GE GTW485 Operating instructions

GEAppliances.com
Safety Instructions .......... 2,s
Operating Instructions
Care and Cleaning
of the Washer .................... 13
Features .......................... 12
Loading and Using
the Washer ...................... lZ
Operating instructions ......... 4-10
Installation Instructions. 14-18
Troubleshooting Tips..... 19-24
Consumer Support
Consumer Help Indicator ......... 10
Consumer Support ................ 26
Parts and Accessories ........... 3, 26
Warranty .......................... 25
GTW485*
GTW460
Printed in the United States
ENERGYSTAR
*As an ENERGY STAR ® partner,
GE has determinedthatthis
product meetstheENERGYSTAR®
guidelinesforenergyefficiency.
Write the model and serial
numbers here:
Model #
Serial #
You can find /-----D
them under
the lid of the
washer. 49-90549 06-15GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
m
Thisisthe safety alert symbol. Thissymbol alerts to potential hazards that can kill or hurt and others.All safety
you you you
messageswill follow the safety alert symbol and the word "DANGER","WARNING",or "CAUTION".Thesewords are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious inJury.
Indicates a hazardous situation which, if not avoided, could result in death or serious inJury.
_ Indicates hazardous situation which, if not avoided, could result in minor moderate
aor inJury.
IMPORTANT SAFETYINSTRUCTIONS
To reduce the risk of death, fire, explosion,electric shock,or injury to persons when usingyour appliance,
follow basic precautions, including the following:
[] Readall instructionsbeforeusingtheappliance.
[] DONOTwash or dry articles that have been previously cleaned in,washed in,soaked in or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode.
[] DONOTadd gasoline, dry-cleaning solvents, or other flammable or explosive substances to the wash water. These
substances give off vapors that could ignite or explode.
[] Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for 2 weeks
or more. HYDROGENGAS ISEXPLOSIVE.If the hot water system has not been used for such a period, before using a
washing machine, turn on all hot-water faucets and let the water flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is flammable, DO NOTsmoke or use an open flame during this time.
[] DONOTallow children to play on or in this appliance. Close supervision of children is necessary when this appliance is
used near children. Before the washer is removed from service or discarded, remove the door or lid. Failure to follow
these instructions may result in death or injury to persons.
[] DONOTreach into the appliance if the tub or agitator is moving to prevent accidental entanglement.
[] DONOTinstall or store this appliance where it will be exposed to the weather.
[] DONOTtamper with controls, repair or replace any part of this appliance or attempt any servicing unless specifically
recommended in the user maintenance instructions or in published user repair instructions that you understand and
have the skills to carry out.
[] DONOToperate this appliance if it isdamaged, malfunctioning, partially disassembled, or hasmissing or broken parts
including a damaged cord or plug.
[] Unplug the appliance or turn off the circuit breaker before servicing. Pressingthe Power button DOESNOTdisconnect power.
[] See "Electrical Requirements" located in the Installation Instructions for grounding instructions.
SAVETHESE INSTRUCTIONS

GEAppliances.com
PROPERINSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before it is used.
[] Ensurethat the hot water hose isconnected to the "H" []
valve and the cold water hoseisconnected to the "C"
valve.
[]
[]
Installor store where it will not be exposed to
temperatures below freezing or exposedto the weather,
which could cause permanent damage and invalidate the
warranty.
Properlyground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
)_ Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
DO NOT remove ground prong.
DO NOT use an adapter.
DO NOT use an extension cord.
Failure to follow these instructions can result in death
or electrical shock.
[] Ensurewasher is properly leveled and washer legs are
adjusted such that unit isstable.
Optional drain hoseextension recommended for
discharging heights from 60" - 96"
[] This washer does not include water supply hoses.
GEstrongly recommends the useof factory specified
parts.A list of factory hoses availablefor purchase are
listed.These hosesare manufactured and tested to meet
GEspecifications.
GEstrongly recommends the useof new water supply
hoses.Hosesdegrade over time and need to be replaced
every 5 years to reduce the risk of hosefailures and water
damage.
Parts and Accessories
Order on-line at GEApplianceparts.com today, 2/4hoursa
day or by phone at 800.626.2002during normal business
hours. InCanada, visityour localGEparts distributor or call
800.66!.1616.
Purt Number
PH!4X!O002
Or
PM!4X!O005
WH49X30!
Accessory
4ft rubberwatersupply hoses
4 ft braided water supply hoses
Drain hoseextension
PH7X! Washer FloorTray
4START-UPSEQUENCE
[] Any time the washer is being started or restarts after the
washer lid has been opened and closed,the washer will
turn on the cold water valve for two short periodsfollowed
by a !0 second pause before continuing.
[] If the lid isopened during this period,the washer will
pause.You will have to push the Start button again to
restart the cycle.
WHEN NOT IN USE
[] Turn off water faucets to minimize leakage ifa break or
rupture should occur.Checkthe condition ofthe fill hoses;
GErecommends changing the hoses every 5 years.
SAVE THESE INSTRUCTIONS

