Gefen Pro 3GSDI User manual

3GSDI
Audio De-Embedder
GEF-SDI-AUDD
User Manual
1080P
www.gefenpro.com
2K

ASKING FOR ASSISTANCE
Rev A1
Technical Support:
Telephone  (818)772-9100
   (800)545-6900
Fax   (818)772-9120
Technical Support Hours:
8:00AMto5:00PMMondaythroughFriday,PacicTime
For24/7support,seethebackoftheproductforthesupportnumber

Write To:
Gefen,LLC.
c/oCustomerService
20600NordhoffSt
Chatsworth,CA91311
www.gefenpro.com
[email protected]
Notice
Gefen,LLCreservestherighttomakechangesinthehardware,packaging,andany
accompanyingdocumentationwithoutpriorwrittennotice.
3GSDI Audio De-Embedder isatrademarkofGefen,LLC


©2013Gefen,LLC.Allrightsreserved.
Alltrademarksarethepropertyoftheirrespectiveowners.

CONTENTS
INTRODUCTION....................................................................................................................1
 ImportantOperatingNotes..............................................................................................2
 Features..........................................................................................................................3
 PackageIncludes............................................................................................................3
 PanelLayout...................................................................................................................4
 PanelDescriptions..........................................................................................................5
CONNECTING THE 3GSDI AUDIO DE-EMBEDDER............................................................6
 Connections....................................................................................................................6
 WiringDiagram...............................................................................................................6
OPERATING THE 3GSDI AUDIO DE-EMBEDDER...............................................................7
 LEDIndicators................................................................................................................7
 BlockDiagram.................................................................................................................8
 SignalFlow......................................................................................................................9
 ControllingandRoutingAudioData..............................................................................11
 Un-routedSourceandAESChannels..........................................................................14
 MutingChannels...........................................................................................................14
 AudioMappingTable....................................................................................................16
RS-232 SERIAL CONTROL................................................................................................17
RS-232 COMMANDS..........................................................................................................18
RACK MOUNT SAFETY INFORMATION............................................................................32
MOUNTING PLATE INSTALLATION...................................................................................33
APPENDIX............................................................................................................................34
FirmwareUpdateProcedure.........................................................................................34
SPECIFICATIONS................................................................................................................35
WARRANTY..........................................................................................................................36

1
INTRODUCTION
Congratulationsonyourpurchaseofthe3GSDIAudioDe-Embedder.Yourcomplete
satisfactionisveryimportanttous.
GefenPRO
Intherealmofvideodistribution,certainfeaturesareinvaluableinacommercialor
broadcastenvironment.Accommodationssuchasabuild-inpowersupplyandat
blackrack-mountenclosuressetGefenPROapartfromourtraditionalproducts.
ComplexdistributionunitsallowforprofessionalDVI,3GSDI,andHDMIsignalstobe
routedandconvertedeasilyandseamlessly,whilebeingbackedupbyarenownedand
dependabletechnicalsupportteam.GefeninvitesyoutoexploretheGefenPROproduct
lineandhopesthatyoundthesolutionthattsyourneeds.
The GefenPRO 3GSDI Audio De-Embedder
TheGefenPRO3GSDIAudioDe-Embedderextractsaudiofrom3GSDI,Single-Link
HDSDI,EDSDI,andSDIvideosignals.UptofourAES/EBUdigitalaudiostreamscanbe
de-embeddedandroutedtoanyofthefouraudiooutputs.Selectionandroutingofeach
audiogrouporpaircanbeconguredviaRS-232.
How It Works
ConnectanSDIsourcetotheSDIInconnector.ConnecttheSDILoopOutconnectorto
anSDIaudio/videodevicetomonitortheoriginalunmodiedsignal.ConnecttheOutput
connectortoanSDIacceptor(suchasvideobroadcastequipment).Connectuptofour
AES/EBUdigitalaudioreproductiondevices(suchasaDATrecorderorpre-amp)tothe
AudioOutconnectors.ConnecttheRS-232cablefromtheAudioDe-EmbeddertoaPCor
automationsystemtocontrolwhichaudiogrouporpairwillbede-embeddedfromthevideo
signal.ConnecttheACpowercordtothe3GSDIAudioDe-Embedderandtoanavailable
electricaloutlet.Oncetheunitispowered,RS-232commandscanbeusedtoselectthe
audiogroupandpairtobede-embeddedfromthevideosignal.

