a fabric
softener in the wash cgcle,according to the
manufacturer's instructions for those products,
or try a dryer-added product for which the
manufacturer gives written assurance on the
package that their product can be safely used
in your drgen Serviceor performance problems
caused bg useof these products are the
responsibility of the manufacturers of those
products and are not covered under the
warrantg to this appliance.
CWHEN NOT USING YOURDRYER
• Graspthe plug firmly when disconnecting this
appliance to avoid damage to the cord while
pulling.Placethe cord awag from traffic areas
soit will not be stepped on,tripped overor
subjected to damage.
• Donotattempt to repairor replaceang part
of this appliance or attempt ang servicingunless
specificallyrecommended in this Owner's Manual
or in publisheduser-repairinstructionsthat gou
understandand havethe skillsto carrg out.
• Beforediscarding a drger,or removing it from
service,remove the dryer door to prevent children
from hiding inside.
• Do not tamper with controls.
READANDFOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS

About the drger control panel.
Control Panel
Throughout this monuol, feotures ond oppeoronce mog vorg from your model
POWER

ge.com
Power
Press to "wake up" the display. If the display is active, press to put the dryer in the idle mode.
NOTE: Pressing POWER does not disconnect the appliance from the power supply.
Cycles
The cycle controls the length and tumble speed of the drying process. The chart below will help you
match the dry setting with the loads.
Sensor Cycles
COTTONS For cottons and most linens.
MIXED LOAD For loads consisting of cottons and polg-blends.
WRINKLE FREE For wrinkle-free and permanent press items.
ACTIVE WEAR Clothing worn for active sports exercise and some casual wean Fabrics include new
technology finishes and stretch fibers such as Spandex.
DELICATES For lingerie and special-care fabrics.
ULTRA DELICATES For delicate fabrics.
Manual Dry Cycles
SPEED DRY For small loads that are needed in a hurry, such as sports or school uniforms. Can also be
used if the previous cycle left some items damp, such as collars or waistbands.
DEWRINKLE For removing wrinkles from items that are dry or slightly damp. This cycle is not
recommended for delicate fabrics.
AIR DRY Use this feature to tumble items without heat.
My Cycles (on some models)
MY CYCLES Press to use, create or modify custom dry cycles.
O
0
Time Dry
Use to set your own dry time. TIMEDRYis also recommended for small loads.
To use TIME DRY:
1. Press the TIME DRY button until the amount of time you want is selected.
2. Select the temperature by pressing the TEMP button.
& Close the door.
4. Press the START/PAUSE button.
Dry Level
The sensor continuously monitors the amount of moisture in the load. When the moisture in your
clothes reaches your selected dry level, the dryer will stop.
VERY DRY Use for heavy fabrics.
MORE DRY Use for heavy or mixed type of fabrics.
NORMAL Use for normal dryness level suitable for most loads. This is the preferred cycle
for energy saving.
LESS DRY Use for lighter fabric (ideal for ironing).
DAMP DRY For leaving items partially damp.

About the dryer control panel (cont.).
OTEMP
You can change the temperature of your dry cycle.
HIGH For regular to heavy cottons.
MEDIUM HIGH For regular cottons.
MEDIUM For synthetics, blends and items labeled permanent press.
LOW For delicates, synthetics and items labeled Tumble Dry Low.
EXTRALOW For lingerie and special-care fabrics.
O My Cycles
Set up your favorite combination of settings and save them here for one touch recall.
These custom settings can be set while acycle is in progress.
To store a MY CYCLES combination of settings:
1. Select your drying cycle.
2. Change TEHP and DRY LEVEL settings to fit your needs.
& Select any drying OPTIONS you want.
4. Press and hold the _ pad for three seconds to store your selection. A beep will sound
and the pad will light up.
To recall your stored MY CYCLES combination:
Press the MY CYCLES button before drying o Iood.
To chonge your stored MY CYCLES combination:
Follow steps 1-4 in "To store o MY CYCLES combination of settings'.
START
Press to start a dry cycle. If the dryer is running, press it once and it will pause the dryeE Press it again
to restart the dryer cycle.
8

