g
PUB # 31-9098 12/02
MODEL SERIES:
TECHNICALSERVICE GUIDE
GE Consumer Home Services Training
JCKSO6
JCKP20
JCK915
JK915
JK955
JKP20
JKP28
JKP48
JKP86
JKS06
JT912
JT915
g
GE and Monogram
27-In. and 30-In. Wall Ovens

IMPORTANT SAFETY NOTICE
The information in this service guide is intended for use by
individuals possessing adequate backgrounds of electrical,
electronic, and mechanical experience. Any attempt to repair a
major appliance may result in personal injury and property
damage. The manufacturer or seller cannot be responsible for the
interpretation of this information, nor can it assume any liability in
connection with its use.
WARNING
Toavoidpersonalinjury,disconnectpowerbeforeservicingthisprod-
uct. If electrical power is required for diagnosis or test purposes,
disconnect the power immediately after performing the necessary
checks.
RECONNECT ALL GROUNDING DEVICES
If grounding wires, screws, straps, clips, nuts, or washers used to
complete a path to ground are removed for service, they must be
returned to their original position and properly fastened.
GE Consumer Home Services Training
Technical Service Guide
Copyright © 2002
All rights reserved. This service guide may not be reproduced in whole or in part
in any form without written permission from the General Electric Company.
!

– 1 –
Table of Contents
Table of Contents
Introduction ..........................................................................................................3
Nomenclature ...................................................................................................... 4
Warrantyz .............................................................................................................. 5
Control Panel Features5 ..................................................................................... 6
Oven.................................................................................................................... 17
Component CompartmentAirflow..................................................................... 19
Control Panel ...................................................................................................... 20
Control Voltage ................................................................................................... 21
Convection Bake Element and Fan Assembly.................................................36
DoorAssembly .................................................................................................... 17
Door Hinge Assemblies ..................................................................................... 19
Door Hinge Replacement .................................................................................. 19
ERC Failure Codes............................................................................................. 26
Electronic Oven Control System ......................................................................20
Electronic Range Control (ERC) ......................................................................20
Glass Touch Models Only.................................................................................. 25
Key Panel Test.................................................................................................... 22
Lift-Off Oven Door ............................................................................................. 17
Lock Thermal Switch.......................................................................................... 35
Motorized Door Lock ......................................................................................... 34
Ohmmeter Test ................................................................................................... 23
Oven Calibration ................................................................................................ 33
Oven Circuits...................................................................................................... 32
Oven Door Gasket ............................................................................................. 18
Oven Sensor and Door Switch Ohmmeter Test ............................................. 30
Oven Thermal Switch ........................................................................................ 35
Sensor and Lock Switch Connectors............................................................... 31
Special Functions............................................................................................... 30

– 2 –
Table of Contents
Table of Contents
Microwave
Refer to Pub # 31-9084, pages 29 through 44, for microwave service
information and warranty for these products.
Schematics and Wiring DiagramsX ..................................................................37

– 3 –
Introduction
The new series of Built-In Electric Wall Ovens are
offered in 27-inch and 30-inch models.They make
an eloquent statement of style, convenience, and
kitchen planning flexibility. In addition to the single
oven and double oven models, a microwave-and-
oven combination unit is available.
The Electronic Touch Controls are simple to
understand and easy to operate. Just read and
touch. It’s easy to see how GE’s fresh ideas can
make anyone more creative in the kitchen!
The information on the following pages will help
you service these new 27-inch and 30-inch Built-
In Electric Wall Ovens effectively and efficiently.
Model ZET958
Model JK915
Model JKP48

