GE JCAS745 Operating instructions

Write the model and serial
numbers here:
Model #
Serial #
behind the storage drawer on the
oven frame.
Owner´s Manual and
Installation Instructions
Coil Top and
Radiant Top Models
Standard
Clean Models
JCAS745
JCAS445
Self-Clean
Models
JCAP750
JCAP760
JCAP765
Ranges
Electric Coil & Radiant
www.GEAppliances.ca
183D9541P011
Safety Information.........................
Operating Instructions
Surface Units...................................
Cookware...........................................
Controls............................................
Oven...........................................
Clock, Timer and
Convenience Outlet....................
Timed Baking and Roasting.............
Special Features..........................
Sabbath Features........................
Temperature Conversions................
Thermostat.......................................
Self Clean...................................
Care and Cleaning......................
Installation Instructions..............
Troubleshooting Tips..................
Accessories.....................................
Consumer Support
Product Registration..................
Warranty..........................................
Consumer Support...........................
2-6
7-8
9
10
11, 12
13, 14
15
16-18
19, 20
20
21
22, 23
24-30
31-35
36-40
41
42, 43
44
45

2
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
WARNING ANTI-TIP DEVICE
SAFETY PRECAUTIONS
For your safety, the information in this manual must be followed to minimize the risk of re or explosion,
electric shock, or to prevent property damage, personal injury, or loss of life.
All ranges can tip and injury could result.
To prevent accidental tipping of the range, attach
it to the wall by installing the Anti-tip device
supplied.
If the Anti-Tip device supplied with the range does
not t this application, use the universal Anti-Tip
device WB2X7909
To check if the device is installed and engaged
properly, carefully tip the range forward. The
Anti-Tip device should engage and prevent the
range from tipping over.
When using electrical appliances, basic safety precautions should be followed, including the following:
Use this appliance only for its intended purpose
as described in this Owner´s Manual.
Be sure your appliance is properly installed
and grounded by a qualied technician in
accordance with the provided installation
instructions.
Do not attempt to repair or replace any
part of your range unless it is specically
recommended in this manual. All other
servicing should be referred to a qualied
technician.
BEFORE PERFORMING ANY SERVICE, DISCONNECT
THE RANGE POWER SUPPLY AT THE HOUSEHOLD
DISTRIBUTION PANEL BY REMOVING THE FUSE
OR SWITCHING OFF THE CIRCUIT BREAKER.
If you pull the range out from the wall for any
reason, make sure the device is properly engaged
when you push the range back against the wall. If
it is not, there is a possible risk of the range tipping
over and causing injury if you or a child stand, sit
or lean on an open door.
Please refer to the Anti-Tip device information in
this manual. Failure to take this precaution could
result in tipping of the range and injury.
Do not leave children alone-children should
not be left alone or unattended in an area where
an appliance is in use. They should never
be allowed to sit or stand on any part of the
appliance.
Do not allow anyone to climb, stand or hang
on the door, storage drawer, or cooktop. They
could damage the range and even tip it oven,
causing severe personal injury.
Do not store ammable materials in an oven or
near the cooktop.
CAUTION: ITEMS OF INTEREST TO CHILDREN
SHOULD NOT BE STORED IN CABINETS ABOVE A
RANGE OR ON THE BACKSPLASH OF A RANGE-
CHILDREN CLIMBING ON THE RANGE TO REACH
ITEMS COULD BE SERIOUSLY INJURED.

3
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions
WARNING!
SAFETY PRECAUTIONS
COOK MEAT AND POULTRY THOROUGHLY…
Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160° F and poultry to at least an
INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against foodborne illness.
Never wear loose-tting or hanging garments
while using the appliance. Be careful when
reaching for items stored over the range.
Flammable material could be ignited if brought
in contact with hot surface units or heating
elements and may cause severe burns.
Use only dry pot holders-moist or damp pot
holders on hot surfaces may result in burns from
steam. Do not let pot holders touch hot surface
units or heating elements. Do not use a towel or
other bulky cloth.
For your safety never use your appliance for
warming or heating the room.
Do not let cooking grease or other ammable
materials accumulate in or near the range.
Do not use water on grease res. Never pick up
a aming pan. Turn the controls off.
Smother a aming pan on a surface unit by
covering the pan completely with a well-
tting lid, cookie sheet or at tray. Use a
multi-purpose dry chemical or foam-type re
extinguisher.
Flaming grease outside a pan can be put out by
covering it with baking soda or, if available, by
using a multi-purpose dry chemical or foam-
type re extinguisher.
Flame in the oven can be smothered completely
by closing the door and turning the oven off or
by using a multi-purpose dry chemical or foam-
type re extinguisher.
Do not touch the surface units, the heating
elements or the interior surface of the oven.
These surfaces may be hot enough to burn
even though they are dark in color. During and
after use, do not touch or let clothing or other
ammable materials contact, the surface units,
areas nearby the surface units or any interior
area of the oven; allow sufcient time for
cooling rst.
Potentially hot surfaces include the cooktop,
areas facing the cooktop, oven vent opening,
surfaces near the opening, crevices around the
oven door and metal trim parts above the door.
REMEMBER: The inside surface of the oven
may be hot when the door is opened.
Do not store or use combustible materials,
gasoline or other ammable vapors and
liquids in the vicinity of this or any other
appliance.
Keep the hood and grease lters clean
to maintain good venting and to avoid
grease res.
Never Block the vents (air openings) of
the range. They provide the air inlet and
outlet that are necessary for the range to
operate properly with correct combustion.
Air openings are located at the rear of the
cooktop, at the top and bottom of the oven
door, and at the bottom of the range under
the storage drawer.

