INSTRUCTION MANUAL
Vacuum cleaner
Model No. BC-8880A

Warning:
1. Read this instruction booklet carefully.
2. This appliance is for domestic use only. Use as described in this instruction booklet.
3. Before using this appliance, check that the mains power voltage corresponds to the voltage
shown on the rating plate.
4. Do not use the appliance to vacuum all the latter things:
water and other liquids
lighted stub, hot ashes and other combustible things
sharp matter
wood pieces, gesso, cement, calcimine and other tiny granules
Keep the vacuum cleaner away from stoves and heat-emitting appliance. Heat can deform
and discolor the plastic parts of unit.
Always remove the plug from the power socket when the appliance is not in charging.
Never use spirits or other solvents to clean the appliance.
Never leave the appliance unattended when it is switched on. Keep the appliance out of the
reach of children or the infirm.
Do not switch the appliance on if it appears to be faulty in any way.
The battery must be removed from the appliance before it is scrapped.
The battery is to be disposed of safely.
The appliance must be disconnected from the supply when removing the battery.
Never use spirits or other solvents to clean the appliance.
Do not put any object into openings. Do not use with any opening blocked; keep free of dust,
lint, hair and anything that may reduce air flow.
Keep hair, loose clothing, fingers, and all parts of body away from openings and moving
parts.
Only the adapter provided by the manufacturer can be used.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.

Parts Description
1. Main unit
9. Floor brush release button
2. Aluminum tube
10. Charging port
3. Electrical floor brush
11. Battery pack
4. On/off button
12. Dust bin release button
5. Dust empty release button
13. Charger
6.Dust bin bottom plate
14. 2 in 1 crevice tool
7. Battery Indicator light
15. Wall mount
8. Aluminum tube release button

INSTRUCTION FOR USE
Note:
Before using the Cordless Vacuum cleaner for the first time, clean it with a soft, damp cloth and
dry thoroughly.
Do not immerse the Cordless Vacuum cleaner in water or any other liquid.
Assembling the Cordless Vacuum cleaner
1. Assembling the aluminum tube
Fit the tube onto the main body’s air inlet until it clicks into the position.
If need to remove the tube, hold the main body, press the release knob and remove the tube
2. Assembling the electrical floor brush
Fit the electrical floor brush on the tube until it click into the position.
If need to remove the electrical floor brush, hold the aluminum tube, press the floor brush
release knob and remove the brush from the tube.
3. Assembling the 2 in 1 crevice tool
Fit the accessory on the main body’s air inlet and/or on the tube until it clicks into the position.
The 2 in 1 crevice is good for cleaning stairs, corners.

Operating the Cordless Vacuum cleaner
Before first time use, ensure the vacuum cleaner has been charged 5-5.5 hours.
Turn on the Cordless vacuum cleaner by pressing the ON/OFF button and press the button max or
min to adjust the power.
Note: Battery indicator light represents battery capacity and will illuminate during use. The
indicator light will extinguish one by one as the battery runs out.
Warning: Do not use the Cordless Vacuum cleaner without the removable filter or dust bin not in
position.
Charging your product
1.Turn off the Cordless vacuum cleaner.
2.Connect the adapter to the charge port on the main unit.
3.Plug the adapter into the main power supply.
The battery indicator display light will flash in a ring. Once the battery fully charged, the battery
indicator stays on in full ring.
Warning: Do not use any mains power adaptor other than that supplied, as using an alternative
will increase the risk of injury and/or damage to main product.