Operating instructions.
Throughout this manual, features and appearance may vary from your model.
Step 1Step 2 Step 3Step 4
, Add fabricsoftenerto the
fabricsoftener dispenser
(onsome models);see page 12.
, Add the manufacturer's
recommended amount of
detergent.GE recommends
the use ofHigh Efficiency
detergentssuch as @)n your
energy efficient washer. Place
detergent pods in the bottom
of the wash basket before
adding clothes.
. Loosely add items around
agitaton Overloading may
negatively impact wash
performance. See page 11
for suggested loading
examples.
. Close lid.
NOTE:Washer will not start
with lid open.
. Select wash cycle.
. Select wash options,
including Deep Rinse
option (on some
models) when using
fabric softener.
. Selectoptions.
,Press Stort.
Controls
Towels /Sheets
Bulky Items
Heavy Duty
_s_ i oa as inse in
+_or,_+_ Options Stain PreTreat
q
Dark Colors
Casuals
Cold Wash
e Wear
2n_
Ato mnse Dia
S_k ...... Extra Spin Tomato ...... Grass
2rid Rinse Off_ I
off + Extra Spin me
Load Size Temperature
All Cold Rinses Options Auto Soak
Large Cold
_ o ¢ooi
sin+ recis+ Fill
Colors
a_m
Normal
Heavy Light
Bulky Items

NO teS. GEAppliances.com

Operating instructions.
Start/Pause
PressStart to beginthe cycle.NOTE:The lid must be closed for the washer to start the cycle. Ifthe lid isclosed, the lid will lock and the Lid
Locked light will illuminate.
Pressing Pausewill unlock the lid (iflocked at that time), pause the cycle and the Pause indicator light will blink.
To continue the cycle,press Start again. If machine is paused more than 24 hours,the cycle will be cancelled. If water remains in the
machine, selectthe Drain &Spin cycle to drain basket and spinwater out of the washer basket.
Cycle Status Lights
Shows whether the washer is in the Fill, Soak, Wash, Rinse or Spin portion of the cycle.
Load Size (on some models)
Add _ detergent to the bottom of the basketandfabric softenerto the dispenser(onsomemodels)prior to loadingclothes.
Loosely load items in the washer basket. Overloading may negatively impact wash performance. Adjust the load size accordingly.
Load Size
Large
Med_er
Makethe load selection: Sma.______j_/rec_ser_,_/_,_"_'_
PreciseFill (onsomemodels)
- Forconvenience,best performanceand optimal efficiency,selectPreciseFill for modelssoequipped.Thisselectionautomatically providesthe
correct amountof water suitedto the sizeand typeof load placed inthe unit. Lidwitt belockedfor the duration of the load sensingprocess,
which includesaseriesof short spinsand aportion of the water fill.
-Ifyou prefer to manually selectthe water level,selectSmallthrough Super.WhilePreciseFill isbestfor most loadsand generalwashing,you
may want to manuallyselectthe load sizefor specialty itemssuchas bulky,lightweight comforters or pillows,whereyou want to ensurea larger
water levelisapplied.Manual loadsizeselectionsshouldbe madefor wet items placedin the washer,suchas soakedtowelsor garments.
- The washer will not fill with water when PreciseFill is selected if the lid is opened. When the lid is closed the machine is able to
begin filling with water in order to sense the load size.
NOTE:Thisisa high-efficiencywashing machine.Thissystem requireslesswaterwhile providingeffective cleaningaction.Youmay notice that the
water levelislower than onyour previouswasher.Thisisnormal.

GEAppliances.com
Wash Cycles-Cycle Selector Knob
Thewash cycle controls the type of washing process. The cycle selector knob can be turned ineither direction. Turning the knob after
starting acycle will stop the washer and change the cycle/options to the new selection. PressStart to begin the new cycle selection.
The chart below will help you match the items to be washed with the best wash cycle settings. For optimal performance, select the
cycle that most closely matches the items being washed.
Selections and options shown in bold are default settings for that cycle.
Some cycles and options may not be available on some models.
items to Wash Cycle Soil Level Spin Selection Cycle Details
Colors Max/Extra
Heavily to
lightly soiled
colorfast cottons,
household linens,
work and play
clothes.
Dark colored
cottons, linens,
and mixed loads.
Casual clothes,
lightly soiled
office wear.
Lingerie and
special care
fabrics with light
to normal soil.
Medium to lightly
soiled athletic
wear items.
Medium to dark
colored cottons,
linens, and mixed
loads.
Wash Temp
Hot
Warm
Colors
Cool
Ex.Heavy
Heavy
Normal
Light
Cold Ex.Light
Tap Cold
Normal
Options Available
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Dark Hot
Colors Warm
Colors
Cool
Cold
Tap Cold
Casuals Hot
Warm
Colors
Cool
Cold
Tap Cold
Delicates Hot
Warm
Colors
Cool
Cold
Tap Cold
Active Hot
Wear Worm
Colors
Cool
Cold
Tap Cold
Cold Hot
Wash Warm
Colors
Cool
Cold
Top Cold
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Max/Extra
Normal
Max/Extra
Normal
Max/Extra
Normal
Hax/Extra
Normal
Hax/Extra
Normal
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
This isthe normal cycle which is
recommended for normally soiled
cotton and linen items. Choose
the Heavy or Extra Heavy soil
level selection and Warm or Hot
water temperature selection as
appropriate for your clothes load
for a higher degree of cleaning.
Incorporates multi-stage fills and
wash periods to provide optimal
fabric care. For models on which
there isno temperature selection on
the control panel, this cycle provides
a Warm wash temperature only.
Lower wash temperatures, a shorter
wash period, and a deep fill rinse
(on some models) minimizes fading
and spotting of dark colored cotton
fabrics. Incorporates multi-stage
fills and wash periods to provide
optimal fabric care. For models
on which there is no temperature
selection on the control panel
this cycle provides a Cold wash
temperature only.
Wash period tailored to care for
casual clothes and office wear items.
Incorporates multi-stage fillsand
wash periods to provide optimal fabric
care.
Utilizesa unique "tri-pulse" extra
gentle agitate profile to provide
special care to delicate fabrics. It is
recommended to place small or ultra
delicate items in mesh bags before
washing. Formodels on which there
isno temperature selection onthe
control panel,this cycle provides a
Coot wash temperature only.
Cycledesigned for care of medium
to lightlysoiledactive wear,aththletic
wear,and technical fabrics.
Incorporates a multi stage wash
period with soak to effectively treat
body soils and odors. Use the Heavy
Dutycyclefor heavily soiled sports
clothing constructed of sturdy fabric.
Cyclecombines multiple extended
wash agitation periods with soak
periods to provide enhanced cleaning
performance and energy efficiency
with colderwater temperatures.

