GE Monogram ZV925SL Manual

Specification Revised 5/08 130668
ZV925SL
GE Monogram®36" Glass Canopy Island Hood
2-3/4"
27 9/16"
35 7/8"
*Height
to
Ceiling
This vent hood may be vented to the outdoors or it can be
installed for recirculating operation. All necessary parts
for recirculating operation are supplied with the hood.
No kits required. Must use an 8" round duct.
A decorative duct cover is provided to cover the duct
from the top of the hood to a 7'11" to 9 ft. ceiling.
Accessories:
An optional stainless steel duct cover is available for 9'1"
to 10'1" ceiling heights. Order ZX92510 optional duct cover
at the same time as the vent hood and have on site
before installation.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information (in inches)
*The supplied duct cover fits
8 ft. to 9 ft. ceiling heights.
Order ZX92510 for 9'1" to
10'1" ft. ceiling heights.
Listed by
Underwriters
Laboratories
Dimensions and Clearances:
The vent hood should be installed 24" min. and 30" max.
above the cooking surface, dependent on the ceiling height.
The cooking surface should be at least 36" above the floor.
Installation will be easier if the vent hood is installed before
the range or cooktop/countertop is installed.
This hood can be installed over a Monogram electric or gas
cooktop. It cannot be installed over a Monogram professional
cooktop or range.
Installation Information: Before installing, consult
installation instructions packed with product or available
on monogram.com for current dimensional data.
Note: Installation height should be measured from the
cooking surface to the outer glass sides.
24" Min.
30" Max.
36" Min.
The exact installation height is determined by the ceiling height
and duct cover trim strips provided with the hood. For optimum
performance, the hood must be installed 24” min. and 30” max.
above the cooking surface.

Specification Revised 5/08 130668
ZV925SL
GE Monogram®36" Glass Canopy Island Hood
Features and Benefits
• Sleek, Understated Appearance - Combines
the durability of professional-grade stainless
steel with the elegant simplicity of bowed,
tempered glass
• Backlit Touch Controls and Digital Readout - Allow
you to easily select and view hood functions
• Powerful Ventilation - Offers three speeds plus a
570-cfm boost to capture cooking fumes
and odors
• Recirculating-Ready Design - Includes a reversible
duct cover and charcoal filter for non-vented
installations, eliminating the need for an
optional kit
• Halogen Lighting - Provides four levels of clean,
brilliant illumination to suit any cooking task
• Removable Stainless Steel Filter - Detaches easily
for safe cleaning in your dishwasher
• Model ZV925SLSS – Glass Canopy/Stainless steel
ZV900SJSS