– 4 –
Feature Pack
Designates features–the higher
the number, the more features.
Nomenclature
Model Number
Serial Number
The first two characters of the serial number
identify the month and year of manufacture.
Example: AA123456S=January,2001
A-JAN 2005 - H
D - FEB 2004 - G
F - MAR 2003 - F
G -APR 2002 - D
H-MAY 2001-A
L-JUN 2000 - Z
M-JUL 1999 - V
R -AUG 1998 - T
S - SEP 1997 - S
T - OCT 1996 - R
V - NOV 1995 - M
Z - DEC 1994 - L
Note: The technical sheet is located under the
control panel.
The letter designating the
year repeats every 12
years.
Example:
T - 1974
T - 1986
T - 1998
J K P 8 6 C D 1 C C
GE Cooking Product
ZE = Monogram Electric
Configuration
K = 27-in. Wall Oven
T = 30-in. Wall Oven
Oven Type
P = Self Clean
S = Standard
Product Color
CC = Bisque WW = White
BB = Black AA=Almond
SS = Stainless Steel
Indicator for Engineering and
Product Service Only
The model/serial number tag of your
built-in oven is located behind the door
on the front frame. For the double
ovens, the tag is located in the upper
oven. In addition to the model and serial
numbers, this plate shows the power
ratings of the supply circuit for the
oven.
Model Year Designator
Glass Color
C = Bisque W = White
B = Black A=Almond
S = Stainless Steel
Model ZEK938
Model/Serial
Number

– 5 –
Warranty
Built-In Electric Oven Warranty
For The Period Of: GE Will Replace:
One Year Any part of the oven which fails due to a defect in materials or workmanship.
From the date of the During this full one-year warranty, GE will also provide, free of charge, all labor
original purchase and in-home service to replace the defective part.
■Service trips to your home to teach you how to use
the product.
■Improper installation.
■Failure of the product if it is abused, misused, or used
for other than the intended purpose or used
commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or conse uential damage caused by possible
defects with this appliance.
What GE Will Not Cover:
■Service trips to your home to teach you how to use
the product.
■Improper installation.
■Failure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or conse uential damage caused by possible
defects with this appliance.
What GE Will Not Cover:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or conse uential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
For The Period Of: GE Will Replace:
One Year Any part of the microwave cooking center which fails due to a defect in materials
From the date of the or workmanship. During this full one-year warranty, GE will also provide,
original purchase free of charge, all labor and in-home service to replace the defective part.
Limited Additional A replacement magnetron tube if the magnetron tube fails because of a
Four Years manufacturing defect. During this limited additional four-year warranty, you
For the second through will be responsible for any labor or in-home service.
the fifth year from date
of the original purchase
Microwave Cooking Center Warranty
Warrantor:GeneralElectricCompany.Louisville,KY40225
.

– 6 –
Control Panel Features
Oven Controls
Models ZEK938, ZEK958, ZET938, and ZET958
f
1 BAKE. Press to select the bake function.
2 BROIL HIGH/LOW. Press to select the
broil function.
3 CONV BAKE/MULTI. Press to select baking
with convection on multiple racks.
4 CONV BAKE/1 RACK. Press to select
baking with convection on one rack.
5 CONV ROAST. Press to select roasting with
convection.
6 WARM/PROOF. Press once for warming or
twice for proofing. See the How to Set the
Oven for Warming section and the How to
Set the Oven for Proofing section.
7 START. Must be pressed to start any
cooking or cleaning function.
8 DISPLAY. Shows the operations you have
selected, the time of day and the cooking
or cleaning status.
9 COOK TIME. Use for Timed Bake, Timed
Convection Bake and Timed Convection
Roast operations.
10 DELAY START. Use along with the
COOK TIME or SELF CLEAN STD/LOW
pads to set the oven to start and stop
automatically at a time you select.
11 SELF CLEAN STD/LOW. Press to select
the self-cleaning function. See the Using
the Self-Cleaning Oven section.
12 PROBE. Press when using the probe to
cook food.
13 OVEN LIGHT ON/OFF. Press to turn the
oven lights on or off.
14 CLEAR/OFF. Press to cancel any oven
operation except the clock and timer.
15 TIMER ON/OFF. Press to select the
timer function. The timer does not control
oven operations. The timer can time up to
9 hours and 59 minutes.
16 NUMBER PADS. Use to set any function
requiring numbers—for example, the time
of day on the clock, the timer, the oven
temperature, the internal food temperature,
the starting and length of cooking time for
Timed Bake and the starting and length of
cleaning time for Self-Clean.
17 CLOCK. Press to enter the time of day.
If “F – and a number or letter” flash in the
display and the oven control signals, this
indicates function error code. Press the
CLEAR/OFF pad. Allow oven to cool for
one hour. Put the oven back into operation.
If function error code repeats, disconnect
power to the oven and call for service.
Double oven control shown. (Appearance may vary.)
Throughout this manual, features and appearance may vary from your model.