INTRODUCTION
2
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
• Thisproductdoesnotsupportdual-linkHDSDIsources.

3
INTRODUCTION
Features
• SupportsSDI,EDSDI,Single-LinkHDSDI,and3GSDI
• Allowsindividualdigitalaudiochannelstobere-arrangedontheoutput
• Audiodelayadjustmentforeachpairofaudiooutputs(0–170ms)
• 3GSDIdetection
• LEDStatusIndicators
• FirmwarecanbeupdatedusingtheUSBport
Package Includes
(1)GefenPRO3GSDIAudioDe-Embedder
(1)6ft.DB-9Cable
(1)ACPowerCord
(1)SetofRackEars
(1)Quick-StartGuide

4
INTRODUCTION
Front Panel
Back Panel
1 3
65 7 8 9 10
2 4
11 12

5
INTRODUCTION
1 Audio
ThisLEDindicatorglowsbrightbluewhenaudiodataisdetectedonthe3GSDIInor
AudioInconnectors.
2 Video
Thisbi-colorLEDindicatorwillglowbrightredwhenanSDIsignalisdetectedonthe
3GSDIInconnector.IfanHDSDIsignalisdetected,thentheLEDwillglowbrightgreen.
3 3GSDI
ThisLEDwillglowbrightbluewhena3GSDIsignalisdetectedonthe3GSDIIn
connector.
4 Power
ThisLEDindicatorwillglowbrightbluewhentheunitispowered.
5 USB
ThisUSBportisusedforupdatingthermware.Seepage34fordetails.
6 RS-232
ConnectanRS-232cablefromthisporttoanRS-232controller.Allaudioroutingis
handledthroughRS-232.Seepage17formoreinformation.
7 AudioOut(1-4)
ConnectuptofourSDIdestinations(DATrecorders,etc)totheseconnectors.
8 3GSDIInput(In)
ConnectaBNCcablefromtheSDIsourcetothisconnector.
9 3GSDIInput(LoopOut)
ConnectaBNCcablefromthisconnectortoalocalSDIdisplay.TheLoopOutconnector
willpass-throughtheSDIsignalwithoutanyprocessing.
10 3GSDIOutput
ConnectaBNCcablefromthisconnectortoanSDIdisplay.
11 PowerReceptacle
ConnecttheincludedACpowercordfromthispowerreceptacletoanavailable
electricaloutlet.
12 PowerSwitch
Pressthisswitchtopower-onorpower-offtheunit.

6
CONNECTING THE 3GSDI AUDIO DE-EMBEDDER
Connections
1. ConnectanSDI,HDSDI,ora3GSDIsourcetothe3GSDIInput(In)connector.
2. UseuptofourBNCcablestoconnecttheAudioOutconnectors(1-4)toDAT
recorders,audioembedders,etc.
3. Connectthe3GSDIbroadcastequipmenttothe3GSDIOutconnector.
4. Ifmonitoringofthe3GSDIsourceisdesired,connectaBNCcablefromthe3GSDI
Input/LoopOutconnectortothe3GSDIdisplay.TheLoopOutconnectorprovides
monitoringoftheinputsignalwithoutanyprocessing.
5. ConnectanRS-232cablebetweentheRS-232controllerandthe3GSDI Audio
De-Embedder.AllaudioroutingiscontrolledusingRS-232.
6. ConnecttheincludedACpowercordfromthepowerreceptacletoanavailable
electricaloutlet.
7. Powerthe3GSDI Audio De-Embedderbypressingthepowerswitchontherearofthe
unittotheONposition.ThePowerLEDonthefrontpanelwillglowbrightbluewhen
theunitispowered.
Wiring Diagram for the 3GSDI Audio De-Embedder
WARNING:Thisproductshouldalwaysbeconnectedtoa
groundedelectricalsocket.
SDI CABLE
RS-232 CABLE
to Video Broadcast Equipment
RS-232 Controller
DAT Recorder 4
3GSDI Digital
Video Player
DAT Recorder 3
DAT Recorder 2
DAT Recorder 1
3GSDI Audio De-Embedder
3GSDI Display
(local monitor)
GEF-SDI-AUDD
®