4
SELF-CLEANING OVEN (on some models)
Do not clean the door gasket. The door
gasket is essential for a good seal. Care
should be taken not to rub, damage or
move the gasket.
Clean only parts listed in this Owner´s
Manual.
Do not use oven cleaners on self-clean
models. No commercial oven cleaner or
oven liner protective coating of any kind
should be used in or around any part of
the oven. Residue from oven cleaners will
damage the inside of the oven when the
self-clean cycle is used.
Before self-cleaning the oven, remove the
broiler pan, grid and other cookware.
Be sure to wipe up excess spillage before
starting the self-cleaning operation.
If the self-cleaning mode malfunctions,
turn the oven off and disconnect the power
supply. Have it serviced by a qualied
technician.
Take the shelves out of the oven before
you begin the self-clean cycle or they may
discolor.
OVEN
Stand away from the range when opening
the oven door. Hot air or steam which
escapes can cause burns to hands, face
and/or eyes.
Do not heat unopened food containers.
Pressure could build up and the container
could burst, causing an injury.
Keep the oven vent unobstructed.
Keep the oven free from grease buildup.
Place the oven shelf in the desired position
while the oven is cool. If shelves must be
handled when hot, do not let pot holder
contact the heating elements.
Pulling out the shelf to the stop-lock is a
convenience in lifting heavy foods. It is also
a precaution against burns from touching
hot surfaces of the door or oven walls.
When using cooking or roasting bags in the
oven, follow the manufacturer’s directions.
Do not use the oven to dry newspapers. If
overheated, they can catch on re.
Do not use the oven for a storage area. Items
stored in an oven can ignite.
Do not leave paper products, cooking
utensils or food in the oven when not in use.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.

5
SURFACE UNITS-ALL MODELS
Use proper pan size-select cookware having at bottoms large enough to cover the surface unit
heating element. The use of undersized cookware will expose a portion of the surface unit to direct
contact and may result ignition of clothing. Proper relationship of cookware to surface unit will also
improve efciency.
Never leave the surface units unattended at
high beat settings. Boilovers cause smoking
and greasy spillovers that may catch on re.
Only certain types of glass, glass/ceramic,
earthenware or other glazed containers are
suitable for cooktop service, others may
break because of the sudden change in
temperature.
To minimize the possibility of burns,
ignition of ammable materials and spillage,
the handle of a container should be turned
toward the center of the range without
extending over nearby surface units.
Always turn the surface units off before
removing cookware.
Do not ame foods on the cooktop. If you
do ame foods under the hood, turn the
fan on.
Keep an eye on foods being fried at high or
medium high heat settings.
Foods for frying should be as dry as possible.
Frost on frozen foods or moisture on fresh
foods can cause hot fat to bubble up and over
the side of the pan.
Use little fat for effective shallow or deep fat
frying. Filling the pan too full of fat can cause
spillovers when food is added.
If a combination of oils or fats will be used in
frying, stir together before heating, or as fats
melt slowly.
Always heat fat slowly, and watch as it heats.
Use a deep fat thermometer whenever
possible to prevent overheating fat beyond the
smoking point.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions

6
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
WARNING!
SAVE THESE INSTRUCTIONS
RADIANT SURFACE UNITS (on some models)
COIL SURFACE UNITS (on some models)
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY
Avoid scratching the glass cooktpo. The
cooktop can be scratched with items such as
sharp instruments, rings or other jewelry and
rivets on clothing.
Large scratches or impacts to glass doors or
cooktops can lead to broken or shattered glass.
Do not operate the radiant surface units if the
glass is broken. Spillovers or cleaning solution
may penetrate a broken cooktop and create
a risk of electrical shock. Contact a qualied
technician immediately should your glass
cooktop become broken.
Never use glass cooktop surface as a cutting
board.
Do not place or store items that can melt or
catch re on the glass cooktop, even when it is
not being used.
Be careful when placing spoons or other
stirring utensils on the glass cooktop surface
when it is in use. They may become hot and
could cause burns.
Clean the cooktop with caution. If a wet
sponge is used to wipe spills on a hot
cooktop, be careful to avoid steam burns.
To avoid the possibility of a burn or electric
shock, always be certain that the controls for
all surface units are at the OFF position and
all coils are cool before attempting to lift or
remove a unit.
Do not immerse or soak the removable
surface units. Do not put them in a
dishwasher.
Clean the cooktop with caution. If a wet
sponge or cloth is used to wipe spills on a
hot surface unit, be careful to avoid steam
burns. Some cleaners can produce noxious
fumes if applied to a hot surface.
NOTE: We recommend that you avoid
wiping any surface unit areas until they have
cooled and the indicator light has gone off.
Sugar spills are the exception to this. Please
see Cleaning the glass cooktop section.
When the cooktop is cool, use only the
recommended cleaning cream to clean the
cooktop.
To avoid possible damage to the cooking
surface, do not apply cleaning cream to the
glass surface when it is hot.
After cleaning, use a dry cloth or paper
towel to remove all cleaning cream residue.
Read and follow all instructions and
warnings on the cleaning cream labels.
Do not lift the cooktop. Lifting the cooktop
can lead to damage and improper operation
of the range.
Be sure the drip pans and the vent duct
are not covered and are in place. Their
absence during cooking could damage
range parts and wiring.
Do not use aluminum foil to line the drip
pans or anywhere in the oven except as
described in this manual. Misuse could
result in a shock, re hazard or damage to
the range.
Use care when touching the cooktop. The glass surface of the cooktop will retain heat after the controls
have been turned off.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions

7
Using the surface units.
Throughout this manual, features and appearance may vary from your model.
Surface Cooking Controls
Your surface units and controls are
designed to give you a variety of heat
settings for surface unit cooking.
At both LO and HI positions, there is a
slight niche so control clicks at those
positions; HI marks the highest setting; LO,
the lowest setting.
How to Set the Controls
Push the control knob in.
Turn either clockwise or
counterclockwise to desired heat
setting.
Control must be pushed in to set only
from the
OFF position.
Heat Setting Guide
MAX ---Quick start for cooking; bring
water to boil.
MEDIUM HIGH --- Fast fry, pan broil;
maintain fast boil on large amount of
food.
MED --- Sauce and brown; maintain slow
boil on large amount of food.
MEDIUM LOW – Cereal; maintain serving
temperature of most foods.
Cooking Tips
Use medium- or heavyweight
cookware. Aluminum cookware
conducts heat faster than other
metals. Cast-iron and coated cast-
iron cookware is slow to absorb heat,
but generally cooks evenly at low or
medium heat settings. Steel pans may
cook unevenly if not combined with
other metals.
Do not overll cookware with fat
that may spill over when adding
food. Frosty foods bubble vigorously.
Watch foods frying at high
temperatures. Keep range and hood
clean from accumulated grease.
In a quiet kitchen, you may hear
slight clicking sounds during cooking,
indicating heat settings selected are
being maintained.
Switching heats to higher settings
always shows a quicker change in
temperature than switching to lower
settings.
When control is in any position other
than
OFF , you can turn it without
pushing in.
Be sure you turn control to OFF when you
nish cooking. An indicator light will
glow when
ANY surfaces unit is on.
A Burner On indicator light will glow
when
ANY surface unit is on.
MIN --- Cook after starting at HI; cook
with little water in covered pan. Use to
steam rice.
NOTE:
At MAX or MEDIUM HIGH, never
leave food unattended. Boilovers
cause smoking; greasy spillovers
may catch re.
At
MIN , melt chocolate, butter on
small unit.
To conserve the most cooking energy,
pans should be at on the bottom,
have straight side and tight-tting lids.
Match the size of the saucepan to the
size of the surface unit. A pan that
extends more than an inch beyond
the edge of the drip pan traps heat,
which causes “crazing” (ne hairline
cracks) on porcelain, and discoloration
ranging from blue to dark gray on
chrome drip pans.
1
1
2
2
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions

8
Using the surface units.
Using the radiant surface units. (on some models)
Throughout this manual, features and appearance may vary from your model.
Indicator Lights (on radiant glass models only).
A Hot indicator light will glow when any
radiant elements is turned on, and will
remain on until the surface is cool enough
to touch.
A Burner On indicator light will glow when any
surface unit is on.
NOTE: The Hot indicator light may glow between
the surface control settings of
Min and OFF , but
there is no power to the surface units.
About the radiant surface units…
The radiant cooktop features heating units
beneath a smooth glass surface.
NOTE: A slight odor is normal when a
new cooktop is used for the rst time. It is
caused by the heating of new parts and
insulating materials and will disappear in a
short time.
The surface unit will cycle on and off to
maintain your selected control setting.
It is safe to place hot cookware from the oven
or surface on the glass surface when the surface
is cool.
Even after the surface units are turned off, the
glass cooktop retains enough heat to continue
cooking. To avoid over-cooking, remove pans
from the surface units when the food is cooked.
Avoid placing anything on the surface unit
until it has cooled completely.
Do not slide cookware across the cooktop
because it can scratch the glass --- the glass
is scratch resistant, not scratch proof.
Temperature Limiter
Every radiant surface unit has a
temperature limiter.
The temperature limiter protects the glass
cooktop from getting too hot.
Water stains (mineral deposits) are
removable using the cleaning cream or
full-strength white vinegar.
Use of window cleaner may leave
an iridescent lm on the cooktop.
The cleaning cream will remove this
discoloration.
Don´t store heavy items above the
cooktop. If they drop onto the cooktop,
they can cause damage.
Do not use the surface as a cutting
board.
The temperature limiter may cycle the
units off for a time if:
The pan boils dry.
The pan bottom is not at.
The pan is off center.
There is no pan on the unit.
SURFACE
COOKING
DRAGGING
OFF CENTER
Never cook directly on the
glass. Always use cookware.
Always place the pan in the center of
the surface unit you are cooking on.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions

9
Selecting types of cookware.
The following information will help you choose cookware will give good performance on glass cooktops.
The following information will help you choose cookware which will give food performance on coil cooktops.
Stainless Steel:
recommended
Aluminum:
heavy weight recommended.
Good conductivity. Aluminum residues
sometimes appear as scratches on the
cooktop, but can be removed if cleaned
immediately. Because of its low melting
point, thin-weight aluminum should not
be used.
Copper Bottom:
recommended
Copper may leave residues which can
appear as scratches. The residues can
be removed, as long as the cooktop is
cleaned immediately. However, do not let
these pots boil dry. Overheated metal can
bond to glass cooktops. An overheated
copper bottom pot will leave a residue
that will permanently stain the cooktop if
not removed immediately.
Porcelain Enamel Covered Cast Iron:
recommended
As long as the cookware is covered
completely with porcelain enamel, this
cookware is recommended. Caution is
recommended for cast-iron cookware that
is not completely covered with smooth
porcelain enamel, as it may scratch the
glass-ceramic cooktop.
Surface Cookware Tips
Use medium- or heavy-weight cookware.
Aluminum cookware conducts heat faster
than other metals. Cast-iron and coated
cast-iron cookware are slow to absorb heat,
but generally cook evenly at low to medium
heat settings. Steel pans may cook unevenly
if not combined with other metals.
Wok Cooking
We recommend that you use only a at-bottomed
wok. They are available at your local retail store.
Do not use woks that have support rings. Use
of these types of woks, with or without the
ring in place, can be dangerous.
Not over 1 inch
Use Only at-bottomed woks.
Glass-ceramic:
usable, but not recommended
Poor performance. May scratch the surface.
Stoneware:
usable, but not recommended
Poor performance. May scratch the surface.
Home Canning Tips:
Be sure the canner is centered over the
surface unit.
Make sure the canner is at on the bottom.
Use recipes and procedures from
reputable sources. These are available
from manufacturers such as Ball® and
Kerr® and the Department of Agriculture
Extension Service.
To prevent burns from steam or heat, use
caution when canning.
Check for at bottoms by using a
straight edge.
Pans with rounded, curved,
ridged or warped bottoms are not
recommended.
For best cooking results, pans should be
at on the bottom. Match the size of the
saucepan to the size of the surface unit.
The pan should not extend over the edge
of the surface unit than 1 inch.
Placing the ring over the surface unit will
cause a buildup of heat that will damage
the porcelain cooktop. Do not try to use
such woks without the ring. You could be
seriously burned if the wok tips over.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions

10
Using the oven controls. (on some models)
Throughout this manual, features and appearance may vary from y our model.
Oven Control, Clock and Timer Features and Settings
1
2
3
4
5
7
6
8
9
10
11
12
BAKE Pad
Touch this pad to select the bake function.
BAKE Light
Flashes while in edit mode---you can change
the oven temperature this point.
BROIL HI/LO Pad
Touch this pad to select the broil function.
BROIL Light
Flashes while in edit mode---you can switch
from
HI to LO BROIL at this point.
Display
Shows the operations you have selected, the
time of day and the cooking status.
COOK TIME Pad
Touch this pad and then touch the+ or –
pad to set the amount of time you want your
food to cook. The oven will shut o when
the cooking time has run out.
START TIME Pad
Use along with the COOK TIME or SELF
CLEAN
pad to set the oven to start and stop
automatically at a time you set.
OVEN LIGHT ON/OFF Pad
Touch this pad to turn the oven lighton or o.
TIMER/CLOCK Pad
Touch this pad to select the timer feature.
Then pres + and – pads to adjust time.
TO set the clock, touch this pad and hold
3 seconds and then touch the
+ and – pads.
START Pad
Must be touched to start any cooking
function.
– Pad
Short taps to this pad will decrease the time
or temperature by small amounts. Touch
and hold the pad to decrease the time or
temperature by larger amounts.
+ Pad
Short taps to this pad will increase the time
or temperature by small amounts. Touch
and hold the pad to increase the time or
temperature by larger amounts.
CLEAR/OFF Pad
Touch this pad to cancel
ALL oven
operations except the clock and timer.
SELF CLEAN Pad
Touch this pad to select the self-cleaning
function. See the Using the self-cleaning
oven
section.
CLEAN Light
Flashes while in edit mode-you can change
the length of time for the self-clean cycle
at this point. Glows when the oven is in the
self-clean cycle. After the self-clean cycle,
the light will turn o. Unlatch the door.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
Time Temps
the oven control signals, this indicates a function
error code.
Touch the
CLEAR/OFF pad. Allow the oven to cool-
for one hour. Put the oven back into operation.
If function error code repeats, disconnect power to
the oven and call for service.

