Gecko in.clear 0605-500002 User manual

in.clearTM
clean water done right
Low maintenance
No chlorine
No chemicals to add
User Manual
Gecko Alliance
450 des Canetons, Quebec City, QC, G2E 5W6 Canada, 1.800.78.GECKO
www.geckoalliance.com Printed in Mexico
9919-101186-I
Rev. 03-2017
© Groupe Gecko Alliance Inc., 2017
All trademarks or registered trademarks
are the property of their respective owners.
English
Français

in.clear user manual
1
in.clear™ Model No. 0605-500002
Bromine based water sanitization system for spas
(using Bromitron Bromine Generator Technology)
Automatic Bromine Generator
For Spa Sanitizing
DOMESTIC
A maximum of 2000 Liters of water can be treated with one in.clear Automatic Bromine Generator unit.
Maximum output of Hypobromus Acid equivalent to 0.04 kg of free available bromine per day.
For spas, a range of 3 – 5 ppm of free available bromine must be maintained.
READ THE LABEL AND OPERATION/INSTALLATION MANUAL BEFORE USING THIS DEVICE
KEEP OUT OF REACH OF CHILDREN
REGISTRATION No. 29628 PEST CONTROL PRODUCT ACT
WARNING: Operating the in.clear Automatic Bromine Generator without
water flow through the cell can cause a buildup of flammable gases which can result in FIRE or EXPLOSION.
NOTICE TO USER:
This pest control product is to be used only in accordance with the instructions shown on the label. Any use not in
accordance with these instructions is an offence under the Pest Control Products Act. The user assumes the risk to
persons or property arising from the use of this product.
Gecko Alliance Group Inc.
450, Des Canetons, Québec (Québec)
Canada G2E 5W6
1-800-78-GECKO

2
in.clear user manual

in.clear user manual
3
Warnings ....................................................................................................................................................................................... 4
Introduction
- How the in.clear works .............................................................................................................................................. 8
- Versions ....................................................................................................................................................................... 8
- Effects of bromine ...................................................................................................................................................... 8
- Bromine in a spa ......................................................................................................................................................... 8
Before starting ............................................................................................................................................................................. 9
in.clear operating modes
- Maintenance Mode .................................................................................................................................................. 10
- Boost Mode ............................................................................................................................................................... 10
Keypad functions ....................................................................................................................................................................... 10
Start up procedure
- Set the maintenance level ........................................................................................................................................ 12
- Determine the boost level ....................................................................................................................................... 12
Troubleshooting ........................................................................................................................................................................ 13
Frequently Asked Questions .................................................................................................................................................... 15
Glossary ...................................................................................................................................................................................... 16
Cell cleaning ............................................................................................................................................................................... 17
Dimensions
- in.clear dimensions ................................................................................................................................................... 18
- Keypad dimensions .................................................................................................................................................. 18
Installation
- in.clear installation .................................................................................................................................................... 19
- in.clear installation with stand .................................................................................................................................. 19
- in.k200 installation .................................................................................................................................................... 21
- in.k200 drill template ............................................................................................................................................... 21
Specifications ............................................................................................................................................................................. 22
Avertissements .......................................................................................................................................................................... 26
Introduction
- Fonctionnement du système in.clear .................................................................................................................... 30
- Modèles .................................................................................................................................................................... 30
- Effets du brome ......................................................................................................................................................... 30
- Le brome dans un spa .............................................................................................................................................. 30
Avant de débuter ....................................................................................................................................................................... 31
Modes de fonctionnement du système in.clear
- Mode de maintien .................................................................................................................................................... 32
- Mode « Boost » .......................................................................................................................................................... 32
Fonctions du clavier .................................................................................................................................................................. 32
Procédure de démarrage ......................................................................................................................................................... 34
- Définir le niveau de maintien .................................................................................................................................. 34
- Déterminer le niveau de « Boost » .......................................................................................................................... 34
Dépannage ................................................................................................................................................................................ 35
Questions fréquentes ............................................................................................................................................................... 37
Glossaire .................................................................................................................................................................................... 38
Nettoyage de la cellule ............................................................................................................................................................ 39
Dimensions
- Dimensions de l’unité in.clear ................................................................................................................................ 40
- Dimensions du clavier in.k200 ............................................................................................................................... 40
Installation
- Installation du système in.clear ................................................................................................................................ 41
- Installation du système in.clear avec le support .................................................................................................... 41
- Installation du clavier in.k200 .................................................................................................................................. 43
- Gabarit de perçage du clavier in.k200 ................................................................................................................... 43
Spécifications ............................................................................................................................................................................ 44
3
Table des matières
Table of contents

