GEAppliances PXR03 Safety guide

GEAppliances.ca
Wine Chiller
Part No. 350A4502P761 09/14 ATS
Safety Instructions............2, 3
Installation Instructions........4
Operating Instructions
Control Settings ...................5, 6
Care and Cleaning ............7, 8
Troubleshooting Tips ....... 9, 10
Consumer Support
Product Registration................11
Warranty ..........................13
Consumer Support .................14
Write the model and serial
numbers here:
Model # _____________________
Serial # ______________________
Find these numbers on the Rating
Plate located either inside the or
outside on the rear wall of the
Wine Chiller.
Owner’s Manual
and Installation
PXR03
Bottom
Hinge
Hinge Cover
Plug Buttons
or screws Top
Hinge
Plug Button
1
2
3
C
WHITE
SET
RED
RED WHITE
MAX
MED
MIN
0
5
4
3
2
1
0
7
6
TEMPERATURE
CONTROL
7 IS COLDEST 15W MAX

USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, we strongly recommend against
the use of an extension cord.
However, if you must use an extension cord, it is absolutely necessary that it be CSA certified, 3-wire
grounding type appliance extension cord having a grounding type plug and outlet and that the electrical
rating of the cord be 15 amperes (minimum) and 120 volts.
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use this appliance only for its intended purpose as described in this Owner’s Manual.
SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should be followed, including
the following:
This wine chiller must be properly installed and
located in accordance with these instructions
before it is used.
Do not allow children to climb, stand or hang
on the shelves in the wine chiller. They could
damage the wine chiller and seriously injure
themselves.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
Keep fingers out of the “pinch point” areas;
clearances between the doors and between
the doors and cabinet are necessarily small.
Be careful closing doors when children are
in the area.
Unplug the wine chiller before cleaning and
making repairs.
NOTE: We strongly recommend that any
servicing be performed by a qualified individual.
Do not store or install this appliance outdoors.
PROPER DISPOSAL OF THE WINE CHILLER
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigeration products are still dangerous…
even if they will sit for “just a few days.”
If you are getting rid of your old appliance, please
follow the instructions below to help prevent
accidents.
Before You Throw Away Your Old
Refrigeration Product:
Take off the doors.
Leave the shelves in place so that children
may not easily climb inside.
CFC Disposal
Your old refrigerator has a cooling system that
used CFCs (chlorofluorocarbons). CFCs are believed
to harm stratospheric ozone.
If you are throwing away your old refrigerator,
make sure the CFC refrigerant is removed for
proper disposal by a qualified servicer. If you
intentionally release this CFC refrigerant, you
can be subject to fines and imprisonment under
provisions of environmental legislation.
DANGER! RISK OF CHILD ENTRAPMENT
Consumer Support Troubleshooting Tips Operating
Instructions Safety Instructions
Installation
Instructions
Care and Cleaning

GEAppliances.ca
3
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with
a 3-prong (grounding) plug which mates with
a standard 3-prong (grounding) wall outlet to
minimize the possibility of electric shock hazard
from this appliance.
Have the wall outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
If you have only a standard 2-prong wall outlet,
it is your personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The wine chiller should always be plugged into its
own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
Never unplug your wine chiller by pulling on
the power cord. Always grip plug firmly and
pull straight out from the outlet.
Repair or replace immediately all power cords
that have become frayed or otherwise damaged.
Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
When moving the wine chiller away from the wall,
be careful not to roll over or damage the power
cord.
USE OF ADAPTER PLUGS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Consumer SupportTroubleshooting Tips
Operating
Instructions
Safety Instructions Installation
Instructions Care and Cleaning
Adapter plugs are not permitted in Canada.

