GE QuickClean JBS15M Manual

†Note: Check local codes for required breaker size.
Effective January 1, 1996, the National Electrical Code requires
that new construction (not existing) utilize a 4-conductor
connection to an electric range.
Receptacle Locations: Locally approved flexible service cord
or conduit must be used because terminals are not accessible
after range installation. See shaded area in drawing for location
of electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
Note: 30" ranges conform to U.L. requirements for 0" spacing
from adjacent walls below countertops. To reduce possibility
of scorching walls, engineering recommends a minimum of
1-1/2" spacing to allow for possible extended, high-heat,
no-load heating element operation.
Installation information: Before installing, consult installation
instructions packed with product for current dimensional data.
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 5/07
KW Rating
240V 10.2
208V 7.7
Breaker Size
40 Amps†
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
26-1/4*
46-1/4
46-1/4
*Dimension from wall to front
of closed door handle is 28-3/4".
29-7/8
*Dimension from wall to front of closed door handle is 27-3/4".
CENTER LINE
2-1/4
7-1/2
7-1/2
7
5
2-1/4
3-1/2
REAR
WALL
26-1/4*
46-1/4
46-1/4
*Dimension from wall to front
of closed door handle is 28-3/4".
29-7/8
322037
JBS15M
GE®30" Free-Standing Electric Range

Features and Benefits
• Upfront Controls - Controls are placed within easy reach at the front center
of the cooktop
• Super-Large Oven Capacity - Provides an impressively large oven interior
for cooking more dishes and large meals at one time
• Coil Heating Elements - Provides consistent and even heat on the cooktop with
a plug-in element that is removable for easy cleaning
• ClearView™ Window - Features a convenient viewing area to check the progress
of food
• Dual Element Bake - Alternates the upper broiling element and the lower baking
element for even heating and optimal baking results
• Porcelain Oven Door - Offers a scratch-resistant porcelain coating for easy cleaning
• Chrome Drip Bowls - Contain minor spills and are removable for easy cleaning
• Six Rack Positions - Provides flexibility and allows consumers to make the most
of available oven capacity
• Interior Oven Light - Supplies light to make viewing the progress of cooking easy
and convenient
• Porcelain Upswept Cooktop - Features raised edges to help contain spills and make
clean-up easy
• Model JBS15MWW – White on white (white door and white cooktop)
• Model JBS15MCC – Bisque on bisque (bisque door and bisque cooktop)
• Model JBS15MBB – Black on black (black door and black cooktop)
JBS15M
Specification Created 5/07 322037
JBS15M
GE®30" Free-Standing Electric Range