4
in.clear user manual
• For Canada, in.clear (using Bromitron Bromine Generator Technology) must only be used with sodium bromide
(such as BromiCharge) scheduled or registered under the Pest Control Product Act. For USA, the sodium bromide
(such as BromiCharge) must be registered under EPA.
• Read and follow this manual carefully and make sure to save it for later. This manual contains important information
on in.clear's installation, use and safety recommendations. It is your responsibility to install and use your in.clear
unit safely.
• The in.clear must be connected to a circuit protected by a ground fault interrupter device (GFCI) in North America
or residual current device (RCD) having a rated residual operating current not exceeding 30 mA in Europe.
• Make sure all electrical power is off before installing the in.clear unit. If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• Use only an electrical cord in good condition to power the in.clear.
• Follow all aspects of the local and National Electrical Code(s) when installing the in.clear Automatic Bromine
Generator.
• Always clean or replace your filter cartridges at regular intervals, otherwise part of the bromine generated
by in.clear will only serve to oxidize the dirt accumulated in the filter.
• Do NOT add any other sanitation chemicals in the spa other than registered sodium bromide
(such as BromiCharge).
• Do not add chemical products for pool or spa directly into the skimmer. This may damage the cell.
• The cell is installed after the heater in the circulation pump line.
• Operating the in.clear at reduced sodium bromide (such as BromiCharge) levels will shorten the life of the cell.
Maintaining overly high sodium bromide and bromine levels above recommended range can contribute
to corrosion of spa equipment and may damage components of the spa.
• Do not open the in.clear unit; there are no serviceable parts inside.
• Disposal of the product: the in.clear unit must be disposed of separately in accordance with the local
waste disposal legislation in force.
• This unit is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• To reduce the risk of injury, do not allow children to operate this device.
• The in.clear may not be suitable for in ground spas, it may affect some materials used in their construction.
• The unit must be installed in a location that is inaccessible to a person in the bath or spa and must be located
or fixed so that it cannot fall into the bath or spa.
• The unit is not designed to be submersed but may be installed underneath the waterproof skirt of the spa.
Aeware®, Gecko®, and their respective logos are Registered Trademarks of Gecko Alliance Group.
in.k200™, in.xe™, in.ye™, in.yt™, and in.clear™, and their respective logos are Trademarks of Gecko Alliance Group.
BromiCharge™ and its logo are Trademarks of Bromitron Corporation.
All other product or company names that may be mentioned in this publication are tradenames, trademarks
or registered trademarks of their respective owners.
Warnings! Important safety instructions
Warnings

in.clear user manual
5
• A means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
• It is the responsibility of the user to test the spa water regularly to ensure that adequate amounts of bromine
are generated to achieve proper sanitizer levels. Heavy spa usage may require higher bromine output
to maintain proper free available bromine residuals.
• The expected lifetime of the electrodes is 30 000 hours when used in normal operating conditions.
• Check the expiry date of the test kit as test results may be inaccurate if used after that date.
• People with a medical condition should consult a physician before entering spa water.
• Women who are pregnant should NOT enter the spa.
• Maximum spa water usage temperature is 40°C. Bathing in spa water at 40°C should not exceed 15 minutes.
• For proper sanitation, spa must be completely drained periodically. The number of days between
COMPLETE SPA DRAINAGE is equal to the volume of the spa water in liters, divided by 10 times
the maximum number of daily spa users.
• Refill spa with water and repeat DIRECTION FOR USE of the device.
- For a 1500 liters (400 US gallons) spa used by 2 adults twice a week: 1500 / (10 x (4/7)) = 262 days or 8 months
• In.clear is meant for a covered spa NOT swimming pools.
• Users should always shower before entering a spa.
Warnings