Operating instructions.
Wash Cycles-Cycle Selector Knob -Continued
Items to Wash Soil Level Spin Selection Options Available Cycle Details
Max/ExtraSmall loads of
lightly soiled items
that are needed in
a hurry.
Wet load of items.
For items that need
only to be rinsed,
usethis cycle with
Deep Rinseoption.
Jeanswith
medium to light
soil.For heavily
soiledwork jeans,
usethe Heavy
Duty Cycle.
Sturdy fabrics with
heavyto medium
soil.
Largecoats, bed
spreads,mattress
covers,sleeping
bags,and similar
large bulky items.
Towels.
Sheets.
Heavy to medium
soiledwhites,
household linens,
work and play
clothes.
Cycle
Speed
Wash
Drain &
Spin
Jeans
Heaw
Duty
Bulky
Items
Towels/
Sheets
Whites
Wash Temp
Hot
Warm
Colors
Cool
Cold
Tap Cold
Hot
Warm
Colors
Cool
Cold
TapCold
Hot
Warm
Colors
Cool
Cold
TapCold
Hot
Warm
Colors
Cool
Cold
TapCold
Hot
Warm
Colors
Cool
Cold
TapCold
Hot
Warm
Colors
Cool
Cold
TapCold
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Ex.Heavy
Heavy
Normal
Light
Ex.Light
Normal
Max/Extra
Normal
Max/Extra
Normal
Max/Extra
Normal
Max/Extra
Normal
Max/Extra
Normal
Max/Extra
Normal
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Deep Rinse
2nd Rinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2ndRinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2ndRinse
Stain PreTreat Guide
Deep Fill
Auto Soak
Deep Rinse
2nd Rinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2ndRinse
Stain PreTreatGuide
Deep Fill
Auto Soak
Deep Rinse
2ndRinse
Utilizesan expedited wash period and
time saving continuous spray rinse to
clean small lightlysoiled loads in the
fastest time possible.
Utilizesa high speed spinto extract
water from wet items. Foritems that
needto be rinsed,select the Deep
Rinseand/or 2nd Rinseoption when
using this cycle.
Combines higher water levels, a
specially designed agitation profile,
and multi step wash andsoak periods
to care for jeans with medium to
light soil. Use the Heavy Duty cycle
for heavily soiled workjeans.
Incorporates multi-step wash and
soak periods combined with extended
wash periods to effectively clean
heavilyto medium soiled sturdy
fabrics.
ProvidesaDeep Fill/max fillwash
water level to wash bulky items.
Alsoincorporates a Deep Fillrinse to
effectively rinsebulkyitems.
Cycledesigned washing towels or
sheets, using a higher water level
and a soakperiod to effectively
clean these items. Itis recommended
that towels and sheets bewashed
separately for best care and
washing performance.
Combines the hottest water
temperature available (based on
water heater setting)with longer wash
periodsto clean andbrighten whites. It
isrecommended that a Oxior chlorine
bleach product appropriate for items
being washed be usedwith this cycle
to maximize whitening performance.
For models on which there is no
temperature selection on the control
panel,this cycle provides a Hot wash
temperature only.