About cycleoptions.
NOTE:Not all featuresare availableonalldrger models.
Wrinkle Care
w_.KLECARE
mumb,esthedrumw,thoutheatfor10
seconds everg 5 minutes for up to 3 hours.
The drger will displag a "racetrack" on the
display during the Wrinkle Care phase.
Wrinkle care shuts off automatically when
the door is opened.
ge.com
Signal
Alerts you that the cycle is complete.
The clothes should be removed when the
beeper goes off so wrinkles don't set in.
PressSIGNAL to select low or high volume,
or to turn the beeper off.
The beeper will continue to sound every
2 minutes (maximum of 4 times).
MORE TIME
MORE TIME ,ncreasesthedryt,mein1-rainute
increments, up to 99 minutes.
LESSTIME LESS TIME
Decreasesthedrytimein1-minute
_ncrements,downto10m_nutes.

Lock
You can lock the controls to prevent ang
selectionsfrom being made. Or you can lock
the controls after you have started a cgcle.
Children cannot occidentally start the dryer
bg touching pods with this option selected.
To lockthe dryer, pressand hold the DRY
LEVELand TEMPbuttons at the same time
for 3 seconds.Tounlock the drger,pressand
hold the DRYLEVELand TEMPbuttons for
3 seconds.
When the lock function is enabled, CL will
blink in the displag with the estimated time
remaining.
Estimated Time Remaining
Displagsthe approximate time remaining
until the end of the cgcle.
Asthe cgcle begins, you will seean initial
approximate total cgcle time in the displag.
Then lights will "race" in the display.This
means the dryer is continuously monitoring
the amount of moisture inthe load.Thelights
will continue until the drger sensesa low level
of moisture in the load.Atthat point, the
dryer will calculate and display the
approximate time remaining.
MY CYCLES
Mg Cgcles
Tosave a favorite cgcle,set the desired
settings and hold down the MYCYCLES
button for 3 seconds.A beep will sound
to indicate the cgcle hasbeen saved.
To usegour custom cgcle,pressthe MY
CYCLESbutton before drying a load.
To change the saved cgcle,set the desired
settings and hold down the MYCYCLES
button for 3 seconds.
Seepage 8 for more details.
10

Dryer Features.
Changing the Drum Lamp
Beforereplacingthe drum lamp, be sureto
unplug the dryer power cord or disconnect
the dryer at the household distribution panel
by removing the fuse or switching off the
circuit breakeE
Thedrum lamp is located at the top left of
the door frame.
1 Removethe screw holding the drum Iomp
shieldin ploce.
2 Slidethe shieldup ond remove.
$ Removethe bulb ond replocewith o
15-wott, 120-volt condelobro-bose bulb.
4 Replocethe Iomp shieldond screw.
Using the Drying Rack
A handy drying rack may be usedfor drying
delicate items such aswashable sweaters.
Hookthe rack over the lint filter sothe rack
extends into the dryer drum.
NOTE:
•Thedrying rack shouldonly be usedwith
the TIMEDRYcycle. It isalso strongly
recommended when drying sneakers.
• Donot usethis drying rack when there are
other clothes inthe dryeE
11

Loadingand Usingthe Dryer.
Always follow fabric manufacturer's care label when laundering.
Sorting and Loading Hints
As a general rule,ifclothes are sorted
properlu for the washer,theu are sorted
properlu for the drueETru alsoto sort items
according to size.Forexample,do not dru a
sheet with socks or other small items.
Donot add fabric softener sheetsonce
the load hasbecome warm. They mau
cause fabric softener stains.Bounce®
Fabric Conditioner Dryer Sheetshave
been approved for usein all GEDryerswhen
usedin accordance with the manufacturer's
instructions.
Do not overload.Thiswastes energUand
causeswrinkling.
Do not dry the following items:
fiberglassitems, woolens,rubber-coated
items, plastics,items with plastictrim and
foam-filled items.
Fabric Care Labels
Beloware fabric care label "symbols"that
affect the clothing you will be laundering.
Dry Labels
TumbleDF" _
dry Dry Normal
setting High Medium
b-qb-q
Permanent Press/ Gentle/
wrinkle resistant delicate
Do not dry
Do not tumble dry (used with
do not wash)
(9 •
Low No heat/air
Line dry/ Drip dry Dry flat In the shade
hang to dry
12