– 7 –
BAKE Pad
Press to select the bake function.
BROIL HI/LO Pad
Press to select the broil function.
CONVECTION BAKE MULTI/1 RACK Pad
Press once to select convection baking with
multiple racks.
Press twice to select convection baking with
one rack.
CONVECTION ROAST Pad
Press to select roasting with the convection
function.
PROOF Pad
Press to select a warm environment useful
for rising yeast-leavened products.
START Pad
Must be pressed to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode and the times set for
the timer or automatic oven operations.
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function
error code Press the CLEAR/OFF pad. Allow the oven to
cool for one hour. Put the oven back into operation. If the
function error code repeats, disconnect the power to the
oven and call for service.
If your oven was set for a timed oven operation
and a power outage occurred, the clock and all
programmed functions must be reset.
The time of day will flash in the display when there
has been a power outage
SELF CLEAN STD/LOW Pad
Press to select self-cleaning function. See
the Using the self-cleaning oven section.
OVEN LIGHT ON/OFF Pad
Press to turn the oven light on or off.
DELAY START Pad
Use along with COOK TIME or SELF CLEAN
STD/LOW pads to set the oven to start and
stop automatically at a time you set.
COOK TIME Pad
Press and then press the number pads to set
the amount of time you want your food to
cook. The oven will shut off automatically
when the cooking time has run out, unless
the WARM feature was set.
CLEAR/OFF Pad
Press to cancel ALL oven operations except
the clock and timer.
CLOCK Pad
Press before setting the clock.
Number Pads
Use to set any function requiring numbers
such as the time of day on the clock, the
timer, the oven temperature, the internal
food temperature, the start time and
length of operation for timed baking
and self-cleaning.
KITCHEN TIMER ON/OFF Pad
Press to select the timer feature.
PROBE Pad
Press when using the probe to cook food.
WARM Pad
Press to keep cooked foods warm. See the
How to Set the Oven for Warming section. 5
Oven Control, Clock and Timer Features and ettings
Double oven control shown.
Oven Controls
Models JK915, JK955, JT915, and JT955
Throughout this manual, features and appearance may vary from your model.
.

– 8 –
Oven Controls
Models JT912 and JT952
Throughout this manual, features and appearance may vary from your model.
BAKE Pad
Press to select the bake function.
BROIL HI/LO Pad
Press to select the broil function.
CONVECTION BAKE Pad
Press to select baking with the convection
function.
CONVECTION ROAST Pad
Press to select roasting with the convection
function.
START Pad
Must be pressed to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode and the times set for
the timer or automatic oven operations.
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function
error code Press the CLEAR/OFF pad. Allow the oven to
cool for one hour. Put the oven back into operation. If the
function error code repeats, disconnect the power to the
oven and call for service.
If your oven was set for a timed oven operation
and a power outage occurred, the clock and all
programmed functions must be reset.
The time of day will flash in the display when there
has been a power outage
SELF CLEAN STD/LOW Pad
Press to select self-cleaning function. See
the Using the self-cleaning oven section.
OVEN LIGHT ON/OFF Pad
Press to turn the oven light on or off.
DELAY START Pad
Use along with COOKING TIME or
SELF CLEAN STD/LOW pads to set the
oven to start and stop automatically at a
time you set.
COOK TIME Pad
Press and then press the number pads to set
the amount of time you want your food to
cook. The oven will shut off automatically
when the cooking time has run out, unless
the Cook and Hold feature was set.
CLEAR/OFF Pad
Press to cancel ALL oven operations except
the clock and timer.
CLOCK Pad
Press before setting the clock.
Number Pads
Use to set any function requiring numbers
such as the time of day on the clock, the
timer, the oven temperature, the internal
food temperature, the start time and
length of operation for timed baking
and self-cleaning.
KITCHEN TIMER ON/OFF Pad
Press to select the timer feature.
PROBE Pad
Press when using the probe to cook food.
Oven Control, Clock and Timer Features and ettings
Double oven control shown.
.

