Geek GeekSmart L7 User manual

设计要求
尺寸：A5 封面250g铜版纸 内页128g铜版纸
双面印 骑马钉封面封底覆亚膜 彩印
外覆膜

IMPORTANT：Read the instructions
carefully before operating the appliance
and keep them for future reference.
Model No.: L7
User Manual
ROBOT VACUUM CLEANER

01
03
10
22
27
Table Of Contents
Safety Instructions
Product Components
How To Use
Cleaning And Maintenance
Troubleshooting
Scan the QR code for more
assistance and support
GeekSmart bids you welcome to a world of smart homedevices, the
robot vacuum ceaner. GeekSmart strives to explore and develop the smart
home industryfor the good of all by combining cutting-edge technologies to
develop products fit and ready for the market. Please visitourwebsite
www.geektechnology.com.
Before use, please scan the QR codes to watch oureasy step-by-step
installation video. If you have questions regarding the installation process,
please contact us by mail [email protected]mor by
phone [phone].
welcome

01
WARNING: TO REDUCE THE RISKOFINJURY ORDAMAGE, READ THEFOLOWING
SAFETY PRECAUTIONS WHENSETTINGUP, USINGAND MAINTAINING YOUR ROBOT.
This product is designed for indoor floor cleaning only, do not use it outdoors
(such as on an open-ended terrace), on any surface other than the ground
(such as a sofa ) , or in any commercial or industrial environment.
Do not use this product on elevated surfaces without barriers such as the
floor of a loft, an open-ended terrace.
Do not use the product when the ambient temperature is higher than 104°F
(40°C) , lower than 39°F (4°C), or if there are liquids or tacky substances on
the floor.
side to prevent them being pulled on by the cleaner.
To prevent blocking the product and to avoid damage to valuables, remove
light-weight items (such as plastic bags) and fragile objects (such as vases)
from the floor before cleaning.
Children should be supervised to ensure that they do not play with the
appliance.
This product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the product by a person responsible for their safety .
This product can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the product in a safe way and understand the hazards
involved. Children shall not play with the product. Cleaning and user mainte-
nance shall not be made by children without supervision (EU).
Keep the main brush cleaning tools out of reach of children.
Do not place any object (including children and pets) on the product ,
whether it is in operation or not.
Keep hair, loose clothing , fingers,and all parts of the body away from open-
ings and moving parts.
Do not use the product on burning objects (such as cigarette butts).
Safety Instructions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
lmportant Safety lnstructions

Safety Instructions
Battery and Charging
02
be reduced on dark carpets).
Do not use the product to clean hard or sharp objects (such as decoration
wastes, glass and nails).
socket-outlet before cleaning or maintaining the product.
Do not use wet cloth or liquids for cleaning the product.
Do not use the mopping module on carpets.
Use the product according to the manual, Any loss or damage caused from
improper use will be borne by the user.
This product contains batteries that are only replaceable by skilled persons.
Do not charge non-rechargeable batteries.
For the purposes of recharging the battery, only use the detachable supply unit
robot provided with this product.
Do not dismantle, repair or modify the battery or charging dock.
Keep the charging dock away from heat (such as heating vents).
The battery must be removed from the appliance before it is scrapped.
The product must be disconnected from the power supply when removing the
battery.
The battery must be disposed of safely. Do not discard waste batteries, leave
them with a professional recycling organization.
Do not wipe or clean the charger prongs with wet cloth or wet hands.
If the power cord is damaged, stop using it immediately. It must be replaced by
the manufacturer, service agent, or similarly qualified persons to avoid a hazard.
Immediately dispose of packaging as it can pose choking
or other hazards to small children and pets. Please carefully
confirm the consistency between the picture and the real
components that correspond to the model you purchased.
13.
14.
15.
16.
17.
18.
19.
20.
1.
3.
2.
4.
5.
6.
7.
8.
9.
CAUTION

03
Robot vacuumcleaner
(main brush x1and side brush x2)
Charging dock
Adapter
Electricalwater tank
(Primary filter x1HEPA filter x1Spongex1)
Dust bin
(Primary filter x1HEPA filter x1Spongex1)
Remote control(“Optional”)
AAA Batteryfor remote control ×2
User manual
Cleaning tool
Product components
OPEN
Product Components
What’s in the Box

