GE Monogram ZET1 User manual

Installation
Instructions 30" Built-In Wall Oven
ZET1,ZET2
If you have questions, call 1.800.GE.CARES or visit our website at:
ge.com
Before You Begin
Read these instructions carefully and completely.
• IMPORTANT-save these
instructions for local inspector's use.
•IMPORTANT-observe all
governing codes and ordinances.
•Note to Installer--Be sure to leave these
instructions with the consumer.
•Note to Consumer--Keep these
instructions for future reference.
•Proper installation is the responsibility
of the installer and product failure due
to improper installation is NOT covered
under warranty.
•NOTE--This appliance must be properly
grounded.
•ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approved junction
box. A plug and receptacle is NOT permitted
on these products.
Parts Included
(2) 5/8"
(4) 3/4" Wood Screws
Woo_
I,,_'S][3___ MetaiB°tt°m
Trim Assembly
Materials Needed
_)_ @ WireNu_ts
Strain Relief Clamp Junction
for 1/2" conduit Box _k. _
36" of String
Tools Needed
1/8" Drill Bit and
Electric or Hand Drill Phillips Screwdriver
Adjustable Wrench
31-10633 12-05 JR

Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
For Your Safety
•Be sure your oven is installed properly by
a qualified installer or service technician.
• Be sure the oven is securely installed in a
cabinet that is firmly attached to the house
structure. Weight on the oven door could
cause the oven to tip and result in injury.
Never allow anyone to climb, sit, stand or
hang on the oven door.
• Make sure the cabinets and wall coverings
around the oven can withstand the
temperatures (up to 200°F) generated
by the oven.
WARNING: The electrical
power to the oven supply line
must be shut off while line
connections are being made. Failure
to do so could result in serious injury
or death.
AVERTISSEMENT :
Vous devez couper I'alimentation
electrique du four avant de le
brancher. Le defaut de se conformer
bcette procedure peut entrainer des
blessures severes et m_me la mort.
Electrical
Requirements
These Monogram built-in ovens require a
separate, properly grounded 3-wire 120/208 or
120/240 volt, 60 Hz power supply, protected by
a time delay fuse or circuit breaker.
• Double ovens are rated at 8.6 KW at 240 volt
and 7.8 KW at 208 volt.
• Single ovens are rated at 4.3 KW at 240 volt
and 3.9 KW at 208 volt.
This appliance must be supplied with the
proper voltage and frequency, and connected
to an individual, properly grounded branch
circuit, protected by a circuit breaker or fuse
having amperage as noted on rating plate.
Rating Plate
We recommend you have the electrical
wiring and hookup of your oven connected by a
qualified electrician. After installation, have the
electrician show you where your main oven
disconnect is located.
Check with your local utilities for electrical
codes which apply in your area. Failure to wire
your oven according to governing codes could
result in a hazardous condition. If there are no
local codes, your oven must be wired and fused
to meet the requirements of the National
Electrical Code, ANSI/NFPA No. 70-Latest
Edition. You can get a copy by writing:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
Effective January 1, 1996, the National
Electrical Code requires that new, but not
existing, construction utilize a four-conductor
connection to an electric oven. When installing
an electric oven in new construction, a mobile
home, recreational vehicle or an area where
local codes prohibit grounding through the
neutral conductor, follow the instructions in
the section on NEW CONSTRUCTION AND
FOUR-CONDUCTOR BRANCH CIRCUIT
CONNECTION.
You must use a three-wire, single-phase A.C.
208Y/120 Volt or 240/120 Volt, 60 hertz
electrical system. If you connect to aluminum
wiring, properly installed connectors approved
for use with aluminum wiring must be used.

Installation Instructions
Pre-lnstallation Checklist
ALL INSTALLATION INFORMATION
ON THE FOLLOWING PAGES IS TO
BE USED FOR SINGLE AND DOUBLE
OVEN INSTALLATION!
Remove packaging materials.
Check behind hinges and under
false bottom. Remove labels on the
outside of the door, plastic on trims
and panel, all tape around the oven,
and any shipping screws securing
the oven to the base pad.
o _o i
Rack Supports
_' _ with Hex Nuts
GTemperature
Probe Oven Racks
/_,o_}_r_ _,__,Tq-_ _ Graphite
__1 Lubricant
Broiler Pan
and Grid Literature
Pack
Open oven door and remove
literature pack, broiler pan and grid,
oven racks, rack supports and a bag
with 9 hex nuts.
Read Installation Instructions carefully
before you begin.
Be sure to place all literature, Owner's
Manual, Installations, etc. in a safe place
for future reference.
i4:.2:_72. ............
(Continued on following page)

