GE JET210 Installation instructions

mdCareof —
of
youroven -p5
bytinle T
p
Save md
you
usetie Solver pv!i
.. .. . —....-—......—-— —-,....--.,.-=

Readthisbookcarefully.
It isdesignedto helpyou operate
and maintainyour newMicrowave
Ovenproperly.
Keepit handyfor answersto your
questions.
If you don’t understandsomething
or need more help. . .
Call, toll free:
The GE Answer Center’”
800.626.2000
consumer information service
or write: (include your phone
number);
Consumer Affairs
General Electric Company
Appliance Park
Louisville, KY40225
Writedownthe rnoddand
serialnumbers.
You’llfind them on a label inside the
oven on the upper left side.
These numbers are alsoon the
Consumer Product Ownership
Registration Card that came with
your Microwave Oven. Before
sending in this card, pleasewrite
these numbers here:
Model No.
Be sure yew’ Mkrowwave
overtisK?gisk!red.
It is important that we,the manu-
facturer, know the location of your
MicrowaveOvenshould a need
occur for adjustments.
Your supplier is responsiblefor
registering you asthe owner.
Pleasecheck with your supplier to
besure he hasdone so; also send
in your Consumer Product Owner-
ship Registration Card. If you move,
or if you are not the original pur-
chaser pleasewrite to us,stating
model and serial numbers.This
appliancemustberegistered.
Pleasebecertainthatitis.
Write to:
General Electric Company
RangeProduct Service
Appliance Park
Louisville, KY 40225
H~OU receivedadamaged
oven.. .
immediately contact the dealer (or
builder) that sold you the Micro-
wave Oven.
Savethe and money.
Beforeyourequestservice,check
theProblemSolveron page 15
lists minor causesof operating
problems that you can correct
yourself.
It
TO
(a) Do Not Attempttooperatethis
ovenwith the door open sinceopen
door operation can result in harmful
exposureto microwaveenergy. It is
important not to defeator tamper
with the safety interlocks,
(b) DoP&MPlaceany object
betweenthe ovenfront face and the
.door or allow soil or cleaner residue
to accumulate on sealingsurfaces.
(c) Do Not Operatethe ovenif it is
damaged. It is particularly important
that the oven door close properly
and that there is no damageto the:
(1) door (bent)
(2) hinges and latches (broken or
loosened)
(3) door sealsand seaiing surfaces.
(d) The (Men Shouldnot be
adjusted or repaired by anyone
except properly qualified service
personnel.
Serial No.
Use these numbers in any
correspondence or servicecalls
concerning your Microwave Oven.
Av-ailableat extra-cost from your GE supplier.
!JXll $Neeve Kit
Converts your countertop oven to abuilt-in wall oven. This microwave
oven is UL listed for installation over GE wall ovens with black glass
doors.
2