7
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
TheLEDindicatorsonthefrontpanelprovideinformationonthetypeofsignalthatisbeing
receivedontheinputs.
SDI / HDSDI Video Input and AES Audio Output
TheAudioLEDindicatorwillglowbrightblueifSDIorAES/EBUaudioisdetectedonany
oftheAudioOut(1-4)connectors.TheVideoLEDindicatorwillglowbrightredifSDI
videodataisdetectedonthe3GSDIInconnector.IfHDSDIvideodataisdetected,then
theVideoLEDwillglowbrightgreen.
3GSDI Video Input
The3GSDILEDindicatorwillglowbrightblueif3GSDIvideodataisdetectedonthe
3GSDIInconnector.
AES/EBUaudio 3GSDIvideo
AES/EBUaudio
SDIvideodetected
3GSDIvideodetected
HDSDIvideodetected
SDI/HDSDIVideo
LED Indicators

8
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
Block Diagram
Grayarrowsindicatethedefaultroutingstate
NotethatS1.1throughS2.4aremirroredonA.1throughA.8
SDIIn
Group1 Group2 Group3 Group4
S1 S2
S1.1 S1.2 S1.3 S1.4
(S1.1) (S1.2) (S1.3) (S1.4)
S2.1 S2.2 S2.3 S2.4
(S2.1) (S2.2) (S2.3) (S2.4)
SDIOut
8x16Matrix
withDelay
4x2Switcher 2x4Switcher
O1 O2
Group1 AudioOut1 Group2 AudioOut2 Group3 AudioOut3 Group4 AudioOut4
O1.1 O1.2 O1.3 O1.4 O2.1 O2.2 O2.3 O2.4 A.1 A.2 A.3 A.4 A.5 A.6 A.7 A.8
DELAY

9

The3GSDI Audio De-Embeddercorehasthreemainelementstoprovideswitchingof
audiogroupsandaudiochannels:
• 4x2 Switcher (input)

TherstelementallowsanytwoofthefourSDI audio input groups(Group1-
Group4)toberoutedtothesource groups(S1-S2).Forexample,Group1can
beroutedtoS2andGroup3canberoutedtoS1.OnlyoneSDI audio input group
canberoutedtoasource groupatatime.












• 8x16 Matrix with Delay

OncetheselectedSDI audio input groupshavebeenroutedtothesource groups,any
ofthefoursource audio channels(S1.1...S2.4)canberoutedonceormultipletimes
toanyoftheoutput audio channels(O1.1...O1.4,O2.1...O2.4)ortoanyAES audio
channel(A.1...A.8).

OPERATING THE 3GSDI AUDIO DE-EMBEDDER
SDIIn
Group1
Group2
Group3
Group4
S1
S2
Signal Flow
S1.1
S1.2
S1.3
S1.4
O1.1
O1.2
O1.3
O1.4
S2.1
S2.2
S2.3
S2.4
O2.1
O2.2
O2.3
O2.4
A.1
A.2
A.3
A.4
A.5
A.6
A.7
A.8
DELAY

10
Noteinthediagram,onthepreviouspage,thatsouce audio channelsS1.1,S1.3,
S2.1,S2.2,andS2.3areroutedtomultipleoutput audio channelsandAES audio
channels.Audiodelay(from0to170ms)canbeapplied,ifdesired,toeachoutput
audio channeland/oreachAES audio channel beforebeingsenttotheoutput groups
orAudioOutBNCconnectors.

• 2x4 Switcher (output)

Thethirdandnalstagecombinestheindividualoutputchannelsintotwooutput
groups(O1andO2).Theoutput groupsarethendeliveredtothespeciedSDI audio
output group(Group1...Group4).Inaddition,anyindividualAES audio channels
arecombinedasaudiopairs(A.1+A.2,A.3+A.4,etc)anddeliveredtotheAudioOut
connectors:A.1+A.2aresenttoAudioOut1,A.3+A.4aresenttoAudioOut2,
andsoon.