Installation Instructions
Pre-lnstallation Checklist cont
To Remove the Door (ifnecessary)
Door removal is not a requirement for Ilk _1_
installation of the product, but is an
added convenience. To remove the door:
Open the oven door as far as it will go.
Push both hinge Hinge
_._L. Unlocked
locks down toward .,_!!_. Position
the door frame, Hinge"_/'_
to the unlocked s_otq_V_
position. This may
require a flat blade Hinge
screwdriver. Arm
Place the oven on a table or platform
even with the cutout opening.
(Platform must support 175 Ibs.
[79 kg] single, 350 Ibs. [159 kg]
double.)
Remove the bottom trim from the top
of the oven. It will be installed at the
end of the installation process. The
trim is wrapped separately and taped
to the top of the unit.
DO NOT LIFT THE DOOR
BY THE HANDLE! i]
Place hands on both sides of
the door, and close the oven _ IIil
door to the removal position, _/._ IIil
which is most of the way. _\_ii
Removal Position
[_ Lift door up
and out until
the hinge arms
clear the slots.
Hinge Clears Slot
NOTE: The oven door is very heavy. Be sure
you have a firm grip before lifting the oven
door off the hinges. Use caution once the
door is removed. Do not lay the door on its
handle. This could cause dents or scratches.

Installation Instructions
CutoUtutfOr Single Built-In Oven
Width
28 1/2" Min.
28 5/8" Max,
(72.4 to
72.7 cm) -->"
•F_Opening
Between
Inside Walls
Must Be
At Least
28 1/2"
Wide
Allow 11/16" --_-_
(1,76 cm) for
overlap of oven
over side edges
of cutout
(63.3c_
Allow 1" (2.6 cm)
minimum for
overlap of oven
Allow a minimum top and 1V4"
of 21" (63.3 cm) for (3.2 cm) overlap
clearance to adjacent of oven bottom
corners, drawers, of cutout
walls, etc. when
door is open Cabinet
Width
30" (76.2 cm)
Cabinet Width
Recommended
Minimum
Junction Box Cutout Location
/Location from Floor
22" (55.9 cm)
to Bottom of
Junction Box
Cutout Depth
Cutout Width
Cutout Height
30" (76.2 cm)
32 1/2" (82.6 cm)
23 1/2" (59.7 cm) Min.
28 1/2" (72.4 cm) Min.
28 5/8" (72.7 cm) Max.
27 1/4" (69.2 cm) Min.
27 5/16" (69.2 cm) Max.
NOTE: If the cabinet does
not have afront frame and
the sides are less than 3/4"
(1.9 cm) thick, shim both
sides equally to establish
the cutout width.
If the cabinet does not have a solid bottom,
two braces or runners must be installed
level with the bottom of the cutout to
support the weight of the oven. For single
ovens, the runners and braces must
support 175 Ibs. (79 kg).
NOTE: If marks, blemishes or the
cutout opening are visible above the
installed oven, it may be necessary to
add wood shims under the runners and
front trim until the marks or opening
are covered.
Suitable
Bracing
to Support
Runners
-- 21 518"
(54.9 cm)_
Over Centerline
of Cabinet
-- Install a
solid bottom
or2" x4"
(6cmxlOcm)
or equivalent
runners level
with bottom
of cutout
The solid bottom or runners must be level
with the bottom of the cutout, or the bottom
trim may not install correctly and then
interfere with the door opening.
This oven is not approved for
stackable or side by side installation.