Before Microwaving ............ 2
SafetyInstructions .....,,.....3-4
Features of Your Oven . . . . . . . . . . 5
TouchControl Panel , , , ., ..., . . 6
Setthe Clock... ............... 6
Time Cook .................... 7
Defrosting..................... 8
Temp Cook ................... 9
Automatic Roasting
&Chart ..................10-11
Hold/Timer, .................. 12
Careof YourOven ............ 13
Grounding Instructions . . . . . . . . 14
Useof Extension Cords. ....... 14
The Problem Solver ........... 15
ConsumerServices. ........... 19
Warranty .............Back Cover
@Makesure all utensils usedin
your microwave oven are labeled
“suitable for microwaving”. Check
your Cookbook forspecifictest
to determine ’’microwave-safe”
utensils.
@papertowels, wax paper, and
plastic wrap can beused tocover
dishesin orderto retain moisture
and prevent spattering.
@Some microwaved foods require
stirring, rotating, or rearranging.
Check your Cookbook forspecific
instructions.
@Some foods such as unshelled
eggsand hot dogs must be pierced
toaliow steamto escape during
cooking.
.-
--
..
-
Read 43!1 before usingthis
When usingelectrical appliances M+%$l=
basic safetyprecautions should e
befollowed, including the
following:
WARNING—TOreduce the risk
of burns, electric shock,fire,
injury to personsor exposureto
excessivemicrowaveenergy:
IS Use this appliance only for its
intended useas described in this
manual.
IS Readand follow the specific
“PRECAUTIONS TO AVOID
POSSIBLEEXPOSURETO
EXCESSIVEMICROWAVE
ENERGY”found on page2.
@This appliance must be
grounded. Connect only to
properly grounded outlet. See
“GROUNDING INSTRUCTIONS”
found on page 14.
eFor best operation, plug this
appliance into it own electrical
outlet, to prevent flickering of
lights, blowing of fuse or trip-
ping of circuit breaker.
eInstall or locate this appliance
only in accordance with the pro-
vided installation instructions.
69 Be certainto phwethe fron~
surfacedthe door threeinches
or more backfrom the cm.mter-
top edge to avoidaccidentaltip-
ping of the appliancein normal
usage.
eDo not cover or block any
openings on the appliance.
eDo not use outdoors.
eDo not immerse cord or plug
in water.
eKeep cord away from heated
surfaces.
oDo not let cord hang over
edge of table or counter.
eDo not operate this appliance
if it has adamaged cord or plug,
if it is not working properly, or if
it has been damaged or
dropped.
oSee door surface cleaning
instructions on page 13.
3
@This appliance should be ser-
viced only by qualified service
personnel.Contact near~st
authorizedservicefacility for
examination, repairor
adjustment.
eAs with any appliance,close
supervision is necessarywhen
used by children.
@To reduce the risk of fire in
the oven cavity:
—Do not overcook food. Care-
fully attend appliance if paper,
plastic, or other combustible
materials are placed inside the
oven to facilitate cooking.
—Removewire twist-ties from
paper or plastic bags’before
placing bag in oven.
—-Donot useyour microwave
oven to dry newspapers.
—Do nol pop popcorn in your
microwaveovenunless in aspe-
cial microwave popcorn acces-
sory or unless you usepopcorn
labeled for use in microwave
ovens.
—Do not operatethe ovenwi=dle
emptyto avoiddamageto the
ovenand the dangerof fire. If by
accident the ovenshould run
empty aminute or two, no harm
is done. However, try to avoid
operating the oven empty at all
times—it savesenergy and pro-
longs life of the oven.
—If materials inside the oven
should ignite, keep oven door
closed, turn oven off, and dis-
connect the power cord, or shut
off power at the fuse or circuit
breaker panel.
@Some products such as
whole eggs and sealed con-
tainers—for example, closed
glass jars—may explode and
should not be heated in this
oven.
63 Avoid baby food in
glass jars, even without their
lids; especially meat and egg
mixtures.
(continued next p~ge)

oDon’t defrostfrozenbever-
ages~nnarrow necked bottles;
especiallycarbonatedones.
Evenif the container is opened,
pressurecan build up. This can
causethe container to burst,
resulting in injury.
@use metalonly as directed in
Cookbook. Metalstrips as used
on meatroastsare helpful when
usedasshown in Cookbook.
TV dinners may be cooked in
metaltrays but when using shelf
they must be replaced in their
box. However,when using metal
in microwaveoven,keepmeta!
(exceptfor DOUBLE DUTY’M
shelf) at lleastl-inch awayfrom
sidesofover%
43Cookingutensilsmay
becomehot becauseof heat
transferred from the heated
food. This is especially true if
plastic wrap has been covering
the top and handles of the
utensil. Potholders may be
neededto handle the utensil.
~Sometimes,the oven floor
Carlbecome too hot to touch.
Be careful touching the floor
during and after cooking.
eDo not useany thermometer
in food you are microwaving
unless that thermometer is
designed or recommended for
use in the microwave oven.
eRemovethe temperature
probe from the oven when not
using it to cook with. If you leave
the probe inside the oven without
inserting it in food or liquid, and
turn on microwave energy, it can
create electrical arcing in the
oven, and damage oven walls.
4BPlastic Utensiis—Plastic
utensils designedfor microwave
cooking arevery useful,but
should be usedcarefully. Even
microwave plastic may not be as
tolerant of overcooking condi-
tions as areglass or ceramic
materialsand may softenor
char if subjected to short periods
of overcooking. In longer expo-
sures to overcooking, the food
and utensils could ignite. For
these reasons:1) Usemicro-
wave plastics only “and use
them” in strict compliance with
the utensil manufacturer’s
recommendations. 2) Do not
subject empty utensilsto micro-
waving. 3) Do not permit children
to use p!astic utensils without
complete su~ervision.
eWhen cooking pork follow
our directions exactly and
always cook the meatto at least
170°.This assuresthat, in the
remote possibility that trichina
may be present in the meat, it
will be killed and meatwill be
safeto eat.
49Boiling eggs (in am! out d
she!!) is not recommended for
microwave cooking. Pressure
can build up inside egg yolk and
may cause it to burst, resulting
in injury.
19Foods with unbroken outer
“skin”such as potatoes, hot
dogs or sausages,tomatoes,
apples, chicken livers and other
giblets, and eggs (seeabove)
should be pierced to allow
steam to escape during cooking.
e+‘T30ihbk” cooking pouches
and tightlyclosedplasticbags
should beslit, pierced or vented
as directed in Cookbook. Ifthey
are not, plastic could burst dur-
ing or immediately aftercooking,
possibly resulting in injury. Also,
plasticstoragecontainersshould
beat leastpartially uncovered
becausethey form atight seal.
When cooking with containers
tightly coveredwith plastic wrap,
removecovering carefully and
direct steamaway from hands
and face.
oUseof the UNJBLE KWWTM
shelf accessory. (Seeyour Cook-
book for proper use.)
—-Removethe shelf from oven
when not in use.
—-Donot store or cook with
shelf on floor of oven.Product
damage may result.
—Use potholders when handling
the shelf and utensils.They may
be hot.
—Do not use microwave brown-
ing dish on shelf.The shelf could
overheat.
THESE

