1Enter Special Features mode. See To Enter Special
Features section above.
2Remove all articles from the washer basket.
3Press the Extra Rinse button.
The My Settings and lights will go out. The Start
button light will blink. The corresponding Tank Levels
lights will show the current tank level.
4Press the Start button.
The tank will dispense for the minutes shown in the
display to empty the selected tank. The Tank Levels
lights will cycle 0,1,2,3,4,5,4,3,2,1,0 until the flush is
finished.
Once finished, the Tank Level will indicate an empty tank
(a single blinking red LED light) and the Start button will
be lit. You can (repeatedly) refill the tank with water and
press the Start button to rinse out the tank as needed.
NOTE: If you suspect that the dispenser is plugged, add
lemon juice to make the water slightly acidic.
5Press the Power button to exit (when the tank is
empty).
This function will automatically exit if neither button is
pressed for 2 hours.
NOTE: Bulk tank flush is recommended if you:
1) Change detergent or softener brands
2) Accidently add softener to the detergent tank or
vice versa
3) Put powdered detergent in the detergent tank
4) Put non-concentrated fabric softener in the
softener tank
10
About special features.
To Enter Special Features
To enter the bulk tank Special Features Mode:
1Press the Power button.
2Simultaneously press and hold either the
Detergent Tank On and Detergent Cup Amount buttons
for 3 seconds
or
Softener Tank On and Softener Cup Amount buttons for
3 seconds
The My Settings and Extra Rinse lights will flash to
indicate you are in the Special Features Mode.
OR
Option 1: Set Concentration Settings
NOTE: During initial installation, or if the household
water pressure dramatically changes, the bulk
dispenser will change to accommodate your homes’
unique water pressure. Wait a few wash cycles before
changing concentrations.
The factory default concentration settings are 1.5 oz
(44 ml) for detergent and 1.0 oz (30 ml) for softener.
To allow maximum user flexibility either of these can
be changed to between 0.5 and 10 ounces.
1Enter Special Features mode. See To Enter Special
Features section above.
2Press the My Settings button.
The My Settings and the chosen (Detergent or Softener)
3 Cup Amount lights will come on and the Extra Rinse
light will go out. The display will show “10
times in ounces”
the current concentration setting (e.g. 15 represents 1.5
ounces). This amount will be
dispensed when 2 (of the 3)
Cup Amount lights are lit.
3Turn the cycle knob clockwise to increase or
counter-clockwise to decrease the setting (within
preset limits). Each click increases or decreases Level
2 (standard amount) by 1/2 ounce. Levels 1 & 3
change proportionally.
4Press the Cup Amount button to save the new
setting.
This function will then exit and the display will reflect
whatever cycle the cycle knob is on.
To exit without changing the setting, press the Power
button. This function will automatically exit (without
saving) if neither button is pressed within 1 minute.
Option 2: SmartDispenseTM Tank Cleaning
The following table shows the approximate amount dispensed (oz) at each Cup Amount setting (1, 2 or 3) for each
Concentration Setting:
Concentration
Setting
510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
200 100 67 50 40 33 29 25 22 20 18 17 15 14 13 13 12 11 11 10
0.6 1.3 1.9 2.5 3.1 3.8 4.4 5.0 5.6 6.3 6.9 7.5 8.1 8.8 9.4 10.0 10.6 11.3 11.9 12.5
0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 8.5 9.0 9.5 10.0
0.4 0.8 1.1 1.5 1.9 2.3 2.6 3.0 3.4 3.8 4.1 4.5 4.9 5.3 5.6 6.0 6.4 6.8 7.1 7.5
Number of
Loads*
*For a 100 oz (2957 ml) bottle for normal ( ) setting.