Installing the wine chiller.
Removing the Packaging
Before using the wine chiller, be sure all packing materials and tape have been
removed, including any protective film covering the control and any film protecting
the cabinet.
If you are discarding an old refrigeration product, remove the doors to reduce the
danger of children being trapped inside.
The wine chiller must be freestanding.
Allow the following clearances for ease
of installation, proper air circulation and
electrical connections:
Each side 2" (51 mm)
Top 2" (51 mm)
Back 3" (51 mm)
Before connecting the appliance to the
power source, let it stand upright for
approximately 2 hours. This will reduce
the possibility of a malfunction in the
cooling system from handling during
transporation.
Do not install the wine chiller where the
temperature will go below 55°F (13°C) or
above 90°F (32°C).
Install it on a level floor.
Do not install the wine chiller where it
will be subject to direct sunlight, heat or
moisture.
Do not store or install this appliance
outdoors.
The following models must be installed
on the floor: GWS04, GCS04.
Installation Guidelines
To raise the wine chiller
Adjustable legs at the front corners of the
wine chiller should be set so the wine chiller
is firmly positioned on the floor, with a 1/8"
(3 mm) tilt to the back to help the door
closure.
To adjust the leveling legs, turn the
legs clockwise to raise the wine chiller,
counterclockwise to lower it.
Leveling Legs
Consumer Support Troubleshooting Tips Operating
Instructions Safety Instructions
Installation
Instructions
Care and Cleaning
Interior Light (available on some Models)
You can turn the light ON or OFF by pushing the light switch located on the right side of
the control panel housing. If the interior light is left on, the temperature will be higher.
Loading the Wine
As with any refrigeration product, there is a slight temperature variance at different
locations within each compartment. The lower shelves provide a slightly cooler
temperature than the upper shelves.
4

About the controls and settings. GEAppliances.ca
Consumer SupportTroubleshooting Tips
Operating
Instructions
Safety Instructions Installation
Instructions Care and Cleaning
Setting the Temperature Control
Display Panel
5
Temperature-drop key
Lock/unlock key
Lighting mode key Temperature-rise key Temperature-area
option key
Upper chamber
display area
Lower chamber
display area
When the Wine Chiller is Plugged In
After plugging in the wine chiller and making your
temperature selection, allow the wine chiller to
reach the set temperature before loading your wine.
This may take up to 12 hours to completely stabilize.
After loading the wine, you may notice a rise in
the temperature. Allow adequate time for the
temperature to return back to the set temperature.
This may take up to 12 hours to completely stabilize.
When first powering on, the display screen
gives a full display for 3 seconds and the
start-up sound rings; then the machine enters
into operation in the locked state. See below
for unlocking instructions.
If there is no key operation for 30 seconds, the
display screen will turn off. The display screen
will turn on again, if you touch any key.
When powering on, the temperature of the upper
chamber will be adjusted according to the factory
pre-set. By pressing the Option key , the
temperature area will be switched between upper
chamber and lower chamber. Once a chamber is
selected, the display will flash and at this time the
temperature of the chamber can be set up. After
locking, temperature display stops flashing.
By selecting the key to switch the
temperature areas (upper or lower chamber),
the temperature display of upper or lower
chamber flashes.
By pressing the Temperature-rise key ,
the temperature will increase 1°C (or °F). After
locking, the cooler will operate according to the
setting temperature;
By pressing the Temperature-drop key ,
the temperature will decrease 1°C (or °F). After
locking, the cooler will operate according to the
setting temperature
The wine cooler‘s temperature can be set
between 7~18°C (44~65°F).
Press the Temperature-rise key and
the Temperature-drop key at the same
time for 3 seconds to switch between Celsius
temperature and Fahrenheit temperature; the
screen will display the Fahrenheit temperature
or Celsius temperature under the current mode.
Switching of the Fahrenheit temperature and Celsius temperature
Lock/Unlock Key Button
By pressing the Lock/Unlock key for
3 seconds, the buzzer rings and the locked
mode is activated; the temperature display
areas (digit display areas) of upper chamber
and lower chamber turn off.
By pressing the Lock/Unlock key for
3 seconds in the locked mode, the buzzer rings
and the locked mode is de-activated; After
unlocking, the temperature display area of
selected chamber turns on.
When in the locked mode, if you touch any
key besides the Light key , the display
screen will keep flashing for 2.5 seconds and
the buzzer will ring, alerting you to unlock the
control.
NOTE: WHEN USING ANY COMPARTMENT FOR BOTH WINE AND BEER STORAGE WE RECOMMEND
THAT YOU PLACE RED WINE BOTTLES ON TOP SHELF AND BEER ON BOTTOM SHELF.