Installation Instructions
Cutout for Double Built-In Oven
Allow 11/16" --_
(1.8 cm) for
overlap of oven
over side edges
of cutout
Allow a minimum
of 21" (53.3 cm) for
clearance to adjacent
corners, drawers,
walls, etc. when
door is open
__ (62.3<_.cm)-_,
Cutout
Width
28 1/2"
(72.4 cm) Min.
_- 28 5/8" __
(72.7 cm) Max.
<_'Opening
Between
Inside Walls
Must Be
At Least
28 1/2"
(72.4 cm)
Wide
Allow 1" (2.5 cn
minimum for
overlap of oven
top and 11/4"
(3,2 cm) overlap
of oven bottom
of cutout |
-J- s"L
_______@,12.7
Junction Box
Cutout
Height
51 13116"
(131.6 cm) Min.
51 15116"
(131.8 cm) Max
Location
/
47" (119.4 cm)
to Bottom of
Junction Box
_.._,"_' _Recommended
30"_*****_ tminimum cutout location
(76.2 cm_)'_ from floor 12" (30.6 cm)
Cabinet
Width
If the cabinet does not have a solid bottom,
two braces or runners must be installed
level with the bottom of the cutout to
support the weight of the oven. For double
ovens, the runners and braces must
support 350 Ibs. (159 kg).
NOTE: If marks, blemishes or the
cutout opening are visible above the
installed oven, it may be necessary to
add wood shims under the runners and
front trim until the marks or opening
are covered.
Cabinet Width 30" (76.2 cm)
Recommended
Minimum
Cutout
Location
from Floor 12" (30.6 cm)
Cutout Depth 23 1/2" (69.7 cm) Min.
Cutout Width 28 1/2" (72.4 cm) Min.
28 5/8" (72.7 cm) Max.
Cutout Height 61 13/16" (131.6 cm) Min.
61 15/16" (131.8 cm) Max.
NOTE: If the cabinet does
not have a front frame and the
sides are less than 3/4" (1.9 cm)
thick, shim both sides equally
to establish the cutout width.
_(21 6/8"----4 t-
54.9 cm) /
Over Centerline
of Cabinet
Install a
solid bottom
or 2" x 4"
(5 cm x 10 cm
or equivalent
runners level
with bottom
of cutout
The solid bottom or runners must be level
with the bottom of the cutout, or the bottom
trim may not install correctly and then
interfere with the door opening.

Installation Instructions
Cutout for Single Built-In Oven
Under Counter
Gas or electric cooktops may
be installed over this oven,
See cooktop installation
instructions for cutout size.
See label on top of oven for
approved cooktop models.
\
Top and/or side fillers
may
if unit is positioned
between existing
cabinets. Be sure
they are attached
securely, since they
will anchor the oven
in the cabinet.
28 1/2"
(72.4 cm) Min.
28 5/8"
27 1/4"
(69.2 cm) Min.
27 5/16"
(69.2 cm) Max.
240V /208V
Junction Box
Location
_5"_,
(12.7 cm)
Allow 1" (2.5
overlap top of
oven and
11/16" (1.8 cm)
overlap side
edges of
cutout
Gas and electrical connections for
30" (76.2 cm) gas cooktop must be
located in an adjacent accessible
location to the right, For 36" (91.4 cm)
gas cooktop, the connections may be
made to the left,
I "l'l I _r
22" (65.9 cm) 36" (91.4 cm)
Min, Above Typical
Support Countertop
Platform Height
3/4" (1.9 cm) -._
Support Platform
Required
MUST SUPPORT 175 LBS.
(78.8 KG)
5 9/16" (14.2 cm)
Reference dimension for
maximum support height with
typical 36" (91.4 cm) countertop
height
This oven is not approved to be
installed under a solid disk, induction
or downdraft modular cooktop. See
the label on the top of the oven for
approved models.