– 9 –
Note: The time on the microwave display is shown in minutes and seconds
(1:30 is one minute, 30 seconds). On the lower oven, time is shown in hours
and minutes (1:30 is one hour, 30 minutes).
Microwave Oven Controls
Models JKP86 and JTP86
Throughout this manual, features and appearance may vary from your model.

– 10 –
Microwave Oven Control Features and ettings
Display
Displays the time during cooking
functions, the power level being used,
the Auto Codes, the Auto Defrost food
weights, the cooking mode and
instructions.
NOTE: The time on the microwave display is
shown in minutes and seconds (1:30 is one
minute, 30 seconds). On the lower oven, time is
shown in hours and minutes (1:30 is one hour,
30 minutes).
AUTO SENSOR AND CONVENIENCE
CONTROLS
The top row of pads lists specific items
you may choose to heat or cook.
POPCORN
Use to pop popcorn.
REHEAT
Use when foods need a quick warm up.
POTATO
Use when cooking whole potatoes.
BEVERAGE
Use to heat a cup of coffee or other
beverage.
SNACKS
Use to warm a variety of snack foods.
COOK
Use to automatically set the cooking
times and power levels for a variety
of foods.
TIME DEFROST
Use Time Defrost for most other foods.
AUTO DEFROST
Use Auto Defrost for meat, poultry
and fish.
TIME COOK
Allows you to microwave for any time up
to 99 minutes and 59 seconds.
POWER LEVEL
Press to choose the power level you want
to set. Watch the display while pressing
this pad to select the power level you want
to set. You will also see a defrost level. This
setting will allow you to choose your own
defrost power level by using the number
pads.
Number Pads
After pressing a function pad, press the
number pads to set the exact amount of
time you want to cook. For example, if
you press the 1, 2 and 5pads, you have
set 1 minute and 25 seconds.
CLEAR/OFF
Pressing the CLEAR/OFF pad cancels all
microwave cooking functions. It does not
cancel the Kitchen Timer.
START
After all selections are made, press this
pad to start the oven. The START pad
must be pressed to turn on any function.
KITCHEN TIMER MIN/SEC
Press to set the timer up to 99 minutes
and 59 seconds. Press the number pads to
set the time. Press the KITCHEN TIMER
MIN/SEC pad again to start. Press the
KITCHEN TIMER MIN/SEC pad twice to
clear the display.
Does not turn on microwave energy.
DELAY START
Allows you to set the microwave to
delay cooking up to 12 hours.
ADD 30 SEC
Each time you press this pad the set
time is increased 30 seconds.
CLOCK
Press this pad before setting the clock.

– 11 –
Lower Oven Controls
Models JKP86 and JTP86
Throughout this manual, features and appearance may vary from your model.