1.
2.
3.
4.
5.
&
7.
49’
\
o–
I
Door Handle. Pull to open door. Door must be
securely latched for oven to operate.
DoorLatches.
ViewingWindowwith Metal Shield. Metal screen
permits viewing of foods and keeps microwaves
confined inside oven.
Antenna Cover. Protects the microwave energy
distributing antenna. Do not remove this cover.
Youwill damage the oven.
Oven Vent.
Own interior Light. Turns on when the door is
opened or when the oven is operating.
Oven Floor.
8.
9.
10*
11.
12.
NIKXKYWEFMJIOMETERTMTemperature Probe.
Use with TEMP COOK and AUTO ROAST func-
tions only.
Receptaclefor TemperatureProbe. Temperature
Probe must be securely inserted into receptacle
when using TEMP COOK or AUTO ROAST.
DOUBLE-DUTYTMShelf. Lets you microwave sev-
eral foods at once. Do not use shelf without
plastic spacers in place as shown. (See Safety
Tips for special instructions.) When this shelf is
not in use, please remove from the oven.
Touch Control Paneland Display. See next page
for instructions.
Model and Serial Numbers.
5

D!SPLAY, Displays time of day,
time or temperature during cooking
functions (or power level when
power Level Pad is touched),
TIME COOK. Microwave for a
preset amount of time using auto-
matic Power Level 10 (or change
power level after entering cooking
time. See page 7.)
TENIP COOK. Use the tempera-
ture probe to cook by using a
preset temperature. Oven shows
temperature until preset tempera-
ture is reached and then turns off.
(See page 9.)
NUMBER PADS. Touch these pads
to enter cooking/defrosting time,
time of day, temperature, Power
level, or Auto Roast Code.
POWER LEVEL. Touch this pad
before entering another power
level number if you want to change
from automatic Power Level 10
(HIGH) for cooking or Power Level
3(LOW) for defrosting.
START. After all selections are
made, touch this pad to start oven.
6
/
\
DEFROST. Gentle, generally uni-
form thawing at automatic Power
ALevel 3(or change power level
after entering defrosting time. See
page 8.)
IHC)LD/Tli’VIER.This feature uses
no microwave energy while it func-
tions as both akitchen timer or as
aholding period between defrost
and time or temperature cooking.
(See page 12.)
CLOCK. Touch this pad to enter
time of day or check time of day
while microwaving. To set clock,
first touch CLOCK pad and then
enter time of day. For example, if
time is 1:30, touch number pads 1,
3, and Oand 1:30 will appear in
display. Re-touch CLOCK pad. To
resetor change time, simply repeat
above process.
Cl-EAR/OFF. When touched, it
shuts off the oven and erases all
settings (except time of day).
AUTO ROAST. Insert Probe, touch
this pad, and desired number pad
for Code to temperature cook meat
with automatic preset program.
(See page 10.)