About the controls and settings.
Consumer Support Troubleshooting Tips Operating
Instructions Safety Instructions
Installation
Instructions
Care and Cleaning
6
Interior Light
After the power is on for 3 seconds, the lighting
turns on by default for 30 seconds. If the
lighting key is not operated within 30 seconds,
the lighting will automatically turn off.
Press the Lighting mode key to turn on
or turn off the light.
Important:
In order to extend the compressor life, please restart wine cooler after waiting 3 minutes.
Memory Function:
The cooler has a power off memory function. When power comes on again, the wine cooler will
operate according to the setting mode before the power went off.
Fault Indication:
If the codes in the following table are displayed on the display area, it means the cooler has the
faults indicated.
Fault code Fault Description
Upper chamber display E1 The fault of temperature sensor of upper chamber
Lower chamber display E1 The fault of temperature sensor of lower chamber
Upper chamber display E4 The fault of defrosting sensor of upper chamber
Lower chamber display E4 The fault of defrosting sensor of lower chamber
Upper chamber display E6 Communication fault
Call for service if any of the above error messages show.
You should touch the temperature control panel softly as the panel is touch screen control. Please
protect the touch control panel carefully to avoid scratching,keep far away from strong magnetic
fields and high humidity, or it can cause wine cooler to not work properly.

If the power fails, open the door as
infrequently as possible to maintain
the temperature. A gradual rise in
temperature should not have any
adverse effect on the wine.
If it is extremely hot, you may want to
unload the wine from the wine chiller and
move the wine to a cooler location until
power is restored.
When power is restored, the controls
automatically are set to the Factory
Setting 50°F (10°C). If needed, reset the
controls to the desired setting.
Consumer SupportTroubleshooting Tips
Operating
Instructions
Safety Instructions Installation
Instructions Care and Cleaning
Care and cleaning. GEAppliances.ca
IMPORTANT: Unplug the wine chiller
before cleaning.
Keep the outside clean. The cabinet can
be washed with mild soap and water. Rinse
thoroughly with clear water.
Never use abrasive scouring powders.
Use a glass cleaner or mild soap and water
and a soft cloth to clean the glass door. Do
not use any abrasive powders.
Wipe the control panel with a damp cloth.
Dry thoroughly. Do not use cleaning sprays,
large amounts of soap and water, abrasives
or sharp objects on the panel—they can
damage it. Some paper towels can also
scratch the control panel.
Do not wipe the wine chiller with a soiled
dishcloth or towel. These may leave a residue
that can erode the paint. Do not use scouring
pads, powdered cleaners, bleach or cleaners
containing bleach because these products
can scratch and weaken the paint finish.
Stainless steel. Regularly clean and polish
the stainless steel areas (on some models)
with a commercially available stainless
steel cleaner such as Gleem-it®to preserve
and protect the fine finish. Gleem-it®is
available at leading hardware stores. It is
also available through our website,
GEAppliances.ca, or call 1.888.261.3055.
Order part number WX10X15.
Do not use appliance wax or polish on the
stainless steel.
Protect the paint finish. The finish on
the outside of the wine chiller is a
high-quality, baked-on paint finish.
With proper care, it will stay new-looking
and rust-free for years. Apply a coat of
kitchen/appliance wax when the wine
chiller is new, and then at least twice
a year.
Cleaning the Outside
IMPORTANT: Unplug the wine chiller
before cleaning.
To clean the inner liner and racks, use
a warm water and baking soda solution—
about one tablespoon (15 mL) of baking
soda to a quart (1 liter) of water. This both
cleans and neutralizes odors.
Rinse and wipe dry.
The vinyl door gasket may be cleaned
with mild soap and water or a baking soda
solution. Rinse well.
Do not use detergents, scouring powders,
spray cleaners or other harsh chemicals
to clean the interior.
Cleaning the Inside
Defrost whenever frost on the inside
surfaces of the storage area becomes 1/8"
(3 mm) thick.
Never use a heater of any kind, scraper
or sharp instrument to remove frost as it
may damage the wine chiller.
To defrost, unplug the wine chiller. Remove
the contents and wipe inside surfaces and
racks with a clean towel. If frost does not
come off easily, allow the frost to melt
somewhat and wipe off.
After defrosting, make sure inside surfaces
are dry; then return the contents to the
wine chiller and set the temperature control
to the desired setting.
Defrosting
In the Event of a Power Failure
7