– 12 –
Lower Oven Control, Clock and Timer Features and ettings
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or
self-cleaning mode and the times set for
the timer or automatic oven operations.
NOTE: The time on the lower oven display is
shown in hours and minutes (1:30 is one hour,
30 minutes). On the microwave oven, time is
shown in minutes and seconds (1:30 is one
minute, 30 seconds).
If “F– and a number or letter” flash in the
display and the oven control signals, this
indicates a function error code Press the
CLEAR/OFF pad. Allow the oven to cool for one
hour. Put the oven back into operation. If the
function error code repeats, disconnect the power
to the oven and call for service.
If your oven was set for a timed oven
operation and a power outage occurred, the
clock and all programmed functions must be reset.
The time of day (may be incorrect) will flash
in the display when the there has been a
power outage
BROIL HI/LO Pad
Press to select the broil function.
BAKE Pad
Press to select the bake function.
SELF CLEAN Pad
Press to select the self-cleaning function.
See the Using the self-cleaning lower oven
section.
OVEN LIGHT Pad
Press to turn the oven light on or off.
Number Pads
Use to set any function requiring
numbers such as the time of day on the
clock, the timer, the oven temperature,
the start time and length of operation for
timed baking and self-cleaning.
CLEAR/OFF Pad
Press to cancel ALL oven operations
except the clock and timer.
START Pad
Must be pressed to start any cooking or
cleaning function.
KITCHEN TIMER ON/OFF Pad
Press to select the timer feature.
DELAY START Pad
Use along with COOKING TIME or SELF
CLEAN pads to set the oven to start and
stop automatically at a time you set.
COOKING TIME Pad
Press and then press the number pads
to set the amount of time you want your
food to cook. The oven will shut off
automatically when the cooking time
has run out, unless the Cook and Hold
feature was set.
CLOCK Pad
Press before setting the clock.
.

– 13 –
Oven Controls
Model JKS06
Oven Control, Clock and Timer Features and ettings
BAKE Pad
Press this pad to select the bake function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake or broil
mode and the times set for the timer or
automatic oven operations.
If “F — and a number or letter” flash in the display
and the oven control signals, this indicates a
function error code Press the CLEAR/OFF pad. Allow
the oven to cool for one hour. Put the oven back into
operation. If the function error code repeats, disconnect
the power to the oven and call for service.
If your oven was set for a timed oven operation and a
power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there
has been a power outage
START Pad
Must be pressed to start any cooking
function.
COOKING TIME Pad
Press this pad and then press the HOUR and
MIN + or –pads to set the amount of time
you want your food to cook. The oven will
shut off automatically when the cooking
time has run out, unless the Cook and
Hold feature was set.
DELAY START Pad
Use along with COOKING TIME pad to set
the oven to start and stop automatically at
a time you set.
CLOCK Pad
Press this pad before setting the clock.
KITCHEN TIMER ON/OFF Pad
Press this pad to select the timer feature.
CLEAR/OFF Pad
Press this pad to cancel ALL oven
operations except the clock and timer.
HOUR and MIN + and – Pads
Press these pads to set times up to 9 hours
and 59 minutes—for example, the time of
day on the clock, the timer, the starting
and length of cooking time for timed bake.
TEMP + and – Pads
Press these pads to set the cooking
temperature you want to use.
OVEN LIGHT ON/OFF Pad
Press this pad to turn the oven light on
or off.
BROIL HI/LO Pad
Press this pad to select the broil function.
Throughout this manual, features and appearance may vary from your model.
.

– 14 –
Microwave Oven Controls
Model JT965
10
Microwave Oven Control Features and ettings
Display
Displays the time during cooking
functions, the power level being used,
the Auto Codes, the Auto Defrost food
weights, the cooking mode and instructions.
NOTE: The time on the microwave display is
shown in minutes and seconds (1:30 is one minute,
30 seconds). On the lower oven, time is shown in
hours and minutes (1:30 is one hour, 30 minutes).
AUTO SENSOR CONTROLS
The top row of pads lists specific items you
may choose to heat or cook.
POPCORN
Use to pop popcorn.
BEVERAGE
Use to heat a cup of coffee or other
beverage.
REHEAT
Use when foods need a quick warm up.
VEGETABLE
Use when cooking fresh, frozen or
canned vegetables. Be sure to remove
all vegetables from airtight and metal
containers before placing them in the
microwave.
POTATO
Use when cooking whole potatoes.
CHICKEN/FISH
Use when cooking chicken pieces or fish
fillets.
ADD 30 SEC
Each time you press this pad the set time is
increased 30 seconds.
DEFROST AUTO/TIME
The Defrost Auto/Time feature gives you
two ways to defrost frozen foods. Press the
DEFROST AUTO/TIME pad once for Auto
Defrost or twice for Time Defrost.
Use Auto Defrost for meat, poultry
and fish.
Use Time Defrost for most other foods.
TIME COOK
Allows you to microwave for any time up to
99 minutes and 99 seconds.
HELP
The help pad displays feature information
and helpful hints. Press the HELP pad,
then press a feature pad.
Throughout this manual, features and appearance may vary from your model.

