GE JK1000 Manual

320441
Specification Revised 4/13
JK1000DF
GE®27" Built-In Single Wall Oven
For answers to your Monogram®or GE appliance
questions, visit our website at geappliances.com
or call GE Answer Center®service, 800.626.2000.
Listed by
Underwriters
Laboratories
*ADA qualified based on Uniform
Federal Accessibility Standards
*
Note: These ovens are not approved for
stackable or side-by-side installations.
Note: These ovens can be installed side-by-side
with no less than 30" distance between center-to-
center of each oven.
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least a 194°F
temperature rating.
Note: For 27" built-in single ovens, if marks,
blemishes or the cutout opening is visible above
the installed oven, it may be necessary to add
wood shims under the runners and front trim until
the marks or openings are covered.
Note: Door handle protrudes 3" from door face.
Cabinets and drawers on adjacent 45° and 90°
walls should be placed to avoid interference with
the handle.
Electric wall ovens are not approved for
installation with a plug and receptacle. They
must be hard wired in accordance with
installation instructions.
Installation Information: Before installing,
consult installation instructions packed
with product for current dimensional data.
Dimensions and Installation Information (in inches)
KW Rating
240V 3.6
208V 2.7
Breaker Size
240V 20 Amps
208V 20 Amps
C
L
Suitable
bracing
to support
runners
(must support 200 lbs.)
2 x 4 or
equivalent runners
level with bottom of cutout
and flush with sides of cutout
or solid bottom floor.
F
E
22
"
Conduit
40"
D
8-3/4" MAX.
Cutout depth
23-1/2" MIN
Cabinet 27"
A – Overlap of oven at top of cutout 1"
B – Overlap of oven over side of edges of cutout 1"
C – Overlap of oven at bottom of cutout 1"
Oven
D – Overall depth with handle 26-23/32"
Overall depth with handle without handle 23-5/8"
E – Overall height with trim 30-3/16"
F – Overall width 26-23/32"
PK7000
JK5000
JK3000
JK1000
B
27''
A
C
Cutout width
25" MIN.
25-1/4" MAX.
Recommended
cutout location
from floor
32-1/2"
Cutout height
27-5/8" MIN.
28-1/8" MAX.
23" minimum
door opening
allowance
22" to
bottom of
junction box
Junction box
location
C
L
Suitable
bracing
to support
runners
(must support 200 lbs.)
2 x 4 or
equivalent runners
level with bottom of cutout
and flush with sides of cutout
or solid bottom floor.
F
E
22
"
Conduit
40"
D
8-3/4" MAX.
Cutout depth
23-1/2" MIN
Cabinet 27"
A – Overlap of oven at top of cutout 1"
B – Overlap of oven over side of edges of cutout 1"
C – Overlap of oven at bottom of cutout 1"
Oven
D – Overall depth with handle 26-23/32"
Overall depth with handle without handle 23-5/8"
E – Overall height with trim 30-3/16"
F – Overall width 26-23/32"
PK7000
JK5000
JK3000
JK1000
B
27''
A
C
Cutout width
25" MIN.
25-1/4" MAX.
Recommended
cutout location
from floor
32-1/2"
Cutout height
27-5/8" MIN.
28-1/8" MAX.
23" minimum
door opening
allowance
22" to
bottom of
junction box
Junction box
location
JK1000
C
L
Suitable
bracing
to support
runners
(must support 200 lbs.)
2 x 4 or
equivalent runners
level with bottom of cutout
and flush with sides of cutout
or solid bottom floor.
F
E
22
"
Conduit
40"
D
8-3/4" MAX.
Cutout depth
23-1/2" MIN
Cabinet 27"
A – Overlap of oven at top of cutout 1"
B – Overlap of oven over side of edges of cutout 1"
C – Overlap of oven at bottom of cutout 1"
Oven
D – Overall depth with handle 26-23/32"
Overall depth with handle without handle 23-5/8"
E – Overall height with trim 30-3/16"
F – Overall width 26-23/32"
PK7000
JK5000
JK3000
JK1000
B
27''
A
C
Cutout width
25" MIN.
25-1/4" MAX.
Recommended
cutout location
from floor
32-1/2"
Cutout height
27-5/8" MIN.
28-1/8" MAX.
23" minimum
door opening
allowance
22" to
bottom of
junction box
Junction box
location
C
L
Suitable
bracing
to support
runners
(must support 200 lbs.)
2 x 4 or
equivalent runners
level with bottom of cutout
and flush with sides of cutout
or solid bottom floor.
F
E
22"
Conduit
40"
D
8-3/4" MAX.
Cutout depth
23-1/2" MIN
Cabinet 27"
A – Overlap of oven at top of cutout 1"
B – Overlap of oven over side of edges of cutout 1"
C – Overlap of oven at bottom of cutout 1"
Oven
D – Overall depth with handle 26-23/32"
Overall depth with handle without handle 23-5/8"
E – Overall height with trim 30-3/16"
F – Overall width 26-23/32"
PK7000
JK5000
JK3000
JK1000
B
27''
A
C
Cutout width
25" MIN.
25-1/4" MAX.
Recommended
cutout location
from floor
32-1/2"
Cutout height
27-5/8" MIN.
28-1/8" MAX.
23" minimum
door opening
allowance
22" to
bottom of
junction box
Junction box
location

320441
Specification Revised 4/13
JK1000DF
GE®27" Built-In Single Wall Oven
JK1000DFBB
Features and Benefits
• 4.3 cu. ft. Oven Capacity - Cook more dishes at once
• Standard Clean with Steam Clean Option - Easily wipe down
loosened, baked-on foods
• Ten-Pass Bake Element - Even baking is assured with heat that
covers more surface area
• Eight-Pass Broil Element - Get full broil coverage and even
browning from edge to edge
• Black Gloss Oven Interior - Enjoy a clean and sleek appearance
• Electronic Touch Controls - Confidently operate the oven with one
easy touch
• Hidden Bake - Make cleanup easy by eliminating hard-to-
reach areas
• Audible Preheat Signal - Know when the oven is ready
• Heavy-Duty Oven Racks - Bake confidently with durable racks
• Certified Sabbath Mode - Prepare foods by kosher standards
• Model JK1000DFBB – Black on black