Product Components
04
Bottom View
Power/Auto cleaning/Pause
Recharge
Height sensor
Laser Distance sensor
Anti-collision bumper
Speaker
Power switch
Dust bin
Charging metal
Contact piece
Charging metal
Contact piece
Omnidirectional wheel
Side brush
Battery cover
Back wheel
Main brush
Dustbin
Side brush
Back wheel
Top View
Robot

Docking Station
Dust Bin
Power indicator
Charging contacts
Power Socket
Cable lines collect slot
Anti-slip mat
Primary filter
Sponge filter Hepa filter
Dust bin cover
Dust bin button
Dust bin block slice
Dust bin unit
Product Components
05

Auto cleaning
Direction forward
Left direction
Spot cleaning
Seek the robot
Suction power
Water tank cover
Sponge filter
Primary filter
Water tank latch
Water flow control
Edge cleaning
Right direction
On/Pause button
Recharge button
Product Components
06
Remote Contro(“Optional”)
Water Tank
OPEN

Water tank unit
Water tank button
07
Product Components
Remark: Storage temperature 0-45℃
Name Parameter
L320*W320*H95mm
14.8V
32w
2600mAh Li-battery
19V
1A
Size
voltage
Battery
Charging base output current
Charging base Output voltage
Rated power
The Robot Parameters

Name and content of hazardous substances in the product
Docking Station Parameters
Name Parameter
L183*W 140*H76mm
50/60Hz
Size
Rated input
Rated power
Rated output
19 v 1A
19 v 1A
This form is compiled in accordance with the regulations of S J/T 11364.
Means that the content of the hazardous substance in all homogeneous
materials of the part is below the limit requirement specified in
GB/T 26572.
Means that the hazardous substance at least in a certain homogeneous
material of the part exceeds the limit requirement of GB/T 26572.
Name
Circuit
Metal
Parts
Plastic
Casing
Battery
Other
parts
Parts
Lead
(Pb)
Mercury
(Hg)
○
○
×
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
○
Mercury
(Cd)
Hexavalent
Chromium
(cr(Vl))
Polybrominat-
ed Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
×:
○:
Product Components
08

The charging dock should have more than 1.0m(3.0ft) of clearance on
each side, and more than 2.0m (6.0ft) in the front.
If the power cable is vertical to the ground, it may be caught by the
robot, causing the charging dock to be disconnected.
The charging dock indicator is on when the charging dock is electri-
How To Use
10
Installation Using the robot
Remove the EVA foam on
each side.
1.
2. Place the charging dock
against the wall on a flat
surface and plug it into the
power socket .
1.
2.
3.
How To Use
NOTE:

Install The Side Brushes
How To Use
11
3. Turn the robot over to install the side brushes.
Install the side brushes on both sides of the roller
at the bottom of the main unit. Pick up the side
brushes with your hands and aim at the hole of
the side brush installed on the base (note that the
square column and the square hole correspond
to each other), press it down to hear a “click"
sound, indicating that the side brush is installed in
place.

How To Use
12
Charging
Power On And Charge
Pause
Auto: After cleaning, the robot will automatically return to the charging dock to
recharge. The button light keeps flashing.
Manual: In pause mode, press the button to send the robot back to the
charging dock. If the robot is stuck or can not find the charging dock, place
the robot directly on the dock to recharge it.
Recharge by remote control.
Placing the robot on to the charging dock and power on. Turning on the
robot is defaulted.
The robot will turn on when turn on main power switch if the robot not
connected the charging dock. The power indicator lights up.
the charging dock.
When the robot is cleaning, press button to pause it. Then press the button to
continue cleaning or the button to stop the current cleaning. Press button
twice to return it to the charging dock.
1.
2.
3.
The battery is fully charged to prolong the battery life. 5 hours
charging time for the first time.
Please keep charging dock power on. Or the robot can not find the
charging dock.
Close the Tuya App to reduce tablet/phone battery consumption
when vacuum robot is cleaning.
The furniture must be at least 98 mm height for the machine to pass
through.
1.
1.
2.
3.
2.
4.
3.
NOTE:

How To Use
13
Sleep
Installation For Use
Start cleanup
If the robot is paused and not connect the charging dock for over 10 minutes, it will
go to sleep, press any button to wake it back up.
Press the button to start cleaning. Once started, the
robot leaves charging dock. The robot will plan its
cleaning route based on its scan of the area. It cleans
along a zone first and then move Zig - zag cleaning route
A. Cleaning mode
Press the button to start cleaning. Once started, the
robot will plan its cleaning route and map based on its scan
of the area After cleaning, the robot will return to the
charging dock automatically.
B. Spot Cleaning (Only remote control support )
After starting the spot cleaning mode, this mode is used to
clean a 1.5m x 1.5m square area centered and it is in zig-zag
cleaning mode on the map. After cleanup, the robot will
return to the center of the square. Use the app to set a
destination for the robot to go to.
Cleaning cannot start if the battery level is too low. Allow the robot to
charge before restarting cleanup.
Tidy away any cables on the ground ( including the power cable of the
charging dock ) before cleaning to avoid losing power or damaging
either the robot or the connected device.
1.
2.
NOTE:

A full map must be created before this function can be used.
After cleaning starts, the robot may move beyond the defined
areas. Make sure there are no obstacles preventing the robot’s
access to the target rooms.
1.
2.
Dry vacuum module can be used on either smooth or carpeted surface.
Remove / secure all loose floor mats / rugs in the area being vacuumed.
Vacuum robot is designed to move across surface between 0 mm to 15 mm.
1.
2.
How To Use
14
C. Zone Cleaning (Only App operation support )
Use the app to draw a specific zone for the robot to
clean. Then, the robot will only clean the designated
zone. After cleaning, the robot will return to the
charging dock automatically.
D. Selective Room Cleaning
(Only App operation support )
Select specific rooms for cleaning in the app. In this
mode, the robot will only clean the selected rooms.
After cleaning, the robot will return to the charging
dock automatically.
√A √B
CD
E. Virtual Wall (Only App operation support )
press virtual wall in APP to draw the virtual wall line.
You can use virtual wall to isolate the areas that do
not want to be cleaned.
NOTE:
NOTE:

How To Use How To Use
15
1. Install the mop cloth. Open the water tank, fill it with water,
and close it tightly
clean it.
It is recommended that all floors are vacuumed at least three times
before the first mopping session to reduce excessive dirt bulidup on
the mop.
To prevent corrosion or damage, do not use cleaning fluid or disinfec-
tion in the water tank.
Remove the mopping module after mopping, empty residual water and
clean the mop cloth to prevent mildew or unpleasant odors.
Remove the mopping module if not mopping.
Mop module is designed only to be used on smooth flooring as the pad
may catch on carpeting and prevent the vacuum unit from moving freely.
1.
2.
3.
4.
5.
2.
3. Install water tank. 4. Start mopping.
OPEN
NOTE:
NOTE:
Installation Using the robot

How To Use
How To Use
16
Please scan the QR code or search “GeekSmart”
and download APP. After the APP is installed.
Please follow the APP instruction to register the
account and login.
Open the APP, click 【add device】or click the button 【+】and select the
“Robot Vacuum”，then click the model you bought.
App Instruction
1.
2.

Please make sure that the product is on (like the picture shows).
Press the pause button for 2-3 seconds for the first time to start the smart
network connection until there is a voice prompt. (WIFI indicator light flashes
quickly); input the wi-fi account and password. (only support 2.4Ghz wifi, 5Ghz
can not be connected. ) A few seconds later, the product will be connected to
your phone.
17
Start/Stop Cleaning
How To Use How To Use
3.
4.

18
App Interface
Setting
Click “Setting” on the home page to enter more pages.
and click to enter the corresponding function.
Recharging: when the robot is in standby mode or auto cleaning mode, if you
press the recharging button, and the robot will look for the charging dock for
recharging.
How To Use
Change the cleaning mode, the current cleaning mode must be ended first.
2.
Cleaning modes “Smart Cleaning”, “Designated Area Cleaning”.
1.
4.
5.
6.
7.
Manual control: control the direction button / pause
button / start cleaning.
Room Manage: Reset or Save the map.
Click “seek robot”: the robot will voice prompt “I am
here”.
Use the app to set start times for scheduled cleanups.
Select scheduled cleaning and save the scheduled
cleaning time.
Suction power: Quiet, Normal, Strong.
Water quantity: Low, Middle,High.
Can adjust voice volume and switch language.
1.
2.
3.
NOTE:
Geek Robot Vacuum – L7