Unload the wine, then secure the racks and
door by taping them in place to prevent
damage.
Turn the adjustable leveling legs up to the
base to avoid damage.
Be sure the wine chiller stays in an upright
position during the move.
Preparing to Move
LED Refrigerator Lights
An authorized technician will need to
replace the LED light
Vacation Time
Short vacations: Leave the Wine/
Beverage Cooler operating during
vacations of less than three weeks.
Long vacations: If the appliance will
not be used for several months, remove
all items and unplug the power cord.
Clean and dry the interior thoroughly.
To prevent odor and mold growth, leave
the door open slightly: blocking it open if
necessary.
Energy Saving Tips
The Wine/Beverage Cooler should be
located in the coolest area of the room,
away from heat producing appliances,
and out of the direct sunlight.
Try not to open the door too often,
especially when the weather is wet or
hot. Once you open the door, mind to
close it as soon as possible.
This appliance is intended to be used
exclusively for the storage wine.
Every now and then check if the
appliance is sufficiently ventilated
(adequate air circulation behind the
appliance).
For wine storage appliances, please
arrange the temperature following the
instruction: SPARKLE: 41-45°F (5-7°C),
WHITE: 46-54°F (8-12°C), RED: 55-65°F
(13-18°C).
Care and cleaning.
Consumer Support Troubleshooting Tips Safety Instructions
Installation
Instructions
Care and Cleaning Operating
Instructions
8

Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
Before you call for service… GEAppliances.ca
Problem Possible Causes What To Do
Wine chiller does not Wine chiller is unplugged. • Push the plug completely into the outlet.
operate and the display The circuit breaker is tripped/ • Replace fuse or reset the breaker.
is blank the fuse is blown.
Vibration or rattling Wine chiller is on an • See the Leveling Legs section.
(slight vibration uneven surface.
is normal)
The Wine/Beverage The rattling noise may come
Cooler seems to make from the flow of the refrigerant,
too much noise. which is normal.
As each cycle ends, you may hear
gurgling sounds caused by the
flow of refrigerant in your Wine/
Beverage Cooler.
Contraction and expansion of the
inside walls may cause popping
and crackling noises.
The Wine/Beverage Cooler is
not level.
Motor operates for Normal when wine chiller • Wait 12 hours for the wine chiller to completely
long periods or cycles is first plugged in. cool down.
Often occurs when large • This is normal.
amounts of wine are placed
in wine chiller.
Door left open. • Door is not self-closing. Always make sure that the
door is closed after opening.
• Check to see if a bottle is holding door open.
Hot weather or frequent • This is normal.
door openings.
Temperature control set • See About the control and settings.
at the coldest setting.
Wine chiller is too close • See the Installation Guidelines section for the
to the wall. correct clearances.
Wine chiller too warm Normal when wine chiller • Wait 12 hours for the wine chiller to completely
is first plugged in. cool down.
Often occurs when large • This is normal.
amounts of wine are placed
in wine chiller.
Temperature control • See About the control and settings.
not set cold enough.
Warm weather or frequent • Set the temperature control one step colder.
door openings. See About the control and settings.
Wine chiller is too close • See the Installation Guidelines section for the
to the wall. correct clearances.
Consumer Support
Operating
Instructions
Safety Instructions Installation
Instructions Care and Cleaning Troubleshooting Tips
9