6
in.clear user manual

in.clear user manual
7
in.clear
clean water done right
Easy to use and built to last, the in.clear is one of
the most efficient water sanitization systems offered
to the spa and hot tub industry today. The in.clear
generates and releases bromine into the spa water,
rapidly destroying any microbiological contaminants
such as water borne bacteria, algae, and organic matter
given off by spa bathers.
The in.clear system eliminates the need to add bromine
or chlorine to your spa on a regular basis. The in.clear
system oxidizes odors, reduces eye irritation, and
is easy to use, making it the best choice for hot tub
sanitization. Spas using the in.clear system need very
little maintenance, and the in.clear can be easily installed
on new or existing spas.
Accessories
In order to use the in.clear system you must also
have an in.k200 keypad or a compatible main
spa keypad, and a government approved sodium
bromide product (such as BromiCharge).
See below for more in.clear accessories.
in.clear parts and accessories:
in.clear: stand alone (in.link) 0605-300002
in.clear: stand alone (QCM) 0605-300001
in.clear: stand alone (AMP) 0605-300003
in.clear: linked (in.link) 0605-500005
in.clear: linked (AMP) 0605-500006
in.clear: linked (QCM) 0605-500007
in.clear: linked (1.5 PSI, QCM) 0605-500010
in.k200 keypad 0607-008010
Bromine test kit 0699-300008
Reducer (2" to 3/4") 0699-300007
Mounting stand 9920-101464
BromiCharge
Canada 0699-300006
United States 0699-300005
Europe 0699-300009
Compatibility
The linked version of the in.clear is compatible with
the in.xe, in.xm, in.ye, in.yt and in.yj spa packs with
necessary software revisions and hardware.
Introduction

8
in.clear user manual
How the in.clear works
When sodium bromide (such as BromiCharge) is added
to the water, it separates into sodium ions and bromide
ions. As the water passes through the in.clear bromine
generator, a low-voltage source supplies a current
that electrolytically reduces the bromine ions into
bromine. The bromine destroys bacteria and algae,
and then releases bromide ions back into the water for
continuous recycling until the spa is emptied.
It is important to note that the amount of bromine
needed will vary in direct proportion to the number of
bathers in the spa (bather load).
Versions
There are two versions of the in.clear module: a stand
alone version that uses the in.k200 keypad directly,
and the linked version, which communicates with the
spa pack for more control and precision.
Effects of bromine
• Bromine destroys waterborne bacteria.
• Bromine destroys algae in water
(e.g. Black, Green, Mustard).
• Bromine swiftly eliminates the presence
of organic matter left behind by spa users
(e.g. oil, sweat, dead skin cells).
• Because bromine doesn’t contain calcium,
it can be used to sanitize hard water without
increasing the calcium hardness.
Bromine in a spa
Bacteria require a certain period of time before forming
into micro colonies and becoming attached to a surface.
Rapid elimination of bacteria is a key element in the
proper maintenance of the spa water. The in.clear
achieves this while oxidizing odors, reducing eye and
skin irritation. The in.clear enhances the clarity and
quality of spa water. For bathers this translates into
a more enjoyable warm water therapy experience.
Introduction

in.clear user manual
9
4. Add sodium bromide (such as BromiCharge)
Water temperature between 32° and 38° C (90° and
100° F) helps dissolve sodium bromide and facilitates the
adjustment of the maintenance level.
Start the pump to allow water to circulate and slowly add
sodium bromide uniformly in the spa by simply pouring
it from the container.
Metric Calculation:
Add 0.143 kg of sodium bromide which has a guarantee
of at least a 98% active ingredient, such as BromiCharge,
per 100 L of water to attain 1 400 ppm TDS value (Total
Dissolved Solids).
Example, if your spa holds 1200 L of water, add 1.72 kg of
sodium bromide (12 X 0.143 kg).
Imperial Calculation:
Add sodium bromide which has a guarantee of at least a
98% active ingredient, such as BromiCharge per 100 US
gallons of water.
Example, if your spa holds 300 US gallons of water,
add 3.6 lbs of sodium bromide (3 X 1.2 lb).
Note: Your spa manufacturer can tell you how much
water your spa holds (in liters or gallons).
Sodium bromide information
In Canada, the in.clear must only be used with
sodium bromide (such as BromiCharge) scheduled or
registered under the Pest Control Product Act.
In the USA, the sodium bromide (such as
BromiCharge) must be registered under the EPA.
Your warranty will be void if a product other than
sodium bromide is used as a substitute.
Do not inhale the product or get into your eyes!
First Aid instructions should appear on the label
of the registered sodium bromide container.
Do not use any other sanitation chemicals
(including shock) other than sodium bromide
in the spa.
When adding fresh water to the spa, start a Boost
to help build a residual bromine bank.
1. Drain and clean the spa
It's important to completely drain and clean the spa
to remove all residues accumulated on the surface
and inside or around the jet area. After draining the spa,
use spa cleaning products only. Household cleaners
contain additives such as phosphates which may affect
the bromine production. When the spa is clean, rinse it
off thoroughly with a garden hose.
It's extremely important to clean your filter cartridge
with a filter soaking solution or replace your filter
cartridges.
It is important that the spa is well cleaned and rinsed
prior to the startup of the new system. Some biofilms
may have formed in the spa that could prevent
the system from functioning properly. We strongly
recommend the use of a flushing product such
as Spa System Flush, Swirl Away or National
Chemistry Spa Purge to clean the plumbing even
if the spa is brand new.
2. Refill the spa with fresh water
After the in.clear unit has been installed, check the TDS
(Total Dissolved Solids) of the water you'll use to refill
the spa. Verifying the TDS range can be done by your
local spa dealer. The TDS range should be within 50
and 400 PPM. When you're certain the water is within
the proper TDS range, refill your spa.
If your TDS is higher than 500 PPM, ask your
spa dealer for additional information to help
reduce initial TDS.
DO NOT use water
from a "Salt Water Softener" system.
Make sure there is adequate flow and that no airlocks
are trapped in the unit's plumbing. If airlocks are formed,
start the pump and slowly loosen one of the union
nuts to release the air trapped in the plumbing. Tighten
the nut again after you are done.
3. Adjust water chemistry in the spa
Proper chemical maintenance of a spa is essential
for the health of bathers. Maintaining the quality of
the spa water within these specified values will enhance
your enjoyment of the spa and prolong the life of the
in.clear system.
For best results, adjust to the following water chemistry
parameters. Check these parameters periodically.
Calcium hardness (TH): between 150 and 200 PPM
Total Alkalinity: between 100 and 120 PPM
pH: between 7.2 and 7.8
Water chemistry should be balanced before adding
sodium bromide into the water. It's essential that the
water chemistry parameters are within the proposed
range to obtain optimal system performance.
High Calcium Hardness may lead to faster
calcification of the electrolytic plates.
(see video: www.geckoal.com/inclear)
Before starting

