GE Profile PT956SRSS Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
Specification Created 5/10
220148
PT956SR
GE Profile™30" Built-In Double Convection/Thermal Wall Oven
Note: Cabinets installed adjacent to wall ovens
must have an adhesion spec of at least a 194°F
temperature rating. Electric wall ovens are
not approved for installation with a plug and
receptacle. They must be hard wired in accordance
with installation instructions.
Door handle protrudes 3" from door face. Cabinets
and drawers on adjacent 45° and 90° walls should be
placed to avoid interference with the handle.
Installation Information: Before installing, consult
installation instructions packed with product for
current dimensional data.
KW Rating
240V 7.6
208V 5.7
Breaker Size
240V 40 Amps
208V 40 Amps
21" minimum
Door Opening
Allowance
B
B
A
A
Cutout height
51-13/16" MIN.
51-15/16" MAX.
Minimum cutout location
12" from the floor.
Cutout depth
23-1/2" MIN
5
47" to
bottom of
junction box
Cutout width
28-1/2'' MIN.
28-5/8'' MAX.
21
Cabinet
width 30"
C
E
D
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
Conduit
48-1/2"
Junction box
location
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
(must support 325 lbs.)
Cabinet 30"
A – Overlap of oven over side of edges of cutout 11/16"-3/4"
B – Overlap of oven at top and bottom of cutout 1"
Oven
C – Overall depth* 23-1/2"
D – Overall height with trim 53-3/8"
Overall height without trim 52-7/8"
E –Overall width 29-3/4"
*Depth including door handle is approximately 26-6/10" min. to
26-9/10" max.
Dimensions and Installation Information (in inches)
21" minimum
Door Opening
Allowance
B
B
A
A
Cutout height
51-13/16" MIN.
51-15/16" MAX.
Minimum cutout location
12" from the floor.
Cutout depth
23-1/2" MIN
5
47" to
bottom of
junction box
Cutout width
28-1/2'' MIN.
28-5/8'' MAX.
21
Cabinet
width 30"
C
E
D
MOST 30'' WALL CABINETS CAN BE USED WITH THIS UNIT.
THE OPENING BETWEEN THE INSIDE WALLS MUST BE AT LEAST 28-1/2'' WIDE.
Conduit
(72"
long)
Junction box
location
C
L2 x 4 or
equivalent
runners
Suitable
bracing
to support
runners
21-5/8"
over centerline
of cabinet
(must support 325 lbs.)
Cabinet 30"
A – Overlap of oven over side of edges of cutout 11/16"-3/4"
B – Overlap of oven at top and bottom of cutout 1"
Oven
C – Overall depth* 23-1/2"
D – Overall height with trim 53-3/8"
Overall height without trim 52-7/8"
E – Overall width 29-3/4"
*Depth including door handle is approximately 26-6/10" min. to
26-9/10" max.

Specification Created 5/10
220148
Features and Benefits
• Glasstouchcontrols–Smoothcontrolsareeasytouseandadda
sophisticated style to the kitchen
• Blackglossoveninterior–Blackoveninterioraddsastylishtouchto
any kitchen
• PreciseAir™convectionsystem–Areversingfancirculatesheatandairfor
evenly browned and baked foods
• Heavy-dutyrollerrack–Racksprovideeasyaccesstoitemsinsidetheoven
by simplifying loading and unloading
• Flatbackconvection–Convectionfansystemisonly1"deeptoprovide
additional room for cookware
• ConvectionBake–Thissettingisoptimalforbakingcasserolesorlasagnas,
yeast breads, pies and pizzas with no need to turn the pan
• Convectionroast–Optimalforlargercutsofmeat,thissettingrotatesthe
heat around all sides, sealing in the juices, producing rotisserie results at up
to 25% faster than a conventional oven
• Hiddenbakeoveninterior–Concealsthelowerovenbakeelementto
eliminate hard-to-reach areas that collect food and spills for easy cleaning
• Upfronthalogenlights–Halogenlightsmakescheckingontheprogressof
your cooking effortless
• Self-cleanoven–Self-cleanallowsyoutospareyourselffromthetroubleand
effort it takes to scrub the oven interior
• ModelPT956SRSS–Stainlesssteel
PT956SR
GE Profile™30" Built-In Double Convection/Thermal Wall Oven