AllroutingofaudiochannelsarehandledusingtheRS-232interface.Seethe
informationonthenextpageforroutingexamplesusingRS-232commands.
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
SDIOut
Group1
AudioOut1
Group2
AudioOut2
Group3
AudioOut3
Group4
AudioOut4
O1
O2

11
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
ThefollowingexampleillustrateshowtheRS-232commandsareusedtorouteaudio
channels.Beforegettingstarted,seepage10onconguringRS-232.
1. TherststepistoroutewhichSDI audio input groupsaretoberoutedtothesource
groups.Usethe#sdi_in_grp_swcommandtoassignthespeciedSDI audio
grouptothedesiredsource group.

Inthisexample,wewillrouteSDI audio input group1(g1)tosource groupS2and
SDI audio input group3(g3)tosource groupS1:

#sdi_in_grp_sw g1 s2
Error! G1 has been already assigned to S1


Here,wetriedtorouteGroup1toS2.However,bydefault,Group1isalreadyrouted
toS1.Wemustrst“un-route”Group1byroutinganunusedSDIaudioinputgroupto
S1.Lookingattheillustration,below,wecanseethatwecanuseeitherGroup3or
Group4.














SinceweplantorouteGroup3toS1,aspartoftheexample,wewillperformthis
routingrst:

#sdi_in_grp_sw g3 s1
IN GROUP G3 IS SWITCHED TO S1 GROUP
Controlling and Routing Audio Data
SDIIn
Group1
Group2
Group3
Group4
S1
S2
SDIIn
Group1
Group2
Group3
Group4
S1
S2

12
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
SinceGroup3hasbeenroutedtoS1,wecannowrouteGroup1toS2:
#sdi_in_grp_sw g1 s2
IN GROUP G1 IS SWITCHED TO S2 GROUP
2. Usethe#ch_swcommandtoselectwhichsource audio channels(S1.1...S1.4,
S2.1...S2.4)areroutedtotheoutput audio channels(O1.1...O1.4,O2.1...O2.4,
andA.1...A.8).

























Refertothenextpageforthelistofcommandsusedtoperformtheroutinginthe
abovediagram,startingwithS1.1andendingwithS2.4.
SDIIn
Group1
Group2
Group3
Group4
S1
S2
DELAY
S1.1
S1.2
S1.3
S1.4
O1.1
O1.2
O1.3
O1.4
S2.1
S2.2
S2.3
S2.4
O2.1
O2.2
O2.3
O2.4
A.1
A.2
A.3
A.4
A.5
A.6
A.7
A.8

13
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
#ch_sw s1.1 o1.3
S1.1 IS SWITCHED INTO O1.3 OF SDI TRANSMITTER
#ch_sw s1.2 a.2
S1.2 IS SWITCHED INTO a.2 OF SDI TRANSMITTER
#ch_sw s1.4 o2.1
S1.4 IS SWITCHED INTO o2.1 OF SDI TRANSMITTER
Asmentionedonpage9,asingleaudiochannelcanberoutedtomultipleoutput
channelsorAESchannels.Inthisexample,S2.1isroutedtobothA.1andA.7:
#ch_sw s2.1 a.1
S2.1 IS SWITCHED INTO a.1 OF SDI TRANSMITTER
#ch_sw s2.1 a.7
S2.1 IS SWITCHED INTO a.1 OF SDI TRANSMITTER
ContinuingwithS2.3,whichisroutedtobothO1.2andO2.3:
#ch_sw s2.3 o1.2
S2.3 IS SWITCHED INTO o1.2 OF SDI TRANSMITTER
#ch_sw s2.3 o2.3
S2.1 IS SWITCHED INTO o2.3 OF SDI TRANSMITTER
Finally,S2.4isroutedtoA.3:
#ch_sw s2.4 a.3
S2.4 IS SWITCHED INTO a.3 OF SDI TRANSMITTER
Forthisexample,wewillalsoadda50msaudiodelaytoO1.2:
#delay o1.2 50
AUDIO CHANNEL O1.2 HAS THE DELAY OF 50ms

14
Un-routed Source and AES Channels
Note,thatinourexample,thatwedidnotroutesourcechannelsS1.3andS2.2.
Accordingtotheblockdiagramonpage8,eachsourcechannelisroutedtoan
associatedoutputchannel(S1.1>O1.1,S1.2>O1.2,etc).Thisisthedefaultsetting.