GEAppliances.com
Settings
Select settings for agitation (Soil) and water temperature (Temp).
NOTE:Longer Spin times typically reduce dryer time/energy usage (i.e.reduces total energy when using both a washer and a dryer).
Cycle Options
Stain PreTreat (on some models)
The Stain PreTreat feature allows you to indicate what stains are on the garments in your load. This feature incorporates a patent
pending treatment method. An initial water fill is performed at a temperature tailored to the stain type selected and to an amount
which enables a concentrated cleaning step. A stain scrubbing period, followed by an active soak, isconducted to effectively treat
the stain. Then additional water is added to the selected temperature and the wash phase is conducted for the cycle selected.
This feature can be applied to most wash cycles as described in the cycle guide.
To use Stain PreTreat: Stain PreTreat
1. Select the desired wash cycle. D_t
2. Select the stain to be treated under the Stain PreTreat options. Tomato Grass
Off Wine
Stain PreTreat Guide
Category
Tomato
Dirt
Grass
Wine
Recommended
Temperatures
Treatment/Wash
Cool/Warm
Cool/Warm
Cold/Warm
Cool/Warm
Stain
Sauce
Catsup
Salsa
Dirt
Clay
Mud
Grass
Lipstick
Chocolate
Gravy
Mayonnaise
BBQSauce
Wine
Soda
KooI-Aid
Tea
Coffee
Juice
Beer
For best results,
before placing in
washer:
Pretreat with liquid
detergent or stain
remover product; rinse
with cool water.
Allow dirt to dry;
remove loose dirt
using a brush. Rinse
with cool water.
Pretreat with liquid
detergent or stain
remover product.
Brush lightly; rinse
with cold water.
Pretreat with mixture
of Oxi product and
cool water. Add Oxi
product along with
detergent in the
washer.
• Recommended temperatures are optimal for stain removal performance; adjust temperature selection to suit load being washed.
• Ensure stain iscompletely removed after wash cycle and before placing in dryer; very tough stains may require a second treatment.

Operating instructions.
Cycle Options -Continued
Deep Fill
Selectthe Deep Fill feature for loads where extra water is needed.
Pressthe Deep Fill button once before starting the cycle to add an incremental amount of water to the wash load. Holding the Deep Fill
button for 5 seconds will provide the deepest fill levelpossible;this will increase cycle time due to the additional time it takes to fill the
washer
Tocancel the option if desired,pressthe Deep Fill button again.
NOTE:TheDeep Fill button can also be pressedafter the washer has completed filling and is in thewash phase if additional water is
desired.Tostop the extra fill, pressthe Deep Fill button again and the water will stop.
Auto Soak
This option beginswith a brief agitation, soaks for a specified period of time, then movesthrough the rest of the cycle automatically.
2nd Rinse
When you useextra detergent or bleach to clean heavily soiled clothes,use the 2rid Rinseoption to better remove additional residues.
Extra Spin
Select to provide additional spin time, increasing energy efficiency through reducing drying times.
2nd Rinse +Extra Spin
Providesboth asecond rinseand an extra spin.
Deep Rinse
Setthis option to provide a deep rinse or when using fabric softener. Thisoption may change other settings (e.g.Spin may go to a higher
setting)to maximize performance.
NOTE:Do not usefabric softener dispensing balls with this washer. Theydo not work correctly in high efficiency washers.
Consumer Help Indicator
Your washer isequipped with Consumer Help Indicator (CH!).CHIis our way to communicate a simple remedy for some situations
that you can perform without the need to call for service. The chart below describes the helpful lights you may notice flashing when
you return to the washer.
Spin LED After the wash cycle, the clothing wasn't evenly distributed enough to spin out the water. Redistribute the
clothes more evenly in the washer and then run a Drain & Spin cycle.
Rinse LED(Water Resume cycle or enter Drain & Spin. Ifwater pumps out, then the clog has likely cleared. If water remains in
took too long to the washer, check for clogged or pinched drain hose. This situation could be more likely to appear, over time, if
Pump Out) the external drain hose has been extended or restricted.
Fill LED(Water not
entering washer)
Two LEDlights
flashing
Check your house water supply. Did you forget to turn on one or both supply valves after installation or
coming back from vacation? As soon asthe message starts to scroll, the washer will initiate a5 minute lock-
out period. The washer controls won't respond/change during this time. After the 5 minutes, you can begin
your cycle again. Ifyou try to bypass the lock-out period by unplugging the washer, the 5 minute timer will
start over again.
Ifyour machine has stopped itself before the cycle completed. The two furthest right LEDlights will flash. This
indicates that an error has occurred. Tryto run a Drain & Spin cycle to see if it will clear. If it does not clear, call
800.GE.CARES(800.432.2737) for service.
10