CARE AND MAINTENANCE
Filter replacement and cleaning
1. Turn off the Cordless vacuum cleaner
2. Press and hold the dust cup release button and rotate the dust cup at a clockwise angle of 30 °,
then remove the whole dust cup.
3.How to clean the dust cup：
Without removing the dust cup，Press the dust cup release button directly, Then drop the dust
into waste container.(fig. A)
Or you can remove the dust cup and Press the dust cup release button directly, Then drop the
dust into waste container.(fig. B)

4.Remove filter assembly: Filter, Hepa , Dust cup.
5.Cleaning the filter/hepa in water, wait for it to dry completely.
6.Put the filter/hepa back into the dust cup carefully.
7.Put the dust cup back into the main body: Dust cup counterclockwise rotation into the slot,
hear the sound of "ka", that means the dust cup installed in place.

Floor brush cleaning
1. Turn the brush bottom screw to unlock position (picture)
2. Open the brush bottom fixed device.
3. Show brush, clean the rotating brush on the twisting thing.
4. Put the rotating brush back.
5. Turn the brush bottom screw to lock position
STORE YOUR PRODUCTS
Your cordless vacuum cleaner is enclosed with a wall mount which will help you to store your
appliance in safe way, follow below steps:
6. Fix your wall mount on suitable wall or cabinet where you wish to store your appliance with
two provided screws, please measure the overall height of appliance at storage condition to
decide right height of wall mount and for the safety, please always make sure the appliance
touches the floor during storage.
7. Store your appliance with simply push your appliance into the holder and click-in sound will
be heard and your 2 in 1 crevice tool can be stored in the same way with the clicker.
8. Please take your appliance away from the holder if you wish to use it again.

BATTERY REMOVAL AND DISPOSAL
Take your cordless vacuum cleaner at the end of the long lifetime is not fit in the trash as it fitted
with a Li-ion battery, it need to be disposed in an environmentally friendly way.
Discarded batteries are nonenvironmentally friendly and disposed of it in accordance with
applicable regulations.
1. Discharge the battery by running the appliance to stop the engine at idle.
2. Remove the battery from the appliance.
3. Dispose of the battery to a collection of chemical waste from.
Attention:
The battery pack of this model vacuum cleaner is Non-removable. If you need to replace battery
pack ,Please send it to a professional maintenance station.
TECHNICAL SPECIFICATION
Model No.
BC-8880A
Voltage
DC 22.2V
Motor
DC 22.2V, 120W
Battery
Lithium, 2200 mAh
Charger Model No.
BZ15-270050-AG
Charger Input
100-240V~ 50/60Hz 0.4A Max
Charger Output
27V 500mA

TROUBLE SHOOTING GUIDE
PROBLEM
POSSIBLE REASON
POSSIBLE SOLUTION
HAND VACUUM
WILL NOT OPERATE
1. no power in electrical outlet
supplying transformer
2. unit needs servicing
1. check fuse or
breaker .replace fuse/reset
breaker.
HAND VACUUM
WILL NOT PICK-UP
OR SUCTION
POWER IS WEAK
1.Dust cup is full.
2.Dust cup filter needs
cleaning.
1.Empty dust cup.
Remove dust cup filter and
check for object(s) in air duct
and remove.
2. Clean filters
DUST ESCAPING
FROM HAND
VACUUM
1.Dust cup is full.
2.Dust cup filter is not installed
correctly.
3. Puncture/hole/damage on dust
cup filter.
1.Empty dust cup .
2. Review dust cup filter
instruction and install again
in proper way.
3. Replace dust cup filter.
HAND VACUUM
BRUSHES WILL NOT
PICK-UP
1.Dust cup is full.
1.Empty and clean dust cup.

Warranty Information
The manufacturer provides warranty in accordance with the legislation of the
customer's own country of residence, with a minimum of 1 year
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service centre.
When making a claim under the warranty, the original bill of purchase (with purchase
date) must be submitted.
The warranty will not apply in cases of:
- Normal wear and tear
- Incorrect use, e.g. overloading of the appliance, use of non-approved accessories
- Use of force, damage caused by external influences
- Damage caused by non-observance of the user manual, e.g. connection to an
unsuitable mains supply or non-compliance with the installation instructions
- Partially or completely dismantled appliances
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
