Write the model and serial
numbers here:
Model # _______________________
Serial #________________________
You can find them on a label on
the front of the lower oven behind the
oven door.
Wall Oven
Safety Instructions ...............2–4
Operating Instructions
Clock and Timer....................................8
Oven...................................................5–14
Sabbath Feature................................12
Self-Cleaning.......................................14
Special Features.........................10, 11
Thermostat........................................... 13
Timed Baking and
Roasting....................................................9
Care and Cleaning
Control Panel....................................... 16
Door.........................................................15
Glass Surfaces....................................16
Heating Element................................16
Knob........................................................16
Lift-Off Oven Door.............................15
Light.........................................................17
Oven Interior........................................ 17
Painted Surfaces................................ 16
Racks.......................................................16
Stainless Steel Surfaces.................16
Troubleshooting Tips......18–20
Consumer Support
Accessories...........................................21
Consumer Support............ Back Cover
Warranty...............................................23
49-80715 04-14 GE
JRP20
JRP28
JRS06
Owner’s Manual
GEAppliances.com
Built-In Electric

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
IMPORTANT SAFETY NOTICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause cancer, birth defects or other reproductive harm,
and requires businesses to warn customers of potential exposure to such substances.
The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during the
cleaning cycle. Exposure can be minimized by venting with an open window or using a ventilation fan or
hood.
IMPORTANT: The health of some birds is extremely sensitive to the fumes given off
during the self-cleaning cycle of any oven. Move birds to another well ventilated room.
Use this appliance only for its intended purpose
as described in this Owner’s Manual.
Be sure your appliance is properly installed
and grounded by a qualified technician in
accordance with the provided installation
instructions.
Do not attempt to repair or replace any part of
your oven unless it is specifically recommended
in this manual. All other servicing should be
referred to a qualified technician.
Have the installer show you the location of the
circuit breaker or fuse. Mark it for easy reference.
Before performing any service, disconnect the
oven power supply at the household distribution
panel by removing the fuse or switching off the
circuit breaker.
'RQRWOHDYHFKLOGUHQDORQH³FKLOGUHQVKRXOG
not be left alone or unattended in an area
where an appliance is in use. They should never
be allowed to sit or stand on any part of the
appliance.
Do not allow anyone to climb, stand or hang on
the door. They could damage the oven, or cause
severe personal injury.
Be sure the oven is securely installed in a cabinet
that is firmly attached to the house structure.
Never allow anyone to climb, sit, stand or hang
on the oven door.
Never leave the oven door open when you are
not watching the oven.
Always keep combustible wall covering, curtains
or drapes a safe distance from your oven.
Always keep dish towels, dish cloths, pot holders
and other linens a safe distance from your oven.
Always keep wooden and plastic utensils and
canned food a safe distance away from your
oven.
Teach children not to play with the controls or
any other part of the oven.
Large scratches or impacts to glass doors can
lead to broken or shattered glass.
Do not use any type of foil or liner to cover the
oven bottom or anywhere in the oven, except as
described in this manual. Oven liners can trap
heat or melt, resulting in damage to the product
and risk of shock, smoke or fire.
When using electrical appliances, basic safety precautions should be followed, including the following:
SAFETY PRECAUTIONS
2

3
GEAppliances.com
Do not store flammable materials in
an oven.
CAUTION: Items of interest to
children should not be stored in cabinets above
an oven; children climbing on the oven toreach
items could be seriously injured.
Never wear loose-fitting or hanging garments
while using the appliance. Be careful when
reaching for items stored in cabinets over the
oven. Flammable material could be ignited if
brought in contact with hot surfaces or heating
elements and may cause severe burns.
8VHRQO\GU\SRWKROGHUV³PRLVWRUGDPSSRW
holders on hot surfaces may result in burns
from steam. Do not let pot holders touch hot
heating elements. Do not use a towel or other
bulky cloth.
For your safety, never use your appliance for
warming or heating the room.
Do not let cooking grease or other flammable
materials accumulate in or near the oven.
Do not use water on grease fires. Never pick up
a flaming pan. Turn the controls off.
Flame in the oven can be smothered
completely by closing the oven door and
turning the oven off or by using a multi-
purpose dry chemical or foam-type fire
extinguisher.
Never leave jars or cans of fat drippings in or
near your oven.
Do not store or use combustible materials,
gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
Stand away from the oven when opening the
oven door. Hot air or steam which escapes can
cause burns to hands, face and/or eyes.
Do not heat unopened food containers.
Pressure could build up and the container could
burst, causing an injury.
Keep the oven vent unobstructed.
Keep the oven free from grease buildup.
Place the oven rack in the desired position while
the oven is cool. If racks must be handled when
hot, do not let pot holder contact the heating
elements.
When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
Do not touch the heating elements or the
interior surface of the oven. These surfaces may
be hot enough to burn even though they are
dark in color. During and after use, do not touch,
or let clothing or other flammable materials
contact any interior area of the oven; allow
sufficient time for cooling first.
Potentially hot surfaces include oven vent
openings, surfaces near the openings, crevices
around the oven door, the edges of the window
and metal trim parts above the door.
REMEMBER: The inside surface of the oven may
be hot when the door is opened.
WARNING!
SAFETY PRECAUTIONS