and using the washer. GEAppliances.comLoading
Always follow fabric manufacturer's care label when laundering.
ProperUseof Detergent
Using too little or too much detergent is a common
cause of laundry problems.
Uselessdetergent ifyou have soft water, (] smaller
loud or u lightly soiledload.
Forspots,apply pre-treotment to itemsus
recommendedon the product label.Application should
be made inthe basketto preventoverspruywhich may
causethe coloringon the lid or graphics to fade.
Placedetergent pods in the bottom of the wash basket
before adding clothes.
GErecommends_,,,,,the useof High Efficiencydetergents
such us _ in your energy efficient washer.
HEdetergen'ts_"are formulated to work with low
water wash and rinsesystems.HEdetergents reduce
the oversudsing problems commonly associated with
regular detergents.
When using high efficiencyor concentrated
detergents, consult the product label to determine
amount required for optimum performance. Excessive
detergent will negatively impact wash performance.
SortingWashLoads
Sort by color (whites,lights,colors),soillevel,fabric type (sturdy cottons, easy care, delicates)and whether the
fabric produces lint (terry cloth,chenille)or collects lint (velveteen,corduroy).Wash lint producers such as cotton
towels and socks separate from lint collectors including synthetic garments and dress pants.
- Fire Hazard
Never place items in the washer that ore dampened with gasoline or other fl(lmmable liquids.
Nowasher con completely remove oil.
Do not dry anything that has ever hod any type of oil on it (including cooking oils).
Doing soso con resultin death, explosion,or fire.
LoadingtheWasher
Load dry items loosely in the washer basket. Forbest
results,loud items evenly and loosely around the
outside of the basket,filling in towards the center on
larger loads.To add items after washer hasstarted,
pressStart/Pause ifthe lid islocked;wait untilthe Lid
Lock indicator on the display is no longer illuminated
before attempting to open the lid.Liftthe lid and
submerge additional items around the outside of
the basket.Closethe lidand pressStart to resume.
Adjust load sizeselection and/or use DeepFill option if
necessary.
[] Donot place large items such assheets, blankets
and towels acrossthe Infusor (onsome models).
Loud them around the outside of the basket.
[] Donot put lawn or sofa cushions into the washer as
they are too big to move. Removeouter covers and
ONLYwash them.
Average Small Load Average Hedium Load Average Large Load
ClothesLevel
Water
ClothesLevel
WaterLevel
ClothesLevel
WaterLevel
11

About washer features.
Automatic Load Sensing (on some models)
This determines the correct agitate profile, agitate duration and amount of water suited to the size and type of load placed inthe washer.
The washer will not start the wash cycle or fill with water if the lid is open. When the lid is closed the machine isable to begin filling with
water in order to sense the load size.
NOTE:Automatic Load Sensing initiates a spin at the beginning of the cycle and will take as much as 3 minutes to complete (significantly
shorter for smaller loads); this is normal operation.
NOTE:Thisis a high efficiency washing machine with agitator wash action. Thissystem requires/ess water while providing effective cleaning
action. Youmay notice that the water level is lower than on your previous washer. This is normal for an agitator-equipped washer.
Liquid Fabric Softener Dispenser (on some models)
Theagitator cap fits into the top of the agitator. If it accidentally comes
off, simply put it back on.
Thefabric softener dispenser automatically releases liquidfabric
softener at the proper time during the cycle.
Do not stop the washer or raise the lid during the first spin. This will
cause the dispenser to empty too soon.
To use,follow these steps:
D Makesure dispenser securely agitator.
is attached to
r21 use only liquid Pour into dispenser,using
diluted fabric softener.
amount recommended on package.
Never pour fabric softener directly on clothes. It may stain them.
F_l Add water to dispenser until it reaches the maximum fill line.
Do not pour anything into the agitator
if the (]gitator cop or dispenser is
removed.
ONLYthis
portion of the
dispenser is
visible once
installed into
agitator
F_ Select Deep Rinseoption.
Options
2rid
Rinse
Soak
2nd Rinse
I-Extra Spin
Deep Rinse
Note: Fabric softener may not dispense properly if the Deep Rinse
option is not selected.
Liquid Bleach
Liquid chlorine bleach should be added through the bleach
dispenser in the front left corner. Follow bleach manufacturer's
recommendations for the correct amount of liquid chlorine bleach
based on load size,taking care to not apply or spill it directly on
clothing.
NOTE:Do not use liquid chlorine bleach and laundry pretreatments
such as an Oxi product inthe same wash load.
0 0-
Pretreatment
Place laundry pretreatments, such as an Oxi product, directly in the
bottom of the wash basket before loading clothes.
NOTE:Do not use liquid chlorine bleach and laundry pretreatments
such as an Oxi product inthe same wash load.
12

Care GEAppliances.comand cleaning of the washer.
Exterior of the Washer
immediately wipe off any spills with a damp cloth.
Interior of the Washer
Leave the lid open after washing to allow
moisture to evaporate, if you want to clean the
basket, use a clean soft cloth dampened with
liquid detergent; then rinse. (Do not use harsh or
gritty cleaners.)
!
I
Separate for cleaning
Cleaning the Fabric Softener Dispenser (on some modelsl
r_ Remove the dispenser from the top of the agitator.
D Separate the from the the and down the inside of
dispenser by
cup cover grasping top pushing on
the cup with your fingers. Dispensercup will pop free from the cover.
D To clean the dispenser,soak both the dispensercup and the dispensercover in the following
solution:
[] 1 USgallon (5.8liters)warm water
[] 1/4 cup (60ml)heavy-duty liquid detergent
[] 1cup (240 ml)bleach
r_]if necessary, buildup a clean, soaking, not use a brush;you may
loosen with soft cloth after Do stiff
roughen the surface of the dispenser.
r51 Rinseand reassemble Place back the
dispenser. dispenser on agitator.
Water Supply Hoses
Hoses connecting washer to faucet should be
replaced every 5years.
Moving and Storage
Ask the service technician to remove water from
drain pump and hoses. Do not store the washer
where it will be exposed to the weather.
Long Vacations
Be sure water supply is shut off at faucets. Drain
all water from hoses and water filter pump area if
weather will be below freezing.
13