AlthoughwedidnotspecifyS1.1toberoutedtoO1.1,thedefaultroutingstatestill
applies(indicatedbythedashed-lines).Thesameholdstrueforthedefaultrouting
stateforS1.4>O1.4,S2.2>O2.2,andS2.4>O2.4.Inaddition,AESaudiochannels
(A.1...A.8)willreceivesourcechannelsS1.1throughS2.4,respectively.

ItisimportanttounderstandthatsinceS1.3wasneverroutedinourexampleand
becauseS1.1wasroutedtoO1.3,thedefaultroutingforS1.3(S1.3>O1.3andS1.3
>A.3)cannottakeplace.


Muting Channels
The3GSDI Audio De-EmbedderallowsanyoutputorAESchannel(orallchannels)
tobemutedbyusingthe#mutecommand(seepage22fordetails).Thiscommand
isusedtomutespecicaudiochannelsbeforebeingsenttotheoutputconnectors.

Forexample,thefollowingcommandwillmuteAESchannelA.4:

#mute a.4 1
MUTE ON CHANNEL A.4 IS ON

OPERATING THE 3GSDI AUDIO DE-EMBEDDER
DELAY
S1.1
S1.2
S1.3
S1.4
O1.1
O1.2
O1.3
O1.4
S2.1
S2.2
S2.3
S2.4
(S1.4)
(S2.1)
(S2.2)

(S2.4)
O2.1
O2.2
O2.3
O2.4
A.1
A.2
A.3
A.4
A.5
A.6
A.7
A.8

15
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
3. ThenalstepistoroutetheoutputchannelstoanSDI audio output group.Inour
example,wewillrouteO1toGroup4andO2toGroup1.

#sdi_out_grp_sw o2 g1
Error! G1 has been already assigned to O1
AswiththeSDI audio input groups,O1andO2areroutedtoGroup1andGroup2,
respectively,bydefault.Therefore,O2cannotbedirectlyroutedtoGroup1.
O2mustrstbere-routedtoanotherGroup,evenifitistemporary.



















However,sincepartofourexampleinvolvesroutingO1toGroup4,wecanperform
thistaskrstbyusingthefollowingcommand:

#sdi_out_grp_sw o1 g4
OUT GROUP O1 IS SWITCHED TO G4 GROUP




















SDIOut
Group1
AudioOut1
Group2
...
Group3
Group4
O1
O2
SDIOut
Group1
AudioOut1
Group2
...
Group3
Group4
O1
O2

16
OPERATING THE 3GSDI AUDIO DE-EMBEDDER
NowthatO1hasbeenroutedtoGroup4,wecannowrouteO2toGroup1:

#sdi_out_grp_sw o2 g1
OUT GROUP O2 IS SWITCHED TO G1 GROUP
Thenumbersnexttoeacharrowindicatetheaudiochannelnumber.SeetheAudio
Mappingtablebelowfordetails.
SinceAESaudiowasroutedinstep2(page12),wedon’thavetoworryaboutrouting
theaudioatthisstage.

Asmentionedearlier,anyindividualAES audio channelsarecombinedasaudiopairs
(A.1+A.2,A.3+A.4,etc)anddeliveredtotheAudioOutconnectors:A.1+A.2are
senttoAudioOut1,A.3+A.4aresenttoAudioOut2,andsoon.

Audio Mapping
The3GSDI Audio De-Embeddercanprocessamaximumofeightaudiochannels.
Theaudio-mappingtableislistedbelow.

Channel Space Channel Space
CH1 Left(L) CH5 LeftSurround(LS)
CH2 Right(R) CH6 RightSurround(RS)
CH3 Center(C) CH7 LeftRear(RL)
CH4 Subwoofer(LFE) CH8 RightRear(RR)

SDIOut
(1)
(1)
(5)
(5)
(2)
(2)
(6)
(6)
(3)
(3)
(7)
(7)
(4)
(4)
(8)
(8)
Group1
AudioOut1
Group2
AudioOut2
Group3
AudioOut3
Group4
AudioOut4
O1
O2