Problem Possible Causes What To Do
Wine chiller too warm Door left open. • Door is not self-closing. Always make sure that the
door is closed after opening.
• Check to see if a bottle is holding door open.
If the temperature setting is • When the power came back on, the wine chiller
not showing what you last returned to the default setting, which is 50°F (10°C).
selected, a power outage Reset the control to the desired setting.
may have occurred.
Wine chiller has odor Interior needs cleaning. • See Care and cleaning.
Moisture forms on Not unusual during periods • Wipe surface dry.
outside of wine chiller of high humidity.
Moisture collects inside Too frequent or too long
(in humid weather, door openings.
Wine bottles touching • Reposition bottles.
the back wall.
Frost forms on interior This is normal. • See the Defrosting section.
surfaces of wine chiller Door left open. • Excessive frost may form if the door is left open.
See the Defrosting section.
• Door is not self-closing. Always make sure that the
door is closed after opening.
• Check to see if a bottle is holding door open.
Wine chiller too cold Temperature control • See About the control and settings.
is set too cold.
If the temperature setting is • When the power came back on, the wine chiller
not showing what you last returned to the default setting, which is 50°F (10°C).
selected, a power outage Reset the control to the desired setting.
may have occurred.
The room temperature where • For proper operation, the room temperature should
the wine chiller is located is be equal to or greater than the set temperature of the
too cold. wine chiller.
Temperature in the This is normal. • After you set the temperature, the display will go
display is not the back to showing the actual temperature.
temperature that
was just set.
Condensation on front Wine chiller is located in a • Wipe off the condensation with a clean, dry cloth.
of door high humidity environment. • Locate the wine chiller in a lower humidity
environment.
Water on floor behind Door left open. • Door is not self-closing. Always make sure that the
wine chiller door is closed after opening.
• Check to see if a bottle is holding door open.
The door will not The Wine/Beverage Cooler is
close properly not level.
The door was reversed and not
properly installed.
The gasket is dirty.
The shelves are out of position.
Consumer Support Troubleshooting Tips Operating
Instructions Safety Instructions
Installation
Instructions
Care and Cleaning
Before you call for service…
air carries moisture
into wine chiller when
door is opened)
10

11
OWNERSHIP REGISTRATION
P.O. BOX 1780
MISSISSAUGA, ONTARIO
L4Y 4G1
(FOR CANADIAN CONSUMERS ONLY -
POUR RÉSIDENTS CANADIENS SEULEMENT)
Please place in envelope and mail to:
Veuillez mettre dans une enveloppe et envoyez à :