11
Using the oven.
Clock and Timer (on some models)
TIMER Pad
Touch this pad to select the timer feature.
CLOCK Pad
Touch this pad before setting the clock.
Display
Shows the time of day and the time set for the timer, cook time or start time.
SET +/- Pads
These pads allow you to set the clock and timer.
Oven Temperature Knob (on some models)
Turn this knob to the setting you want.
Before you begin…
To avoid possible burns, place the shelves in the
desired position before you turn the oven on.
The shelves have stop-locks, so that when
placed correctly on the shelf supports (A
through E), they will stop before coming
completely out, and will not tilt.
When placing and removing cookware,
pull the shelf out to the bump on the
shelf support.
Oven shelf positions
The oven has four shelf supports—A
(bottom), B, C and D (top).
The oven cycling light glows until the
oven reaches your selected temperature,
then goes off and on with the oven
element(s) during cooking.
1
2
3
4
To remove a shelf , pull it toward you, tilt
the front end up and pull it out.
To replace, place the end of the shelf
(stop-locks) on the support, tilt up the
front and push the shelf in.
NOTE: The shelf is not designed to slide out
at the special low shelf (R) position.
The oven has 4 shelf positions.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions
Appearance may vary.

12
Using the oven.
How to Set the Oven for Baking or Roasting
Preheating and Pan Placement
Aluminum Foil
Touch the BAKE pad.
Touch the
+ or – pad to set the
desired temperature
Touch the
START pad.
Check food for doneness at
minimum time on recipe. Cook
longerifnecessary.
Touch the
CLEAR/OFF pad when
cooking iscomplete.
Preheat the oven if the recipe calls
for it. To preheat, set the oven at the
correct temperature. Preheating is
necessary for good results when baking
cakes, cookies, pastry and breads.
For ovens without a preheat indicator light or
tone, preheat 10 minutes.
Do not use aluminum foil on the bottom of
the oven.
Never entirely cover ashelf with
aluminumfoil. This will disturb the heat
circulation and result in poor baking.
1
2
3
4
5
NOTE: A cooling fan may automatically
turn on and o to cool internal parts. This is
NOTE:
Close the door beforestart any
broiling function.
normal, and the fan may continue to run even
after the oven is turned o.
Baking results will be better baking
pans are centered in the oven as much
as possible. Pan should not touch each
other or the walls of the oven. If you
need to use two shelves, stagger the
pans so one is not directly above the
other, and leave approximately 1 ½”
between pans, from the front, back and
slides of the wall.
A smaller sheet of foil may beused to catch
aspillover by placing it on a lower shelf
several inches below the food.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
grid in a broiler pan.
Follow suggested rack positions in the
Broiling Guide.
Broil.
1
2
3
4
Close the over door.
Turn the Oven Temperature Knob to
5
When broiling is nished, turn the Oven
temperature Knob to OFF .
On models with an oven temperature knob:On models without an oven temperature knob:
Place the meat or sh on a broiler
How to Set the Oven for Broiling
grid in a broiler pan designed for
broiling.
Touch the BROIL HI/LO pad once for
HI Broil.
To change to LO Broil, touch the BROIL
HI/LO
pad again.
1
2
3
4
Touch the START pad.
CLEAR/OFF pad.
If your oven is connected to 208 volts, rare steaks
may be broiled by preheating the broiler and
positioning the oven shelf one position higher.