– 15 –
Lower Oven Controls
Model JT965
Throughout this manual, features and appearance may vary from your model.
Lower Oven Control, Clock and Timer Features and ettings
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or self-
cleaning mode and the times set for the
timer or automatic oven operations.
NOTE: The time on the lower oven display is shown in
hours and minutes (1:30 is one hour, 30 minutes). On the
microwave, time is shown in minutes and seconds (1:30
is one minute, 30 seconds).
If “F– and a number or letter” flash in the display and
the oven control signals, this indicates a function
error code Press the CLEAR/OFF pad. Allow the oven to
cool for one hour. Put the oven back into operation. If the
function error code repeats, disconnect the power to the
oven and call for service.
If your oven was set for a timed oven operation and
a power outage occurred, the clock and all programmed
functions must be reset.
The time of day (may be incorrect) will flash in the
display when there has been a power outage
BROIL HI/LO Pad
Press to select the broil function.
BAKE Pad
Press to select the bake function.
CONVECTION BAKE Pad
Press to select baking with convection.
CONVECTION ROAST Pad
Press to select roasting with convection.
Number Pads
Use to set any function requiring numbers
such as the time of day on the clock, the
timer, the oven temperature, the internal
food temperature, the start time and
length of operation for timed baking and
self-cleaning.
CLEAR/OFF Pad
Press to cancel ALL oven operations except
the clock and timer.
PROBE Pad
Press when using the probe to cook food to
the desired internal temperature. (For use
in the lower oven only.)
SELF CLEAN Pad
Press to select the self-cleaning function. See
the Using the self-cleaning lower oven section.
START Pad
Must be pressed to start any cooking or
cleaning function.
KITCHEN TIMER ON/OFF Pad
Press to select the timer feature.
OVEN LIGHT Pad
Press to turn the oven light on or off.
DELAY START Pad
Use along with COOKING TIME or SELF
CLEAN pads to set the oven to start and stop
automatically at a time you set.
COOKING TIME Pad
Press and then press the number pads to set
the amount of time you want your food to
cook. The oven will shut off automatically
when the cooking time has run out, unless
the Cook and Hold feature was set.
CLOCK Pad
Press before setting the clock.
23
.

– 16 –
Oven Controls
Models JKP20, JTP20, JKP28, JTP28, JKP48,
Oven Control, Clock and Timer Features and ettings
BAKE Pad
Press this pad to select the bake function.
BROIL HI/LO Pad
Press this pad to select the broil function.
SELF CLEAN STD/LOW Pad
Press this pad to select the self-cleaning
function. See the Using the self-cleaning oven
section.
START Pad
Must be pressed to start any cooking or
cleaning function.
Display
Shows the time of day, oven temperature,
whether the oven is in the bake, broil or self-
cleaning mode and the times set for the
timer or automatic oven operations.
If “F — and a number or letter” flash in the display
and the oven control signals, this indicates a
function error code Press the CLEAR/OFF pad. Allow the
oven to cool for one hour. Put the oven back into operation. If
the function error code repeats, disconnect the power to the
oven and call for service.
If your oven was set for a timed oven operation and
a power outage occurred, the clock and all programmed
functions must be reset.
The time of day will flash in the display when there
has been a power outage
OVEN LIGHT ON/OFF Pad
Press this pad to turn the oven light on or off.
DELAY START Pad
Use along with COOKING TIME or SELF
CLEAN pads to set the oven to start and stop
automatically at a time you set.
COOKING TIME Pad
Press this pad and then press the HOUR and
MIN + and – pads to set the amount of time
you want your food to cook. The oven will
shut off automatically when the cooking time
has run out unless the Cook and Hold
feature was set.
CLEAR/OFF Pad
Press this pad to cancel ALL oven
operations except the clock and timer.
TEMP + and – Pads
Press these pads to set the cooking
temperature you want to use.
CLOCK Pad
Press this pad before setting the clock.
HOUR and MIN + and – Pads
Press these pads to set times up to 9 hours
and 59 minutes—for example, the time of
day on the clock, the timer, the starting and
length of cooking time for timed bake and
the starting and length of cleaning time
for self-clean.
KITCHEN TIMER ON/OFF Pad
Press this pad to select the timer feature.
Double oven control shown
Lower Oven Control ettings on models with a knob
OVEN Knob
Turn this knob to
the temperature
setting you want.
The OVEN CYCLE light glows until the oven reaches your
selected temperature, then goes off and on with the oven
element(s) during cooking.
5
Throughout this manual, features and appearance may vary from your model.