Cabinetry
Single Oven Cutout
for Installation Over
a Monogram Warming
Drawer 231,2,
(59.7 cm)
i_,__Min,
27 5/16"
(69.2 cm)
Max,
2" x2"(Scm x 5cm) or
2" x 4" (5 cm x 10 cm)
Anti-Tip Block Against
Rear Wall, 9" (22.9 cm)
From Floor to Bottom
of Block
9" (22.9 cm)
Max. 2" (5.1 cm)
Min,
(1.5 cm)
Overlap
on All
Sides
Double Oven Cutout
i - i for Installation Over
a Monogram Warming
Drawer 231,2,,
(59.7 cm)
_Min.
Inside--*
51 15/16"
(131.8 cm)
Max,
NOTE: Install the
oven only with
specific models rn_)
Iisted on the labeI 9" (22.9 c
located on top of Max.
the oven.
1"(2.5 cm) Min, Above Toekick or
Adjust to Oven Installation Height
NOTE: Additional clearances between cutouts
may be required. Check to be sure the oven
supports above the Warming Drawer location
do not obstruct the required interior 23 1/2"
(59.7 cm) depth and 9 1/4" (23.5 cm) height.
• These Monogram Ovens require 3/4" (1.9
cm) overlap on both sides. Allow 1" (2.5 cm)
Min. for top overlap and clearance to upper
doors.
2" x 2" (5 cm x
5 cm) or 2" x
4" (5 cm x 10
cm) Anti-Tip
Block Against
Rear Wall, 9"
(22.9 cm)
From Floor
to Bottom
of Block
2" (5.1 cm)
Min.
5/8"
(1.Scm)
Overlap
on All
Sides
(72.4 cm)
1" (2.5 cm) Min. Above Toekick
• The Monogram Warming Drawers require
5/8" (1.6 cm) overlap on all sides.
• When installing a Monogram Warming
Drawer below a single or double oven, a
separate 120V, 60 Hz, properly grounded
receptacle must be installed. Refer to
installation instructions packed with the
Warming Drawer for specific installation
requirements.
Cutout for Frameless Cab
Frameless Cabinets
Whenever possible, order 30" (76.2 cm)
frameless cabinet with the cutout sided to fit
the oven. If using stock cabinets, additional
finished filler pieces may be required to
cover the opening.
• A stock frameless cabinet cutout width
may be up to 28 3/4" (73 cm). If necessary,
add 1/2" (1.3 cm) cleats to the sides, flush
with the front edge of the side panels to
accept mounting screws.
/
Install 1/2"
(1.3 cm)
Cleats to
Hold Oven
Mounting
Screws
Double
51 15/16" (131.8 cm
Single
27 5/16" (69.2 cm)
l.
nets
"_--_-30"
Min,
Cabinet Depth
23 1/2" (59.7 cm)
Min, From Inside
Back to Front of
Cabinet Frame
Panel
3/4" (1.9 cm) Min.
Thick Bottom Shelf
Cut Back Flush
with Front of
Side Panel

Cabinetry
Single Oven Cutout
for Installation Below
a Monogram Advantium
Oven 231,2-
(59.7 cm)
Min.
ns de_
Per Advantium
Requiremer
Min.
45 1/4"
(114.9 cm)
Note: Install the
oven only with
specific models
listed on the label
located on top of
the oven.
NOTE: The middle rail separating the two
openings may need to be larger than the 2"
(5.1 cm) minimum shown. Always refer to the
individual installation instructions packed with
each product for specific requirements.
Combined Advantium and Wall
Oven Installation:
When installed in combination with a
Monogram single wall oven, use separate
electrical junction boxes.
• Refer to the Advantium oven installation
instructions for electrical requirements of
that product.
• These connections must be made
by a qualified electrician. All electrical
connections must meet National Electrical
Code or prevailing local codes.
Single Oven Cutout
for Installation Between
a Monogram Advantium
Oven and a Monogram
Warming Drawer
Per Advantium
Requirem_
(69.2 cm)
45 1/4" Max.
(114.9 cm)
1/4" _
(23.5 cm)-
23 1/2"
i_(s9.7cm)
Inside
_28 1/2"
Min.
2" (5.1 cm) Min.
L_ 1" (2,5 cm) Min.
Above Toekick
J
NOTE: Additional clearances may be
required. Check to be sure the oven
supports above the Warming Drawer
do not obstruct the required interior 23 1/2"
(59.7 cm) depth and 9 1/4" (23.5 cm) height.
The middle rail separating the openings
may need to be larger than the 2" (5.1 cm)
minimum shown. Always refer to the
individual installation instructions packed
with each product for specific requirements.
Warming Drawer
Combined with Advantium
and Single Oven:
Install a separate 120V, 60Hz, properly
grounded receptacle. See installation
Instructions packed with each product
for specific requirements.