13
To Set the Clock
To Set the Timer
The clock must be set to the correct time
of day for the automatic oven timing
functions to work properly. The time of
day cannot be changed during a timed
baking or self-cleaning cycle.
The timer does not control oven operations.
The maximum setting on the timer is 9 hours
and 59 minutes.
1
1
2
2
3
3
4
Touch the START/ON pad until the
time of day shows in the display. This
enters the time and starts the clock.
Touch the START/ON pad. The time
will start counting down, although
the display does not change until
one minute has passed.
When the timer reaches :00, the
control will beep 3 times followed
by one beep every 6 seconds until
the TIMER pad is touched.
Using the clock, timer and convenience outlet. (on some models)
Not all features are on all models.
To check the time of day when the display
is showing other information, simply touch
the TIMER pad. The time of day shows
until another pad is touched.
Touch TIMER pad and hold for 3
seconds
Touch the
+ or – pads.
Touch the TIMER pad.
Touch the +
or – pads until the
amount of time you want shows
in the display. The maximum time
that can be entered in minutes is 59.
Times more than 59 minutes should
be changed to hours and minutes.
If the + or – pads are not touched within
one minute after you touch the
TIMER pad,
the display reverts to the original setting.
If this happens, touch the
TIMER pad and
reenter the time of day.
If you make a mistake, touch the TIMER
pad and begin again.
Make sure the clock is set to the
correct time of day.
The timer is a minute timer only.
The OFF pad does not affect the
timer.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions

14
To Reset the Timer
To Cancel the Timer
End of Cycle Tones
(on some models)
Clear the tones by pressing the pad of the
function you are using.
Power Outage
If a ashing time is in the display, you have
experienced a power failure. Reset the clock.
Convenience Outlet (on some models)
The 120V convenience outlet located on
the top of the backguard may be used to
plug in small electrical appliances.
When using the outlet, be sure that the
electrical cord does not rest on or near a
surface unit. If the surface unit is turned
on, the cord will be damaged.
If the display is still showing the time
remaining, you may change it by touching
the
TIMER pad, then touch the + or – pads
until the time you want appears in the
display.
Touch the TIMER pad twice.
If the remaining time is not in the display
(clock, delay start or cooking timer are in
the display), recall the remaining timer by
touching the
TIMER pad and then touching
the
+ or – pads to enter the new time you
want.
Using the clock, timer and convenience outlet. (on some models)
Not all features are on all models.
To reset the clock, touch the TIMER pad
twice. Enter the correct time of day by
touching the
+ or – pads. Touch the
START/ON pad.
To reset the circuit breaker, press the
switch located near the outlet on top of
the backguard.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions

15
How to Set an Immediate Start and Automatic Stop
How to Set a Delayed Start and Automatic Stop
The oven will turn on immediately and cook for a
selected length of time. At the end of the cooking
time the oven will turn off automatically.
Make sure the clock shows the correct
time of day.
You can set the oven control to delay-start
the oven, cook for a specic length of time
and then turn off automatically.
Make sure the clock shows the correct time
of day.
1
1
2
2
3
3
4
4
5
6
5
7
The oven temperature and the cooking
time that you entered will be displayed.
Touch the START pad.
Using the timed baking and roasting features, (on some models)
NOTE: Foods that spoil easily-such as milk, eggs, sh, stufngs, poultry and pork-should not be allowed to sit for
more than 1 hour before or after cooking. Rom temperature promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will speed harmful bacteria growth.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions
Touch the BAKE pad
Using the
+ or – pad, enter the
desired temperature.
Touch the
COOK TIME pad.
NOTE: If your recipe requires preheating,
you may need to additional time to the
length of the cooking time.
Using the + or – pad, enter the
desired baking time.
Touch the
START pad.
The display shows the oven temperature
that you set and the cooking time
countdown. The display starts changing
once the temperature reaches 100° F.
The oven will continue to cook for the
programmed amount of time, then shut
off automatically.
Touch the
CLEAR/OFF pad to clear the
display.
Touch the BAKE pad.
Using the
+ or – pad, enter the
desired temperature.
Touch the
COOK TIME pad.
NOTE: If your recipe requires preheating,
you may need to add additional time to the
length of the cooking time.
Using the + or – pad, enter the desired
baking time.
Touch the
START TIME pad.
Using the
+ or – pad, enter the time of
day you want the oven to turn on and
start cooking.
NOTE: An attention tone will sound if you are
using timed baking and do not touch the START
pad after entering the baking temperature.
If you would like to check the times you
have set touch the
START TIME pad to check
the start time you have set or touch the
COOK
TIME
pad to check the length of cooking time
you have set.
When the oven turns on at the time of day
you have set, the display will show the
changing temperature (starting at 100°F) and
the cooking time countdown.
At the end of timed baking, the oven will
turn off. The end of cycle tone will sound.
Touch the
CLEAR/OFF pad to clear the
display.