12
CUT ALONG THIS LINE AND RETURN CARD – THANKS
DÉCOUPEZ ICI ET ENVOYEZ LA FICHE – MERCI
For Canadian
Customers
Pour les
consommateurs
canadiens
OWNERSHIP REGISTRATION CERTIFICATE – FICHE D’INSCRIPTION DU PROPRIÉTAIRE
Please register your product to enable us to contact you in
the remote event a safety notice is issued for this product
and to allow for efficient communication under the terms of
our warranty, should the need arise.
REGISTER ON-LINE:
www.geappliances.ca
ENREGISTREMENT SUR INTERNET À :
www.electromenagersge.ca
MAIL TO:P.O. BOX 1780, MISSISSAUGA
POSTEZ À : ONTARIO, L4Y 4G1
MR. / M. MRS. / MME
MISS/MLLE MS.
FIRST NAME / PRÉNOM LAST NAME / NOM
STREET NO / N
O
RUE STREET NAME / RUE APT.NO/APP./RR#
CITY / VILLE
PROVINCE
AREA CODE/
IND. RÉG.
TELEPHONE/TÉLÉPHONE E-MAIL/COURRIEL
DID YOU PURCHASE A SERVICE CONTRACT FOR THIS APPLIANCE?
AVEZ-VOUS ACHETÉ UN CONTRAT DE SERVICE POUR CET APPAREIL ?
YES/OUI
NO/NON
IF YES/SI OUI : EXPIRATION
Y/A MD/J
NAME OF SELLING DEALER / NOM DU MARCHAND
INSTALLATION DATE / DATE D’INSTALLATION
Y/A M D/J CORRESPONDENCE
ENGLISH
CORRESPONDANCE
FRANÇAIS
I do not wish to receive any promotional offers regarding this product.
Je ne désire pas recevoir d’offres promotionnelles concernant ce produit
.
MODEL / MODÈLE
SERIAL / SÉRIE
Veuillez enregistrer votre produit afin de nous permettre de
communiquer avec vous si jamais un avis de sécurité concernant
ce produit était émis et de communiquer facilement avec vous en
vertu de votre garantie, si le besoin s’en fait sentir.
POSTAL CODE/CODE POSTAL

Wine Chiller Warranty. GEAppliances.ca
Consumer SupportTroubleshooting Tips
Operating
Instructions
Safety Instructions Installation
Instructions Care and Cleaning
All warranty service provided by our Factory Service Centers, or an authorized
Customer Care®technician. For service call 1-800-561-3344.
Proof of the original purchase date is needed to obtain service under warranty.
Mabe Will Replace:
Any part of the wine chiller which fails due to a defect in materials or workmanship. During
this limited one-year warranty, Mabe will also provide, free of charge, all labour and service
to replace the defective part.
Service trips to your home to teach you how to use the
product.
Improper installation.
Failure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
Loss of wine due to spoilage.
Replacement of house fuses or resetting of circuit
breakers
Damage to the product caused by accident, fire, floods
or acts of God.
In-home warranty service will be provided in areas
where it is available and deemed reasonable by Mabe
to provide.
Incidental or consequential damage to personal
property caused by possible defects with this
appliance.
Please read your Use & Care Material:
If you then have any questions about operating the
product, please contact your dealer or our Consumer
Affairs office at the address below, or call toll free:
MC Commercial Inc.
1-800-561-3344
Consumer Information Service
What Mabe Will Not Cover:
For The Period Of:
One Year
From the date of the
original purchase
This warranty is extended to the original purchaser and any succeeding owner for products purchased in Canada
for home use within Canada. If the product is located in an area where service by a Mabe Authorized Servicer is not
available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized Mabe
Service location.
Some provinces do not allow the exclusion or limitation of consequential damages, so the above limitation or exclusion
may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary
from province to province. To know what your legal rights are in your province, consult your local or provincial
consumer affairs office.
Warrantor: MC Commercial Inc.
If further help is needed concerning this warranty, write;
Consumer Relations Manager - MC Commercial Inc.
1 Factory Lane, Suite 310, Moncton NB E1C 9M3
13

Service Telephone Numbers
In-Home Repair Service 1-800-561-3344
Expert Mabe repair service is only a phone call away.
Parts and Accessories 1-800-263-0686
Individuals qualified to service their own appliances can have parts or accessories sent directly to
their homes.
Instructions contained in this manual cover procedures to be performed by any user. Other
servicing generally should be referred to qualified service personnel. Caution must be exercised,
since improper servicing may cause unsafe operation.
Service Satisfaction
If you are not satisfied with the service you receive from Mabe, follow these steps. First, contact the
people who serviced your appliance. Next, if you are still not pleased, write all the details–including
your phone number–to:
Manager, Consumer Relations,
MC Commercial Inc., Suite 310, 1 Factory Lane,
Moncton (N.-B.) E1C 9M3
14
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions
Installation
Instructions
Care and Cleaning