Insta atio
Istructi Wher
If you have any questions, call 800.GE.CARES (800.432.2737)
or visit our Website at: GEAppliances.com
In Canada, call 1.800.561.3344 or visit www.GEAppliances.ca
AThis is the safety alert symbol. This symbol alerts you to potential hazards that can kill you or hurt you and others.
All safety messages will follow the safety alert symbol and the word "DANGER","WARNING", or "CAUTION".These
words are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
.IMPORTANT -Savetheseinstructions
for local inspector's use.
. IMPORTANT - ObserveaI,governing
codes and ordinances.
. Note to Installer - Be sure to leave these
instructions with the Consumer.
. Note to Consumer - Keepthese instructions
for future reference.
. Skill level - Installation of this appliance requires
basic mechanical and electrical skills.
. Completion time - 1-3 hours
. Proper installation isthe responsibility of the installer.
. Product failure due to improper installation is not
covered under the Warranty.
PARTS SUPPLIED
[] Drain Hose
[] Cable Tie
[]
[]
U
Owner's Reference Guide
Drain Hose Clip
[] Clamp 14
TOOLS REQUIRED FOR
WASHER INSTALLATION
[] Pliers
PARTS REQUIRED (Sold separately}
[] Water Hoses(2) o [] Rubber Washers (2)
and Strainer Screens (2)
[] DrainHoseExtension(Fordischargeheightsfrom 60"- 96"
GEParts and Accessories
Orderon-line at GEApplianceparts.com today,24 hours a day
or by phone at 800.626.2002during normal business hours.
Part Number Accessory
4 ft RubberWater SupplyHoses
PMI4XIO002
Or
PMI4XIO005
WH1X2267
WH49X301
4ft Braided Metal Water SupplyHoses
Rubber Washer (1)and Screen (1)
Drain Hose Extension (Fordischarge
heights from 60" - 96"
NOTE:We strongly recommend the use of new water
supply hoses. Hosesdegrade over time and need to be
replaced every 5 years to reduce the risk of hose failures
and water damage.

Installation Instructions
LOCATION OF YOUR WASHER
Do Not Install the Washer:
1.In an area exposed to dripping water or outside
weather conditions. The ambient temperature
should never be below 60°F (!5.6°C) for proper
washer operation.
2.In an area where it will come in contact with curtains or
drapes.
S.On carpet. The floor MUST be a hard surface with
a maximum slope of 1/2" per foot (1.27cm per
30 cm).To make sure the washer does not vibrate
or move, you may have to reinforce the floor.
NOTE:If floor is in poor condition, use 3/4" impregnated
plywood sheet solidly attached to existing floor covering.
IMPORTANT: Minimum Installation Clearances
- Alcove or Closet
. Ifyour washer is approved for installation in an alcove
or closet, there will be a label on the back of the
machine describing requirements.
. Hinimum clearance between washer and adjacent
walls or other surfaces: 0" either side, 2"front, 3"
rear.Vertical space from floor to overhead shelving,
cabinets, ceiling, etc. = 60".
. Closet doors must be Iouvered or otherwise ventilated
and require 60 square inches of opening near the top
of the door and 60 square inches near the bottom of
the door. If a dryer is located in the same closet, then
these areas must be doubled.
NOTE:The clearances stated on this label are minimums.
Consideration must be given to providing adequate
clearances for installing and servicing.
WATER SUPPLY REQUIREMENTS
WATERPRESSURE- Must be 20 psiminimum to 120 psimaximum.
WATERTEHPERATURE- Householdwater heater should besetto deliverwater at 120°to !50°F (50°to 66°@TOTHEWASHERwhen
hotwash isselected.
SHUTOFFVALVES- Bothhot and cold shutoff valves (faucets)should be supplied.
DRAIN- Water should be drained into standpipe. Dischargeheight HUSTNOTBELESSTHAN30 INCHES,and no more than 8 feet
above the baseofthe washer.Standpipe must be 1-1/2 inches minimum insidediameter and must be open to atmosphere.
[!] UNPACKING THE WASHER
After the machine isinthe home, remove outside packing
material/carton from washer.
Removebag (containing clamp, cabletie and drain hoseclip),
drain hoseand Owner's ReferenceGuidefrom tub.
NOTE:Leavefoam shipping material insidetub opening to
hold tub in placeduring the rest of installation.
_._ _ Bag
Owner's Reference Guide
Leave foam shipping
material inside tub
F2]REMOVE THE BASE
Removebase from unit by placing foot on sideof base and
tipping unit back on corner post. Removebaseand bring the
washer back upright.
5

