GE GTX33EASK Manual

GTX33EASK
GE Appliances 6.2 Cu. Ft. Capacity
Aluminized Alloy Drum Electric Dryer
For answers to your Monogram, GE Café™Series, GE Profile™Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center®Service, 800.626.2000. Specification Revised 5/16
ELECTRIC DRYER RATING:
240V 5600W 24A 60Hz
208V 4400W 22A 60Hz
EXHAUST OPTION: 4-way rear, right,
left and bottom
CIRCUIT REQUIREMENTS: An
individual, properly-grounded branch
circuit, protected by a 30-amp circuit
breaker or a time-delay fuse, is required.
NOTE: Dryer wall outlet must be
located within 36" of service cord entry
and acessible when dryer is mounted in
position.
INSTALLATION INFORMATION :
For complete information, see installation
instructions packed with your dryer.
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
22 1/2" 26 3/4"
4"
1 3/4"
3 1/4"
4 1/4"
37 1/2"
44"
27"
5"
POWER CORD 4 1/2"
11 3/4"
SIDE VIEW REAR VIEW
Listed by
Underwriters
Laboratories
SPECIAL INSTALLATION REQUIREMENTS
ALCOVE OR CLOSET INSTALLATION:
- If your dryer is approved for installation in an alcove or closet, it will be stated on a label on
the dryer back.
- The dryer MUST be exhausted to the outside.
- Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side; 1" front, top and rear
- Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in.
of open area equally distributed. If this closet contains both a washer and a dryer, doors must
contain a minimum of 120 sq. in. of open area equally distributed.
- No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
BATHROOM OR BEDROOM INSTALLATION:
- The dryer MUST be exhausted to the outdoors.
- The installation must conform with the local codes, or in the absence of local codes, with the
National Electric Code and National Fuel Gas Code, ANSI Z223 for gas dryers.
MINIMUM CLEARANCES OTHER THAN ALCOVE OR CLOSET INSTALLATION:
- Minimum clearances to combustible surfaces are: 0" both sides; 1" rear
DRYER EXHAUSTING INFORMATION:
Use metal duct only, vertical and horizontal ducting.

GTX33EASK
GE Appliances 6.2 Cu. Ft. Capacity
Aluminized Alloy Drum Electric Dryer
For answers to your Monogram, GE Café™Series, GE Profile™Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center®Service, 800.626.2000. Specification Revised 5/16
FOR COMPLETE INFORMATION, SEE INSTALLATION INSTRUCTIONS PACKED
WITH YOUR DRYER.
DUCTING MATERIALS:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust
duct. If rigid metal duct cannot be used, then UL-listed flexible metal (semi-rigid) ducting can
be used (Kit WX08X10077). In special installations, it may be necessary to connect the dryer
to the house vent using a flexible metal (foil-type) duct. A UL-listed flexible metal (foil-type)
duct may be used ONLY in installations where rigid metal or flexible metal (semi-rigid) ducting
cannot be used AND where a 4" diameter can be maintained throughout the entire length of
the transition duct. Please see installation instruction packed with your dryer for complete
instructions when using flexible metal (foil type) ducting.
EXHAUST LENGTH CALCULATION:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or
bottom of dryer, add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is
shown in the table. A turn of 45° or less may be ignored. Two 45° turns within the duct
length should be treated as a 90° elbow. A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
CAUTION: For personal safety do not terminate exhaust into a chimney, under any enclosed
house floor (crawl space), or into an attic, since the accumulated lint could create a fire hazard
or moisture could cause damage. Never terminate the exhaust into a common duct or plenum
with a kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird
nesting, etc. The wall cap must also be located at least 12" above the ground or any other
obstruction with the opening pointed down.
FOR MORE INFORMATION ON VENTING KITS AND ACCESSORIES, PLEASE CALL
1-800-GE-CARES.
DRYER EXHAUSTING INFORMATION—
USE METAL DUCT ONLY VERTICAL AND
HORIZONTAL DUCTING
A
B
2-1/2
4
GE Dryer Vent
A
B
2-1/2
4
GE Dryer Vent
A
BEST PERFORMANCE
Maximum length
of 4" dia rigid
metal duct
Exhaust hood type
Domestic dryer models
Number
of 90°
turns
A
4"
opening
B
2-1/2"
opening
Long Vent 6.1-7.4 cu. ft.
capacity electric & gas
(GTD33, GTD42, GTD45,
GTD65, GTX22, GTX33, GTX42
and GTX65)
0120 ft. 90 ft.
1100 ft. 75 ft.
285 ft. 65 ft.
370 ft. 55 ft.
460 ft. 45 ft.
555 ft. 35 ft.
For every extra 90° elbow, reduce the allowable vent system
length by 10 ft.
Two 45° elbows will be treated like one 90° elbow.
For the side exhaust installations, add one 90° elbow to the chart.
When calculating the total vent system length, you must add all
the straight portions and elbows of the system (including the
transition duct.

GTX33EASK
GE Appliances 6.2 Cu. Ft. Capacity
Aluminized Alloy Drum Electric Dryer
Specification Revised 5/16
FEATURES AND BENEFITS
Aluminized alloy drum – Improves energy efficiency and resists corrosion
3 heat selections – Offer a choice of drying temperatures for personalized
fabric care.
Up to 120 ft. venting capability – Provides flexible installation
Auto Dry – For clothes that come out feeling and looking great, this setting
monitors air temperature to set the optimal drying time
Rotary electromechanical controls – Make it simple to set cycles
Up-front lint filter – Makes cleaning out lint easy
Reverse-a-door – Door opening can be reversed to meet laundry room needs
Model GTX33EASKWW – White
GTX33EASKWW_GTX33GASKWW_GTX33GASKWW_GTD33GASKWW