The TIME COOK feature allows
you to preset the cooking time.
The oven shuts off automatically.
Power Level 10is automatically set
for time cooking, but you may
change this for more flexibility.
See your Cookbook.
To become better acquainted with
TIME COOK function, make acup
of coffee by following the steps
below.
Step 1: Fill acup 2/3 full of water
and add 1teaspoon of freeze dried
coffee. Useacup that has no metal
decoration. Place cup in oven and
close door.
Step 2: Touch TIME COOK. The
display shows :0, Signal light
above TIME COOK flashes. Power
Level 10 is automatically set, but
does not appear on display.
Step 3: Select your time. Touch
1, 2 and Ofor aminute and 20 sec-
onds. 1:20 and signal light above
TIME COOK appear on display. If
another Power Level is desired
touch POWER LEVEL and the
number, although Power Level 10
(HIGH) is preferred for this cup of
coffee.
Step 4: Touch START. Time
counting down shows on display.
Step 5: When time is up, oven
sounds and oven, light, and fan
shut off.
arid
Q. Iset my oven for the time called
for in the recipe but at the end of
the time allowed, my dish wasn’t
done. What happened?
A. Since house power varies due
to time or location, many Time
Cook recipes give you atime range
to prevent overcooking. Set the
oven for minimum time, test the
food for doneness, and cook your
dish alittle longer, if necessary.
Q. Iwant to cook my dish on a
Power Level other than HIGH, what
do Ineed to do?
A. To change the Power Level,
touch the POWER LEVEL pad after
entering desired cooking time.
Enter the desired number and then
touch START.
Q. Can Iinterrupt my Time Cook
function to check the food?
A. Yes. To resume cooking, simply
close the door and touch START.
NOTE: Microwave power will not
come on until you are ready. You
must touch START for cooking to
begin.
Q. itouched the number pads and
selected my power level. When I
touched START, however, my oven
didn’t come on. Why not?
A. The TIME COOK pad must be
touched before setting the number
pads or else your oven will not be-
gin cooking.
Q. Itried to change Power Level
but the display changed back to
cooking time. Why?
A. After touching Power Level pad
you only have 4seconds to enter
the number. Try setting controls
again.
7

The Defrost setting is designed for
even thawing necessary for large
amounts of food and is one of the
most important advantages of a
microwave oven.
Power Level 3is automatically
set for defrosting, but you may
change this for more flexibility.
See your Cookbook for the
complete defrosting chart.
become better acquainted with
the defrost functions: defrost fro-
zen pork chops by following the
steps below.
Step 1: Place package of frozen
chops in the oven and close door.
Step 2: Touch DEFROST. Display
reads :0. Power Level 3is automat-
ically set in oven but does not
appear on readout. Signal Light
above DEF. flashes.
Step 3: Touch 8,0, and Ofor 8min-
utes. 8:00 and signal light above
DEF. are displayed. If you wish to
change Power Level,touch POWER
LEVEL pad and then new number.
Step 4: Touch START. Time counts
down on display. When cycle is
completed, the oven signals and
automatically shuts off.
Step 5: Turn package over, close
door and repeat Steps 2, 3 and 4.
Step 6: When oven signals and
shuts off, remove package and sep-
arate chops to finish defrosting.
!llefmhg Tips
@Foodsfrozen in paper or
plastic can be defrosted in the
package.
@For even defrosting, many
foods need to be broken up or
separated part of the way through
the defrosting time.
@Homemade dinners can be
frozen in shallow foil trays and
heated for later use. (Do not heat
on metal shelf). Select foods
which microwave well.
ePre-packaged frozen dinners
can be defrosted and microwave
cooked, but foil tray must be
returned to box before cooking
on metal shelf.
@Check your Cookbook for
other defrosting tips.
and
Q. When Ipress START, Ihear a
dull thumping noise. What is it?
A. This sound is normal. It is letting
you know the oven is using a
Power Level lower than HIGH.
Q. Can IDefrost small items in a
hurry?
A. Yes, but they will need more fre-
quent attention than usual. Raise
the Power Level after entering the
time by touching POWER LEVEL
and 7 or 10. Power Level 7cuts the
time in Yp;Power Level 10 cuts the
time to %. During either, rotate or
stir food frequently.
Q. Can Iopen the door during DE-
FROST to check on the progress
of my food?
A. Yes. You may open the door at
any time during microwaving. To
resume defrosting, close the door
and press START.
Q. Why don’t the defrosting times
in the Cookbook seem right for my
food?
A. Cookbook times are average.
Defrosting time can vary according
to the temperature in your freezer.
Set your oven for the time in-
dicated in your Cookbook. If your
food is still not completely thawed
at the end of that time, re-$et your
oven and adjust the time ac-
cordingly.
C?.Can Iselect aPower Level other
than automatic Power Level 3for
defrosting?
A. Yes. Some smaller foods may be
defrosted quicker on higher Power
Levels but for even, carefree de-
frosting, Power Level 3is sug-
gested. Check the chart in the
Cookbook for specific times and
Power Levels.
8
.