10
in.clear user manual
Maintenance Mode
Maintenance Mode keeps the bromine bank levels at
a stable and acceptable range when the spa is not being
used. Maintenance mode is the “everyday” mode
and is automatically ON when the system is activated.
Maintenance level adjustment changes the rate at which
bromine will be released into the spa water.
Finding and setting the right maintenance level will
keep the residual bromine level between 3 and 5 PPM
(the recommended range) when the spa is not being
used or is left unused for an extended period of time.
Once the proper maintenance level is determined,
keep the same setting unless the spa conditions change
(change in water temperature, spa location etc).
Finding the right bromine generation level is a crucial
step for the in.clear system to be stable and effective
(see Set Maintenance Mode).
With the stand alone version, the spa filtration should
be set to a minimum of 8 hours per day. To check the
minimum filtration time for your spa, see the Program
Key section.
With the linked version, it is not necessary to set
the filtration duration, as communication between
the pack and in.clear allows the system to stop and
start the associated pump at the best times.
It is important to note that the in.clear system can
ONLY generate bromine when the water is circulating.
If you are having problems maintaining a stable level
of bromine, or determining the proper maintenance
level for your spa, you may have to increase the daily
filtering time. Longer filtration produces a more steady
level of bromine.
Boost Mode
The Boost Mode should be activated every time you use
your spa. Boost mode increases the bromine generation
rate to attack pollutants in the water and helps rebuild
the necessary residual bromine in the water after each
use of the spa. Pollutants are introduced to the water
by the bathers, causing the bromine levels to decrease.
Activating the boost mode when you enter the spa will
prevent inadequate bromine levels and will restore your
bromine to the proper residual level.
Finding the right boost level is another crucial step for
the in.clear system to be stable and effective.
If water quality is not good after use, only the boost
level should be adjusted, not the maintenance level.
Keypad functions
On/Off &
Boost key Maintenance Diagnostic key Down keyUp key
Bromine
Generation
Indicator lo hi
BromiCharge gauge
This manual details the functions of the in.clear with the default keypad (in.k200). If your spa pack uses a compatible
keypad (ex. in.k800) please see its manual for more specific information.
in.clear operating modes