J
ge.com
Care and Cleaning of the Dryer
Dryer Interior and Duct: Theinterior of
the appliance and exhaust duct should be
cleaned once a year by qualified service
personnel.
TheExterior: Wipe or dust any spillsor
washing compounds with a damp cloth.
Dryer control panel and finishes may be
damaged by some laundry pretreatment
soil and stain remover products.Apply these
products away from the dryer Thefabric
may then be washed and dried normally.
Damage to your dryer caused by these
products isnot covered by your warranty.
Donot touch the surface or the display with
sharp objects.
TheLint Filter: Cleanthe lint filter beforeeach
use.Removeby pulling straight up. Runyour
fingers acrossthe filter A waxy buildup may
form on the lint filter from using dryer-added
fabric softener sheets.Toremove this buildup,
wash the lint screen in warm, soapy water
Dry thoroughly and replace. Donot operate
the dryer without the lint filter in place.
Vacuum the lint from the dryer lintfilter area
if you notice a change in dryer performance.
Stainless Steel: Toclean stainlesssteel
surfaces, usea damp cloth with a mild,
nonabrasive cleaner suitable for stainless
steel surfaces.Removethe cleaner residue,
and then dry with a clean cloth.
Thestainless steel usedto make the
dryer drum provides the highest reliability
available in a GEdryer. If the dryer drum
should be scratched or dented during normal
use,the drum will not rust or corrode.These
surface blemisheswill not affect the function
or durability of the drum.
TheExhaust Hood: Checkwith a mirror that
the insideflaps of the hood move freely when
operating. Hake surethat there isno wildlife
(birds,insects,etc.)nesting insidethe duct or
hood.
13

Installation
Instructions Drger
DPGT650 and UPGT650
I uestions? Call 800.GE.CARES (800.432.2737) or visit our Web site at: ge.com
In Canada, call 1.800.561.3344, or visit geappliances.ca
BEFORE YOU BEGIN
Read these instructions completely end carefully.
• IMPORTANT- savetheseinstructionsfor
local electrical inspector's use.
• IMPORTANT- Observe ell governing codes
and ordinances.
• Note to Installer- Be sure to leave these
instructions with the Consumer.
• Note to Consumer - Keep these instructions for
future reference.
• This dryer must be exhausted to the outdoors.
• Before the old dryer is removed from service or
discarded, remove the dryer door.
• Service information and the wiring diagram ore
located in the control console.
• Do not allow children on or in the appliance. Close
supervision of children is necessary when the
appliance is used near children.
• Proper installation is the responsibility of
the installer.
• Product failure due to improper installation
is not covered under the Warranty.
• Gas dryers are not approved for mobile home
installation.
FOR YOUR SAFETY:
-&WARNING
Use only rigid metal or flexible metal 4-inch
diameter ductwork for exhausting to the
outdoors. Never use plastic or other combustible
easy-to-puncture ductwork.
This appliance must be properly grounded and
installed as described in these instructions.
Do not install or store appliance in an area where
it will be exposed to water and/or weather.
The National Fuel Gas Code restricts installations
of gas appliances in garages. They must be 18
inches off the ground and protected by a barrier
from vehicles.
• Install the dryer where the temperature is above
50°F for satisfactory operation of the dryer
control system.
FOR GAS MODELS ONLY:
NOTE: Installation and service of this drger must
be performed bg a qualified installer, service
agencg or the gas supplier.
In the Commonwealth of Massachusetts:
This product must be installed bg
a licensed plumber or gas fitter.
When using ball-tgpe gas shut-off valves,
theg shell be T-handle-tgpe.
A flexible gas connector, when used,
must not exceed 3 feet,
I
14