Installation Instructions
_] CONNECT DRAIN HOSE TO WASHER
Connect drain hose to drain port on back of washer. Open
clamp with pliers and slideonto hoseend. Holdingclamp open,
pushhoseend onto drain port until fully seated. Releaseclamp
between locating ribs on hose end. Outlet of hoseend should
be orientedvertically. Drain
[_] CONNECT WATER HOSES TO WASHER
Disconnect electrical cord before installing water hoses.If not
installed, install rubber washer in one end of hot water hose.
Thread hotwater hoseonto connection labeled Hat top rear of
washer.Handtighten and usepliers to tighten hoses between
1/8 and 1/4 turn beyond hand-tight.
If not installed, install rubber washer in one end of cold water
hoseC.Threadcoldwater hoseontoconnection labeledCattop
rear of washer.Hand tighten and use pliers to tighten hoses
between 1/8 and 1/4 turn beyond hand-tight.
Move washer as close to final location as possible, leaving
room for you to make water, drain, and electrical connections
to your home.
_] CONNECT WATER HOSES TO OUTLET
VALVES
Determine which is HOTwater line before attaching water
hoses to faucets. Traditionally, HOTfaucet ison left.
(If screen washers are not installed) With protruding part of
screen toward you, install strainer screen/rubber washer
into each of the free ends of two water hoses.
Connect hot water hose to hot water
outlet valve of your home. Hand
tighten and use pliers to tighten hoses
between 1/4 and 1/2 turn beyond
hand-tight. Open hot water valve.
Connect cold water hose to cold
water outlet valve of your home. Hand
tighten and use pliers to tighten hoses
between 1/4 and 1/2 turn beyond
hand-tight. Open cold water valve.
Check for leaks and drips at the hose
couplings. Tighten as necessary.
Rubber
washer --
\Rubber
washer
16

Installation Instructions
[] CONNECT TO DRAIN
Install drain hose clip on rear
panel of washer. Route drain
hose through clip and insert
free end into drain opening
of your home.
NOTE:If longer drain
hose is required, order
drain hose extension
kit, GEpart number
WH49×301. Connect
additional drain hose
(contained in kit)to
original hosewith hose
clamp (contained in kit).
Drain/
hose
NOTE:Install hose
guide on hose end
if equipped.
_rain_
clip__ )Washer
back
If water valves and drain are built into wall, fasten drain
hose to one of the water hoses with cable tie provided.
Drain Wall Cable
hose tie
\
Drain
hose
Washer
back
NOTE:Placingthe drain hose too far down the drain pipe can
cause a siphoning action. Nomore than 5"of hose should be
in the drain pipe.There must be an air gap around the drain
hose. A snug fit can also cause a siphoning action.
CONNECT TO DRAIN (Continued}
If your drain is a standpipe, fasten drain hose to
standpipe with cable tie provided.
Drain
hose hose clip
Washer
back
Standpipe
NOTE:Placingthe drain hosetoo far down the drain pipe can
cause a siphoning action. No more than 5" of hoseshould be
in the drain pipe.There must be an air gap around the drain
hose. A snug fit can also cause a siphoning action.
If drain discharge height does not meet 30" minimum
height requirement, end of drain hose must be secured
in drain opening of home by installer and have an air gap
around hose to prevent siphoning.
hose
clip
Washer
back
Drain --
hose
NOTE:Placingthe drain hose too far down the drain pipecan
cause a siphoning action. No more than 5" of hoseshould be
in the drain pipe.There must be an air gap around the drain
hose. A snug fit can also cause a siphoning action.
17

Installation Instructions
ELECTRICAL REQUIREMENTS
- Fire Hazard
Plug into a grounded 3-prong outlet.
DO NOT remove ground prong.
DO NOT use an adapter.
DO NOT use an extension cord.
Failure to follow these instructions can result in death,
fire or electrical shock.
CIRCUIT- Individual, properly polarized and grounded 25
or 20 amp circuit breaker or time-delay fuse.
POWERSUPPLY- 2 wire plus ground, 120 Volt, single
phase, 60 Hz,alternating current.
Outlet Receptacle - Properly grounded 3-prong
receptacle to be located so the power
cord isaccessible when the washer
is in an installed position. If a 2-prong
receptacle is present, it is the owner's
responsibility to have a licensed
electrician replace it with a properly
grounded 3-prong grounding type
receptacle.
Washer must be electrically grounded in accordance with
local codes and ordinances, or in the absence of local
codes, in accordance with the NATIONALELECTRICAL
CODE,ANSI/NFPANO.70 latest edition. Check with a
licensed electrician ifyou are not sure that the washer is
properly grounded.
[] CONNECT POWER AND INSTALL
Make sure large dial control (on some models) on washer is
pushed in to the OFFposition.
Insert plug of electrical cord into a 115V,15- or 20-amp wall
receptacle.Movewasher intofinal position.Placelevelon flat top
sideedge and sideof washer.Adjust all four levelinglegs until
washer islevel left-to-right and front-to-back. Removelevel.
Opentublid.Removeanddiscardtubshippingmaterial(seeStep1).
Remove plastic protector sheet from control panel face.
Level
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of
malfunction or breakdown, grounding will reduce the risk
of electric shock by providing a path of least resistance
for electric current. This appliance is equipped with
a cord having an equipment- grounding conductor
and a grounding plug. The plug must be plugged
into an appropriate outlet that isproperly installed
and grounded in accordance with all local codes and
ordinances.
Improper connection of the equipment-
grounding conductor can result in a risk
of electrical shock. Checkwith a qualified electrician, or
service representative or personnel,ifyou are in doubt asto
whether the appliance isproperly grounded. DO NOT
modifythe plug on the power supply cord. If it will not fit the
outlet, havea properoutlet installed bya qualified
electrician.
If required by local codes, an external 18 gauge or larger
copper ground wire (not provided) may be added. Attach
to washer cabinet with a #10-16 x 1/2" sheet metal screw
(available at any hardware store) to rear of washer as
illustrated.
Attach ground
wire and ground
screw (obtain
locally)
IIIIIII
Washer
back
Mobile Home Installation:
Installation must conform to Standard for Mobile Homes,
ANSIAl19.1 and National Mobile Home Construction and
Safety Standards Act of 1974 (PL93-383).
FINAL CHECKLIST
Before starting the washer, check to make sure:
[] Main power isturned on.
[] Thewasher is plugged in.
[] Thewater faucets are turned on.
[] Theunit isleveland all four levelinglegsare firmly
on the floor.
[] Theshipping foam and cardboard are removed.
[] Thedrain hose isproperly tied up.
[] Thereare no leaks at the faucet, drain line
or washer.
Run the washer through a complete cycle.
[] Check for water leaks and proper operation.
[] Placethese instructions in a location near the
washer for future reference.
18