16
12 Hour Shut-Off
Fahrenheit or Celsius Temperature Selection
Control Lockout
With this feature should you forget and leave the
oven on, the control will automatically turn off
the oven after 12 hours during baking functions
or after 3 hours during a broil function.
If you wish to turn off this feature, follow
the steps below.
Your oven control is set to use the Fahrenheit
temperature selections buy you may change
this to use the Celsius selections.
Your control will allow you to lock down the touch
pads so they cannot be activated when touched.
1
1
1
2
2
2
3
3
3
4
Touch the START TIME pad. The
display will show
12 shdn (12 hour
shut-off). Touch the
START TIME pad
again and the display will show
no
shdn
(no shut-off).
Touch the
START pad to activate the
no shut-off and leave the control set
in this special features mode.
Touch the
BROIL HI/LO and COOK
TIME pads again the same time for
2 seconds. The display will show
C
(Celsius).
Touch the
START pad.
Touch the
START pad to activate
the control lockout feature and
leave the control set in this special
features mode.
Special features of your oven control.
Your new touch pad control has additional features that you may choose to use. The following are the features and
how you may activate them.
The special feature modes can only be activated while the display is showing the time of day. They remain in the
control´s memory until the steps are repeated.
When the display shows your choice, touch the START pad. The special features will remain in memory after a
power failure, except for the Sabbath feature, which will have to be reset.
Touch the BAKE and BROIL HI/LO pads
at the same time for 3 seconds until the
display shows
SF .
Touch the
BAKE and BROIL HI/LO pads
at the same time for 3 seconds until
the display shows
SF.
Touch the BROIL HI/LO and COOK TIME
pads at the same time for 2 seconds.
The display will show
F (Fahrenheit).
Touch the
BAKE and BROIL HI/LO pad
at the same time for 3 seconds until
the display shows
SF .
Touch the
SELF CLEAN pad. The
display will show
LOC OFF.
Touch the SELF CLEAN pad again. The
display will show
LOC ON.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
When this feature is on and the touch
pads are touched the control will beep
and the display will show
LOC .
NOTE: The control lockout mode will not affect
the TIMER/CLOCK and OVEN LIGHT ON/
OFF touch pads.

17
Tones at the End of a Timed Cycle
12 Hour, 24 Hour or Clock Black-Out
At the end of a timed cycle, 3 short beeps will
sound followed by one beep every 6 seconds until
the CLEAR/OFF pad is touched. This continuous 6
second beep may be canceled.
To cancel the 6 second beep:
Your control is set to use a 12 hour clock.
If you would prefer to have a 24 hour
military time clock or black-out the clock
display, follow the steps below.
1
1
2
2
3
Touch the BROIL HI/LO pad. The
display shows
CON BEEP (continuous
beep). Touch the
BROIL HI/LO pad
again. The display shows
BEEP .
(This cancels the one beep every 6
seconds.)
Touch the
START pad.
NOTE :If the clock is in the black-out mode you
will not be able to use the Delay Start function.
Touch the BAKE and BROIL HI/LO pads
at the same time for 3 seconds until
the display shows
SF .
Touch the BAKE and BROIL HI/LO pads
at the same time for 3 seconds until
the display shows
SF .
Touch the
TIMER /CLOCK pad once.
The display will show
12 hr. If this is
the choice you want touch the
START
pad.
Touch the
TIMER/CLOCK pad again to
change to the 24 hour military time
clock. The display will show
24 hr. If
this is the choice you want touch the
START pad.
Touch the
TIMER/CLOCK pad again
to black-out the clock display. The
display will show
OFF . If this is the
choice you want touch the
START
pad.
Special features of your oven control.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions

18
Changing the Speed of the + or – Pads
As you use the + or – pads when setting a time
or temperature, you may notice the display
changes slowly. This special feature allows
you to change the speed. To set the speed you
prefer follow the steps below.
1
2
3
4
Special features of your oven control.
Cook and Hold
You new control has a cook and hold feature that
keeps cooked foods warm for to up to 3 hours
after Timed Baking or Roasting is nished.
NOTE : This feature can only be programmed to
work with Timed Baking or Roasting (See the
Using the timed baking and roasting features
section). After Timed Baking or Roasting has
automatically stopped, the programmed Cook
and Hold will automatically start.
To activate this feature for use after Timed
Baking or Roasting, follow the steps bellow.
1
2
3
Touch the COOK TIME pad. The
display will show
Hid OFF.
Touch the COOK TIME pad again
to activate the feature. The
display will show
Hid ON.
Touch the START pad to activate the
cook and hold feature and leave the
control set in this special features
mode.
Touch the BAKE and BROIL HI/LO
pads at the same time for 3 seconds
until the display shows SF .
Touch the
+ pad. The display will
show you a set speed between 1
and 5
Touch the
+ pad to increase the
speed up to the number 5
Touch the
– pad to decrease the
speed down to the number 1.
Touch
START to activate the setting
and leave the control set in this
special mode.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
Touch the BAKE and BROIL HI/LO pads
at the same time for 3 seconds until
the display shows
SF.