Pulling out the rack to the stop-lock is a
convenience in lifting heavy foods. It is also a
precaution against burns from touching hot
surfaces of the door or oven walls.
Do not use the oven to dry newspapers. If
overheated, they can catch on fire.
Do not use the oven for a storage area. Items
stored in an oven can ignite.
Do not leave paper products, cooking utensils or
food in the oven when not in use.
After broiling, always take any broiler pan out of
the oven and clean it. Leftover grease in a broiler
pan can catch fire next time you use the pan.
Clean only parts listed in this Owner’s Manual.
Never place cooking utensils, pizza or baking
stones, or any type of foil or liner on the oven
floor. These items can trap heat or melt, resulting
in damage to the product and risk of shock,
smoke or fire.
&RRNPHDWDQGSRXOWU\WKRURXJKO\³PHDWWRDWOHDVWDQ,17(51$/WHPSHUDWXUHRI)DQGSRXOWU\
WRDWOHDVWDQ,17(51$/WHPSHUDWXUHRI)&RRNLQJWRWKHVHWHPSHUDWXUHVXVXDOO\SURWHFWVDJDLQVW
foodborne illness.
&22.0($7$1'328/75<7+2528*+/<«
Do not clean the door gasket. The door gasket is
essential for a good seal. Care should be taken
not to rub, damage or move the gasket.
Do not use oven cleaners. No commercial oven
cleaner or oven liner protective coating of any
kind should be used in or around any part of the
oven. Residue from oven cleaners will damage
the inside of the oven when the self-clean cycle
is used.
Before self-cleaning the oven, remove shiny,
silver-colored oven racks (on some models) and
all other cookware.
Be sure to wipe up excess spillage before
starting the self-cleaning operation.
If the self-cleaning mode malfunctions, turn the
oven off and disconnect the power supply. Have
it serviced by a qualified technician.
6(/)&/($1,1*29(1RQVRPHPRGHOV
5($'$1')2//2:7+,66$)(7<,1)250$7,21&$5()8//<
SAVE THESE INSTRUCTIONS
4
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
SAFETY PRECAUTIONS

Using the oven controls. GEAppliances.com
/RZHU2YHQ&RQWURORQVRPHPRGHOV
29(17(03.QRE
Turn this knob to the
temperature setting you
want.
The 29(1&<&/(
light glows until the oven reaches your selected temperature,
WKHQJRHVRIIDQGRQZLWKWKHRYHQHOHPHQWVGXULQJFRRNLQJ
5
Throughout this manual, features and appearance may vary from your model.
Upper Oven Control, Clock and Timer Features and Settings
BAKE Pad
Touch this pad to select the bake function.
%$.(/LJKW
)ODVKHVZKLOHLQHGLWPRGH³\RXFDQFKDQJHWKHRYHQ
temperature at this point. Glows when the oven is in
bake mode.
%52,/+,/23DG
Touch this pad to select the broil function.
%52,//LJKW
)ODVKHVZKLOHLQHGLWPRGH³\RXFDQVZLWFKIURPHI to
LO BROIL at this point. Glows when the oven is in broil
mode.
Display
Shows the operations you have selected, the time of
day and the cooking status.
COOKING TIME Pad
Touch this pad and then touch the +or –pad to set the
amount of time you want your food to cook. The oven
will shut off when the cooking time has run out.
'(/$<67$573DG
Use along with the COOKING TIME or SELF CLEAN pad
to set the oven to start and stop automatically at a
time you set.
29(1/,*+7212))3DG
Touch this pad to turn the oven light on or off.
7,0(5&/2&.3DG
Touch this pad to select the timer feature. Then touch +
and –pads to adjust time.
To set the clock, touch this pad twice and hold 3
seconds and then touch the +and –pads. The time of
day will flash in the display when the oven is first turned
on.
START Pad
Must be touched to start any cooking function.
– Pad
Short taps to this pad will decrease the time
or temperature by small amounts. Touch
and hold the pad to decrease the time or temperature
by larger amounts.
+ Pad
Short taps to this pad will increase the time
or temperature by small amounts. Touch
and hold the pad to increase the time or temperature
by larger amounts.
&/($52))3DG
Touch this pad to cancel ALL oven operations except
the clock and timer.
6(/)&/($13DGRQVRPHPRGHOV
Touch this pad to select the self-cleaning function. See
the Using the self-cleaning oven section.
&/($1/LJKW
)ODVKHVZKLOHLQHGLWPRGH³\RXFDQFKDQJHWKHOHQJWK
of time for the self-clean cycle at this point. Glows when
the oven is in the self-clean cycle. After the self-clean
cycle, the light will turn off. Unlatch the door.
If “F– and a number or letter” flash in the display and the oven
control signals, this indicates a function error code.
7RXFKWKH&/($52))SDG$OORZWKHRYHQWRFRROIRURQHKRXU
Put the oven back into operation.
If function error code repeats, disconnect power to the oven
and call for service.