– 17 –
Oven
Lift-Off Oven Door
To remove the door:
1. Fully open the door.
2. Pull the hinge locks down toward the door
frame, to the unlocked position. This may
require a flat-blade screwdriver to start the hinge
locks moving.
3. Firmly grasp both sides of the door at the top.
4. Close the door to the door removal position,
which is halfway between the broil stop position
and fully closed.
Caution: Do not lift the door by the handle.
5. Lift the door up and out until the hinge arm is
clear of the slot.
To replace the door:
1. Firmly grasp both sides of the door at the top.
2. With the door at the same angle as the removal
position, seat the indentation of the hinge arm
into the bottom edge of the hinge slot. The
notch in the hinge arm must be fully seated
into the bottom of the slot.
3. Fully open the door. If the door connot be fully
opened, the hinge is not properly seated.
4. Push the hinge locks up against the front frame
of the oven cavity, to the locked position.
5. Close the oven door and check for proper
alignment (rubbing, etc.).
Door Assembly
The door assembly can be broken down into 2
basic assemblies: 1) The outer assembly consists
of the door handle, vent trim, outer glass, bottom
trim, and frame and 2) The inner assembly is
made up of the inner panel, gasket, 2 or 3 glass
panels (depending on model), and insulation. The
assemblies are held together by 2 screws on each
side and 3 (or 4) screws across the bottom.
To replace outer door assembly:
1. Remove the door. Refer to Lift-Off Oven Door.
2. Remove 3 (or 4) screws from the bottom door
frame.
Hinge lock (unlocked position)
Slot
Hinge arm
he
f the
o the
f the
Hinge arm
Indentation
Bottom
edge
of slot
Locked position
Sealed hinge arm
3 Screws
2 Screws

– 18 –
3. Remove 2 screws from each side of the door
on the liner.
4. Separate the liner assembly and the outer glass
assembly.
5. Remove 2 screws from the door handle near
the door vent trim.
6. Reassemble in reverse order.
To replace liner assembly:
1. Remove 3 screws on each side of the door liner
to remove the door hinge assembly.
2. Remove 4 screws from the insulation retainer.
3. Remove 6 screws and the insulation retainer.
The window pack and window gasket are now
accessable on units with a window door.
Caution: Care must be taken when mounting door
handle not to overtighten screws. Overtightening
screws can strip the threads in the plastic handle.
Hand-tighten ONLY. Make sure handle fits snug
to door panel.
Oven Door Gasket
The gasket forms a seal around the front edge of
the oven liner and the inner door panel, except for
approximately a 6-in. opening at the center bottom.
The gasket is attached to the inner door panel by a
chain of spring clips.
To remove door gasket:
1. Open the door completely.
2. Pull the end of the gasket out of the slots at the
bottom of the door.
3. Finish removing the gasket by placing a finger
under the gasket beside the clip and pulling
straight up.
To install gasket:
1. Locate the 2 clips on the gasket just right and
left of center.
Note: The gasket will go on easier if folded
90 degrees at the clip being inserted.
2. Place a finger on top of the spring clip and press
into the 2 center top holes in the inner door
panel.
2 Screws
Window
Pack and
Gasket
6 Screws
4 Screws
3 Screws