19
The Sabbath feature can be used for baking/roasting only. It cannot be used for broiling, self-cleaning, or
Delay Start cooking.
NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when
the door is closed. The bulb may be removed. See the Oven Light Bulb section. On models with a light switch
on the control panel, the oven light may be turned on and left on.
How to Set Sabbath Feature for Regular Baking /Roasting
How to Set Sabbath Feature for Timed Baking/Roasting—Immediate Start and
Automatic Stop.
NOTE: To understand how the oven control works,
practice using regular baking (non – Sabbath)
before entering Sabbath mode.
Make sure the clock shows the correct time of day.
NOTE: To understand how the oven control works,
practice using regular (non – Sabbath) immediate Start
and Automatic Stop before entering the Sabbath mode.
Make sure clock shows the correct time of day.
1
1
2
2
3
3
4
4
The preset starting temperature will
automatically be set to 350°. Tap the
+ or – pad to increase or decrease
the temperature in 5° increments. The
temperature can be set between 170°
and 550°. No signal or temperature
will be given.
Touch the
START pad.
After a random delay period of
approximately 30 seconds to 1
minute,
will appear in the display
indicating that the oven is baking/
roasting. If does not appear in the
display, start again at step 4.
Touch the
BAKE PAD. No signal will
be given.
The preset starting temperature will
automatically be set to 350°. Tap the
+ or – pad to increase or decrease the
temperature in 5° increments. The
temperature can be set between 170°
and 550°. No signal or temperature
will be given.
Touch the
START pad.
After a random delay period of
approximately 30 seconds to 1 minute,
will appear in the display
indicating that te oven is baking/
roasting. If does not appear in
the display, start again at step 7.
Touch and hold
both the BAKE and
BROIL HI/LO pads, at the same time,
until the display shows SF.
NOTE:
If bake or broil appears in the
display, the BAKE and BROIL HI/LO pads
were not touched at the same time. Touch
the CLEAR/OFF pad and begin again.
Tap the START TIME pad until
Sabbath appears in this display.
Touch the
START pad and will
appear in the display.
Touch the
BAKE pad. No signal will
be given.
Touch and hold
both the BAKE and
BROIL HI/LO pads, at the same time,
until the display shows SF .
NOTE: If bake or broil appears in the
display, the BAKE and BROIL HI/LO pads
were not touched at the same time.
Touch the CLEAR/OFF pad and begin
again.
Tap the START TIME pad until Sabbath
appears in the display.
Touch the
START pad and will
appear in the display.
Touch the
COOK TIME pad.
Touch the
+ or – pad to set the
desired length of cooking time
between 1 minute and 9 hours and 59
minutes. The cooking time that you
entered will be displayed.
Touch the
START pad.
Using the Sabbath Feature.
(Designed for use on the Jewish Sabbath and Holidays) (on some models)
5
5
6
9
8
6
7
10
7
To adjust the oven temperature, touch the
BAKE pad and tap the + or – pad to increase or
decrease the temperature in 5° increments. Touch
the START pad.
NOTE: The CLEAR/OFF and COOK TIME pads
are active during the Sabbath feature.
To adjust the oven temperature, touch the
BAKE pad and tap the + or – pad to increase
or decrease the temperature in 5° increments.
Touch the START pad.
When cooking is nished, the display will
change from to and
0:00 will appear,
indicating that the oven has turned OFF but is
still set in Sabbath. Remove the cooked food.
When the display shows t he oven
is set in Sabbath. When the display
shows , the oven is baking/
roasting.
When the display shows « » the
oven is set in Sabbath. When the
display shows the oven is
baking/roasting.
Consumer Support
Troubleshooting Tips
Care and CleaningSafety Instructions Installation
Instructions
Operating
Instructions

20
Using the Sabbath Feature.
(Designed for use on the Jewish Sabbath and Holidays) (on some models)
How to Exit the Sabbath Feature
Power Outage
Temperature Conversions
° Fahrenheit 140 150 170 200 250 275 300 325 350 375 400 425 450 475 500 525 550
° Celsius 60 65 75 95 120 135 150 160 175 190 205 220 230 245 260 275 290
Touch the CLEAR/OFF pad.
If the oven is cooking, wait
for a random delay period of
approximately 30 seconds to 1
minute, until only is in the
display.
Touch and hold both the BAKE and
BROIL HI/LO pads, at the same time,
until the display shows SF.
Tap the START TIME pad until 12
shdn or no shdn appears in the
display. 12 shdn indicates that the
oven will automatically turn off
after 12 hour. no shdn indicates that
the oven will not automatically
turn off.
If a ashing time is in the display, you have experienced
a power failure. Reset the clock.
5Touch the START pad.
1
2
3
4
To reset the clock, touch the TIMER pad. Enter the
correct time of day by touching the
+ or – pads.
Touch the STAT/ON pad.
Consumer Support Troubleshooting Tips Care and Cleaning Safety Instructions
Installation
Instructions
Operating
Instructions
NOTE: If a power outage occurred while
the oven was in Sabbath mode, the oven
will automatically turn off and the oven
control must be reset.