in.clear user manual
11
Diagnostic mode
Diagnostic mode can be
used to periodically adjust
the sodium bromide
level or to check sodium
bromide keypad warnings
and errors.
The BromiCharge Gauge
will indicate the level of
sodium bromide in the
spa water. As you add
sodium bromide to the
spa an animation will
indicate rising levels*.
If the levels go down
(when adding fresh
water, for example) the
animation will indicate
diminishing levels.
Press the Prog key to exit
diagnostic mode or the
system will automatically
exit after 15 minutes.
*In older versions a
number will be displayed
instead of an animation to
indicate the level.
The target number is 12.
Boost key
The first press of the Boost
key turns the in.clear ON
and puts the in.clear into
maintenance mode.
ON appears on the
keypad display.
Press the Boost key once
while in maintenance
mode to start a boost,
or to adjust boost settings.*
The Bromine Generation
Indicator (LED), located
above the Boost key,
lights up when the cell is
producing bromine and
is off when no bromine is
being produced.
Program key
Press and hold
the Program key for
2 seconds to change the
maintenance mode level.
Once in maintenance
mode adjustment, press
the Program key again
to view the suggested
minimum filtration time *
(stand alone version only).
Press the Program key
once more for Diagnostic
mode.
* Not displayed in older
versions.
+ / - Keys
Use the Up and Down
keys to adjust the
maintenance and boost
levels while in the
appropriate mode.
Water must be
circulating through the
in.clear cell in order for
the diagnostic mode
to work. If no water
is circulating through
the in.clear unit, a FLO
message will appear
on the keypad display.
Make sure the pump
is circulating water
through the in.clear.
Be aware that the
gauge will move
according to sodium
bromide level.
Make sure your water
temperature is at least
32° C (90° F).
BromiCharge gauge
BromiCharge gauge (LEDs)
In diagnostic mode, the BromiCharge gauge (LEDs) indicates the approximate
sodium bromide level of your spa water. Do not add sodium bromide if the indicator
is in the green zone.
When adding sodium bromide, the gauge indicator will gradually shift to the right.
When adding clean water to the spa the indicator will shift to the left. In order to
achieve the proper level, start pumps and add 227g (.5 lb) at a time and always allow
5 minutes for the gauge to react before adding more sodium bromide.
The green zone in the center area of the gauge should be targeted for optimal performance.
increase
decrease
Keypad functions
Press and hold the Boost
key for 2 seconds to turn
the in.clear off. OFF will
appear on the keypad
display. Do not turn the
in.clear off unless required
for maintenance, or if
advised by a technician
or Gecko representative.
Turning the in.clear off will
cancel the boost.
Note: With the standalone
version the Bromine
Generation indicator will
blink if the in.clear system
cannot generate bromine
due to low or no water
flow.
* In older versions,
pressing the Boost key
during a boost cycle will
cancel the remainder of
that boost cycle and return
the in.clear system to
maintenance mode.

12
in.clear user manual
Determine the boost level
Every time you use your spa, activate the boost mode.
As a rule of thumb, the boost level corresponds to the
number of bathers using the spa. For example, activate
the boost level to 2 if two bathers are entering the spa.
1. With the system in maintenance mode,
press the Boost key to activate the Boost mode.
2. The keypad display will show a numeric value that
corresponds to the selected level. There are 8 possible
levels available with the boost mode. Set the boost
level by using the up and down arrow to select the
number of bathers that use the spa.
3. Confirm the selection by pressing the Boost key again
or wait 5 seconds for the system to save the desired
level and activate the Boost cycle.
Note: The in.clear keeps the last used boost level
in memory.
4. At the end of the boost period, verify that the bromine
level has returned to the 3-5 PPM range. If the bromine
level is too low or too high after the Boost period,
the boost level should be adjusted the next time
the spa is used. For example, if bromine level is higher
than 5 PPM after a boost of 2, lower the boost level
to 1 the next time. Repeat these steps until you are able
to determine the ideal boost level for your usage.
Note: Boost levels depend on the number of bathers
using the spa. We recommend you validate the Boost
level after each use to determine the ideal boost level
for all numbers of bathers.
Changing the water temperature setpoint of your
spa, or using the economy mode, could require a
change in the maintenance level of your in.clear.
Lower water temperatures may require a lower
maintenance level than higher temperature
setpoints. Please check your bromine level when
changing your temperature setpoint or using the
economy mode of your spa.
Never adjust the maintenance level of your in.clear
without allowing at least 24 hours following the end
of the boost period. Boost cycles allow the residual
bromine level to stabilize. Bromine levels outside
the 3-5 PPM range may result from pollutants
following usage.
Linked version only: If the pack connected to
the in.clear detects spa use (pumps, blower, or
lights active) for 5 minutes without a boost, it will
automatically start a boost at the last used level. This
is a security feature only, and should not be used to
replace the boost setting. Incorrect boost settings for
the bather load could damage spa parts and/or be
hazardous to bathers.
Set the maintenance level
Determining the proper maintenance level for your spa
is an extremely important step. DO NOT use your spa
during this step as it will slow the process. Be patient.
Make sure you follow steps 1 through 4 of the Before
Starting section before performing the following steps.
1. Power up your spa and activate the system by pressing
the Boost key.
2. Make sure your maintenance level is set to 15.
To adjust the level, press and hold the Program key for
2 seconds, then use the Up and Down keys to adjust
the maintenance level. The bromine generation rate
ranges from 1 to 50, where 1 corresponds to the system’s
minimum generating rate and 50 corresponds to the
maximum generation rate allowed by the system.
OPTIONAL: Set the boost to level 2 to help build up the
bromine bank faster and speed up the startup process.
3. Use a test kit to check the bromine level every
12-24 hours*. The bromine level should be between
3-5 PPM. If the bromine level is within that range for
3 consecutive days, you are ready to use your spa.
If the bromine level is above 5 PPM, decrease the
maintenance level. If the bromine level is below 3 PPM,
increase the maintenance level.
4. Repeat step 3 until bromine is stable between 3 and
5 PPM for 3 consecutive days.
Do NOT increase/decrease maintenance level in
steps greater than 2.
Setting the maintenance level to a value that's too
high can cause damage to your equipment.
Check bromine level and always test water before
entering the spa.
If the bromine level is higher than 5 PPM, lower
the maintenance level and turn off the system
until the bromine level is back below 5 PPM.
Then, restart the system and continue monitoring
the bromine level.
To lower the bromine level, expose your spa water
to the sun and activate all pumps for a few cycles.
*Testing bromine levels with FAS-DPD drop count
method is more accurate than using test strips. Bromine
FAS-DPD is available at www.geckodepot.com under
number 0699-300008.
Start up procedure