—For many foods, internal temperature is the best
test of doneness.
Roasts or poultry are cooked to your preference
when temperature cooking. Heating or reheating
foods accurately to aserving temperature you
desire is simple and easy,
TEMP COOK takes the guesswork out of cooking
because the oven shuts off automatically when the
food is done.
The Probe
The temperature probe is afood thermometer that
gauges the internal temperature of your food; it
must be used when using TEMP COOK or AUTO
ROAST. Follow the directions for use and insertion
on page 10. HANDLE
SENSOR CLIP
Step 1: Insert temperature probe
as directed in Cookbook and at-
tach probe securely in oven wall.
Close the door.
Step 2: Touch TEMP COOK. The
readout display shows Oand signal
light above TEMP COOK flashes.
Step 3: Touch 1, 3, 0or 130°. 130
shows on display. Power Level 10
is automatically set in oven but
does not appear on display.
Step 4: Touch POWER LEVEL pad.
Touch 5for MEDIUM power. P-5
shows on display and then display
reverts back to set finished
temperature.
Step 5: Touch START. After food
reaches 80°, display shows tem-
perature of food counting up.
Step 6: When 130° is reached, the
oven will sound and automatically
shut off. Remove probe and food
from the oven.
cooking Tips
@Usealower power level setting;
it will generally heat more evenly
even though requiring more time.
@Be sure frozen food has been
completely defrosted before insert-
ing probe. Probe may break off if
used in frozen foods.
@Always insert probe into the
center of meaty areas; take care
not to touch the fat or the bone.
6$ Insert probe as horizontally as
possible into foods as directed in
the recipes. Make sure the handle
does not touch the food.
eUse the clip to keep the probe
in place while heating.
@Cover foods as directed in
Cookbook for moisture control and
quick, even heating.
and
Q. Are there any foods Ican’t
TEMP COOK?
A. Yes. Delicate butter icings, ice
cream, frozen whipped toppings,
etc., soften rapidly at warm temp-
eratures. Batters and doughs as
ivell as frozen foods are also diffi-
cult to cook precisely with the
probe. It is best to TIME COOK
these foods.
Q. After Ifollowed the steps and
touched START, asignal sounded
and oven did not start. What is
wrong?
A. If you set the temperature either
below 80° or greater than 199° the
oven will not start. To re-enter,
touch CLEAFVOFF pad and begin
steps again.
Q. Oven sounded and would not
start although Ientered the temp-
erature correctly. What is wrong?
A. If you have not securely seated
the end of the probe into the
receptacle in the oven wall, if you
touch TEMP COOK and have for-
gotten to use the probe or if the
actual food temperature is higher
than set temperature, oven will
sound and not start.
Q. Can Ileave my probe in the
oven if it’s not inserted in the food?
A. No. If the probe is left inside the
oven, touching the oven wall, and
not inserted in food, you may dam-
age the oven.
C?.How do Iknow what tempera-
ture to set?
A. Your Cookbook contains sec-
tions on all types of foods showing
the temperatures needed to cook
the foods to different degrees of
doneness. For reheating, refer to
Reheating Charts in the front
of the Cookbook for specific
temperatures.
9
—.

Auto Roast uses the temperature probe to cook to Just as in conventional roasting, only tender roasts
the desired serving temperature. Unlike Temp should beAuto Roasted until specified internal tem-
Cook, which uses asingle power level, Auto Roast peratures are reached. Lesstender roasts should be
is designed to use up to 3power settings which microwaved by time, according to the Cookbook
automatically switch during roasting, for even and which comes with your oven. Complete information
tender cooking results without overcooking. on preparing roasts for microwaving is in your
—
1
Place tender beef roasts on trivet in
microwave safe dish. Insert probe
horizontally into center meaty area
not touching bone or fat. Cover
with wax paper.
Poultry, pork or ham roasts need
no trivet. Add Yzcup water to roast
dish, cover with plastic wrap. (For
cooking bag. method, see cook-
book.) Insert probe into center
——————r—————ml
Place meat in oven with probe to
the right. Insert cable end of probe
firmly into receptacle on oven wall.
—.
1. Touch AUTO ROAST Pad. Cooking signal light
over Code flashes. Touch number pad 3. Touch
START.
3. Oven monitors internal temperature, automati-
cally switching to lower power as meat’s tempera-
ture rises. This prevents toughening or overcooking.
2. Light over Code shows on display. Readout dis-
plays internal food temperature.
4. After temperature is reached, oven signals and
then shuts off.
.-
10
..—--——-----— ------- ---