Installation Instructions
UNPACKING YOUR DRYER
Tilt the dryer sideways and remove the foam
shipping pads by pulling at the sides and breaking
them away from the dryer legs. Be sure to remove
all of the foam pieces around the legs.
Remove the bag containing the drying rack,
literature and serial cable.
LOCATION OF YOUR DRYER
I MPORTANT: Gas dryers are not approved for
mobile home installation.
MINIMUM CLEARANCE OTHER THAN
ALCOVE OR CLOSET INSTALLATION
Minimum clearance to combustible surfaces and
for air openings are:
• 0 inch clearance both sides
• 1 inch front
• ] inches rear
Consideration must be given to provide adequate
clearance for proper operation and service.
DRYER DIMENSIONS
Front View
27"
(68.6 cm)
437/8"
(111.4cm)
Side View
)
51"
'_ (129.5 cm)
]7z/4"
(94.6 cm)
29"
I_ (7].7 cm)

Installation Instructions
LOCATION OF YOUR DRYER (cont.)
REQUIREMENTS FOR ALCOVE OR
CLOSET INSTALLATION
• Your dryer is approved for installation in an
alcove or closet, as stated on a label on the
dryer back.
• The dryer MUST be vented to the outdoors.
See the EXHAUST INFORMATION section.
° Minimum clearance between dryer cabinet and
adjacent walls or other surfaces is:
0" either side
3" frontand rear
• Minimum vertical space from floor to overhead
shelves, cabinets, ceilings, etc., is 52".
• Closet doors must be Iouvered or otherwise
ventilated and have at least 60 square inches
of open area equally distributed. If the closet
contains both awasher and a dryer, doors must
contain a minimum of 120 square inches of open
area equally distributed.
• No other fuel-burning appliance shall be
installed in the same closet with the dryer
(gas models only).
BATHROOM OR BEDROOM
INSTALLATION
• The dryer MUST be vented to the outdoors.
See EXHAUST INFORMATION.
• The installation must conform with local codes or,
in the absence of local codes, with the NATIONAL
ELECTRICALCODE, ANSI/NFPA NO. 70 (for electric
dryers) or NATIONAL FUEL GAS CODE,ANSI Z223
(for gas dryers).
16

Installation Instructions
CONNECTING A GAS DRYER(skip for electric dryers)
TOOLS AND MATERIALS YOU WILL NEED
FOR CONNECTING THE GAS SUPPLY
C! Flat- or straight-blade screwdriver (mag be
needed for cord strain relief)
17Flexible stainless steel or plastic-coated brass
connecting tube (if allowed bg building code)
C! Open-end wrenches for flexible tube and
connector
C!Adjustable pliers (to adjust leveling legs)
C! Pipe wrench for holding drger gas inlet while
attaching adapter elbow
C!Adjustable wrenches (2) for tightening
connections
FOR YOUR SAFETY:
-&WARNING
Before beginning the installation, turn off the circuit
breaker(s) or remove the drger's circuit fuse(s) at the
electrical box. Be sure the drger cord is unplugged
from the wall.
Turn the drger's gas shutoff valve in the supplg line
to the OFF position.
Shutoff
Valve
Disconnect and discard old flexible gas connector
and ducting material.
17