in.clear user manual
13
Low Sodium Bromide
Error
Low Sodium Bromide
Error (Err) occurs when
the sodium bromide level
is too low. The lo LED
indicator will blink when
the error is present. The
in.clear system will not
generate bromine until
the Low Sodium Bromide
Error (Err) is cleared.
To clear the Low Sodium
Bromide error (Err), add
sodium bromide to the
spa water. Let water
circulate for 5 minutes.
Activate diagnostic mode
and add more sodium
bromide until gauge is
back in the green zone.
Exit diagnostic mode.
Low Sodium Bromide
Warning
Low Sodium Bromide
Warning (Lo) indicates
the need to add sodium
bromide to the spa water.
In diagnostic mode, add
sodium bromide to the
water until the gauge
reaches the green zone
to clear a Low Sodium
Bromide Warning (Lo).
If after adding sodium
bromide the Low
Sodium Bromide
Warning (Lo) or Low
Sodium Bromide
Error (Err) still occurs it
could be the result of:
• calcification of the
electrolytic plates;
• airlocks trapped
in the in.clear unit or
insufficient flow;
• internal pressure
switch problem.
Blinking “AC ”
A blinking “AC” message
displayed on the keypad
indicates that there is a
problem with the power
input. The most common
reason is that the in.clear
unit is supplied with 120 V
instead of 240 V. Please
make sure power cord is
connected properly to a
240 V source.
Standalone version
only: Bromine
Generation indicator
blinking
A blinking Bromine
Generation LED means
that the system is unable
to generate bromine
because no water flow is
detected by the in.clear
system. This situation is
normal if the pump is not
running and no water
is flowing through the
in.clear. However, if water
is circulating through
the in.clear unit, and the
Bromine Generation LED
is still blinking, make sure
that the in.clear is installed
on the pressure side of the
pump and that water is
properly flowing through
the in.clear unit.
Bromine Generation
indicator is off
The Bromine Generation
LED indicator is OFF
when there is no need
for bromine generation.
This situation is normal,
especially with low
maintenance level of
bromine generation set on
the keypad.
Troubleshooting

14
in.clear user manual
FLO error (out of
diagnostic mode)
With the linked version
the FLO error appears
when the in.clear's
pressostat is open for
longer than 3 minutes and
the pump associated with
it was activated by the spa
pack.
Verify that the in.clear unit
was installed on the right
pump (must be installed
on the circulation pump if
present).
Check that the in.clear is
installed on the pressure
side of the pump and that
water is flowing through
the in.clear unit.
Communication Error
The Co error indicates
that a linked version of
the in.clear is being used,
but a pack cannot be
detected. Ensure that you
are using a compatible
pack with appropriate
software, and that all
connections are secure.
If this does not clear the
message, contact your
dealer for help.
High Sodium Bromide
Warning
High Sodium Bromide
Warning (Hi) occurs
when too much sodium
bromide is present in the
water or there is a high
TDS level (water hardness,
alkalinity, organic
compounds, etc).
To clear a High Sodium
Bromide Warning,
readjust the sodium
bromide content of your
water in diagnostic mode,
into the green zone by
draining some water from
your spa and adding fresh
water.
in.clear is turned off
The OFF message
indicates that the in.clear
is turned off.
Press the Boost key to
reactivate the in.clear.
Troubleshooting