Installation Instructions
Electrical Connections
ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approved junction
box. A plug and receptacle is NOT permitted
on these products.
DO NOT shorten the flexible conduit.
The conduit strain relief clamp must be
securely attached to the junction box
and the flexible conduit must be securely
attached to the clamp. If the flexible
conduit will not fit within the clamp, do not
install the oven until a clamp of the proper
size is obtained.
NOTE TO ELECTRICIAN: The 3 power
leads supplied with this appliance are
UL recognized for connection to heavier
gauge household wiring. The insulation
of these 3 leads is rated at temperatures
much higher than the temperature rating
of household wiring. The current carrying
capacity of the conductor is governed
by the wire gauge and the temperature
rating of the insulation around the wire.
WARNING: Improper
connection of aluminum house
wiring to copper leads can
result in an electrical hazard or fire.
Use only connectors designed for
joining copper to aluminum and follow
the manufacturer's recommended
procedure closely.
AVERTISSEMENT :
Le raccordement inadequat d'un
c_blage residentiel en aluminium
des fils de sortie en cuivre peut
entrai'ner un risque electrique ou
d'incendie. Utilisez uniquement des
connecteurs con_us pour raccorder
du cuivre a I'aluminium et respectez
minutieusement la procedure
recommandee par le fabricant.
=
10
Turn off the circuit breaker or remove
fuses to the oven branch circuit.
With the oven supported on a table
or platform in front of the cabinet
opening, connect the flexible conduit
to the electrical junction box as shown
below. Position the conduit in such a
manner that it will lie on top of the
oven in a natural loop when the oven
is installed. You will need to purchase
an appropriate strain relief clamp to
complete the connection of the conduit
to the junction box.
Junction Box
Location ,5'_
Conduit (12,7c_
48 1/2"
(123 cm)
long
Place oven on a
support to assist in
connecting conduit
Strain Relief Clamp
(not included)
must be used at
Junction Box
(Continued on following page)

Installation Instructions
IBIElectrical Connections cont.
[_ New Construction and
Four-Conductor Branch
Circuit Connection
• When installing in new construction, or
• When installing in a mobile home, or
• When installing in a recreational vehicle, or
• When local codes do not permit grounding through
neutral:
a. Cut the neutral (white) lead from the crimp.
Re-strip the neutral (white) lead to expose the
proper length of conductor.
b. Attach the appliance grounding lead (green or
bare copper) in accordance with local codes. If the
residence grounding conductor is aluminum, see
WARNING on page 10.
c. Connect the oven neutral (white) lead to
the branch circuit neutral (white or gray) in
accordance with local codes, using a wire nut.
d. Connect the oven red lead to the branch circuit
red lead and the oven black lead to the branch
circuit black lead in accordance with local codes,
using wire nuts. If the residence red, black or
white leads are aluminum conductors, see
WARNING on page 10.
e. Install Junction Box Cover.
This oven is supplied with a 48" (123 cm)
long flexible conduit consisting of:
3 insulated conductors (copper)
1 bare ground conductor (copper)
r-B--_ Attach conductors to residence wiring as
shown by wiring diagram.
1.....RED'.....
GROUND
ULAPPROVEO
CONNECTOR
_-_ Three-Conductor Branch
Circuit Connection
When connecting to a three-conductor branch circuit,
if local codes permit:
a. Connect the bare oven ground conductor with the
crimped neutral (white)lead to the branch circuit
neutral (white or gray in color), using a wire nut.
_'__Ground and
_-_ I _ Neutral Wires
IJunction Box
Cover
b. Connect the oven red lead to the branch circuit
red lead in accordance with local codes, using a
wire nut.
c. Connect the oven black lead to the branch circuit
black lead in accordance with local codes, using a
wire nut. If the residence red, black or white leads
are aluminum conductors, see WARNING on
page 10.
d. Install Junction Box Cover.
11

Installation Instructions
lcl Securing the Oven in the Opening
I_ Sliding the Oven Into
the Opening
a. Loop (do not tie) a 36" (91 cm) string
around the conduit before the oven is slid
into place. This will keep the conduit from
falling behind the oven.
Pull out on
string loop
while pushing
the oven into
the cabinet
b. Lift oven into cabinet cutout using the oven
opening as a grip. Carefully push against
oven front frame. Do not push against
outside edges.
c. As you slide the oven back, pull the string
so that the conduit will lie on top of the
oven in a natural loop.
d. When you are sure the conduit is out of the
way, slide the oven 3/4 way back into the
opening. Remove the string by pulling on
one end of the loop.
Drilling the Pilot Holes
and Mounting the Oven
i
a,
NOTE: Before drilling the pilot holes,
make sure the oven is pushed as far
back into the opening as it will go
and centered.
i
Drill through the mounting holes (top and
bottom) of the side trim, for the #8 screws
provided.
Hole
The screws must
be a minimum of
1/4" (0.64 cm)
from the front
of the cutout.
WARNING: Mounting
screws must be used. Failure to
do so could result in the oven
falling out of the cabinet causing
serious injury.
i
AVERTISSEMENT :
Des vis de montage doivent
_tre utilisees. Le defaut de se
conformer a cette directive peut
occasionner la chute de four et, par
vole de consequence, des blessures
severes.
=
b. Secure the oven to cabinet with screws
provided.
NOTE: If the cabinet is particle board, you
must use #8 x 3/4" (1.9 cm) particle board
screws. These may be purchased at any
hardware store.
12 (Continued on following page)

