GE Profile PT970DR Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
Specification Created 5/10
220153
KW Rating
240V 6.8
208V 5.1
Breaker Size
240V 30 Amps
208V 30 Amps
PT970DR
GE Profile™30" Built-In Double Microwave/Convection Oven
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
(must support 275 lbs.)
Cabinet 30"
A – Overlap of oven over side of edges of cutout 11/16"
B – Overlap of oven at top and bottom of cutout 1"
C – Overall of oven at top of cutout 1/2"
Oven
D – Overall depth* 23-1/2"
E – Overall height with trim 44"
Overall height without trim 43-1/2"
E –Overall width 29-3/4"
*Depth including door handle is approximately 26-6/10" min. to
26-9/10" max.
20''
28''
21''
A
F
A
B
C
CONDUIT
(72'' LONG)
CUTOUT
HEIGHT
42-3/16'' MIN.
42-1/4'' MAX.
CUTOUT
WIDTH
28-1/2'' MIN.
28-5/8'' MAX.
Minimum
cutout location
21-5/8''
from the floor
21" Minimum
Door Allowance
JUNCTION BOX
LOCATION
CABINET
WIDTH
30''
DOOR MUST BE
REMOVED BEFORE
INSTALLATION
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
D
CUTOUT DEPTH
23-1/2'' MIN.
E
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least a 194°F
temperature rating. Electric wall ovens are
not approved for installation with a plug and
receptacle. They must be hard wired in accordance
with installation instructions.
Door handle protrudes 3" from door face. Cabinets
and drawers on adjacent 45° and 90° walls should be
placed to avoid interference with the handle.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
(must support 275 lbs.)
Cabinet 30"
A – Overlap of oven over side of edges of cutout 11/16"
B – Overlap of oven at top and bottom of cutout 1"
C – Overall of oven at top of cutout 1/2"
Oven
D – Overall depth* 23-1/2"
E – Overall height with trim 44"
Overall height without trim 43-1/2"
E –Overall width 29-3/4"
*Depth including door handle is approximately 26-6/10" min. to
26-9/10" max.
20''
28''
21''
A
F
A
B
C
CONDUIT
(72'' LONG)
CUTOUT
HEIGHT
42-3/16'' MIN.
42-1/4'' MAX.
CUTOUT
WIDTH
28-1/2'' MIN.
28-5/8'' MAX.
Minimum
cutout location
21-5/8''
from the floor
21" Minimum
Door Allowance
JUNCTION BOX
LOCATION
CABINET
WIDTH
30''
DOOR MUST BE
REMOVED BEFORE
INSTALLATION
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
D
CUTOUT DEPTH
23-1/2'' MIN.
E
Dimensions and Installation Information (in inches)

BROIL CLEAN
BAKE
O
N
PROBE COOK TIMER
STOP
CLOCK CLEAN
START
DELAY
S
E
T
S
E
T
CONV
Specification Created 5/10
220153
Features and Benefits
• Blackglossoveninterior–Blackoveninterioraddsastylishtouchtoanykitchen
• PreciseAir™convectionsystem–Areversingfancirculatesheatandairforevenly
browned and baked foods
• ConvectionBake–Thissettingisoptimalforbakingcasserolesorlasagnas,yeast
breads, pies and pizzas with no need to turn the pan
• Convectionroast–Optimalforlargercutsofmeat,thissettingrotatestheheataround
all sides, sealing in the juices, producing rotisserie results at up to 25% faster than a
conventional oven
• Super-largeovencapacity–Remarkablylargeoveninteriorisidealforholidays,dinner
parties and everyday family cooking
• Self-cleanoven–Self-cleanallowsyoutospareyourselffromthetroubleandeffortit
takes to scrub the oven interior
• Electronicovencontrols–Electronicpadsonthecontrolpanelareeasytooperatewith
just a touch
• 1.6Cu.Ft.Capacity(UpperOvenOnly)–Providesalargeinteriortoaccommodatea
variety of cookware, dinnerware and food containers
• Turntable(upperovenonly)–Rotatesfoodthroughoutthecookingcycleforeven
cooking results
• Hiddenbakeoveninterior–Concealsthelowerovenbakeelementtoeliminatehard-to-
reach areas that collect food and spills for easy cleaning
• ModelPT970DRBB–Blackonblack
• ModelPT970DRWW–Whiteonwhite
PT970DR
GE Profile™30" Built-In Double Microwave/Convection Oven