in.clear user manual
15
Q: What should I use to clean my spa?
A: Always use a non-sudsing cleaner found
at your spa store.
Q: When my in.clear bromine generator is off does
the sodium bromide continue sanitizing my spa?
A: No, the in.clear system does not sanitize if inactive.
If there is a residual bank of bromine, bromine
continues to sanitize the spa water. The in.clear may
be off at certain times and the spa will still be fine
and clean.
The sodium bromide is converted to bromine as it
passes through the electrodes of the in.clear system
and the pump associated with the in.clear is running.
Q: Why is my spa water cloudy/oily?
A: If your spa becomes cloudy or oily due to bather
load perform an additional Boost and wait for
24 hours to see if conditions return to normal.
If the problem persists consult a spa/pool dealer
to have your water balanced properly.
Q: Does the sodium bromide evaporate?
A: No. Sodium bromide is only lost through splash
out, eaks or when draining your spa.
Low or no bromine reading
Make sure the maintenance level is properly set
according to the procedure described in the section
Set Maintenance Level. Make sure there is no error or
warning message on the display, the cell is activated
and that water is circulating properly through the cell.
Make sure water chemistry is balanced. Refer to
the section Adjust Water Chemistry in the Spa for
more details.
Test your spa water for phosphate to make sure there is
no contamination. Phosphates should never exceed
100 PPB. Phosphates can be introduced to your spa
water by household cleaners, soaps and lotions.
Change your filter or clean it with a filter cleaner
and rinse thouroughly with cold water.
Make sure the in.clear cell is not damaged and that
no calcium or lime deposits appear on the cell plates.
Clean your cell regularly (at least once a year).
Long recovery time after usage
Activate Boost Mode at the appropriate level every time
you use your spa. Refer to the section Determine the
Boost Level.
Heavy bather loads will require longer boost periods.
If bromine level is below 3 PPM following a boost
period, re-activate Boost Mode to bring the bromine
bank within 3-5 PPM.
The bromine bank should always be regenerated
following a boost period. If a high boost level does not
regenerate the bromine bank properly, increase the daily
filtration time.
If bromine production is still inadequate after following
all of the instructions above, biofilm deposits could
be causing the lack of bromine generation. Flushing
products such as Sea Klear Spa System Flush, Swirl Away
or National Chemistry Spa Purge have shown to be
effective for biofilm removal.
Troubleshooting
Frequently Asked Questions

16
in.clear user manual
Organic Matter
Substances left behind
by spa users such as oil,
sweat and dead skin cells
that serve as "food" for
bacteria.
Calcium Hardness (CH)
Calcium Hardness
describes the
concentration of calcium
in your spa water.
Total Hardness (TH)
Total Hardness describes
the concentration of
calcium and magnesium
in your spa water.
Bather Load
This term is used to
describe the number
of bathers using a spa,
combined with the length
and frequency of its usage.
The higher the bath usage,
the greater quantity of
chemicals needs to be
added to maintain the
same spa water quality.
TDS
Total Dissolved Solids
(TDS) is an expression for
the combined content of
all inorganic and organic
substances contained in a
liquid which are present
in a molecular, ionized or
micro-granular (colloidal
sol) suspended form.
pH
pH (potential hydrogen) is
a measure of the acidity or
basicity of a solution.
PPM
"Parts-per million"
notation is used to denote
relative proportions or
a comparative ratio in a
given measured quantity.
The expression "1 PPM"
means a given property
exists at a relative
proportion of one part per
million parts examined, as
would occur if a water-
borne pollutant was
present at a concentration
of one-millionth of a
gram per gram of sample
solution.
Total Alkalinity (TA)
Total Alkalinity or TA is a
measure of the ability of
a solution (such as water)
to neutralize acids to the
equivalence point of
carbonate or bicarbonate.
Glossary