Installation Instructions
Installing the Oven
Rack Supports and
Oven Racks
Oven Rack Supports
Place the rack support with the slotted
holes over the rear bolts and the round holes
over the front bolts. Using an adjustable
wrench, lightly secure with four nuts but
do not overtighten or the enamel could be
chipped. Repeat for the second rack support.
Slotted Round
holes over holes over
rear bolts front bolts
Oven Racks
a. Place the rear rack locks over and onto
the rack supports (five rack positions are
available, including the top position).
b. Slide the rack all the way in until the rear
rack locks are secure on the rear rack
supports, and press the front rack locks
onto the front rack supports. Slide the rack
all the way in
and push
down to lock
the front rack
locks onto the
front rack
supports
Installing the Metal
Bottom Trim
a. Place the bottom trim between the side
trim and against the bottom of the cutout.
b. Using two trim screws provided, secure
the bottom trim to the bottom edge of the
cabinet.
IMPORTANT: If this unit is ever
removed from the cabinet or the oven
is ever pulled out for service, the trim
must be removed first or damage to
the trim will occur.
13

Installation Instructions
I-D-1Replacing the Oven Door
NOTE: The oven door is heavy. You
may need help lifting the door high
enough to slide it into the hinge slots.
Do not lift the door by the handle.
= J
Lift the oven door by
placing one hand on
each side. The door is
heavy, so you may need
help. Do not lift the door
by the handle.
r-_ With the door at the same angle as
the removal position, seat the notch of
the hinge arm into the bottom edge of
the hinge slot. The notch of the hinge
arm must be fully seated into the
bottom of the slot.
Hinge Arm
Bottom Edge
of Slot ._
/I
f
Hinge Notch
I-_ Open the oven door as far as it
will open.
r-_ Push the hinge locks up against the
front frame of the oven cavity, to the
locked position.
Hinge in
Locked Position
Notch of Hinge
Securely Fitted
into Bottom
Hinge Slot
r-_ Close the oven door.
14

Installation Instructions
Pre-Test Checklist
[_ emove all protective film, if present, and
any stickers.
Check to be sure that all wiring is secure
and not pinched or in contact with moving
parts.
NOTE TO ELECTRICIAN: You must
unplug the green wire (near where the
long flexible conduit exits the unit)
when conducting high-potential testing.
Please replug prior to operation.
Check that the bottom trim is installed
properly (see page 13).
Check to be sure the mounting screws are
installed and flush with the side trim (see
page 12).
Operation Checklist
Remove all items from the inside
of the oven.
Check that conduit is securely connected
to the junction box.
Turn on the power to the oven. (Refer to
your Owner's Manual.) Verify that the bake
and broil units, and all cooking functions
operate properly.
Check that the circuit breaker is not tripped
nor the house fuse blown.
See your Owner's Manual for
troubleshooting list.
If "bAd.... LINE" appears in the display
when the power is turned on, the house
wiring connections are incorrect.
@
I'I_r_BE ]IMI_I CI.OCK COOl( I}EI A'*'
TIME S]"_*_I]"
NOTE TO ELECTRICIAN: The power
leads supplied with this appliance are
UL recognized for connections to larger
gauge household wiring. The insulation
of these leads is rated at temperatures
much higher than the temperature
rating of household wiring. The current
carrying capacity of a conductor
is governed by the wire gauge and also
the temperature rating of the insulation
around the wire.
NOTE: ALUMINUM WIRING
A.
B.
WARNING:IMPROPER
CONNECTION OF ALUMINUM
HOUSE WIRING TO THE COPPER
LEADS CAN RESULT IN AN
ELECTRICAL HAZARD OR FIRE.
Splice copper wires to aluminum
wiring using special connectors
designed and UL approved for
joining copper to aluminum,
and follow the manufacturer's
recommended connector procedure
closely.
NOTE: Wire used, location and
enclosure of splices, etc., must
conform to good wiring practice and
local codes.
15

Printed in U.S.A.
16