Before you call for service...Troubleshooting Tips
Save time and money! Review the charts on the following pages, or visit GEAppliances.com. You may not need to call for service.
WATER Possible Causes What To Do
Small amount of water Normal dispenser It isnormal for a small amount of water to remain in dispenserafter the
remaining in dispenser operation cycle.
(onsome models) at
end ofcycle
Short spray and delay Lidwas openedand closed This is normal. SeeSTART-UPSEOUENCEin the Safety Instructions
after pushing the Start between cycle selection section.
button and start
Water level seems low This is normal Water may not cover the top level of the clothes. This is normal for this
high efficiency washer.
Low water flow Water valve screens are Turn off the water source and remove the water connection hoses from
stopped up the upper back of the washer and the water faucets. Clean both the
hose screens (ifso equipped) and the screens in the machine using a
brush or a toothpick. Reconnect the hoses and turn the water back on.
Check to ensure there are no leaks at the connections.
Wutersiphoning out Drain standpipe is too The drain hose must exceed 32" height at some point between
of washer low or hose too far into the washer back and the drain pipe. Use anti-siphon clip. See the
standpipe Installation Instructions.
Too many suds Soft water Try less detergent.
Too much detergent Measure your detergent carefully. Use less soup ifyou have soft water, a
smaller loud or a lightly soiled loud.
Type of detergent Switchto HighEfficiencydetergent such as_[.
Water leaks Type of detergent Switchto HighEfficiencydetergent such as_.
Using too much detergent Use lessdetergent. Uselesssoap ifyou havesoft water, a smaller load
in washer or a lightly soiledload.
Fillhoses or drain hose is Make sure hoseconnections are tight at faucets and rubber washers
improperly connected are installed.Makesure end of drain hose iscorrectly inserted in and
secured to drain facility.
Household drain clogged Checkhousehold plumbing. You may need to call a plumber.
Drain hose rubs on wall Make sure drain hosedoes not make contact with the wall. May cause
excessivewear on the hose.
Constant water pressure to Tighten hoses at the faucets.
fill hoses at water source Checkcondition of the fill hoses:they should be replaced every 5 years.
Water temperature Cooler water temperatures New laundry detergents have been formulated to work with cooler
seems incorrect provide improved energy water temperatures without affecting wash performance.
efficiency
Water supply is turned off Turn both hot and cold faucets fully on and make sure hoses are
or improperly connected connectedto correctfaucets.NOTE:Water valvesare marked "H" and "C".
Water valve screens are Turnoff the water source and remove the water connection hosesfrom
stopped up the upper back of the washer and the water faucets. Clean both the
hose screens(ifso equipped)and the screensin the machine usinga
brush or a toothpick. Reconnectthe hoses and turn the water back on.
Checkto ensurethere are no leaksat the connections.
Cool/Cold Water when Thisisnormal. The washer senseswater temperature (onsome models)
selecting Hot and optimizes for best results.Coldwater isadded periodically when hot
isselected.
Housewater heater isnot
set properly Make sure house water heater is delivering water at 120°F-140°F
(48°C-60°0.
19

Before you call for service...Troubleshooting Tips
Save time and money! Review the charts on the following pages, or visit GEAppliances.com. You may not need to call for service.
WATER Possible Causes What To Do
Water pumped out Lidlifted or cycle was put Reset cycle.
before cycle is complete in pause for over 24 hours
Water won't drain Drain hose is kinked or Straighten drain hose and make sure washer is not sitting on it.
improperly connected Top of drain outlet should be less than 6 ft (1.8 m) above floor.
Washer spins and pauses This is normal The washer is sensing the load.
at the beginning of cydes
Washer pauses during The Soak Option was
wash cycle chosen
This is normal
This isnormal. Thewasher alternates between agitate and soak during
these cyclesto get your clothes cleaner with lesswear.
Many cycles incorporate asseriesof soakswithin the agitation period to
getyour clothes clean with lesswear.
20