Installation Instructions
CONNECTING A GAS DRYER(cont.)
GAS REQUIREMENTS
WARNING
• Installation must conform to local codes and
ordinances, or in their absence, the NATIONAL
FUEL GAS CODE, ANSI Z223.
• This gas drger is equipped with a Valve and
Burner Assemblg for use onlg with natural gas.
Using conversion kit WE25X10014, gour local
service organization can convert this drger for
use with propane (LP)gas. ALL CONVERSIONS
MUST BE MADE BY PROPERLYTRAINED AND
QUALIFIED PERSONNELAND IN ACCORDANCE
WITH LOCAL CODES AND ORDINANCE
REQUIREMENTS.
• The drger must be disconnected from the gas
supplg piping sgstem during ang pressure testing
of that system at a test pressure in excess of
0.S PSI(3./4 KPa).
• The dryer must be isolated from the gas supply
piping system by closing the equipment shut-off
valve during any pressure testing of the gas
supplg piping of test pressure equal to or less
than 0.5 PSI (3.I4KPa).
DRYER GAS SUPPLY CONNECTION
GAS SUPPLY
• A 1/8" National Pipe Taper thread plugged
tapping, accessible for test gauge connection,
must be installed immediately upstream of the
gas supplg connection to the dryer. Contact your
local gas utility should you have questions on the
installation of the plugged tapping.
• Supplg line is to be 1/2" rigid pipe and equipped
with an accessible shutoff within 6 feet of, and in
the same room with, the dryer.
• Use pipe compound appropriate for natural or LP
gas or use Teflon ®tape.
• Connect flexible metal connector to dryer and
gas supply.
IN THE COMMONWEALTH
OF MASSACH USETTS
• This product must be installed by a licensed
plumber or gas fitter,
• When using ball-type gas shut-off valves, they
shall be the T-handle type.
• A flexible gas connector, when used, must not
exceed 3 feet.
t 2s/8,, 3/8" NPT MALE THREAD GAS SUPPLY
(6ca}
NOTE: Add to vertical dimension
the distance between cabinet
bottom to floor.
18

Installation Instructions
CONNECTING THE DRYER TO THE
GAS SUPPLY
[] Install a female 3/8" NPT elbow at the end of
the drger gas inlet.
Install a 3/8" flare union adapter to the female
elbow.
IMPORTANT: Use a pipe wrench to securelg hold
on to the end of the drger gas inlet to prevent
twisting the inlet.
NOTE: Applg pipe compound or Teflon ®tape to
the threads of the adapter and drger gas inlet.
Applg Pipe Compound
[] Attach the flexible metal gas line connector
to the adapter.
/
[] Tighten the flexible gas line connection using
two adjustable wrenches.
CONNECTING THE DRYERTO THE
GAS SUPPLY{cont.}
[] Install a 1/8" NPT plugged tapping to the drger
gas line shut-off valve for checking gas inlet
pressure.
Install a flare union adapter to the plugged
tapping.
NOTE: Applg pipe compound or Teflon ®tape to
the threads of the adapter and plugged tapping.
Applg pipe compound or S_
Teflon ®tape to all male _:------_ /Plugged
threads. _ _1_"Tapping
\
Shut-off Valve _
[] Tighten all connections using two adjustable
wrenches. Do not overtighten,
[] Open the gas shutoff valve.

Installation Instructions
CONNECTING A GAS DRYER(cont.)
TEST FOR LEAKS
WARNING - Never use an open
flame to testforgas leaks.
Check all connections for leaks with soapg solution
or equivalent.
Applg a soap solution. The leak test solution must
not contain ammonia, which could cause damage
to the brass fittings.
If leaks are found, close the valve, retighten the joint
and repeat the soap test.
Open Gos
Volve
ELECTRICAL CONNECTION
INFORMATION FOR GAS DRYERS
_AWARNING - Toreducetheriskof
fire, electrical shock and personal injury:
• Do not use an extension cord or an adapter plug
with this appliance.
• The drger must be electricallg grounded in
accordance with local codes and ordinances, or
in the absence of local codes, in accordance with
the NATIONAL ELECTRICALCODE, ANSI/NFPA
NO. 70.
ELECTRICAL REQUIREMENTS
FOR GAS DRYERS
This appliance must be supplied with 120V, 60Hz,
and connected to a properlg grounded branch
circuit, protected bg a 15- or 20-amp circuit breaker
or time-delag fuse.
If electrical supplg provided does not meet the
above specifications, it is recommended that a
licensed electrician install an approved outlet.
_i,WARNING - This dryer is
equipped with a three-prong (grounding) plug for
your protection against shock hazard and should
be plugged directlg into a properlg grounded
three-prong receptacle. Do not cut or remove
the grounding terminal from this plug.
Ensure proper
ground exists
before use.
If local codes permit, on external ground wire (not
provided), which meets Iocol codes, moy be odded
by ottoching to the green ground screw on the reor
of the dryer, and to an olternate estoblished ground.
Ground
Screw
2O