in.clear user manual
17
Phosphoric acid
or muriatic acid
Refer to acid manufacturer's instructions.
Wear eye protection and rubber gloves during these
operations. Splashing or spilling acid can cause
severe personal injuries and/or property damage.
Always work in a well-ventilated area.
Always add acid to the water; never add water
to the acid.
Do not pour acid outside of the unit where
the connectors are located.
Never use acetic acid to clean the cell, as this will
cause permanent damage to cell components and
void the warranty.
In.clear includes a self-cleaning feature to prevent scale
deposits on the graphite electrodes of the in.clear
system. However, deposits may still form due to hard
water. If that happens the cell should be cleaned in an
acidic solution.
All power must be disconnected before any service
procedure is performed.
Disconnect the communication cable and power cable
of the in.clear unit.
To clean the in.clear cell, follow these steps:
• To remove scales from the cell, we recommend
using phosphoric acid (non-diluted) as the preferred
cleaning product.
• Close the spa flow shut off valves. Unscrew both
unions from the unit and remove the cell from
the spa equipment compartment.
• Install the rubber washer and the plastic nut on the
threaded end of the cell. Tighten plastic nut firmly.
• Place the cell vertically with the cap end down into
a plastic 19 L (5 U.S. gallon) bucket and carefully
pour the acid solution into the cell until the 4 plates
are covered (careful not to overflow). The acid
solution will begin to produce bubbles to clean
the electrodes.
A foaming action will follow, which is caused by
the scale deposits being dissolved from the plates.
If rigorous foaming action does not begin, the cell
does not need to be cleaned. Rinse and reinstall
the cell.
• Allow the electrodes to remain in the solution until
the foaming has stopped. However, DO NOT leave
in acid for more than fifteen minutes. Excessive acid
cleaning will damage the electrolytic cell.
• Pour the acid solution back into the bucket and rinse
the cell thoroughly with clean tap water. If deposits
are still visible, repeat operation for fifteen minutes
maximum (some acid may need to be added to
the solution).
• Remove the plastic nut and washer from the cell
and keep them for future cell cleaning.
• Rinse the in.clear with fresh water.
• Re-install the in.clear unit into spa system plumbing,
tighten all connections by hand. Open the spa flow
shut off valves.
• Reconnect the keypad and power cable.
• Turn power on and start up the pump. Check the
keypad to see that the bromine generation LED is
on and resume normal operation.
Cell cleaning

18
in.clear user manual
in.clear dimensions
Inside diameter
2"
(50.8 mm)
6.1"
(155 mm)
Rugged plastic watertight enclosure
4.7"
(120 mm)
Power input cable
10.9"
(277 mm)
Comm. PortKeypad connector
Buttress threads
3-8 both ends Buttress threads
3-8 both ends
4.75"
(120 mm)
1.7"
(43 mm)
Keypad dimensions
2"
(51 mm)
Dimensions

in.clear user manual
19
The stand can be used for
floor mounting and for wall
mounting.
The stand includes the
required screws to mount
the device to the stand.
The mounting screws to
attach the stand to the spa
are not included.
The following material is recommended:
4- # 10 screws of appropriate length with round,
truss or pan head.
4- washers 12 mm OD x 1.5 mm thickness
(1/2" OD x 1/16”).
Select the most appropriate location for in.clear and
firmly attach each stand to wooden base with 2 screws
backed by 2 washers.
in.clear installation with stand
Gecko # 9920-101464
www.geckodepot.com
Floor and side mounting
Fig.A: in.clear installation scheme with circulation pump
Note: The pressure in the piping must be at least 3 psi when water is circulating
spa filter
circulation pump
11.4 to 151 liters/min
(3 to 40 US GPM)
water jet
heater
spa
in.clear
Make sure there are no kinks in the plumbing.
Water flow must run from bottom to top
if installed vertically.
If water flow is as low as 11.4 l/min (3 GPM) and
the in.clear is to be installed horizontally, an air gap
may appear at the top which may decrease the
performance of the unit. In this case, raise the outlet
1" above the water inlet level.
We do not recommend installing the linked version
of the in.clear on a heat recovery system, as the
in.clear forces filtration and risks raising the water
temperature above the Set Point.
The in.clear must be installed on a circulation pump
if one is present.
We do not recommend installing the in.clear on a
spa equipped with a dual-speed pump. The in.clear
works only when the pump is running; therefore
a dual-speed pump will need to run 8-10 hours for
optimum bromine production. This may be difficult
for a large pump to do in warm weather, without
overheating the spa.
Install the in.clear on the pressure side on a 11.4 to
151 l/min (3 to 40 US GPM) flow line. Do not to
exceed 151 l/min (40 US GPM) to prevent excessive
electrode wear and damage to the in.clear unit.
Installation
Warnings!
in.clear installation
