GE PB970BMBB Manual

†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
PB970BM/TM
GE Profile™ 30" Free-Standing Double Oven Range
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 1/07 221008
KW Rating
240V 13.9
208V 10.4
Breaker Size
40 Amps†
30
24
3
7-1/2
29-7/8
25-3/4*
45
47
3
Acceptable electrical
outlet area
Orient the electrical
receptacle so the length
is parallel to the floor.
*Dimension from wall to front of
closed oven door handle is 28-7/8.
fse_dual_cavity_install.eps
Dimensions and Installation Information (in inches)

PB970BM/TM
GE Profile™ 30" Free-Standing Double Oven Range
Specification Created 1/07 221008
Features and Benefits
• Upper Oven - With an additional 2.1 cu. ft. of capacity, the upper oven is perfect for
preparing food items at the same time as the lower oven
• Large 4.4 Cu. Ft. Lower Oven Capacity - Provides an impressively large oven interior
to cook more dishes and large meals at once
• Self-Clean Oven - Conveniently cleans the oven cavity without need of scrubbing
• Dual Size Ribbon Element - Offers a convenient choice of using a 6" or 9" on one
and a 9" or 12" on the other heating element, depending on the size of the pan
• Warming Zone - Provides low heat capability for foods, making meal
coordination simple
• Self-Clean Heavy-Duty Oven Racks - Double coated porcelain-enameled racks
no longer require hand cleaning
• TrueTemp™System - Delivers even heat distribution and maximum oven control
• Eight-Pass Broil Element - Provides more even coverage of the food
• Double Oven Controls - Glass touch controls are easy to clean and provide
easy instruction
• Model PB970BMBB – Black on black (black glass door and black patterned cooktop)
• Model PB970TMWW - True white (white glass door and true white cooktop)
PB970KM/TM/BM
H
I
H
I
H
I
F
RONT
R
EAR
H
I
R
EAR
M
ED
W
ARMING
Z
ONE
H
I
F
RONT
S
TART
C
LEAR
O
FF
C
ook
T
ime
S
tart
D
elay
U
PPER
O
VEN
